Cleaning Procedure Cadillac Escalade GMT800

Important: Do not use the intake manifold-to-cylinder head sealing gaskets again.

Scheme 640

Scheme 641

Scheme 642

Scheme 643

Scheme 644

1. Remove the manifold absolute pressure (MAP) sensor (1) from the rear of the intake. The MAP sensor is to be reinstalled upon completion of the cleaning and inspection procedures.
2. Inspect the sealing grommet on the MAP sensor. The grommet should not be torn or damaged.
3. Remove and discard the intake manifold-to-cylinder head gaskets (1).
4. Remove the fuel rail with injectors. Refer to «FUEL RAIL AND INJECTORS REMOVAL»(ref-180687-S27176646162005072800000) .
5. Remove the throttle body and gasket. Refer to «THROTTLE BODY REMOVAL»(ref-180687-S21961473192005072800000) .
6. Remove the evaporative emissions (EVAP) purge solenoid (3), bolt (2), and isolator (1).
7. Clean the intake manifold in solvent. Clean the intake manifold gasket surfaces. Clean the intake manifold internal passages. CAUTION: Refer to «SAFETY GLASSES CAUTION»(ref-175132-S23208358672005041500000) in Cautions and Notices.
8. Dry the intake manifold with compressed air.

Scheme 645

Scheme 646

Scheme 647

Scheme 648

Scheme 649

1. Inspect the throttle body studs and threaded inserts for looseness or damaged threads.
2. Inspect the wire harness stud and threaded insert for looseness or damaged threads.
3. Inspect the fuel rail bolt inserts for looseness or damaged threads.
4. Inspect the intake manifold vacuum passages for debris or restrictions.
5. Inspect for damaged or broken vacuum fittings, damaged MAP sensor (1) mounting bore, or broken MAP sensor retaining tabs.
6. Inspect the composite intake manifold assembly for cracks or other damage. Inspect the areas between the intake runners.
7. Inspect all the gasket sealing surfaces for damage.
8. Inspect the fuel injector bores for excessive scoring or damage.
9. Inspect the intake manifold cylinder head deck for warpage. 9.1. Locate a straight edge across the intake manifold cylinder head deck surface. Position the straight edge across a minimum of two runner port openings. 9.2. Insert a feeler gage between the intake manifold and the straight edge. A intake manifold with warpage in excess of 3 mm (0.118 in) over a 200 mm (7.87 in) area is warped and should be replaced.
10. Install the MAP sensor (1). NOTE: Refer to «FASTENER NOTICE»(ref-175132-S17785009232005041500000) in Cautions and Notices.
11. Install the EVAP solenoid, bolt, and isolator. Tighten Tighten the EVAP solenoid bolt to 10 N-m(89 lb in).
