Camshaft Installation Cadillac Escalade GMT800

Important: If camshaft replacement is required, the valve lifters must also be replaced.

Scheme 710

Scheme 711

Scheme 712

1. Lubricate the camshaft journals and the bearings with clean engine oil.
2. Install 3 M8 - 1.25 x 100 mm (M8 - 1.25 x 4.0 in) bolts into the camshaft front bolt holes. NOTE: All camshaft journals are the same diameter, so care must be used in removing or installing the camshaft to avoid damage to the camshaft bearings.
3. Using the bolts as a handle, carefully install the camshaft into the engine block.
4. Remove the 3 bolts from the front of the camshaft. NOTE: Refer to «FASTENER NOTICE»(ref-175132-S17785009232005041500000) in Cautions and Notices. Important: Install the retainer plate with the sealing gasket facing the engine block. The gasket surface on the engine block should be clean and free of dirt or debris.
5. Install the camshaft retainer and the bolts. Tighten Tighten the camshaft retainer bolts to 25 N.m (18 lb ft).
6. Inspect the camshaft sensor O-ring seal. If the O-ring seal is not cut or damaged, it may be used again.
7. Lubricate the O-ring seal with clean engine oil.
8. Install the camshaft sensor and bolt. Tighten Tighten the camshaft sensor bolt to 25 N.m (18 lb ft).
