Automatic Transaxle System - General Information - 2.0L: Other Kia Soul I рестайлинг

Automatic Trans 1 illustration ~230 words

Sensors

Input Speed Sensor

  1. Type: Hall effect sensor
  2. Specifications
Operation condition (°C)°F((-)40 ~ 150)) -40 ~ 302
Air gap(mm)in.(1.2 ~ 1.8) 0.0472 ~ 0.0709
Output voltage(V)High1.18 ~ 1.68
Low0.59 ~ 0.84

Output Speed Sensor

  1. Type: Hall effect sensor
  2. Specifications
Operation condition (°C)°F((-)40 ~ 150)) -40 ~ 302
Air gap(mm)in.(1.1 ~ 1.15) 0.043 ~ 0.061
Output voltageHigh1.18 ~ 1.68
Low0.59 ~ 0.84

Oil Temperature Sensor

  1. Type: Negative thermal coefficient type
  2. Specifications
Temp.[(°C)°F]Resistance (kohms)
(-40)-4048.1
(-20)-4.015.6
(0)32.05.88
(20)68.02.51
(40)104.01.19
(60)140.00.61
(80)176.00.32
(100)212.00.18
(120)248.00.10
(140)284.00.06
(150)302.00.05

Inhibitor Switch

  1. Type: Combination of output signals from 4 terminals
  2. Specifications
Power supply (V)12
Output typeCombination of output signals

Solenoid Valves

Direct control VFS[26/B, T/CON]

  1. Control type: Normal low type
Control Pressure kpa (kgf/cm 2 , psi)9.81 ~ 500.14 (0.1 ~ 5.1, 1.42 ~ 72.54)
Current value(mA)50 ~ 850
Internal resistance(ohms)5.1

Direct control VFS[UD/B, OD/C, 35R/C]

  1. Control Type: Normal high type
Control Pressure kpa (kgf/cm 2 , psi)500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42)
Current value(mA)50 ~ 850
Internal resistance(ohms)5.1

Line Pressure Control VFS

  1. Control type: Normal high type
Control Pressure kpa (kgf/cm 2 , psi)500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42)
Current value(mA)50 ~ 850
Internal resistance(ohms)5.1

ON/OFF Solenoid Valve(SS-A, SS-B)

  1. Control type: Normal low type
Control pressure kpa (kgf/cm 2 , psi)490.33(5.0, 71.12)
Internal resistance(ohms)10 ~ 11

Lubricants

ItemSpecified lubricantQuantity
Transaxle fluidSK ATF SP-IV, MICHANG ATF SP-IV, NOCA ATF SP-IV, Kia Genuine ATF SP-IV or other brands meeting the above specification approved by Kia Motors Corp.7.1L (1.89 U.S gal., 7.50 U.S.qt., 6.25 lmp.qt.)

Sealant

ItemSpecified sealant
Rear coverLOCTITE FMD-546(P/N: UM010CH046) or equivalent or THREE-BOND TB1281B
Torque converter housing

Special Service Tools

Tools (Number and name) Illustration Use 09200-38001 / 3N000 Engine support fixture (Beam) Removal and installation of the transaxle. Use this adapter (SST No.: 09200-4X000) with the supporter (SST No.: 09200-2S100, 2S200). *Permit operating with 09200-38001. 09200-2S100 Engine support fixture (Supporter) Removal and installation of the transaxle. Use this beam (SST No.: 09200-38001/3N000) with the supporter (SST No.: 09200-2S200) and adapter (SST No.: 09200-4X000). 09200-2S200 Engine support fixture (Supporter) Removal and installation of the transaxle. Use this beam (SST No.: 09200-38001/3N000) with the adapter (SST No.: 09200-4X000) and supporter (SST No.: 09200-2S100). 09200-4X000 Engine support fixture (Adapter) Installation of transaxle case oil seal. [Using with handle (SST No.:09231-H1100)] 09453-3L241 Oil seal installer Installation of transaxle case oil seal. [Using with handle (SST No.:09231-H1100)] 09231-H1100 Bar Installation of transaxle case oil seal. [Using with oil seal installer (SST No.:009453-3L241)]

Scheme 142

Scheme 142: Special Service Tools
Scheme 142: Special Service Tools
