Automatic Transaxle Control System - 2.0L: Diagnosis Kia Soul I рестайлинг

Fault Diagnosis

Features a fail-safe mechanism that prevents dangerous situations from developing in the event of a transaxle failure. The limp home mode engages if the transaxle malfunctions. In this mode, the transaxle operates at a minimal functionality level, making it possible for the vehicle to reach a service center.

Fail-Safe: Prevents dangerous situations from developing in the event of a malfunction.

Limp Home: Maintains minimal functionality (*) in the event of a malfunction, making it possible for the vehicle to reach a service center.

(*) Minimal Functionality: Drive (fixed gear setting), Reverse, and Neutral

Self-diagnosis

TCM is in constant communication with the control system's components (sensors and solenoids). If an abnormal signal is received for longer than the predefined duration, TCM recognizes a fault, stores the fault code in memory, and then sends out a fault signal through the self-diagnosis terminal. Such fault codes are independently backed up and will not be cleared even if the ignition switch is turned off, the battery is disconnected, or the TCM connector is disconnected.

Checking Procedure (Self-diagnosis)

Inspection Procedure (Using the GDS)

1. Turn OFF the ignition switch.
2. Connect the GDS to the data link connector on the lower crash pad.
3. Turn ON the ignition switch.
4. Use the GDS to check the diagnostic trouble code.
5. Repair the faulty part from the diagnosis chart.
6. Erase the diagnostic trouble code.
7. Disconnect the GDS. CAUTION: Perform TCM learning after replacing the automatic transaxle to prevent slow automatic transaxle response, jerky acceleration and jerky startup. (Refer to "Automatic transaxle control system ( «REPAIR PROCEDURES»(ref-537306-S16246276662013032200000) )" in this group) Adding automatic transaxle fluid. (Refer to «SERVICE ADJUSTMENT PROCEDURE»(ref-537304-S39342190972013032200000) . After servicing the automatic transaxle or TCM, clear the diagnostic trouble code (DTC) using the GDS tool. Diagnostic trouble codes (DTC) cannot be cleared by disconnecting the battery.

TCM Problem Inspection Procedure

1. TEST TCM GROUND CIRCUIT: Measure resistance between TCM and chassis ground using the backside of TCM harness connector as TCM side check point. If the problem is found, repair it. Specification: Below 1ohms
2. TEST TCM CONNECTOR: Disconnect the TCM connector and visually check the ground terminals on TCM side and harness side for bent pins or poor contact pressure. If the problem is found, repair it.
3. If problem is not found in Step 1 and 2 , the TCM could be faulty. If so, make sure there were no DTC's before swapping the TCM with a new one, and then check the vehicle again. If DTC's were found, examine this first before swapping TCM.
4. RE-TEST THE ORIGINAL TCM: Install the original TCM (may be broken) into a known-good vehicle and check the vehicle. If the problem occurs again, replace the original TCM with a new one. If problem does not occur, this is intermittent problem (Refer to "Intermittent Problem Inspection Procedure" under «BASIC INSPECTION PROCEDURE»(ref-537295-S07597895822013032200000) .

Scheme 227

Scheme 228

1. Turn ignition switch OFF.
2. Disconnect the negative (-) battery cable.
3. Disconnect the TCM connector (A).
4. Remove the TCM after removing the mounting bolts (A-2ea) and nut (B). TCM installation bolt/nut: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)

Inspection

1. Turn ignition switch OFF.
2. Disconnect the solenoid valve connector.
3. Measure resistance between sensor signal terminal and sensor ground terminal.
4. Check that the resistance is within the specification.

Scheme 229

Scheme 230

Scheme 231

Scheme 232

1. Remove the battery and the battery tray. (Refer to " «CHARGING SYSTEM»(ref-537199-S25919029862013032200000) " in EE group)
2. Remove the under cover (A). Tightening torque: 6.9 ~ 10.8 N.m (0.7 ~ 1.1 kgf.m, 5.1 ~ 8.0 lb-ft))
3. Replace new gasket and the plug after draining the automatic transaxle fluid by removing the drain plug. (Refer to «SERVICE ADJUSTMENT PROCEDURE»(ref-537304-S39342190972013032200000) .
4. Remove the air breather hose (A).
5. Remove the valve body cover (B). Tightening torque: 13.7 ~ 15.7 N.m (1.4 ~ 1.6 kgf.m, 10.8 ~ 11.6 lb-ft)
6. Disconnect the oil temperature sensor connector (A).
7. Remove the oil temperature sensor (A) after removing a bolt. Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)

Scheme 233

1. Installation is the reverse of removal. NOTE: The gasket of the valve body gasket (A) use new one. Adding automatic transaxle fluid. (Refer to «SERVICE ADJUSTMENT PROCEDURE»(ref-537304-S39342190972013032200000) . Perform TCM learning after replacing the automatic transaxle to prevent slow automatic transaxle response, jerky acceleration and jerky startup. (Refer to ( «REPAIR PROCEDURES»(ref-537306-S16246276662013032200000) )" in this group)

1. Check signal waveform of Input & output speed sensor using the GDS. Specification: Refer to «Signal Waveform»(ref-537306-S18999809922013032200000) .

Scheme 234

Scheme 235

Scheme 236

Scheme 237

Scheme 238

Scheme 239

1. Remove the battery and the battery tray. (Refer to " «CHARGING SYSTEM»(ref-537199-S25919029862013032200000) " in EE group.)
2. Remove the under cover (A). Tightening torque: 6.9 ~ 10.8 N.m (0.7 ~ 1.1 kgf.m, 5.1 ~ 8.0 lb-ft)
3. Replace new gasket and the plug after draining the automatic transaxle fluid by removing the drain plug. (Refer to «SERVICE ADJUSTMENT PROCEDURE»(ref-537304-S39342190972013032200000) .
4. Remove the air breather hose (A).
5. Remove the valve body cover (B). Tightening torque: 13.7 ~ 15.7 N.m (1.4 ~ 1.6 kgf.m, 10.8 ~ 11.6 lb-ft) NOTE: Remove installation bolts in the engine compartment first and then remove others under the vehicle.
6. Remove the plate and the detent spring (A) after removing the bolt. Tightening torque: 11.8 ~ 15.7 N.m (1.2 ~ 1.6 kgf.m, 8.7 ~ 11.6 lb-ft)
7. Remove the bolt (3ea) after disconnecting the solenoid valve connector (B) and the oil temperature sensor connector (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) CAUTION: Be careful not to damage the harness lock connector.
8. Remove the valve body assembly (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
9. Disconnect the input & output speed sensor connector(A).
10. Remove the input & output speed sensor (B) after removing the bolts (2ea). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)

Scheme 240

1. Installation is the reverse of removal. NOTE: The gasket of the valve body gasket (A) use new one. Adding automatic transaxle fluid. (Refer to «SERVICE ADJUSTMENT PROCEDURE»(ref-537304-S39342190972013032200000) . Perform TCM learning after replacing the automatic transaxle to prevent slow automatic transaxle response, jerky acceleration and jerky startup. (Refer to ( «REPAIR PROCEDURES»(ref-537306-S16246276662013032200000) )" in this group)

1. Check signal waveform of Input & output speed sensor using the GDS. Specification: Refer to «Signal Waveform»(ref-537306-S18932294342013032200000) .

Scheme 241

Scheme 242

Scheme 243

Scheme 244

Scheme 245

Scheme 246

1. Remove the battery and the battery tray. (Refer to " «CHARGING SYSTEM»(ref-537199-S25919029862013032200000) " in EE group.)
2. Remove the under cover (A). Tightening torque: 6.9 ~ 10.8 N.m (0.7 ~ 1.1 kgf.m, 5.1 ~ 8.0 lb-ft)
3. Replace new gasket and the plug after draining the automatic transaxle fluid by removing the drain plug. (Refer to «SERVICE ADJUSTMENT PROCEDURE»(ref-537304-S39342190972013032200000) .
4. Remove the air breather hose (A).
5. Remove the valve body cover (B). Tightening torque: 13.7 ~ 15.7 N.m (1.4 ~ 1.6 kgf.m, 10.8 ~ 11.6 lb-ft) CAUTION: Always replace the gasket of the eyebolt use new one whenever loosening eyebolt. NOTE: Remove installation bolts in the engine compartment first and then remove others under the vehicle.
6. Remove the plate and the detent spring (A) after removing the bolt. Tightening torque: 11.8 ~ 15.7 N.m (1.2 ~ 1.6 kgf.m, 8.7 ~ 11.6 lb-ft)
7. Remove the bolt (3ea) after disconnecting the solenoid valve connector (B) and the oil temperature sensor connector (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) CAUTION: Be careful not to damage the harness lock connector.
8. Remove the valve body assembly (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
9. Disconnect the input & output speed sensor connector (A).
10. Remove the input & output speed sensor (B) after removing the bolts (2ea). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)

Scheme 247

1. Installation is the reverse of removal. NOTE: The gasket of the valve body gasket (A) use new one. Adding automatic transaxle fluid. (Refer to «SERVICE ADJUSTMENT PROCEDURE»(ref-537304-S39342190972013032200000) . Perform TCM learning after replacing the automatic transaxle to prevent slow automatic transaxle response, jerky acceleration and jerky startup. (Refer to ( «REPAIR PROCEDURES»(ref-537306-S16246276662013032200000) )" in this group)

1. Turn ignition switch OFF.
2. Disconnect the solenoid valve connector.
3. Measure resistance between sensor signal terminal and sensor ground terminal.
4. Check that the resistance is within the specification.

Scheme 248

Scheme 249

Scheme 250

Scheme 251

Scheme 252

1. Remove the battery and the battery tray. (Refer to " «CHARGING SYSTEM»(ref-537199-S25919029862013032200000) " in EE group.)
2. Remove the under cover (A). Tightening torque: 6.9 ~ 10.8 N.m (0.7 ~ 1.1 kgf.m, 5.1 ~ 8.0 lb-ft)
3. Replace new gasket and the plug after draining the automatic transaxle fluid by removing the drain plug. (Refer to «SERVICE ADJUSTMENT PROCEDURE»(ref-537304-S39342190972013032200000) .
4. Remove the air breeder hose (A).
5. Remove the valve body cover (B). Tightening torque: 13.7 ~ 15.7 N.m (1.4 ~ 1.6 kgf.m, 10.1 ~ 11.6 lb-ft)
6. Remove the bolt (3ea) after disconnecting the solenoid valve connector (B) and the oil temperature sensor connector (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
7. Remove the solenoid valve support bracket (B) and the valve body mounting bolt (A-1ea). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
8. Remove the torque converter control solenoid valve (A).

Scheme 253

1. Installation is the reverse of removal. NOTE: The gasket of the valve body gasket (A) use new one. Adding automatic transaxle fluid. (Refer to «SERVICE ADJUSTMENT PROCEDURE»(ref-537304-S39342190972013032200000) . Perform TCM learning after replacing the automatic transaxle to prevent slow automatic transaxle response, jerky acceleration and jerky startup. (Refer to ( «REPAIR PROCEDURES»(ref-537306-S16246276662013032200000) )" in this group)

1. Turn ignition switch OFF.
2. Disconnect the solenoid valve connector.
3. Measure resistance between sensor signal terminal and sensor ground terminal.
4. Check that the resistance is within the specification.

1. Turn ignition switch OFF.
2. Disconnect the solenoid valve connector.
3. Measure resistance between sensor signal terminal and sensor ground terminal.
4. Check that the resistance is within the specification.

1. Turn ignition switch OFF.
2. Disconnect the solenoid valve connector.
3. Measure resistance between sensor signal terminal and sensor ground terminal.
4. Check that the resistance is within the specification.

1. Turn ignition switch OFF.
2. Disconnect the solenoid valve connector.
3. Measure resistance between sensor signal terminal and sensor ground terminal.
4. Check that the resistance is within the specification.

1. Turn ignition switch OFF.
2. Disconnect the solenoid valve connector.
3. Measure resistance between sensor signal terminal and sensor ground terminal.
4. Check that the resistance is within the specification.

1. Turn ignition switch OFF.
2. Disconnect the solenoid valve connector.
3. Measure resistance between sensor signal terminal and sensor ground terminal.
4. Check that the resistance is within the specification.

Scheme 254

Scheme 255

Scheme 256

Scheme 257

1. Remove the battery and the battery tray. (Refer to " «CHARGING SYSTEM»(ref-537199-S25919029862013032200000) " in EE group.)
2. Remove the under cover (A). Tightening torque: 6.9 ~ 10.8 N.m (0.7 ~ 1.1 kgf.m, 5.1 ~ 8.0 lb-ft)
3. Replace new gasket and the plug after draining the automatic transaxle fluid by removing the drain plug. (Refer to «SERVICE ADJUSTMENT PROCEDURE»(ref-537304-S39342190972013032200000) .
4. Remove the air breather hose (A).
5. Remove the valve body cover (B). Tightening torque: 13.8 ~ 14.7 N.m (1.3 ~ 1.5 kgf.m, 9.4 ~ 10.8 lb-ft) CAUTION: Always replace the gasket of the eyebolt use new one whenever loosening eyebolt. NOTE: Remove installation bolts in the engine room first and then remove others under the vehicle.
6. Remove the bolt (3ea) after disconnecting the solenoid valve connector (B) and the oil temperature sensor connector (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
7. Remove the solenoid valve (B) after removing the solenoid support (A).

Scheme 258

Scheme 259

1. Installation is the reverse of removal. NOTE: When installing, apply the ATF oil or white vaseline to the O-ring (A) not to be damaged. The gasket of the valve body gasket (A) use new one. Adding automatic transaxle fluid. (Refer to «SERVICE ADJUSTMENT PROCEDURE»(ref-537304-S39342190972013032200000) . Perform TCM learning after replacing the automatic transaxle to prevent slow automatic transaxle response, jerky acceleration and jerky startup. (Refer to ( «REPAIR PROCEDURES»(ref-537306-S16246276662013032200000) )" in this group)

1. Turn ignition switch OFF.
2. Disconnect the solenoid valve connector.
3. Measure resistance between sensor signal terminal and sensor ground terminal.
4. Check that the resistance is within the specification.

Scheme 260

Scheme 261

Scheme 262

Scheme 263

1. Remove the battery and the battery tray. (Refer to " «CHARGING SYSTEM»(ref-537199-S25919029862013032200000) " in EE group.)
2. Remove the under cover (A). Tightening torque: 6.9 ~ 10.8 N.m (0.7 ~ 1.1 kgf.m, 5.1 ~ 8.0 lb-ft)
3. Replace new gasket and the plug after draining the automatic transaxle fluid by removing the drain plug. (Refer to «SERVICE ADJUSTMENT PROCEDURE»(ref-537304-S39342190972013032200000) .
4. Remove the valve body cover (A) and eyebolt (B). Tightening torque: 13.7 ~ 15.7 N.m (1.4 ~ 1.6 kgf.m, 10.1 ~ 11.6 lb-ft) CAUTION: Always replace the gasket of the eyebolt use new one whenever loosening eyebolt. NOTE: Remove installation bolts in the engine room first and then remove others under the vehicle.
5. Remove the bolt (3ea) after disconnecting the solenoid valve connector (B) and the oil temperature sensor connector (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
6. Remove the solenoid valve (B) after removing the solenoid support (A).

Scheme 264

Scheme 265

1. Installation is the reverse of removal. NOTE: When installing, apply the ATF oil or white vaseline to the O-ring (A) not to be damaged. The gasket of the valve body gasket (A) use new one. Adding automatic transaxle fluid. (Refer to «SERVICE ADJUSTMENT PROCEDURE»(ref-537304-S39342190972013032200000) . Perform TCM learning after replacing the automatic transaxle to prevent slow automatic transaxle response, jerky acceleration and jerky startup. (Refer to ( «REPAIR PROCEDURES»(ref-537306-S16246276662013032200000) )" in this group)

1. Check the damage and operation of the control cable.
2. Check the damage of the boot.
3. Check the damage and corrosion of the bushing.
4. Check the damage or weakening of the spring.

Scheme 266

Scheme 267

Scheme 268

1. Remove the floor console assembly. (Refer to " «INTERIOR»(ref-537209-S17469936702013032200000) " in BD group.)
2. Loosen the mounting nut (A) and then remove the shift lock cable from the shift lock cam (B). Tightening torque: 9.8 ~ 13.7 N.m (1.0 ~ 1.4 kgf.m, 7.2 ~ 10.1 lb-ft)
3. Remove the snap pin (B) and shift lock cable (C) from the brake pedal assembly (A).
4. Installation is the reverse of removal. NOTE: Adjust the shift lock cable after installing. (Refer to " «SHIFT LOCK CABLE (ADJUST)»(ref-537306-S24052855362013032200000) " in this group)

1. With shift lever at "P" position and brake pedal not depressed, push button can not operated. (shift lever can not be shifted to other positions from "P") push button can be operated at the positions except "P".
2. With brake pedal stroke 15 ~ 25mm (with shift lever at "P" position), push button can be operated and shift lever can be shifted to smoothly to other from "P".
3. With brake pedal not depressed, shift lever can be shifted smoothly to "P" positions from other position.
