Hydraulic System - 2.0L: Removal & Installation Kia Soul I рестайлинг

Replacement

Note. ATF of 6 speed automatic transaxle doesn't need to be replaced. If the vehicle is used severely in business or personal use, replace ATF every 60, 000 miles. Severe usage is defined as Driving in rough road (Bumpy, Gravel, Snowy, Unpaved road, etc) Driving in mountain road, ascent/descent Repetition of short distance driving More than 50% operation in heavy city traffic during hot weather above 32°C(89.6°F). Police, Taxi, Commercial type operation or trailer towing, etc

Scheme 181

1. Remove the drain plug (A) and reinstall the drain plug after draining ATF totally. Drain plug tightening torque: 38.2 ~ 48.1 N.m (3.9 ~ 4.9 kgf.m, 28.2 ~ 35.4 lb-ft) CAUTION: The gasket of the drain plug use new one.
2. Fill the oil about 5 liters through eyebolt.
3. Check the oil level. (Refer to «Oil level Check»(ref-537304-S00240743582013032200000) .

Installation

1. Install is the reverse of the removal. NOTE: Must be replaced with new O ring when assembling. Adding automatic transaxle fluid. (Refer to «Oil level Check»(ref-537304-S00240743582013032200000) .

Scheme 182

1. Install is the reverse of the removal.
