- Mark component location for reassembly reference. Ensure components are installed in original location. Disassemble rocker arm assembly. Inspect components for damage.
- Using "V" block and dial indicator, check runout of rocker arm shafts. Measure rocker arm shaft O.D. in rocker arm operating area. Replace components if measurements are not within specifications. See «ROCKER ARM SPECIFICATIONS»(ref-49505-S21258037682001011500000).
- Measure rocker arm I.D. and rocker arm shaft O.D. to determine oil clearance. Replace components if oil clearance is not within specification. See «ROCKER ARM SPECIFICATIONS»(ref-49505-S21258037682001011500000). ROCKER ARM SPECIFICATIONS Application In. (mm) Maximum Oil Clearance.008 (.20) Maximum Rocker Arm Shaft Runout.008 (.20) Minimum Rocker Arm Shaft O.D..623 (15.83)
- To reassemble, coat components with engine oil. Rocker arm shafts and rocker arms are different. Ensure shafts and arms are installed in proper position. Ensure a wave washer is installed between intake and exhaust rocker arms and all reused rocker arms are returned to original position. (Scheme 16)
