Engine Mechanical Specifications Buick Century VI

Mechanical 6 illustrations ~106 words
ApplicationSpecification
MetricEnglish
General Data
Engine Type60° V-6
Displacement3.1L191 cu in
RPOLG8
VINJ
Bore89 mm3.50 in
Stroke84 mm3.31 in
Compression Ratio9.6:1
Firing Order1-2-3-4-5-6
Spark Plug Gap1.52 mm0.60 in
Block
Camshaft Bearing Bore Diameter - ID47.516-47.541 mm1.871-1.872 in
Camshaft Bearing Bore Diameter - Front and Rear51.03-51.08 mm2.009-2.011 in
Camshaft Bearing Bore Diameter - Middle #2, #350.77-50.82 mm1.999-2.001 in
Crankshaft Main Bearing Bore Diameter72.1535-72.1695 mm2.8407-2.8413 in
Crankshaft Main Bearing Bore Out-of-Round0.008 mm0.0003 in
Cylinder Bore Diameter - Production89.016-89.034 mm3.5046-3.5053 in
Cylinder Bore Diameter - Service89.016-89.042 mm3.5046-3.5056 in
Cylinder Bore Out-of-Round - Diametral - Production0.020 mm0.0008 in
Cylinder Bore Out-of-Round - Diametral - Service0.025 mm0.001 in
Cylinder Bore Taper - Production0.020 mm0.0008 in
Cylinder Bore Taper - Service0.025 mm0.001 in
Cylinder Head Deck Height224 mm8.819 in
Cylinder Head Deck Surface Flatness0.05 mm per 152 mm0.002 in per 6 in
Valve Lifter Bore Diameter21.417-21.455 mm0.843-0.845 in
Camshaft
Camshaft Bearing Inside Diameter47.516-47.541 mm1.871-1.872 in
Camshaft Journal Diameter47.443-47.468 mm1.868-1.869 in
Camshaft Journal Out-of-Round0.003 mm0.00012 in
Camshaft Journal to Bearing Clearance0.048-0.098 mm0.002-0.004 in
Camshaft Lobe Lift - Exhaust6.9263 mm0.2727 in
Camshaft Lobe Lift - Intake6.9263 mm0.2727 in
Camshaft Runout0.050 mm0.002 in
Cooling System
Capacity @ Engine RPM12.4 liters13.1 quarts
Thermostat Full Open Temperature195 degrees
Connecting Rod
Connecting Rod Bearing Clearance0.18-0.062 mm0.0007-0.017 in
Connecting Rod Bore Diameter53.962-53.978 mm2.124-2.125 in
Connecting Rod Bore Out-of-Round0.008 mm0.00031 in
Connecting Rod Length - Center to Center144.75-144.81 mm5.69-5.70 in
Connecting Rod Side Clearance0.25-0.37 mm0.010-0.015 in
Crankshaft
Connecting Rod Journal Diameter50.768-50.784 mm1.9987-1.9994 in
Connecting Rod Journal Out-of-Round0.005 mm0.0002 in
Connecting Rod Journal Taper0.005 mm0.0002 in
Connecting Rod Journal Width21.92-22.08 mm8.62-8.69 in
Crankshaft End Play0.060-0.210 mm0.0024-0.0083 in
Crankshaft Main Bearing Journal Width - #129.5 mm1.161 in
Crankshaft Main Bearing Journal Width - #224.0 mm0.945 in
Crankshaft Main Bearing Jounal Width - #324.04 mm0.946 in
Crankshaft Main Bearing Journal Width - #435.8 mm1.409 in
Crankshaft Main Bearing Clearance - Except #30.019-0.064 mm0.0008-0.0025 in
Crankshaft Main Bearing Clearance - #3 Thrust Bearing0.032-0.077 mm0.0012-0.0030 in
Crankshaft Main Journal Diameter67.239-67.257 mm2.6473-2.6483 in
Crankshaft Main Journal Out-of-Round0.005 mm0.0002 in
Crankshaft Main Journal Taper0.005 mm0.0002 in
Crankshaft Rear Flange Runout0.04 mm0.0016 in
Crankshaft Reluctor Ring Runout - Max0.34 mm0.0134 in
Crankshaft Runout0.025 mm0.0010 in
Cylinder Head
Combustion Chamber Depth - at Measurement Point2.2 mm0.087 in
Surface Finish - Maximum2.8 RA
Surface Flatness - Block Deck0.08 mm per 152 mm0.003 in per 6 in
Surface Flatness - Exhaust Manifold Deck0.1 mm0.004 in
Surface Flatness - Intake Manifold Deck0.1 mm0.004 in
Valve Guide Bore - Exhaust8.01 mm0.315 in
Valve Guide Bore - Intake8.01 mm0.315 in
Valve Guide Installed Height16.6 mm0.654 in
Lubrication System
Oil Capacity - with Filter4.3 liters4.5 quarts
Oil Capacity - without Filter3.8 liters4.0 quarts
Oil Pressure - @ 1850 RPM414 kPa60 psi
Oil Pump
Gear Diameter38.05-38.10 mm1.498-1.500 in
Gear Pocket - Depth30.52-30.58 mm1.202-1.204 in
Gear Pocket - Diameter38.176-38.226 mm1.503-1.505 in
Gears Lash0.094-0.195 mm0.0037-0.0077 in
Relief Valve-to-Bore Clearance0.038-0.089 mm0.0015-0.0035 in
Piston Ring End Gap
First Compression Ring0.15-0.36 mm0.006-0.014 in
Second Compression Ring0.5-0.71 mm0.0197-0.0280 in
Oil Control Ring0.25-1.02 mm0.009-0.040 in
Piston Ring to Groove Clearance
First Compression Ring0.04-0.086 mm0.002-0.0033 in
Second Compression Ring0.04-0.08 mm0.002-0.0035 in
Oil Control Ring0.07-0.095 mm0.0028-0.0037 in
Piston Ring Thickness
First Compression Ring1.164-1.190 mm0.046-0.047 in
Second Compression Ring1.470-1.490 mm0.057-0.058 in
Oil Control Ring - Maximum2.960 mm0.116 in
Pistons
Piston Diameter - New88.986-89.024 mm3.503-3.504 in
Piston Ring Groove Width - Top1.23-1.25 mm0.048-0.049 in
Piston Ring Groove Width - Second1.53-1.55 mm0.060-0.061 in
Piston Ring Groove Width - Third3.03-3.05 mm0.119-0.120 in
Piston to Bore Clearance0.008--0.048 mm0.0003--0.0018 in
Rocker Arms
Valve Rocker Arm Ratio1.6:1
Valves
Valve Face Angle45 degrees
Valve Face Runout0.050 mm0.002 in
Valve Seat Angle46 degrees
Valve Seat Depth - Intake7.9-8.1 mm0.311-0.318 in
Valve Seat Depth - Exhaust8.9-9.1 mm0.350-0.358 in
Valve Seat Runout0.037 mm0.0015 in
Valve Seat Width - Intake1.55-1.80 mm0.061-0.071 in
Valve Seat Width - Exhaust1.70-2.0 mm0.067-0.079 in
Valve Stem-to-Guide Clearance0.026-0.068 mm0.0010-0.0027 in
Valve Stem Diameter - Intake7.967-7.980 mm0.3137-0.3142 in
Valve Stem Diameter7.944-7.965 mm0.3128-0.3136 in
Valve Lifters/Push Rods
Push Rod Length - Intake146.0 mm5.75 in
Push Rod Length - Exhaust152.5 mm6.0 in
Valve Lifter Diameter21.387-21.405 mm0.8420-0.3136 in
Valve Lifter-to-Bore Clearance0.012-0.068 mm0.0005-0.0027 in
Valve Springs
Valve Spring Free Length48.5 mm1.89 in
Valve Spring Installed Height43.2 mm1.701 in
Valve Spring Load - Closed320 N @ 43.2 mm75 lb @ 1.701 in
Valve Spring Load - Open1036 N @ 32 mm230 lb @ 1.260 in
Valve Spring Total Number of Coils6.55

Engine Mechanical Specifications

Scheme 1

Scheme 1: Sealers, Adhesives, and Lubricants

Scheme 2

Scheme 2: Disassembled Views

Scheme 3

Scheme 3

Scheme 4

Scheme 4

Scheme 5

Scheme 5

Scheme 6

Scheme 6: Engine Identification

The Vehicle Identification Number - VIN derivative (1) for 3100 LG8 and 3400 LA1 is stamped or laser etched on the left side rear of the engine block. The Vehicle Identification Number - VIN derivative is nine digits long and can be used to determine if a vehicle contains the original engine.

  1. The first digit identifies the division.
  2. The second digit identifies the model year.
  3. The third digit identifies the assembly plant.
  4. The fourth through ninth digits are the last six digits of the Vehicle Identification Number -VIN.
