Engine Block Plug Installation Buick Park Avenue II рестайлинг

Note. Refer to FASTENER NOTICE .

Scheme 381

Scheme 382

Scheme 383

1. Install the threaded oil gallery plugs. Tighten Tighten the oil gallery plugs to 30 N.m (22 lb ft).
2. Install the remaining oil gallery plugs using GM P/N 12346004 (Canadian P/N 10953480) or the equivalent.
3. Apply sealant GM P/N 12346004
4. (Canadian P/N 10953480) or the equivalent to the threads of the knock sensor. NOTE: Refer to «FASTENER NOTICE»(ref-175132-S17785009232005041500000) .
5. Install the knock sensors. Tighten Tighten the knock sensors to 18 N.m (13 lb ft).
6. Install the knock sensor heat shield and bolts, if applicable. Tighten Tighten the knock sensor heat shield bolts to 50 N.m (37 lb ft).
