Specifications

Type: Negative Thermal Coefficient Type

Temp.[(°C)°F]	Resistance (kohms)
(-40)-40	48.1
(-20)-4.0	15.6
(0)32.0	5.88
(20)68.0	2.51
(40)104.0	1.19
(60)140.0	0.61
(80)176.0	0.32
(100)212.0	0.18
(120)248.0	0.10
(140)284.0	0.06
(150)302.0	0.05

Scheme 196

Scheme 197

Scheme 197: Circuit Diagram

Type: Hall effect sensor

Operation condition [°C(°F)]		((-)40 ~ 150)) -40 ~ 302
Air gap(mm)in.		(1.2 ~ 1.8) 0.0472 ~ 0.0709
Output voltage(V)	High	1.18 ~ 1.68
Output voltage(V)	Low	0.59 ~ 0.84

Scheme 198

Scheme 198: Circuit Diagram

Scheme 199

Scheme 199: Signal Waveform

Scheme 200

Type: Hall effect sensor

Operation condition [°C(°F)]		((-)40 ~ 150)) -40 ~ 302
Air gap(mm)in.		(1.1 ~ 1.55) 0.043 ~ 0.061
Output voltage	High	1.18 ~ 1.68
Output voltage	Low	0.59 ~ 0.84

Scheme 201

Scheme 201: Circuit Diagram

Scheme 202

Scheme 202: Signal Waveform

Scheme 203

Direct control VFS[T/CON]

Control type: Normal low type

Control Pressure kpa (kgf/cm 2 , psi)	9.81 ~ 500.14 (0.1 ~ 5.1, 1.42 ~ 72.54)
Current value(mA)	50 ~ 850
Internal resistance(ohms)	5.1

Scheme 204

Scheme 204: Circuit Diagram

Direct control VFS[26/B]

Control type: Normal low type Control Pressure kpa (kgf/cm 2 , psi) 9.81 ~ 500.14 (0.1 ~ 5.1, 1.42 ~ 72.54) Current value(mA) 50 ~ 850 Internal resistance(ohms) 5.1

Scheme 205

Scheme 205: Circuit Diagram

Direct control VFS[LINE Pressure]

Control type: Normal low type Control Pressure kpa (kgf/cm 2 , psi) 500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42) Current value(mA) 50 ~ 850 Internal resistance(ohms) 5.1

Scheme 206

Scheme 206: Circuit Diagram

Direct control VFS[35R/C]

Control type: Normal low type Control Pressure kpa (kgf/cm 2 , psi) 500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42) Current value(mA) 50 ~ 850 Internal resistance(ohms) 5.1

Scheme 207

Scheme 207: Circuit Diagram

Direct control VFS[UD/B]

Control type: Normal low type Control Pressure kpa (kgf/cm 2 , psi) 500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42) Current value(mA) 50 ~ 850 Internal resistance(ohms) 5.1

Scheme 208

Scheme 208: Circuit Diagram

Direct control VFS[OD/C]

Control type: Normal low type Control Pressure kpa (kgf/cm 2 , psi) 500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42) Current value(mA) 50 ~ 850 Internal resistance(ohms) 5.1

Scheme 209

Scheme 209: Circuit Diagram

ON/OFF Solenoid Valve(SS-A, SS-B)

Control type: Normal low type Control pressure kpa (kgf/cm 2 , psi) 490.33(5.0, 71.12) Internal resistance(ohms) 10 ~ 11

Scheme 210

Scheme 210: Circuit Diagram
