Automatic Transaxle Control System - 1.6L: Specifications Kia Soul I рестайлинг

Automatic Trans 11 illustrations ~166 words

Specifications

Temp.[(°C)°F]Resistance (kohms)
(-40)-4048.1
(-20)-4.015.6
(0)32.05.88
(20)68.02.51
(40)104.01.11
(60)140.00.61
(80)176.00.32
(100)212.00.18
(120)248.00.10
(140)284.00.06
(150)302.00.05

TRANSAXLE OIL TEMPERATURE SENSOR SPECIFICATIONS - NEGATIVE THERMAL COEFFICIENT TYPE

Scheme 55

Scheme 55
Scheme 55

Scheme 56

Scheme 56: Circuit Diagram
Scheme 56: Circuit Diagram
Operation condition [°C(°F)]((-)40 ~ 150)) -40 ~ 302
Air gap(mm)in.(0.85 ~ 1.3) 0.0335 ~ 0.0512
Output voltage(V)High1.18 ~ 1.68
Low0.59 ~ 0.84

HALL EFFECT SENSOR SPECIFICATIONS

Scheme 57

Scheme 57: Circuit Diagram
Scheme 57: Circuit Diagram

Scheme 58

Scheme 58: Signal Waveform
Scheme 58: Signal Waveform

Scheme 59

Scheme 59
Scheme 59
Operation condition [°C(°F)]((-)40 ~ 150)) -40 ~ 302
Air gap(mm)in.(1.2 ~ 1.8) 0.0472 ~ 0.0709
Output voltageHigh1.18 ~ 1.68
Low0.59 ~ 0.84

HALL EFFECT SENSOR SPECIFICATIONS

Scheme 60

Scheme 60: Circuit Diagram
Scheme 60: Circuit Diagram

Scheme 61

Scheme 61: Signal Waveform
Scheme 61: Signal Waveform

Scheme 62

Scheme 62
Scheme 62

Direct control VFS[T/CON]

Control Pressure kpa (kgf/cm 2 , psi)9.81 ~ 500.14 (0.1 ~ 5.1, 1.42 ~ 72.54)
Current value(mA)50 ~ 850
Internal resistance(ohms)5.1

DIRECT CONTROL VFS[T/CON] SPECIFICATIONS - NORMAL LOW TYPE

Scheme 63

Scheme 63: Circuit Diagram
Scheme 63: Circuit Diagram

Direct control VFS[26/B]

Control Pressure kpa (kgf/cm 2 , psi)9.81 ~ 500.14 (0.1 ~ 5.1, 1.42 ~ 72.54)
Current value(mA)50 ~ 850
Internal resistance(ohms)5.1

DIRECT CONTROL VFS[T/CON] SPECIFICATIONS - NORMAL LOW TYPE

Direct control VFS[LINE Pressure]

Control Pressure kpa (kgf/cm 2 , psi)500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42)
Current value(mA)50 ~ 850
Internal resistance(ohms)5.1

DIRECT CONTROL VFS[T/CON] SPECIFICATIONS - NORMAL LOW TYPE

Direct control VFS[35R/C]

Control Pressure kpa (kgf/cm 2 , psi)500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42)
Current value(mA)50 ~ 850
Internal resistance(ohms)5.1

DIRECT CONTROL VFS[T/CON] SPECIFICATIONS - NORMAL LOW TYPE

Direct control VFS[35R/C]

Control Pressure kpa (kgf/cm 2 , psi)500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42)
Current value(mA)50 ~ 850
Internal resistance(ohms)5.1

DIRECT CONTROL VFS[T/CON] SPECIFICATIONS - NORMAL LOW TYPE

Direct control VFS[35R/C]

Control Pressure kpa (kgf/cm 2 , psi)500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42)
Current value(mA)50 ~ 850
Internal resistance(ohms)5.1

DIRECT CONTROL VFS[T/CON] SPECIFICATIONS - NORMAL LOW TYPE

ON/OFF Solenoid Valve (SS-A, SS-B)

Control pressure kpa (kgf/cm 2 , psi)490.33(5.0, 71.12)
Internal resistance(ohms)10 ~ 11

ON/OFF SOLENOID VALVE (SS-A, SS-B) SPECIFICATIONS - NORMAL LOW TYPE

Scheme 64

Scheme 64: Circuit Diagram
Scheme 64: Circuit Diagram

ON/OFF Solenoid Valve (SS-A, SS-B)

Control pressure kpa (kgf/cm 2 , psi)490.33(5.0, 71.12)
Internal resistance(ohms)10 ~ 11

ON/OFF SOLENOID VALVE (SS-A, SS-B) SPECIFICATIONS - NORMAL LOW TYPE

Scheme 65

Scheme 65: Circuit Diagram
Scheme 65: Circuit Diagram
Power supply (V)12
Output typeCombination of output signals

INHIBITOR SWITCH SPECIFICATIONS - COMBINATION OF OUTPUT SIGNALS FROM 4 TERMINALS
