Removal Procedure Buick Century VI

Mechanical 4 illustrations ~360 words

Note. The inertial weight section of the crankshaft balancer is assembled to the hub with a rubber type material. The correct installation procedures (with the proper tool) must be followed or movement of the inertial weight section of the hub will destroy the tuning of the crankshaft balancer.

Scheme 135

Scheme 135: Removal Procedure

Scheme 136

Scheme 136
  1. Remove the drive belt. Refer to «DRIVE BELT REPLACEMENT»(ref-189348-S04700214262005090900000) .
  2. Raise and support the vehicle. Refer to «LIFTING AND JACKING THE VEHICLE»(ref-189331-S23727654502005090900000) in General Information.
  3. Remove the right front tire and wheel. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION in Tires and Wheels.
  4. Remove the right engine splash shield. Refer to SPLASH SHIELD REPLACEMENT - ENGINE in Body Front End.
  5. Install the jack stands to the frame.
  6. Loosen the left frame bolts and remove the right side frame bolts.
  7. Using the jack stands, lower the right side of the frame to access the crankshaft balancer.
  8. Remove the torque converter covers.
  9. Install the J 37096 to the flywheel to prevent flywheel rotation.
  10. Remove the crankshaft balancer bolt and the washer.
  11. Remove the crankshaft balancer. Use the J 24420-C.

Scheme 137

Scheme 137: Installation Procedure

Scheme 138

Scheme 138
  1. Apply sealant GM P/N 12346286 (Canadian P/N 10953472) or the equivalent to the keyway of the balancer.
  2. Install the crankshaft balancer. Use the J 29113
  3. Remove the J 29113.
  4. Install the J 37096 to the flywheel to prevent flywheel rotation. NOTE: Refer to «FASTENER NOTICE»(ref-175132-S17785009232005041500000) in Cautions and Notices.
  5. Install the crankshaft balancer washer and the bolt. Tighten 5.1. Tighten the bolt to 70 N.m (52 lb ft). 5.2. Use the J 36660-A to rotate the crankshaft balancer bolt an additional 72 degrees.
  6. Remove the J 37096 from the flywheel.
  7. Install the torque converter covers.
  8. Raise the frame to the original position.
  9. Install and tighten the frame bolts.
  10. Install the right engine splash shield. Refer to SPLASH SHIELD REPLACEMENT - ENGINE in Body Front End.
  11. Install the right front tire and wheel. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION in Tires and Wheels.
  12. Lower the vehicle.
  13. Install the drive belt. Refer to «DRIVE BELT REPLACEMENT»(ref-189348-S04700214262005090900000) .
  14. Perform a CKP system variation learn procedure. Refer to «CKP SYSTEM VARIATION LEARN PROCEDURE»(ref-156775-S20850332652003072900000) in Self-Diagnostics -3.1L.
