Automatic Transaxle Control System - 2.0L: Adjustments Kia Soul I рестайлинг

Adjustment

Adjusting method for shift lock cable

Scheme 225

Scheme 226

1. Install the snap pin (B) and shift lock cable (C) to brake pedal assembly (A).
2. Move the shift lever to P range.
3. Temporarily install shift lock cable to P lock cam fixing pin (B).
4. Slightly pull outer casing of shift lock cable to direction "E", this prevents shift lock cable from being loose.
5. After checking portion of cable end touches cable fixing pin of P lock cam, tighten the nut (A). Tightening torque: 9.8 ~ 13.7 N.m (1.0 ~ 1.4 kgf.m, 7.2 ~ 10.1 lb-ft)
6. Again check that cable end touches.
