Tools Required Cadillac Escalade GMT800

1. J 41798 Engine Lifting Brackets
2. J 21366 Converter Holding Strap

Scheme 327

Scheme 328

Scheme 329

Scheme 330

Scheme 331

Scheme 332

Scheme 333

Scheme 334

Scheme 335

Scheme 336

Scheme 337

Scheme 338

Scheme 339

Scheme 340

Scheme 341

Scheme 342

Scheme 343

Scheme 344

Scheme 345

Scheme 346

Scheme 347

Scheme 348

Scheme 349

Scheme 350

Scheme 351

Scheme 352

Scheme 353

Scheme 354

Scheme 355

Scheme 356

Scheme 357

1. Open the hood.
2. Place fender covers over both fenders.
3. Raise the hood to the service position, then perform the following: 3.1. Remove the hood hinge bolts (1). 3.2. Raise the hood until vertical. 3.3. Install the hood hinge bolts until snug in the service position (2).
4. Remove the air conditioning (AC) compressor. Refer to COMPRESSOR REPLACEMENT (LR4, LM7, AND LQ4) in HVAC Systems - Manual.
5. Remove the radiator supports. Refer to RADIATOR SUPPORT REPLACEMENT in Body Front End.
6. Reposition the radiator inlet hose clamp at the water pump.
7. Remove the radiator inlet hose from the water pump.
8. Reposition the radiator outlet hose clamp at the water pump.
9. Remove the radiator outlet hose from the water pump.
10. Remove the heater hoses. Refer to HEATER HOSE REPLACEMENT - INLET (UTILITY LR4, LM7, LQ4) or HEATER HOSE REPLACEMENT - INLET (AVALANCHE/XIT LR4, LM7, LQ4) or HEATER HOSE REPLACEMENT - OUTLET (UTILITY LR4, LM7, LQ4) or HEATER HOSE REPLACEMENT - OUTLET (AVALANCHE/XIT LR4, LM7, LQ4) in Heating, Ventilation, and Air Conditioning.
11. If equipped with the 4.8L, 5.3L, or 6.0L regular production option (RPO) LQ4, loosen the intake manifold sight shield bolt.
12. Remove the sight shield from the retainer.
13. If equipped with the 6.0L with RPO LQ9, perform the following: 13.1. Loosen the intake manifold sight shield bolt. 13.2. Loosen the left fuel rail cover bolts. 13.3. Remove the left fuel rail cover. 13.4. Loosen the right fuel rail cover bolts. 13.5. Remove the right fuel rail cover. 13.6. Remove the sight shield from the retainer.
14. Disconnect the following electrical connectors: Evaporative emissions (EVAP) canister purge solenoid (1) Generator (3) Electronic throttle control (ETC)
15. Remove the harness bracket nut (2) in order to remove the engine harness from the intake manifold.
16. Reposition the vent inlet hose clamp at the throttle body.
17. Remove the radiator vent inlet hose from the throttle body.
18. Remove the generator cable from the generator, perform the following: 18.1. Slide the boot down revealing the terminal stud. 18.2. Remove the generator cable nut from the terminal stud. 18.3. Remove the generator cable.
19. Disconnect the main coil harness (2) and fuel injector (3) electrical connectors on the left side.
20. Disconnect the following electrical connectors: The main coil harness (1) The fuel injectors (3)
21. Disconnect the manifold absolute pressure (MAP) sensor (1) and knock sensor (2) electrical connectors.
22. Remove the harness ground bolt.
23. Reposition the harness ground and negative battery cable from the block.
24. Disconnect the following electrical connectors: The coolant temperature sensor (1) The electronic variable orifice switch (2)
25. Remove the harness ground bolt at the right rear of the engine block.
26. Reposition the harness ground, and auxiliary negative battery cable, if equipped from the block.
27. Remove the harness ground bolt at the left rear of the engine block
28. Reposition the harness ground, and engine ground strap from the block.
29. Disconnect the following electrical connectors: The oil pressure sensor (1) The camshaft position (CMP) sensor (2)
30. Unclip all of the engine harness clips from the engine.
31. Remove the battery cable junction block from the junction block bracket.
32. Remove the EVAP purge solenoid vent tube, perform the following: Remove the EVAP tube end (2) from the solenoid (1). Remove the EVAP tube end (3) from the vapor pipe.
33. Disconnect the fuel pipes. Refer to «FUEL LINE DISCONNECT FITTINGS»(ref-159266-S04103116342003112100000) in Engine Controls - 4.8L, 5.3L, and 6.0L.
34. Raise the vehicle.
35. Disconnect the following electrical connectors: The crankshaft position (CKP) sensor (1) The engine oil level sensor (6) The coolant heater, if equipped
36. Remove the battery cable channel bolt.
37. Slide the channel pin out of the oil pan tab.
38. Gather all branches of the engine wiring harness and reposition off to the side.
39. Lower the vehicle.
40. Remove the rear power steering pump-to-engine block bolt.
41. Remove the generator bracket mounting bolts.
42. Position the bracket aside.
43. Remove the vacuum brake booster hose.
44. Remove the ignition coil, as required for the proper fit of the J 41798 before lifting the engine. Refer to Ignition Coil(s) Replacement in Engine Controls - 4.8L, 5.3L and 6.0L. NOTE: Refer to «FASTENER NOTICE»(ref-175132-S17785009232005041500000) in Cautions and Notices.
45. Install the J 41798 to the cylinder heads. Tighten Tighten the M8 engine lift bracket bolts to 25 N.m (18 lb ft). Tighten the M10 engine lift bracket bolts to 50 N.m (37 lb ft).
46. Remove the left and right engine mount-to-engine mount bracket bolts.
47. Raise and suitably support the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(ref-180627-S40085739202005072800000) in General Information.
48. Remove the engine shield bolts and shield.
49. Remove the oil pan skid plate bolts and plate, if equipped.
50. Drain the engine oil.
51. Remove the starter motor. Refer to STARTER MOTOR REPLACEMENT (4.8L, 5.3L, AND 6.0L ENGINES) in Engine Electrical.
52. Remove the catalytic converter. Refer to CATALYTIC CONVERTER REPLACEMENT (4.8L AND 5.3L ENGINES) or CATALYTIC CONVERTER REPLACEMENT (6.0L AND 8.1L ENGINES) in Engine Exhaust.
53. Remove the positive battery cable clip bolt and clip.
54. Remove the flywheel to torque converter bolts.
55. Remove the transmission oil level indicator tube nut, if equipped.
56. Remove the transmission oil level indicator tube, if equipped.
57. If equipped with the 4L60-E automatic transmission, remove the transmission bolt and stud on the right side.
58. If equipped with the 4L80-E automatic transmission, remove the transmission converter cover bolts.
59. Remove the automatic transmission bolt/studs, if equipped.
60. Separate the engine from the automatic transmission. Install the J 21366 to the transmission in order to hold the torque converter.
61. Lower the vehicle.
62. Install an engine hoist to the J 41798 .
63. Install a floor jack under the transmission for support. NOTE: Use care while moving the engine assembly in order to avoid breaking the MAP sensor locating tabs. Broken MAP sensor tabs may result in decreased engine performance.
64. Remove the engine.
65. Install the engine to an engine stand.
66. Remove the engine hoist.
67. Remove the J 41798 from the engine.
