Note. It is not necessary to completely removal noise insulation from beneath the engine. Only remove the quick release fasteners the attach to the front bumper assembly.
Scheme 4
Scheme 5
Scheme 6
- Remove front bumper. See «FRONT BUMPER»(ref-147486-S21797918242002091600000).
- Unbolt air guide between lock carrier and air filter on lock carrier. Inspect headlight and turn signal electrical connectors and wiring harness (which may hang up when lock carrier is moved forward).
- On right side, remove bolt (5) and install support tool (3369) in its place. (Scheme 4)and (Scheme 5).
- On left side, install support tool (3369) in threaded hole in chassis. (Scheme 6)
- Remove on both sides, all (No. 2) bolts. (Scheme 4)
- Remove on both sides, all (No. 3 and 4) bolts. (Scheme 4) Slide lock carrier forward unit the rear bolt hole in lock carrier aligns with the forward threaded fender bolt hole.
- Secure lock carrier in this position, by placing fender bolts in holes. (Scheme 7) To install, reverse placing in service position procedure.
