Special Service Tools
| KM-128-A | Tension Gauge |
|---|---|
| To check the V-belt tension | |
| KM-134-A | Socket Wrench |
| To remove and install cylinder head bolts | |
| KM-161-B | Bearing Puller |
| To remove toothed belt drive gear from crankshaft | |
| KM-226-A | Measuring Device |
| To adjust beginning of supply with MKM-571-B | |
| KM-232 | Adapter |
| To check oil pressure with KM-498-B | |
| KM-252-2-B | Cable |
| To remove and install engine |
Special Service Tools
| KM-263-B | Engine Bridge |
|---|---|
| To suspend engine with engine lifter and cable from KM-252-2-B | |
| KM-340-G | Cutter Set |
| To mill, rework valve seats | |
| KM-348 | Spring Compressor |
| To compress valve spring in conjunction with KM-653-A with cylinder head removed | |
| KM-412 | Engine Overhaul Stand |
| To hold the removed engine | |
| KM-412-11-B | Adapter |
| To hold engine in conjunction with KM-412 | |
| KM-470-B | Angular Torque Wrench |
| To tighten cylinder head bolts |
Special Service Tools
| KM-471 | Adapter |
|---|---|
| To check cooling system with cooling system tester diagnosis on cooling system | |
| KM-498-B | Oil Pressure Manometer |
| To check the engine oil pressure in conjunction with KM-232 | |
| KM-517-B | Flywheel Locking Device |
| To lock flywheel | |
| KM-533-B | Adapter |
| To check compression using KM-649 | |
| MKM-571-B | Dial Gauge |
| To measure beginning of delivery in conjunction with KM-226-A | |
| MKM-604-D | Torx Bit and Socket Set |
| To remove and install Torx bolt |
Special Service Tools
| KM-609 | Electronic-Kit |
|---|---|
| Diagnosis of electrical and electronic systems | |
| MKM-610 | Torque Wrench, 1/2" |
| Range 30 - 130 Nm / 22 - 96 lbf. ft. | |
| MKM-611 | Torque Wrench, 3/8" |
| Range 10 - 60 Nm / 7 - 44 lbf. ft. | |
| KM-648 | Oil Filter Wrench |
| To remove and install oil filter | |
| KM-649 | Adapter |
| To check compression in conjunction with KM-533-A | |
| KM-650-A | Valve Compressor |
| To adjust valve clearance |
Special Service Tools
| KM-651-A | Remover |
|---|---|
| To remove injection pump gear with engine installed | |
| KM-652 | Flywheel Locking Device |
| To lock flywheel | |
| KM-653-A | Adapter |
| To compress valve springs in conjunction with KM-348 | |
| KM-654 | Remover/Installer |
| To remove and install valve guide | |
| KM-655 | Installer |
| To install piston cooling (oil nozzle) | |
| KM-656 | Installer |
| To install front crankshaft and camshaft seal ring |
Special Service Tools
| KM-657 | Installer |
|---|---|
| To install oil pump seal ring in oil pump bracket | |
| KM-658 | Installer |
| To install rear crankshaft seal ring in seal ring bracket | |
| KM-659-A | Guide Drift |
| To centre clutch disc | |
| KM-660 | Installer |
| To install front camshaft seal ring (engine removed) | |
| MKM-667 | Pressure and Vacuum Pump |
| To measure turbocharger charge pressure | |
| MKM-669 | Torque Wrench, 1/2" |
| Range 50 - 300 Nm / 37 - 221 lbf. ft. |
Special Service Tools
| KM-728 | Remover/Installer Wrench |
|---|---|
| To remove and install injector nozzles | |
| KM-734 | Guide Drift |
| To centre clutch disc | |
| KM-798 | Dial Gauge |
| To measure beginning of delivery | |
| MKM-883-1 | Engine Bridge |
| To hold the engine | |
| KM-884 | Oil Filter Wrench |
| To remove and install oil filter | |
| KM-904 | Base Frame |
| To remove and install various vehicle components with additional adapters |
Special Service Tools
| KM-6054 | Engine Mount |
|---|---|
| To remove and install engine |
