Crankshaft Balancer Removal Cadillac Escalade GMT800

Tools Required

1. J 41816 Crankshaft Balancer Remover
2. J 41816-2 Crankshaft End Protector
3. J 42386-A Flywheel Holding Tool

Note. Refer to FASTENER NOTICE in Cautions and Notices.

Scheme 400

Important

1. Do not use the crankshaft balancer bolt again. Install a NEW crankshaft balancer bolt during final assembly.
2. Ensure the teeth of the flywheel holding tool mesh with the teeth of the engine flywheel.

Scheme 401

Scheme 402

1. Install the J 42386-A and bolts. Use one M10 - 1.5 x 120 mm and one M10 - 1.5 x 45 mm bolt for proper tool operation. Tighten Tighten the J 42386-A bolts to 50 N.m (37 lb ft).
2. Remove the crankshaft balancer bolt. Do not discard the crankshaft balancer bolt. The balancer bolt will be used during the balancer installation procedure.
3. Use the J 41816 and the J 41816-2 in order to remove the crankshaft balancer.
4. Remove the J 42386-A and bolts.
