Engine Mechanical Specifications — Buick Park Avenue II рестайлинг (2002-2005)

Engine Mechanical Specifications Buick Park Avenue II рестайлинг

Mechanical 9 illustrations ~133 words

Application		Specification
Application		Metric	English
General Data
	Engine Type	90 degrees V-6
	Displacement	3.8L	231 cu in
	RPO	L36, L67
	VIN	K, 1
	Bore	96.52 mm	3.8 in
	Stroke	86.36 mm	3.4 in
	Compression Ratio VIN K - 4 Compression Strokes	9.4:1
	Compression Ratio VIN 1 - 4 Compression Strokes	8.5:1
	Firing Order	1-6-5-4-3-2
	Spark Plug Gap	1.52 mm	0.60 in
Balance Shaft
	Bearing Bore Diameter - Front	51.973-51.999 mm	2.0462-2.0472 in
	Bearing Bore Diameter-Rear-In Block	47.584-47.612 mm	1.8735-1.8745 in
	Bearing Inside Diameter - Rear	38.117-38.194 mm	1.5007-1.5037 in
	Bearing Journal Diameter - Rear	38.072-38.105 mm	1.4989-1.5002 in
	Bearing Clearance - Rear	0.0127-0.1219 mm	0.0005-0.0048 in
	End Play	0.0-0.171 mm	0.0-0.0067 in
	Gear Lash	0.050-0.125 mm	0.002-0.0049 in
Block
	Balance Shaft Bearing Bore Diameter - Front	51.973-51.999 mm	2.0462-2.0472 in
	Balance Shaft Bearing Inside Diameter - Rear	38.118-38.194 mm	1.5007-1.5037 in
	Balance Shaft Bearing Bore Diameter - Rear, In Block	47.584-47.612 mm	1.8735-1.8745 in
	Camshaft Bearing Inside Diameter - Front and Rear	46.970-46.934 mm	1.8428-1.8492 in
	Camshaft Bearing Inside Diameter - Middle #2, #3	46.977-46.942 mm	1.8481-1.8495 in
	Crankshaft Main Bearing Bore Diameter	68.249-68.270 mm	2.6870-2.6878 in
	Cylinder Bore Diameter	98.5 mm	3.8 in
	Cylinder Bore Out-of-Round - Diametral	0.0254 mm	0.001 in
	Cylinder Bore Taper	0.0254 mm	0.001 in
	Cylinder Head Deck Height	216.459 mm	8.522 in
	Cylinder Head Deck Surface Flatness - Overall	0.0762 mm	0.003 in
	Valve Lifter Bore Diameter	21.424-21.450 mm	0.8435-0.8445 in
Camshaft
	Camshaft Bearing Inside Diameter - 1 and 4	46.970-46.934 mm	1.8478-1.8492 in
	Camshaft Bearing Inside Diameter 2 and 3	46.977-46.942 mm	1.8481-1.8495 in
	Camshaft Journal Diameter	47.655-46.858 mm	1.8462-1.8448 in
	Camshaft Journal Out-of-Round	0.00635 mm	0.00025 in
	Camshaft Journal to Bearing Clearance	0.041-0.119 mm	0.0016-0.0047 in
	Camshaft Lobe Duration - Exhaust	330 Crankshaft degrees
	Camshaft Lobe Duration - Intake	320 Crankshaft degrees
	Camshaft Lobe Lift - Exhaust	6.56 mm	0.258 in
	Camshaft Lobe Lift - Intake	6.56 mm	0.258 in
	Camshaft Lobe Overlap	96 Crankshaft degrees
Connecting Rod
	Connecting Rod Bearing Clearance	0.0127-0.0660 mm	0.0005-0.0026 in
	Connecting Rod Bore Diameter	60.295-60.312 mm	2.37378-2.3745 in
	Connecting Rod Length - Center to Center - S/C	143.205-143.307 mm	5.638-5.642 in
	Connecting Rod Length - Center to Center - Non S/C	145.796-145.898 mm	5.740-5.744 in
	Connecting Rod Side Clearance	0.102-0.508 mm	0.004-0.0200 in
Crankshaft
	Connecting Rod Journal Diameter	57.1170-57.1475 mm	2.2487-2.2499 in
	Connecting Rod Journal Out-of-Round	0.00508 mm	0.00020 in
	Connecting Rod Journal Taper	0.00889 mm	0.00035 in
	Crankshaft End Play	0.076-0.276 mm	0.003-0.011 in
	Crankshaft Main Bearing Clearance - #1	0.0178-0.0406 mm	0.0007-0.0016 in
	Crankshaft Main Bearing Clearance - #2, 3 and 4	0.0229-0.0457 mm	0.0009-0.0018 in
	Crankshaft Main Journal Diameter	63.470-63.495 mm	2.4988-2.4998 in
	Crankshaft Main Journal Out-of-Round	0.00635 mm	0.00025 in
	Crankshaft Main Journal Taper	0.00889 mm	0.00035 in
	Crankshaft Rear Flange Runout	0.05 mm	0.002 in
	Crankshaft Runout - from Main 2 & 3 to 1 & 4	0.076 mm	0.003 in
Cylinder Head
	Combustion Chamber Depth - at Measurement Point	3.9166-5.4356 mm	0.154-0.214 in
	Cylinder Head Height/Thickness	103.492-104.178 mm	4.0745-4.1015 in
	Surface Finish	0.0032 mm	0.000125 in
	Surface Flatness - Block Deck	0.1016 mm	0.004 in
	Surface Flatness - Exhaust Manifold Deck	0.1016 mm	0.004 in
	Surface Flatness - Intake Manifold Deck	0.1016 mm	0.004 in
	Valve Guide Bore - Exhaust	8.001-8.0213 mm	0.3150-0.3158 in
	Valve Guide Bore - Intake	8.001-8.0213 mm	0.3150-0.3158 in
Exhaust Manifold
	Surface Flatness	0.5 mm	0.02 in
Lubrication System
	Oil Capacity - with Filter	4.3L	4.5 qts
	Oil Capacity - without Filter	3.76L	4 qts
	Oil Pressure --1850 RPM	414 kPa	60 psi
Oil Pump
	Gear Pocket - Depth	11.71-11.75 mm	0.461-0.4625 in
	Gear Pocket - Diameter	89.10-89.20 mm	3.508-3.512 in
	Inner Gear Tip Clearance	0.152 mm	0.006 in
	Relief Valve-to-Bore Clearance	0.038-0.076 mm	0.0015-0.003 in
Piston Ring End Gap
	First Compression Ring	0.25-0.46 mm	0.010-0.018 in
	Second Compression Ring	0.58-0.84 mm	0.023-0.033 in
	Oil Control Ring	0.254-0.762 mm	0.010-0.030 in
Piston Ring to Groove Clearance
	First Compression Ring	0.033-0.079 mm	0.0013-0.0031 in
	Second Compression Ring	0.033-0.079 mm	0.0013-0.0031 in
	Oil Control Ring	0.023-0.201 mm	0.0009-0.0079 in
Piston Ring Thickness
	First Compression Ring	1.176-1.197 mm	0.0463-0.0471 in
	Second Compression Ring	1.1476-1.497 mm	0.0581-0.0589 in
	Oil Control Ring	1.854-2.007 mm	0.073-0.079 in
Pistons and Pins - Piston
	Piston Diameter - Production - S/C	96.489-96.528 mm	3.7988-3.8003 in
	Piston Diameter - Production - Non S/C	96.482-96.497 mm	3.7985-3.7991 in
	Piston Diameter - Service Limit - Minimum - S/C	96.434 mm	3.7966 in
	Piston Diameter - Service Limit - Minimum - Non S/C	96.442 mm	3.7969 in
	Piston Pin Bore Diameter - S/C	23.0065-23.0105 mm	0.9058-0.9059 in
	Piston Pin Bore Diameter - Non S/C	22.0060-22.0110 mm	0.8664-0.8666 in
	Piston to Bore Clearance - New - VIN K	0.010-0.051 mm	0.0004-0.0020 in
	Piston to Bore Clearance - Used - VIN K	0.050-0.091 mm	0.0020-0.0036 in
	Piston to Bore Clearance - New - VIN 1	0.0207-0.0437 mm	0.0008-0.0018 in
	Piston to Bore Clearance - Used VIN 1	0.0193-0.0997 mm	0.0008-0.0039 in
Pistons and Pins - Pin
	Piston Pin Clearance to Connecting Rod Bore - Press Fit - VIN K	0.0066-0.0217 mm	0.0003-0.0009 in
	Piston Pin Clearance to Piston Pin Bore - VIN K	0.0020-0.0130 mm	0.00008-0.00051 in
	Piston Pin Diameter - VIN K	21.9950-22.000 mm	0.8659-0.8661 in
	Piston Pin Clearance to Connecting Rod Bore - Press Fit - VIN 1	0.0073-0.0225 mm	0.00029-0.00089 in
	Piston Pin Clearance to Piston Pin Bore - VIN 1	0.0065-0.0155 mm	0.00061-0.00026 in
	Piston Pin Diameter - VIN 1	22.995-23.000 mm	0.90531-0.90551 in
Valves
	Valve Face Angle	46 degrees
	Valve Face Runout	0.0508 mm	0.002 in
	Valve Head Diameter - Intake	46.37-46.63 mm	1.826-1.836 in
	Valve Head Diameter - Exhaust	38.481-38.735 mm	1.515-1.525 in
	Valve Length	119.464-119.972 mm	4.7033-4.7233 in
	Valve Seat Angle	45 degrees
	Valve Seat Runout	0.050 mm	0.002 in
	Valve Seat Width - Intake	1.53-2.03 mm	0.060-0.080-in
	Valve Seat Width - Exhaust	2.29-2.79 mm	0.090-0.110 in
	Valve Stem Diameter	7.948-7.965 mm	0.3129-0.3136 in
	Valve Stem-to-Guide Clearance - Intake	0.031-0.071 mm	0.0012-0.0028 in
	Valve Stem-to-Guide Clearance - Exhaust	0.036-0.074 mm	0.0014-0.0029 in
Valve Lifters/Push Rods
	Push Rod Length - Intake, Yellow	178.13 mm	7.013 in
	Push Rod Length - Exhaust, Green	178.13 mm	7.013 in
	Valve Lifter Diameter	21.387-21.405 mm	0.842-0.843 in
Valve Rocker Arms
	Valve Rocker Arm Ratio	1.66:1
Valve Springs
	Valve Spring Free Length	49.78 mm	1.960 in
	Valve Spring Installed Height	42.93-44.45 mm	1.690-1.750 in
	Valve Spring Load - Closed	334 N 43.69 mm	75 lb 1.72 in
	Valve Spring Load - Open	1014 N 32.4 mm	228 lb 1.277 in
	Valve Spring Total Munber of Coils	6.6

ENGINE MECHANICAL SPECIFICATIONS

Scheme 1

Scheme 1: Sealers, Adhesives, and Lubricants

Scheme 2

Scheme 2: Disassembled Views

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 8: Engine Identification

The primary Vehicle Identification Number-VIN derivative for the 3800-L36 and 3800-L67 is stamped or laser etched on the left side of the engine block above the starter motor (1).

Scheme 9

The secondary Vehicle Identification Number-VIN, derivative for the 3800-L36 and 3800-L67 is stamped or laser etched below the water pump on the engine block (1). The Vehicle Identification Number-derivative is nine digits long and can be used to determine if a vehicle contains the original engine.

The first digit identifies the division.
The second digit identifies the model year.
The third digit identifies the assembly plant.
The fourth through ninth digit are the last six of the Vehicle Identification Number-VIN.
