Monitor GDS Data

  1. Ignition ON & Engine OFF.
  2. Connect GDS to Data Link Connector(DLC).
  3. Select "Diagnostic Trouble Codes(DTCs)" mode and monitor "DTC Status" parameter.
  4. Clear recorded DTC using GDS.
  5. Ignition switch OFF <--> Ignition switch ON 2~3 times and Selet "Diagnostic Trouble Codes(DTCs)" mode and monitor "DTC Status" parameter.
  6. Is the DTC present? YES PCM's ROM or DATA is changed by reprogram illegally. Substitute with a known-good PCM and check for proper operation. If the problem is corrected, replace PCM and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-537316-S42902207892013032200000) " procedure. NO Fault is intermittent caused by poor contact of PCM and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-537316-S42902207892013032200000) " procedure.

Verification of Vehicle Repair

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect GDS and select "Diagnostic Trouble Codes(DTCs)" mode and then clear DTC.
  2. Operate the vehicle and monitor the DTC on the GDS.
  3. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 578

Scheme 578: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect GDS and select "Diagnostic Trouble Codes(DTCs)" mode and then clear DTC.
  2. Operate the vehicle and monitor the DTC on the GDS.
  3. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 579

Scheme 579: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect GDS and select "Diagnostic Trouble Codes(DTCs)" mode and then clear DTC.
  2. Operate the vehicle and monitor the DTC on the GDS.
  3. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 580

Scheme 580: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect GDS and select "Diagnostic Trouble Codes(DTCs)" mode and then clear DTC.
  2. Operate the vehicle and monitor the DTC on the GDS.
  3. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 581

Scheme 581: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect GDS and select "Diagnostic Trouble Codes(DTCs)" mode and then clear DTC.
  2. Operate the vehicle and monitor the DTC on the GDS.
  3. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 582

Scheme 582: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect GDS and select "Diagnostic Trouble Codes(DTCs)" mode and then clear DTC.
  2. Operate the vehicle and monitor the DTC on the GDS.
  3. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 583

Scheme 583: Component Location

Pass "Stall Test" caused by hard to test at D-RANGE 6TH SPEED, go to " VERIFICATION OF VEHICLE REPAIR " procedure.

Scheme 584

Scheme 584: Signal Circuit Inspection
  1. Connect GDS to Data Link Connector(DLC).
  2. Ignition "ON" & Engine "ON".
  3. Selet "Current Data" mode and monitor "Engine speed, Input speed sensor(PG-A), Output speed sensor(PG-B) and Gear position" parameter used select option.
  4. Engine speed up to about 2000rpm and check Input speed(PG-A)&Output speed(PG-B) are within specific at 6th speed of gear. Specification Output speed>(input speed+200rpm)/6th. gear ratio Output speed<(input speed-200rpm)/6th. gear ratio
  5. Are measured Input speed(PG-A)&Output speed(PG-B) within specifiction? YES Go to " «COMPONENT INSPECTION»(ref-537316-S15134899182013032200000) " procedure. NO Check there are electrical nosie at Inout/output speed and Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-537316-S16050780812013032200000) " procedure.

Scheme 585

Scheme 585: Component Inspection
  1. Connect oil pressure gage at "2/6 Brake" port and "OD Clutch" port.
  2. Engine ON.
  3. Driving with 6th speed of gear at sports mode.
  4. Check by below specification table. Specification : See below specification table Shift lever position RPM Solenoid current(mA) ON/OFF Solenoid Pressure(kgf/cm 2 ) UD/B OD/C 26/B 35R/C LP T/CON SS-A SS-B UD/C OD/C 26/B 35R/C LR/B RED1 RED2 DR DA D1 2500 0 852 0 852 0 0 OFF OFF 16.2±0.4 - 0.1 under - - 5.0±0.2 5.5±0.2 7.3±0.4 4.4±0.4 ↑ 700 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 0.6~1.4 - - - - - - - - ↑ 600 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 2.7~3.1 - - - - - - - - ↑ 500 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 4.6~5.4 - - - - - - - - D2 ↑ 0 852 852 852 0 0 OFF OFF 15~17.5 - 162.2±0.4 0.03~0.4 - 5.0±0.2 5.5±0.2 - - ↑ ↑ ↑ 352 ↑ ↑ ↑ ↑ ↑ - - 0.9~1.7 - - - - - - ↑ ↑ ↑ 452 ↑ ↑ ↑ ↑ ↑ - - 2.8~3.2 - - - - - - ↑ ↑ ↑ 652 ↑ ↑ ↑ ↑ ↑ - - 4.6~5.4 - - - - - - D3 ↑ 0 852 0 0 0 0 OFF ON 15~17.5 0.03~0.4 - 16.2±0.4 0.03~0.4 5.0±0.5 5.5±0.5 - - ↑ ↑ ↑ ↑ 700 ↑ ↑ ↑ ↑ - - - 0.4~1.2 - - - - - ↑ ↑ ↑ ↑ 600 ↑ ↑ ↑ ↑ - - - 2.5~2.9 - - - - - ↑ ↑ ↑ ↑ 500 ↑ ↑ ↑ ↑ - - - 4.3~5.1 - - - - - D4 ↑ 0 0 0 852 0 0 OFF OFF 15~17.5 15~17.5 - - - 5.0±0.5 5.5±0.5 - - ↑ ↑ 700 ↑ ↑ ↑ ↑ ↑ ↑ - 0.6~1.4 - - - - - - - ↑ ↑ 652 ↑ ↑ ↑ ↑ ↑ ↑ - 2.2~2.6 - - - - - - - D5 ↑ 852 0 0 0 0 0 OFF ON 0.03~0.4 16.2±0.4 - 15~17.5 - 5.0±0.5 5.5±0.5 - - D6 ↑ 852 0 852 852 0 852 OFF OFF - 15~17.5 15~17.5 - - 5.0±0.5 5.5±0.5 0~0.2 7.7~8.4 ↑ ↑ ↑ ↑ ↑ 400 ↑ ↑ ↑ - 2.5~13.5 - - - - - - - ↑ ↑ ↑ ↑ ↑ 600 ↑ ↑ ↑ - 8.1~9.1 - - - - - - - ↑ ↑ ↑ ↑ ↑ 852 ↑ ↑ ↑ - 4.0~5.0 - - - - - - - ↑ ↑ ↑ ↑ ↑ 0 552 OFF OFF - - - - - - - DA-DR:3.2~4.2 ↑ ↑ ↑ ↑ ↑ ↑ 452 ↑ ↑ - - - - - - - DA-DR:1.3~2.3 L ↑ 0 0 0 852 0 0 ON OFF 15~17.5 - - - 16.2±0.4 - - - - D1 600 0 852 0 852 0 0 OFF OFF Above 7 (1) - - - - - - - - N ↑ 852 0 0 852 0 0 ON OFF - - - - Above 7 5.0±0.5 5.5±0.5 - - R 2500 852 852 0 0 0 0 OFF ON - - - 15~17.5 16±1 5.0±0.5 5.5±0.5 - - (1) A6LF1, 2, 3: Above 7 A6MF1, 2: Above 6 Above specification value can be different by vehicle model/measured variation.
  5. Is measured oil pressure value within specification? YES Repair automatic transmission and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-537316-S16050780812013032200000) " procedure. NO Repair automatic transmission(valve body) and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-537316-S16050780812013032200000) " procedure.

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect GDS and select "Diagnostic Trouble Codes(DTCs)" mode and then clear DTC.
  2. Operate the vehicle and monitor the DTC on the GDS.
  3. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 586

Scheme 586: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect GDS and select "Diagnostic Trouble Codes(DTCs)" mode and then clear DTC.
  2. Operate the vehicle and monitor the DTC on the GDS.
  3. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 587

Scheme 587: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect GDS and select "Diagnostic Trouble Codes(DTCs)" mode and then clear DTC.
  2. Operate the vehicle and monitor the DTC on the GDS.
  3. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 588

Scheme 588: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect GDS and select "Diagnostic Trouble Codes(DTCs)" mode and then clear DTC.
  2. Operate the vehicle and monitor the DTC on the GDS.
  3. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 589

Scheme 589: Component Location

Pass "Stall Test" caused by hard to test at D-RANGE 5TH SPEED, go to " VERIFICATION OF VEHICLE REPAIR " procedure.

Scheme 590

Scheme 590: Signal Circuit Inspection
  1. Connect GDS to Data Link Connector(DLC).
  2. Ignition "ON" & Engine "ON".
  3. Selet "Current Data" mode and monitor "Engine speed, Input speed sensor(PG-A), Output speed sensor(PG-B) and Gear position" parameter used select option.
  4. Engine speed up to about 2000rpm and check Input speed(PG-A)&Output speed(PG-B) are within specific at 5th speed of gear. Specification Output speed>(input speed+200rpm)/5th. gear ratio Output speed<(input speed-200rpm)/5th. gear ratio
  5. Are measured Input speed(PG-A)&Output speed(PG-B) within specifiction? YES Go to " «COMPONENT INSPECTION»(ref-537316-S25732437172013032200000) " procedure. NO Check there are electrical nosie at Inout/output speed and Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-537316-S28091161312013032200000) " procedure.

Scheme 591

Scheme 591: Component Inspection
  1. Connect oil pressure gage at "3/5/R Clutch" port and "OD Clutch" port.
  2. Engine ON.
  3. Driving with 5th speed of gear at sports mode.
  4. Check by below specification table. Specification : See below specification table Shiftlever position RPM Solenoid current(mA) ON/OFF Solenoid Pressure(kgf/cm 2 ) UD/B OD/C 26/B 35R/C LP T/CON SS-A SS-B UD/C OD/C 26/B 35R/C LR/B RED1 RED2 DR DA D1 2500 0 852 0 852 0 0 OFF OFF 16.2±0.4 - 0.1 under - - 5.0±0.2 5.5±0.2 7.3±0.4 4.4±0.4 ↑ 700 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 0.6~1.4 - - - - - - - - ↑ 600 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 2.7~3.1 - - - - - - - - ↑ 500 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 4.6~5.4 - - - - - - - - D2 ↑ 0 852 852 852 0 0 OFF OFF 15~17.5 - 162.2±0.4 0.03~0.4 - 5.0±0.2 5.5±0.2 - - ↑ ↑ ↑ 352 ↑ ↑ ↑ ↑ ↑ - - 0.9~1.7 - - - - - - ↑ ↑ ↑ 452 ↑ ↑ ↑ ↑ ↑ - - 2.8~3.2 - - - - - - ↑ ↑ ↑ 652 ↑ ↑ ↑ ↑ ↑ - - 4.6~5.4 - - - - - - D3 ↑ 0 852 0 0 0 0 OFF ON 15~17.5 0.03~0.4 - 16.2±0.4 0.03~0.4 5.0±0.5 5.5±0.5 - - ↑ ↑ ↑ ↑ 700 ↑ ↑ ↑ ↑ - - - 0.4~1.2 - - - - - ↑ ↑ ↑ ↑ 600 ↑ ↑ ↑ ↑ - - - 2.5~2.9 - - - - - ↑ ↑ ↑ ↑ 500 ↑ ↑ ↑ ↑ - - - 4.3~5.1 - - - - - D4 ↑ 0 0 0 852 0 0 OFF OFF 15~17.5 15~17.5 - - - 5.0±0.5 5.5±0.5 - - ↑ ↑ 700 ↑ ↑ ↑ ↑ ↑ ↑ - 0.6~1.4 - - - - - - - ↑ ↑ 652 ↑ ↑ ↑ ↑ ↑ ↑ - 2.2~2.6 - - - - - - - D5 ↑ 852 0 0 0 0 0 OFF ON 0.03~0.4 16.2±0.4 - 15~17.5 - 5.0±0.5 5.5±0.5 - - D6 ↑ 852 0 852 852 0 852 OFF OFF - 15~17.5 15~17.5 - - 5.0±0.5 5.5±0.5 0~0.2 7.7~8.4 ↑ ↑ ↑ ↑ ↑ 400 ↑ ↑ ↑ - 2.5~13.5 - - - - - - - ↑ ↑ ↑ ↑ ↑ 600 ↑ ↑ ↑ - 8.1~9.1 - - - - - - - ↑ ↑ ↑ ↑ ↑ 852 ↑ ↑ ↑ - 4.0~5.0 - - - - - - - ↑ ↑ ↑ ↑ ↑ 0 552 OFF OFF - - - - - - - DA-DR:3.2~4.2 ↑ ↑ ↑ ↑ ↑ ↑ 452 ↑ ↑ - - - - - - - DA-DR:1.3~2.3 L ↑ 0 0 0 852 0 0 ON OFF 15~17.5 - - - 16.2±0.4 - - - - D1 600 0 852 0 852 0 0 OFF OFF Above 7 (1) - - - - - - - - N ↑ 852 0 0 852 0 0 ON OFF - - - - Above 7 5.0±0.5 5.5±0.5 - - R 2500 852 852 0 0 0 0 OFF ON - - - 15~17.5 16±1 5.0±0.5 5.5±0.5 - - (1) A6LF1, 2, 3: Above 7 A6MF1, 2: Above 6 Above specification value can be different by vehicle model/measured variation.
  5. Is measured oil pressure value within specification? YES Repair automatic transmission and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-537316-S28091161312013032200000) " procedure. NO Repair automatic transmission(valve body) and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-537316-S28091161312013032200000) " procedure.

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect GDS and select "Diagnostic Trouble Codes(DTCs)" mode and then clear DTC.
  2. Operate the vehicle and monitor the DTC on the GDS.
  3. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 592

Scheme 592: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect GDS and select "Diagnostic Trouble Codes(DTCs)" mode and then clear DTC.
  2. Operate the vehicle and monitor the DTC on the GDS.
  3. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 593

Scheme 593: Component Location

Can not "Stall Test" at D-RANGE 2ND SPEED, go to " VERIFICATION OF VEHICLE REPAIR " procedure.

Scheme 594

Scheme 594: Signal Circuit Inspection
  1. Connect GDS to Data Link Connector(DLC).
  2. Ignition "ON" & Engine "ON".
  3. Selet "Current Data" mode and monitor "Engine speed, Input speed sensor(PG-A), Output speed sensor(PG-B) and Gear position" parameter used select option.
  4. Engine speed up to about 2000rpm and check Input speed(PG-A)&Output speed(PG-B) are within specific at 2nd speed o gear. Specification Output speed>(input speed+200rpm)/2nd. gear ratio Output speed<(input speed-200rpm)/2nd. gear ratio
  5. Are measured Input speed(PG-A)&Output speed(PG-B) within specifiction? YES Go to " «COMPONENT INSPECTION»(ref-537316-S31026738862013032200000) " procedure. NO Check there are electrical nosie at Inout/output speed and Repair as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-537316-S17045835242013032200000) " procedure.

Scheme 595

Scheme 595: Component Inspection
  1. Connect oil pressure gage at "UD brake" port and "2/6 brake" port.
  2. Engine ON.
  3. Driving with 2nd speed of gear at sports mode.
  4. Check by below specification table. Specification : See below specification table Shiftlever position RPM Solenoid current(mA) ON/OFF Solenoid Pressure(kgf/cm 2 ) UD/B OD/C 26/B 35R/C LP T/CON SS-A SS-B UD/C OD/C 26/B 35R/C LR/B RED1 RED2 DR DA D1 2500 0 852 0 852 0 0 OFF OFF 16.2±0.4 - 0.1 under - - 5.0±0.2 5.5±0.2 7.3±0.4 4.4±0.4 ↑ 700 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 0.6~1.4 - - - - - - - - ↑ 600 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 2.7~3.1 - - - - - - - - ↑ 500 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 4.6~5.4 - - - - - - - - D2 ↑ 0 852 852 852 0 0 OFF OFF 15~17.5 - 162.2±0.4 0.03~0.4 - 5.0±0.2 5.5±0.2 - - ↑ ↑ ↑ 352 ↑ ↑ ↑ ↑ ↑ - - 0.9~1.7 - - - - - - ↑ ↑ ↑ 452 ↑ ↑ ↑ ↑ ↑ - - 2.8~3.2 - - - - - - ↑ ↑ ↑ 652 ↑ ↑ ↑ ↑ ↑ - - 4.6~5.4 - - - - - - D3 ↑ 0 852 0 0 0 0 OFF ON 15~17.5 0.03~0.4 - 16.2±0.4 0.03~0.4 5.0±0.5 5.5±0.5 - - ↑ ↑ ↑ ↑ 700 ↑ ↑ ↑ ↑ - - - 0.4~1.2 - - - - - ↑ ↑ ↑ ↑ 600 ↑ ↑ ↑ ↑ - - - 2.5~2.9 - - - - - ↑ ↑ ↑ ↑ 500 ↑ ↑ ↑ ↑ - - - 4.3~5.1 - - - - - D4 ↑ 0 0 0 852 0 0 OFF OFF 15~17.5 15~17.5 - - - 5.0±0.5 5.5±0.5 - - ↑ ↑ 700 ↑ ↑ ↑ ↑ ↑ ↑ - 0.6~1.4 - - - - - - - ↑ ↑ 652 ↑ ↑ ↑ ↑ ↑ ↑ - 2.2~2.6 - - - - - - - D5 ↑ 852 0 0 0 0 0 OFF ON 0.03~0.4 16.2±0.4 - 15~17.5 - 5.0±0.5 5.5±0.5 - - D6 ↑ 852 0 852 852 0 852 OFF OFF - 15~17.5 15~17.5 - - 5.0±0.5 5.5±0.5 0~0.2 7.7~8.4 ↑ ↑ ↑ ↑ ↑ 400 ↑ ↑ ↑ - 2.5~13.5 - - - - - - - ↑ ↑ ↑ ↑ ↑ 600 ↑ ↑ ↑ - 8.1~9.1 - - - - - - - ↑ ↑ ↑ ↑ ↑ 852 ↑ ↑ ↑ - 4.0~5.0 - - - - - - - ↑ ↑ ↑ ↑ ↑ 0 552 OFF OFF - - - - - - - DA-DR:3.2~4.2 ↑ ↑ ↑ ↑ ↑ ↑ 452 ↑ ↑ - - - - - - - DA-DR:1.3~2.3 L ↑ 0 0 0 852 0 0 ON OFF 15~17.5 - - - 16.2±0.4 - - - - D1 600 0 852 0 852 0 0 OFF OFF Above 7 (1) - - - - - - - - N ↑ 852 0 0 852 0 0 ON OFF - - - - Above 7 5.0±0.5 5.5±0.5 - - R 2500 852 852 0 0 0 0 OFF ON - - - 15~17.5 16±1 5.0±0.5 5.5±0.5 - - (1) A6LF1, 2, 3: Above 7 A6MF1, 2: Above 6 Above specification value can be different by vehicle model/measured variation.
  5. Is measured oil pressure value within specification? YES Repair automatic transmission and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-537316-S17045835242013032200000) " procedure. NO Repair automatic transmission(valve body) and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-537316-S17045835242013032200000) " procedure.

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect GDS and select "Diagnostic Trouble Codes(DTCs)" mode and then clear DTC.
  2. Operate the vehicle and monitor the DTC on the GDS.
  3. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 596

Scheme 596: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect GDS and select "Diagnostic Trouble Codes(DTCs)" mode and then clear DTC.
  2. Operate the vehicle and monitor the DTC on the GDS.
  3. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 597

Scheme 597: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect GDS and select "Diagnostic Trouble Codes(DTCs)" mode and then clear DTC.
  2. Operate the vehicle and monitor the DTC on the GDS.
  3. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 598

Scheme 598: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect GDS and select "Diagnostic Trouble Codes(DTCs)" mode and then clear DTC.
  2. Operate the vehicle and monitor the DTC on the GDS.
  3. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 599

Scheme 599: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect GDS and select "Diagnostic Trouble Codes(DTCs)" mode and then clear DTC.
  2. Operate the vehicle and monitor the DTC on the GDS.
  3. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 600

Scheme 600: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect GDS and select "Diagnostic Trouble Codes(DTCs)" mode and then clear DTC.
  2. Operate the vehicle and monitor the DTC on the GDS.
  3. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 601

Scheme 601: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect GDS and select "Diagnostic Trouble Codes(DTCs)" mode and then clear DTC.
  2. Operate the vehicle and monitor the DTC on the GDS.
  3. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 602

Scheme 602: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect GDS and select "Diagnostic Trouble Codes(DTCs)" mode and then clear DTC.
  2. Operate the vehicle and monitor the DTC on the GDS.
  3. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 603

Scheme 603: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect GDS and select "Diagnostic Trouble Codes(DTCs)" mode and then clear DTC.
  2. Operate the vehicle and monitor the DTC on the GDS.
  3. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 604

Scheme 604: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect GDS and select "Diagnostic Trouble Codes(DTCs)" mode and then clear DTC.
  2. Operate the vehicle and monitor the DTC on the GDS.
  3. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 605

Scheme 605: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect GDS and select "Diagnostic Trouble Codes(DTCs)" mode and then clear DTC.
  2. Operate the vehicle and monitor the DTC on the GDS.
  3. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 606

Scheme 606: Component Location
  1. Connect GDS to Data Link Connector(DLC).
  2. Ignition "ON" & Engine "ON".
  3. Driving 1st speed to 6th speed at D-range.
  4. Selet "Current Data"mode and monitor "Shift Control Solenoid Valve(SS-B)" parameter current value. Specification : See below data OPERATING STEP TABLE AT EACH STATUS Solenoid SS-A SS-B OD N-H 35R N-H UD N-H 26 N-L N, P o o o o 1st o delta o 2nd o o o 3rd o o 4th o 5th o o 6th o o o L o o REV o o delta o o: Connected status delta: Connedted at Vehicle speed above 8km/h Clutch Brake 35R OD C 26 B UD B LR B O.W. P, N • R • • D1 • o • D2 • • D3 • • D4 • • D5 • • D6 • • •: Operated at Vehicle speed under 5km/h
  5. Is Shift Control Solenoid Valve(SS-B) within specification? YES Fault is intermittent caused by poor contact of PCM & sensor and DTC was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair as necessary and go to «Verification of Vehicle Repair»(ref-537316-S22092665332013032200000) procedure. NO Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-537316-S00325491432013032200000) " procedure.

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect GDS and select "Diagnostic Trouble Codes(DTCs)" mode and then clear DTC.
  2. Operate the vehicle and monitor the DTC on the GDS.
  3. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 607

Scheme 607: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect GDS and select "Diagnostic Trouble Codes(DTCs)" mode and then clear DTC.
  2. Operate the vehicle and monitor the DTC on the GDS.
  3. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.

Scheme 608

Scheme 608: Component Location

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect GDS and select "Diagnostic Trouble Codes(DTCs)" mode and then clear DTC.
  2. Operate the vehicle and monitor the DTC on the GDS.
  3. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System is performing to specification at this time.
