Engine Flywheel Replacement Buick Park Avenue II рестайлинг

Tools Required

1. J 8001 Dial Indicator Set
2. J 36660-A Torque Angle Meter

Scheme 181

1. Remove the transaxle. Refer to «TRANSAXLE»(ref-154016-S24574111862003050100000) .
2. Remove the eight bolts attaching the flywheel to the crankshaft flange. Discard the bolts.
3. Remove the flywheel.
4. Inspect the crankshaft mating surfaces for burrs.
5. Clean and inspect the engine flywheel. Refer to «ENGINE FLYWHEEL CLEANING AND INSPECTION»(ref-187842-S09991901412005090800000) .

Scheme 182

1. Install the flywheel. NOTE: Refer to «FASTENER NOTICE»(ref-175132-S17785009232005041500000) .
2. Install the flywheel bolts. Tighten Tighten the new flywheel bolts to 15 N.m (11 lb ft). Use the J 36660-A in order to tighten the bolts an additional 50 degrees.
3. Install the J 8001 to the engine block.
4. Check the flywheel runout at the three attaching bosses. Ensure that the crankshaft end-play is held in one direction when checking flywheel runout. Flywheel runout should not exceed 0.381 mm (0.015 in).
5. If flywheel runout is out of specification, tap on the high side with a mallet in order to correct runout.
6. Replace the flywheel if runout cannot be corrected.
7. Install the transaxle. Refer to «TRANSAXLE»(ref-154016-S24574111862003050100000) .
