Camshaft Oil Seals Audi A6 C5

Note. For help in identifying components and component locations see scheme 84and see scheme 85.

Note. Various oil seal configurations may be used, ensure proper seal application is used.

Scheme 53

1. Remove timing belt. See «TIMING BELT»(ref-147486-S11057228442002091600000).
2. Remove camshaft drive sprocket bolt. Remove camshaft drive sprocket.
3. Unscrew inner part of Oil Seal Extractor (3240) oil seal extractor 2 turns (about 3 mm) out of outer part and lock with knurled screw. see scheme 65
4. Lubricate thread head of Oil Seal Extractor (3240), place it in position while applying firm pressure screw it as far as into oil seal. Loosen knurled screw and turn inner part of extractor against camshaft until oil seal has been extracted.
