Timing Chain and Sprockets Installation Cadillac Escalade GMT800

Tools Required

J 41665 Crankshaft Balancer and Sprocket Installer

Scheme 713

Scheme 714

Scheme 715

Scheme 716

Scheme 717

Scheme 718

1. Install the key into the crankshaft keyway, if previously removed.
2. Tap the key (1) into the keyway until both ends of the key bottom onto the crankshaft.
3. Install the crankshaft sprocket onto the front of the crankshaft. Align the crankshaft key with the crankshaft sprocket keyway.
4. Use the J 41665 in order to install the crankshaft sprocket. Install the sprocket onto the crankshaft until fully seated against the crankshaft flange.
5. Rotate the crankshaft sprocket until the alignment mark is in the 12 o'clock position. Important: Properly locate the camshaft sprocket locating pin with the camshaft sprocket alignment hole. The sprocket teeth and timing chain must mesh. The camshaft and the crankshaft sprocket alignment marks MUST be aligned properly. Locate the camshaft sprocket alignment mark in the 6 o'clock position.
6. Install the camshaft sprocket and timing chain.
7. If necessary, rotate the camshaft or crankshaft sprockets in order to align the timing marks. NOTE: Refer to «FASTENER NOTICE»(ref-175132-S17785009232005041500000) in Cautions and Notices.
8. Install the camshaft sprocket bolts. Tighten Tighten the camshaft sprocket bolts to 35 N.m (26 lb ft).
