Engine Front Cover Installation Buick Park Avenue II рестайлинг

Tools Required

J 36660-A Torque Angle Meter

Scheme 408

Scheme 409

Scheme 410

Scheme 411

1. Install the engine front cover gasket.
2. Install the engine front cover. Align the cogs on the crankshaft sprocket with the cogs on the oil pump in the engine front cover.
3. Apply sealant GM P/N 12346004
4. (Canadian P/N 10953480) or the equivalent to the engine front cover bolt threads. NOTE: Refer to «FASTENER NOTICE»(ref-175132-S17785009232005041500000) .
5. Install the engine front cover bolts. Tighten Tighten the engine front cover bolts to 20 N.m (15 lb ft). Use the J 36660-A to tighten the engine front cover bolts an additional 40 degrees.
6. Install the oil pan to engine front cover bolts. Tighten Tighten the oil pan bolts to 14 N.m (125 lb in).
7. Install the oil filter. Tighten Tighten the oil filter to 30 N.m (22 lb ft).
8. Install the crankshaft position sensor. Tighten Tighten the crankshaft position sensor studs to 30 N.m (22 lb ft).
9. Install the crankshaft position sensor shield.
