Intake Manifold Installation Cadillac Escalade GMT800

Mechanical 6 illustrations ~224 words

Important

  1. The intake manifold, throttle body, fuel injection rail and fuel injectors may be removed as an assembly. If not servicing the individual components, install the intake manifold as a complete assembly.
  2. DO NOT use the old intake manifold gaskets again. Install NEW intake manifold-to-cylinder head gaskets.

Scheme 777

Scheme 777

Scheme 778

Scheme 778

Scheme 779

Scheme 779

Scheme 780

Scheme 780

Scheme 781

Scheme 781

Scheme 782

Scheme 782
  1. Install NEW intake manifold-to-cylinder head gaskets (1).
  2. Install the intake manifold.
  3. Apply a 5 mm (0.20 in) band of threadlock GM P/N 12345382 (Canadian P/N 10953489) or equivalent to the threads of the intake manifold bolts. Refer to «Sealers, Adhesives And Lubricants»(ref-180687-S12053191792005101000000) . NOTE: Refer to «FASTENER NOTICE»(ref-175132-S17785009232005041500000) in Cautions and Notices.
  4. Install the intake manifold bolts. Tighten 4.1. Tighten intake manifold bolts first pass in sequence to 5 N.m (44 lb in). 4.2. Tighten intake manifold bolts final pass in sequence to 10 N.m (89 lb in).
  5. Install the manifold absolute pressure (MAP) sensor (1), if previously removed. The electrical connector end of the sensor should be facing the front of the engine.
  6. Install the positive crankcase ventilation (PCV) valve (2) and hose (1).
  7. Install the engine coolant air bleed hose and clamp onto the throttle body.
  8. Install the evaporative emission (EVAP) purge solenoid (3), bolt (2), and isolator (1). Tighten Tighten the solenoid bolt to 10 N.m (89 lb in).
