Automatic Transaxle Control System - 2.0L: Removal & Installation Kia Soul I рестайлинг

Automatic Trans 11 illustrations ~640 words

Installation

  1. Installation is reverse of removal. NOTE: In the case of the vehicle equipped with immobilizer or button engine start system, perform "Key Teaching" procedure together (Refer to " «IMMOBILIZER LAMP»(ref-537220-S34506530442013032200000) " or " «BUTTON ENGINE START SYSTEM»(ref-537235-S27939495982013032200000) in BE group).

Removal

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. (Refer to " VALVE BODY " in this group)

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. (Refer to " VALVE BODY " in this group)

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. (Refer to " VALVE BODY " in this group)

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. (Refer to " VALVE BODY " in this group)

Note. Replacing an on/off solenoid valve (SS-A, SS-B) does not require additional hydraulic pressure adjustment; however, the hydraulic pressure will need to be adjusted after replacing the VFS solenoid valve. If replacing the VFS solenoid valve; also replace the valve body assembly. (Refer to " VALVE BODY " in this group)

  1. Installation is the reverse of removal.

Scheme 269

Scheme 269: Components
Scheme 269: Components

Scheme 270

Scheme 270: Removal
Scheme 270: Removal

Scheme 271

Scheme 271
Scheme 271

Scheme 272

Scheme 272
Scheme 272

Scheme 273

Scheme 273
Scheme 273
  1. Remove the floor console assembly. (Refer to " «INTERIOR»(ref-537209-S17469936702013032200000) " in BD group.)
  2. Disconnect sports mode connector (A).
  3. Remove the control cable (A).
  4. Loosen the mounting nut (A) and shift lock cable from the shift lock cam (B). Tightening torque: 9.8 ~ 13.7 N.m (1.0 ~ 1.4 kgf.m, 7.2 ~ 10.1 lb-ft)
  5. Remove the shift lever assembly (A) by removing the bolts. Tightening torque: 8.8 ~ 13.7 N.m (0.9 ~ 1.4 kgf.m, 6.5 ~ 10.1 lb-ft)
  6. Installation is the reverse of removal. NOTE: When installing, set room side lever and T/M side lever to N position. Adjust the shift lock cable after installing. (Refer to " «SHIFT LOCK CABLE (ADJUST)»(ref-537306-S24052855362013032200000) " in this group)

Scheme 274

Scheme 274: Components
Scheme 274: Components

Scheme 275

Scheme 275: Replacement
Scheme 275: Replacement

Scheme 276

Scheme 276
Scheme 276

Scheme 277

Scheme 277
Scheme 277
  1. Remove the floor console assembly. (Refer to " «INTERIOR»(ref-537209-S17469936702013032200000) " in BD group.)
  2. Remove the shift cable (A).
  3. Remove the retainer (A) by loosening the nut (B-2ea). Tightening torque: 9.8 ~ 13.7 N.m (1.0 ~ 1.4 kgf.m, 7.2 ~ 10.1 lb-ft)
  4. Loosen the nut (C) and then remove the cable (B) from the bracket (A) at transaxle assembly side. Tightening torque: 9.8 ~ 13.7 N.m (1.0 ~ 1.4 kgf.m, 7.2 ~ 10.1 lb-ft)
  5. Remove the shift cable inside of cab.
  6. Installation is the reverse of removal. NOTE: When installing, set room side lever and T/M side lever to N position. Adjust the shift lock cable after installing. (Refer to " «SHIFT LOCK CABLE (ADJUST)»(ref-537306-S24052855362013032200000) " in this group)

Scheme 278

Scheme 278: Adjusting method for T/M shift cable
Scheme 278: Adjusting method for T/M shift cable

Scheme 279

Scheme 279
Scheme 279
  1. Set room side lever and T/M side lever to N position.
  2. Connect the room side lever (A) and shift cable (B).
  3. Push cable to "F" direction shown to eliminate FREE PLAY.
  4. Tighten adjusting nut (A). Tightening torque: 9.8 ~ 13.7 N.m (1.0 ~ 1.4 kgf.m, 7.2 ~ 10.1 lb-ft)
  5. After adjusting, check to be sure that this part operates as designed at each range of T/M side corresponding to each position of room lever.
