Engine Replacement Buick Park Avenue II рестайлинг

Tools Required

J 38185 Hose Clamp Pliers

Scheme 190

Scheme 191

Scheme 192

Scheme 193

Scheme 194

Scheme 195

Scheme 196

Scheme 197

Scheme 198

Scheme 199

Scheme 200

Scheme 201

Scheme 202

Scheme 203

Scheme 204

Scheme 205

Scheme 206

Scheme 207

Scheme 208

1. Remove the hood. Refer to HOOD REPLACEMENT in Body Front End.
2. Remove the battery. Refer to BATTERY REPLACEMENT (TOP POST) in Engine Electrical.
3. Remove the fuel injector sight shield. Refer to «FUEL INJECTOR SIGHT SHIELD REPLACEMENT (L36)»(ref-187842-S38668557822005090800000) or «FUEL INJECTOR SIGHT SHIELD REPLACEMENT (L67)»(ref-187842-S10477858142005090800000) .
4. Disconnect the vacuum brake booster hose from the vacuum connections and position aside.
5. Disconnect the fuel feed and return lines from the fuel rail and secure to the air inlet grill. Refer to «FUEL LINE DISCONNECT FITTINGS»(ref-157368-S00115252352003081100000) .
6. Remove the evaporative emission canister purge valve and secure the hose to the air inlet grill. Refer to «EVAP CANISTER PURGE SOLENOID»(ref-157368-S05644758262003090400000) .
7. Push the lock release and remove the cruise control cable from the throttle body bracket and lever.
8. Disconnect the electrical connector from the cruise control module.
9. Remove the retaining nuts (2) and the cruise control module (1) from the mounting studs. CAUTION: In order to avoid possible injury or vehicle damage, always replace the accelerator control cable with a NEW cable whenever you remove the engine from the vehicle. In order to avoid cruise control cable damage, position the cable out of the way while you remove or install the engine. Do not pry or lean against the cruise control cable and do not kink the cable. You must replace a damaged cable.
10. Remove the accelerator control cable. Refer to CRUISE CONTROL CABLE REPLACEMENT in Cruise Control.
11. Remove the drive belt. Refer to «DRIVE BELT REPLACEMENT (L36)»(ref-187842-S09207139312005090800000) or «DRIVE BELT REPLACEMENT (L67)»(ref-187842-S41628165262005090800000) .
12. Raise and support the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(ref-187771-S24456970052005090800000) .
13. Remove the bolt securing both the battery negative cable and the engine harness ground lead to the engine block.
14. Disconnect the wiring harness connectors from the following components: The A/C compressor clutch (1) The A/C pressure sensor (2) The knock sensor #1 (3) The engine coolant block heater (4) The oil level sensor (7)
15. Disconnect the wiring harness from the harness clip at the rear of the A/C compressor.
16. Remove the torque converter cover. Refer to «TORQUE CONVERTER COVER»(ref-154016-S03999798592003050100000) .
17. Remove the starter motor. Refer to STARTER MOTOR REPLACEMENT in Engine Electrical.
18. Remove the bolts securing the flywheel to the torque converter.
19. Disconnect and secure the following wiring harness electrical connectors to the cowl: The knock sensor #2, located behind the right exhaust manifold The oil pressure sensor (2) The vehicle speed sensor (VSS) (3)
20. Remove the 2 bolts securing the transaxle brace to the transaxle. CAUTION: Always wear protective goggles and gloves when removing exhaust parts as falling rust and sharp edges from worn exhaust components could result in serious personal injury.
21. Remove the 2 nuts attaching the exhaust manifold pipe to the right exhaust manifold.
22. Remove the exhaust manifold pipe from the right exhaust manifold studs, allowing it to rest on top of the power steering gear heat shield. Remove the gasket. Do not reuse the gasket.
23. Remove the right front fascia extension. Refer to FASCIA EXTENSION REPLACEMENT - FRONT in Bumpers.
24. Remove the front A/C compressor mounting nuts.
25. Remove the rear A/C compressor mounting bolt.
26. Slide the A/C compressor forward off of the mounting studs and allow the compressor to rest on top of the engine frame.
27. Lower the vehicle.
28. Remove the bolt securing the PCM ground located at the left front cylinder head.
29. Disconnect the wiring harness electrical connectors from the following components on the left side of the engine: The fuel injectors The ignition harness The boost control solenoid (L67 only) The engine coolant temperature (ECT) sensor The throttle position (TP) sensor The idle air control (IAC) valve The mass air flow (MAF) sensor
30. Disconnect the wiring harness connectors from the following components on the right side of the engine: Fuel injectors Exhaust gas recirculation (EGR) valve Manifold absolute pressure (MAP) sensor Heated oxygen sensor (HO2S) AIR solenoid, if equipped with NC8 Generator
31. Secure the engine wiring harness rearward to the air inlet grill.
32. Remove the generator. Refer to GENERATOR REPLACEMENT (L36) or GENERATOR REPLACEMENT (L67) in Engine Electrical.
33. Remove the air cleaner intake duct.
34. Install the engine support fixture. Refer to «ENGINE SUPPORT FIXTURE»(ref-187842-S39672672042005090800000) .
35. Remove the two front power steering pump mounting bolts.
36. Raise and support the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(ref-187771-S24456970052005090800000) .
37. Remove the side power steering pump mounting bolt.
38. Position the power steering pump against the cowl, allowing it to rest on top of the transaxle housing.
39. Remove the right engine mount bracket. Refer to «ENGINE MOUNT BRACKET REPLACEMENT-RIGHT»(ref-187842-S07820206822005090800000) .
40. Remove the right lower engine to transaxle mounting bolt (1).
41. Drain the cooling system. Refer to DRAINING AND FILLING COOLING SYSTEM in Engine Cooling
42. Lower the vehicle.
43. Position the J 38185 to the clamp in order to remove the radiator inlet hose from the water pump.
44. Position the J 38185 to the clamp in order to remove the radiator outlet hose from the thermostat housing.
45. Remove the heater hoses from the drive belt tensioner fittings.
46. Using a block of wood between a floor jack and the transaxle, support the transaxle at the pan.
47. Remove the engine support fixture. Refer to «ENGINE SUPPORT FIXTURE»(ref-187842-S39672672042005090800000) .
48. Install a engine lift chain to the engine lift brackets and attach to an engine lift devise.
49. Remove the remaining engine to transaxle mounting bolts. IMPORTANT: Ensure clearance is maintained between the engine and the following: A/C accumulator A/C accumulator hose A/C compressor A/C compressor hose Engine wiring electrical harness Vacuum brake booster
50. Carefully raise the engine from the engine compartment.
51. Drain the engine oil. Refer to «ENGINE OIL AND OIL FILTER REPLACEMENT»(ref-187842-S14729902812005090800000) .
52. Remove the 2 bolts securing the transaxle brace to the engine.
53. Remove the exhaust manifold pipe. Refer to EXHAUST MANIFOLD PIPE REPLACEMENT in Engine Exhaust.

Scheme 209

Scheme 210

Scheme 211

Scheme 212

Scheme 213

Scheme 214

Scheme 215

Scheme 216

Scheme 217

Scheme 218

Scheme 219

Scheme 220

Scheme 221

Scheme 222

Scheme 223

Scheme 224

Scheme 225

Scheme 226

Scheme 227

1. Loosely install the 2 bolts securing the transaxle brace to the engine. Do not tighten at this time.
2. Install the exhaust manifold pipe. Refer to EXHAUST MANIFOLD PIPE REPLACEMENT in Engine Exhaust. IMPORTANT: Ensure clearance is maintained between the engine and the following: The A/C accumulator The A/C accumulator hose The A/C compressor The A/C compressor hose The engine wiring electrical harness The vacuum brake booster
3. Carefully lower the engine into the engine compartment.
4. Align the engine dowels to the transaxle cover. NOTE: Refer to «FASTENER NOTICE»(ref-175132-S17785009232005041500000) .
5. Install the 5 upper engine to transaxle mounting bolts. Tighten Tighten the engine to transaxle mounting bolts to 75 N.m (55 lb ft).
6. Remove the engine lift chain from the engine lift brackets.
7. Install the engine support fixture. Refer to «ENGINE SUPPORT FIXTURE»(ref-187842-S39672672042005090800000) .
8. Remove the support jack from under the transaxle.
9. Connect the heater hoses to the drive belt tensioner fittings.
10. Position the J 38185 to the clamp in order to connect the radiator outlet hose to the thermostat housing.
11. Position the J 38185 to the clamp in order to connect the radiator inlet hose to the water pump.
12. Fill the cooling system. Refer to DRAINING AND FILLING COOLING SYSTEM in Engine Cooling.
13. Raise and support the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(ref-187771-S24456970052005090800000) .
14. Install the right lower engine to transaxle mounting bolt (1). Tighten Tighten the engine to transaxle mounting bolt to 75 N.m (55 lb ft).
15. Install the right engine mount bracket. Refer to «ENGINE MOUNT BRACKET REPLACEMENT-RIGHT»(ref-187842-S07820206822005090800000) .
16. Position the power steering pump to the engine.
17. Loosely install the side power steering pump mounting bolt. Do not tighten at this time.
18. Lower the vehicle.
19. Install the 2 front power steering pump mounting bolts. Tighten Tighten the power steering pump mounting bolts to 27 N.m (20 lb ft).
20. Remove the engine support fixture. Refer to «ENGINE SUPPORT FIXTURE»(ref-187842-S39672672042005090800000) .
21. Install the air cleaner intake duct.
22. Install the generator. Refer to GENERATOR REPLACEMENT (L36) or GENERATOR REPLACEMENT (L67) in Engine Electrical.
23. Position the engine wiring electrical harness to the engine.
24. Connect the wiring harness electrical connectors to the following components on the right side of the engine: The fuel injectors The exhaust gas recirculation (EGR) valve The manifold absolute pressure (MAP) sensor The heated oxygen sensor (HO2S) The AIR solenoid, if equipped with NC8 The generator
25. Connect the wiring harness electrical connectors to the following components on the left side of the engine: The fuel injectors The ignition harness The boost control solenoid (L67 only) The engine coolant temperature (ECT) sensor The throttle position (TP) sensor The idle air control (IAC) valve The mass air flow (MAF) sensor
26. Install the bolt securing the PCM ground to the left front cylinder head. Tighten Tighten the PCM ground lead bolt to 50 N.m (37 lb ft).
27. Raise and support the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(ref-187771-S24456970052005090800000) .
28. Tighten the side power steering pump mounting bolt previously installed in step 14. Tighten Tighten the power steering pump mounting bolt to 27 N.m (20 lb ft).
29. Slide the A/C compressor rearward over the mounting studs.
30. Install the rear A/C compressor mounting bolt.
31. Install the front A/C compressor mounting nuts. Tighten Tighten the A/C compressor mounting fasteners to 50 N.m (37 lb ft).
32. Place a NEW exhaust manifold pipe gasket over the right exhaust manifold studs.
33. Position the exhaust manifold pipe to the right exhaust manifold.
34. Install the 2 nuts attaching the exhaust manifold pipe to the right exhaust manifold. Tighten Tighten the exhaust manifold pipe nuts to 40 N.m (30 lb ft).
35. Install the 2 bolts securing the transaxle brace to the transaxle. Tighten the 2 bolts previously installed in step 1. Tighten Tighten the transaxle brace bolts to 65 N.m (48 lb ft).
36. Connect the wiring harness electrical connectors to the following components The knock sensor #2, located behind the right exhaust manifold The oil pressure sensor (2) The vehicle speed sensor (VSS) (3)
37. Install the bolts securing the flywheel to the torque converter. Tighten Tighten the flywheel to torque converter bolts to 63 N.m (46 lb ft).
38. Install the starter motor. Refer to STARTER MOTOR REPLACEMENT in Engine Electrical.
39. Install the torque converter cover. Refer to «TORQUE CONVERTER COVER»(ref-154016-S03999798592003050100000) .
40. Connect the wiring harness to the harness clip at the rear of the A/C compressor.
41. Connect the wiring harness connectors to the following components: A/C compressor clutch (1) A/C pressure sensor (2) Knock sensor #1 (3) Engine coolant block heater (4) Oil level sensor (7)
42. Install the bolt in order to secure both the battery negative cable and the engine harness ground lead to the engine block. Tighten Tighten the battery negative cable to engine block bolt to 25 N.m (18 lb ft).
43. Install the right front fascia extension. Refer to FASCIA EXTENSION REPLACEMENT - FRONT in Bumpers.
44. Lower the vehicle.
45. Install the drive belt. Refer to «DRIVE BELT REPLACEMENT (L36)»(ref-187842-S09207139312005090800000) or «DRIVE BELT REPLACEMENT (L67)»(ref-187842-S41628165262005090800000) . CAUTION: In order to avoid possible injury or vehicle damage, always replace the accelerator control cable with a NEW cable whenever you remove the engine from the vehicle. In order to avoid cruise control cable damage, position the cable out of the way while you remove or install the engine. Do not pry or lean against the cruise control cable and do not kink the cable. You must replace a damaged cable.
46. Remove the accelerator control cable. Refer to CRUISE CONTROL CABLE REPLACEMENT in Cruise Control.
47. Position the cruise control module (1) to the mounting studs on the cowl. Install the 2 cruise control module bracket retaining nuts (2). Tighten Tighten the cruise control module bracket retaining nuts to 9 N.m (80 lb ft).
48. Connect the electrical connector to the cruise control module.
49. Install the cruise control cable to the throttle body lever.
50. Slide the cruise control cable fully into the throttle body bracket until it snaps into place.
51. Install the evaporative emission canister purge valve. Refer to «EVAP CANISTER PURGE SOLENOID»(ref-157368-S05644758262003090400000) .
52. Connect the fuel feed and return lines to the fuel rail. Refer to «FUEL LINE DISCONNECT FITTINGS»(ref-157368-S00115252352003081100000) .
53. Connect the vacuum brake booster hose to the vacuum connections.
54. Install the fuel injector sight shield. Refer to «FUEL INJECTOR SIGHT SHIELD REPLACEMENT (L36)»(ref-187842-S38668557822005090800000) or «FUEL INJECTOR SIGHT SHIELD REPLACEMENT (L67)»(ref-187842-S10477858142005090800000) .
55. Install the battery. Refer to BATTERY REPLACEMENT (TOP POST) in Engine Electrical.
56. Install the hood. Refer to HOOD REPLACEMENT in Body Front End.
57. Fill the engine oil. Refer to «ENGINE OIL AND OIL FILTER REPLACEMENT»(ref-187842-S14729902812005090800000) .
