Crank Drive
Flywheel
| Engine | 15 D (4EC1), 15 DT, X 15 DT (T4EC1), 17 D, X 17 D (4EE1) | |
|---|---|---|
| Starter ring gear | Heat ring gear to 180 �C to 230 �C before installing | |
| Lateral runout | mm | Permissible lateral runout of installed starter ring gear to flywheel: 0.5 |
| Precision turning | mm | Maximum permissible removal of material in the area of the clutch lining surface: 0.3 |
| To restore functional relationships after removing material. the raised face of the flywheel (bearing surface for clutch assembly) must have the same amount of material removed. |
Dimension "I" must always be: 19.05 to 19.25
