Draining fuel system

Draining fuel system Draining fuel injection system Section 2 (23, 28), Engine management system Motronic 1996 4.4 850

Scheme 526

1. Remove the larger clamp (Torx 25). Removing clamp: squeeze clamp with a pipe wrench. Hold in place pry apart with a small screwdriver. NOTE: It is reusable.
2. Remove fuel pressure regulator. Removing clamp: squeeze clamp with a pipe wrench. Hold in place pry apart with a small screwdriver. NOTE: It is reusable.
3. Remove small clamp. NOTE: The clamp will be reused. Removing clamp: squeeze clamp with a pipe wrench. Hold in place pry apart with a small screwdriver. NOTE: It is reusable.
4. Disconnect hose.
