ON-VEHICLE INSPECTION

1. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Inspect the oil control valve (for intake camshaft). Enter the following menus: Powertrain / Engine / Active Test / Control the VVT System (Bank 1). Check the engine speed when the oil control valve is operated using the Techstream with the engine coolant temperature at 50°C (122°F) or less. HINT: When performing the Active Test, the air conditioning should be on. Engine coolant temperature when the engine is started should be 30°C (86°F) or less. OK Control Range Specified Condition OFF Normal engine speed ON Rough idle or engine stalls (soon after oil control valve switched from OFF to ON) If the operation is not as specified, check the oil control valve, wire harness and ECM. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT System (Bank 2). Check the engine speed when the oil control valve is operated using the Techstream with the engine coolant temperature at 50°C (122°F) or less. HINT: When performing the Active Test, the air conditioning should be on. Engine coolant temperature when the engine is started should be 30°C (86°F) or less. OK Control Range Specified Condition OFF Normal engine speed ON Rough idle or engine stalls (soon after oil control valve switched from OFF to ON) If the operation is not as specified, check the oil control valve, wire harness and ECM. Inspect the oil control valve (for exhaust camshaft). Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Exhaust Linear (Bank 1). Check the engine speed when the oil control valve is operated using the Techstream with the engine coolant temperature at 50°C (122°F) or less. HINT: When performing the Active Test, the air conditioning should be on. Engine coolant temperature when the engine is started should be 30°C (86°F) or less. OK Control Range Specified Condition -100% Normal engine speed 100% Rough idle or engine stalls (soon after oil control valve switched to 100%) If the operation is not as specified, check the oil control valve, wire harness and ECM. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Exhaust Linear (Bank 2). Check the engine speed when the oil control valve is operated using the Techstream with the engine coolant temperature at 50°C (122°F) or less. HINT: When performing the Active Test, the air conditioning should be on. Engine coolant temperature when the engine is started should be 30°C (86°F) or less. OK Control Range Specified Condition -100% Normal engine speed 100% Rough idle or engine stalls (soon after oil control valve switched to 100%) If the operation is not as specified, check the oil control valve, wire harness and ECM.

Scheme 137

Scheme 138

Scheme 139

Scheme 140

Scheme 141

1. REMOVE INTAKE AIR SURGE TANK ASSEMBLY Refer to «REMOVAL»(ref-494152-S35940360142012081000000)
2. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Intake Side of Bank 1) Disconnect the oil control valve connector. Remove the bolt and oil control valve. Remove the O-ring from the oil control valve.
3. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Intake Side of Bank 2) Disengage the 2 clamps. Disconnect the oil control valve connector. Remove the bolt and oil control valve. Remove the O-ring from the oil control valve.
4. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Exhaust Side of Bank 1) Disengage the wire harness clamp. Disconnect the oil control valve connector. Remove the bolt and oil control valve. Remove the O-ring from the oil control valve.
5. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Exhaust Side of Bank 2) Disconnect the oil control valve connector. Remove the bolt and oil control valve. Remove the O-ring from the oil control valve.

Scheme 142

Scheme 143

1. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Measure the resistance according to the value(s) in the table below. TEXT IN ILLUSTRATION *a Component without harness connected (Camshaft Timing Oil Control Valve Assembly) Standard Resistance Tester Connection Condition Specified Condition 1 (+B) - 2 (GND) 20°C (68°F) 6.9 to 7.9 ohms If the result is not as specified, replace the oil control valve. Check the operation. TEXT IN ILLUSTRATION *1 Spool Valve *2 Battery *a Component without harness connected (Camshaft Timing Oil Control Valve Assembly) Connect a battery positive (+) lead to terminal 1 and negative (-) lead to terminal 2, and check the movement of the spool valve. OK Tester Connection Condition Specified Condition 1 - 2 Battery positive (+) voltage is applied Valve moves in direction of left arrow shown in the illustration Battery positive (+) voltage is cut off Valve moves in direction of right arrow shown in the illustration If the result is not as specified, replace the oil control valve. NOTE: Accumulation of foreign matter can cause minor pressure leaks. Minor pressure leaks in the intake side oil control valve will cause the intake camshaft to advance. Minor pressure leaks in the exhaust side oil control valve will cause the exhaust camshaft to retard. The inappropriate camshaft timing that results from these leaks will cause a DTC to be set.

Scheme 144

1. INSTALL CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Intake Side of Bank 1) Apply a light coat of engine oil to a new O-ring and install it to the oil control valve. TEXT IN ILLUSTRATION *a New O-Ring Install the oil control valve with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: Do not allow foreign matter to contact the oil seal face of the oil control valve (connecting surface with cylinder head). Be careful that the O-ring is not cracked when installing the oil control valve. Connect the camshaft timing oil control valve connector.
2. INSTALL CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Intake Side of Bank 2) Apply a light coat of engine oil to a new O-ring and install it to the oil control valve. TEXT IN ILLUSTRATION *a New O-Ring Install the oil control valve with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: Do not allow foreign matter to contact the oil seal face of the oil control valve (connecting surface with cylinder head). Be careful that the O-ring is not cracked when installing the oil control valve. Connect the oil control valve connector. Engage the 2 clamps.
3. INSTALL CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Exhaust Side of Bank 1) Apply a light coat of engine oil to a new O-ring and install it to the oil control valve. TEXT IN ILLUSTRATION *a New O-Ring Install the oil control valve with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: Do not allow foreign matter to contact the oil seal face of the oil control valve (connecting surface with cylinder head). Be careful that the O-ring is not cracked when installing the oil control valve. Connect the oil control valve connector. Engage the wire harness clamp.
4. INSTALL CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (for Exhaust Side of Bank 2) Apply a light coat of engine oil to a new O-ring and install it to the oil control valve. TEXT IN ILLUSTRATION *a New O-Ring Install the oil control valve with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) NOTE: Do not allow foreign matter to contact the oil seal face of the oil control valve (connecting surface with cylinder head). Be careful that the O-ring is not cracked when installing the oil control valve. Connect the oil control valve connector.
5. INSTALL INTAKE AIR SURGE TANK ASSEMBLY Refer to «INSTALLATION»(ref-494152-S30012053282012081000000)
6. ADD ENGINE COOLANT . Refer to «REPLACEMENT - Step 4»(ref-494109-S04675173472012081000000)
7. INSPECT FOR COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-494155-S35188277742012081000000)
8. INSPECT FOR OIL LEAK Start the engine, and check that there are no oil leaks.

Scheme 145

Scheme 146

1. INSPECT THROTTLE WITH MOTOR BODY ASSEMBLY Check the throttle control motor operating sound. Turn the ignition switch to ON. When depressing the accelerator pedal, check the operating sound of the motor. Make sure that no friction noises are from the motor. If friction noise exists, replace the throttle with motor body assembly. Check the throttle position sensor. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Throttle Sensor Position. Depress the accelerator pedal. When the throttle valve is fully open, check that the Throttle Sensor Position value is within the specification. Standard Throttle Valve Opening Percentage Tester Display Specified Condition Throttle Sensor Position 60% or more NOTE: When checking the throttle valve opening percentage, the shift lever should be in neutral. Fully depress the accelerator pedal. If the percentage is less than 60%, replace the throttle with motor body assembly.

Scheme 147

Scheme 148

Scheme 149

Scheme 150

Scheme 151

Scheme 152

Scheme 153

Scheme 154

Scheme 155

Scheme 156

Scheme 157

1. REMOVE WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Refer to «REMOVAL»(ref-494141-S07171082372012081000000)
2. REMOVE FRONT OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «REMOVAL - Step 10»(ref-494142-S07546098752012081000000)
3. REMOVE V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 24»(ref-494105-S25363989382012081000000)
4. REMOVE NO. 1 ENGINE UNDER COVER . Refer to «REMOVAL - Step 4»(ref-494152-S23880985802012081000000)
5. DRAIN ENGINE COOLANT . Refer to «REPLACEMENT - Step 3»(ref-494109-S04675173472012081000000)
6. REMOVE AIR CLEANER INLET COVER ASSEMBLY SEAL Disengage the 3 vacuum hose clamps. Remove the 2 bolts and the air cleaner inlet cover assembly seal.
7. REMOVE AIR CLEANER AND HOSE Disconnect the mass air flow meter connector. Disengage the wire harness clamp. Disconnect the vacuum hose. Separate the vacuum hose from the hose clamp. Disconnect the vacuum switching valve connector. Disengage the 2 wire harness clamps. Disconnect the 2 vacuum hoses. Loosen the clip and disconnect the No. 2 ventilation hose. Separate the fuel vapor feed hose from the hose clamp. Loosen the hose clamp and disconnect the air cleaner hose. Remove the 2 bolts and the air cleaner assembly.
8. DISCONNECT WATER BY-PASS HOSE Loosen the clip and disconnect the water bypass hose.
9. DISCONNECT NO. 2 WATER BY-PASS HOSE Loosen the clip and disconnect the No. 2 water bypass hose.
10. REMOVE THROTTLE WITH MOTOR BODY ASSEMBLY Disconnect the throttle body connector and the wire harness clamp. Remove the 4 bolts, wire harness clamp stay and the throttle body. Remove the gasket from the intake air surge tank assembly.

Scheme 158

1. INSPECT THROTTLE WITH MOTOR BODY ASSEMBLY Measure the resistance according to the value(s) in the table below. TEXT IN ILLUSTRATION *a Component without harness connected (Throttle with Motor Body Assembly) Standard Resistance Tester Connection Condition Specified Condition 1 (M-) - 2 (M+) 20°C (68°F) 0.3 to 100 ohms If the result is not as specified, replace the throttle with motor body assembly.

Scheme 159

Scheme 160

Scheme 161

Scheme 162

Scheme 163

Scheme 164

1. INSTALL THROTTLE WITH MOTOR BODY ASSEMBLY Install a new gasket to the intake air surge tank assembly. TEXT IN ILLUSTRATION *a Recess *b Protrusion *c New Gasket Install the throttle body and wire harness clamp stay to the intake air surge tank assembly with the 4 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Connect the throttle body connector and wire harness clamp.
2. INSTALL NO. 2 WATER BY-PASS HOSE Connect the No. 2 water bypass hose with the clip. TEXT IN ILLUSTRATION *a View A *b Top HINT: Connect the hose so that the direction of the hose clip is as indicated in the illustration.
3. INSTALL WATER BY-PASS HOSE Connect the water bypass hose with the clip. TEXT IN ILLUSTRATION *a View A *b Top HINT: Connect the hose so that the direction of the hose clip is as indicated in the illustration.
4. INSTALL AIR CLEANER AND HOSE Insert the tab of the air cleaner assembly to the hole of the vehicle body as shown in the illustration. TEXT IN ILLUSTRATION *a Tab *b Hole Install the air cleaner assembly with the 2 bolts. Torque: 5.0 N*m (51 kgf*cm, 44 in.*lbf) Connect the air cleaner hose to the throttle body with the hose clamp. TEXT IN ILLUSTRATION *a Protrusion *b Groove *c Upper HINT: Connect the hose so that the direction of the hose clip is as indicated in the illustration. Install the fuel vapor feed hose to the hose clamp. Connect the No. 2 ventilation hose with the clip. TEXT IN ILLUSTRATION *a RH *b Upper HINT: Connect the hose so that the direction of the hose clip is as indicated in the illustration. Connect the 2 vacuum hoses. Engage the 2 wire harness clamps. Connect the vacuum switching valve connector. Install the vacuum hose to the hose clamp. Connect the vacuum hose to the intake air surge tank assembly. Engage the wire harness clamp. Connect the mass air flow meter connector.
5. INSTALL AIR CLEANER INLET COVER ASSEMBLY SEAL Install the air cleaner inlet cover assembly seal with the 2 bolts. Torque: 6.0 N*m (61 kgf*cm, 53 in.*lbf) Engage the 3 vacuum hose clamps to the air cleaner inlet cover assembly seal.
6. ADD ENGINE COOLANT . Refer to «REPLACEMENT - Step 4»(ref-494109-S04675173472012081000000)
7. INSPECT FOR COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-494155-S35188277742012081000000)
8. INSTALL NO. 1 ENGINE UNDER COVER . Refer to «INSTALLATION - Step 16»(ref-494152-S30385650972012081000000)
9. INSTALL V-BANK COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 24»(ref-494105-S25363989382012081000000)
10. INSTALL FRONT OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «INSTALLATION - Step 12»(ref-494142-S39362593912012081000000)
11. INSTALL WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Refer to «INSTALLATION - Step 2»(ref-494141-S24285663502012081000000)
12. PERFORM INITIALIZATION NOTE: Be sure to perform this procedure after reassembling the throttle body or removing and reinstalling any throttle body component. Perform the following procedure after replacing the ECM, throttle body assembly or any throttle body components. The following procedure should also be performed if the throttle body is cleaned. Be sure to perform this procedure after replacing the ECM and reconnecting the battery cable. Disconnect the cable from the negative (-) battery terminal. Wait at least 60 seconds and reconnect the cable. Turn the ignition switch to ON without operating the accelerator pedal. NOTE: If the accelerator pedal is operated, perform the above steps again. Connect the Techstream to the DLC3 and clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . Start the engine and check that the MIL is not illuminated and that the idle speed is within the specified range when the A/C is switched off after the engine is warmed up. Standard Condition Engine Idle Speed A/C switched off 600 to 700 RPM NOTE: Be sure to perform this step with all accessories off. Make sure that the shift lever is in neutral. Enter the following menus: Powertrain / Engine / Data List / Throttle Sensor Position. Fully depress the accelerator pedal and check that the value is 60% or more. Perform a road test and confirm that there are no abnormalities.

Scheme 165

Scheme 166

Scheme 167

Scheme 168

1. REMOVE AIR CLEANER INLET COVER ASSEMBLY SEAL See step 6
2. REMOVE DUTY VACUUM SWITCHING VALVE Disconnect the duty vacuum switching valve connector. Disengage the wire harness clamp. Disconnect the 3 vacuum hoses from the duty vacuum switching valve. Remove the bolt. Disconnect the hose from the duty vacuum switching valve.

Scheme 169

Scheme 170

1. INSPECT DUTY VACUUM SWITCHING VALVE (OPERATION) Check the operation of the duty vacuum switching valve when positive battery voltage is applied to its terminals. TEXT IN ILLUSTRATION *a Component without harness connected (Duty Vacuum Switching Valve) OK Tester Connection Condition Specified Condition 1 - 2 Battery voltage is not applied The air from pipe G is flowing out through pipes E and H. Battery voltage is applied The air from pipe F is flowing out through pipes E and H.
2. INSPECT DUTY VACUUM SWITCHING VALVE (RESISTANCE) Measure the resistance according to the value(s) in the table below. TEXT IN ILLUSTRATION *a Component without harness connected (Duty Vacuum Switching Valve) Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 19 to 21 ohms If the resistance is not as specified, replace the duty vacuum switching valve.

Scheme 171

Scheme 172

1. INSTALL DUTY VACUUM SWITCHING VALVE Connect the hose to the duty vacuum switching valve. TEXT IN ILLUSTRATION *a Front Engine Mounting Insulator Side NOTE: Confirm that the hose on the front engine mounting insulator side is securely connected. Install the duty vacuum switching valve with the bolt. Torque: 4.0 N*m (41 kgf*cm, 35 in.*lbf) Connect the 3 vacuum hoses to the duty vacuum switching valve. TEXT IN ILLUSTRATION *a Large Hose *b Dummy Hose (not Used for Ventilation, the Other End is Plugged) Connect the duty vacuum switching valve connector. Engage the wire harness clamp.
2. INSTALL AIR CLEANER INLET COVER ASSEMBLY SEAL See step 5

Scheme 173

Scheme 174

1. INSPECT FRONT ENGINE MOUNTING INSULATOR ASSEMBLY Check the operation. Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the ACM Inhibit. Tester Display Test Part Control Range Diagnostic Note Control the ACM Inhibit ACM ON / OFF Test is possible while engine is idling Check if the front engine mounting insulator assembly operates in accordance with tester operation. OK Condition Specified Condition "Control the ACM Inhibit" is OFF The engine does not move (insulator operation is normal). "Control the ACM Inhibit" is ON The engine moves in accordance with insulator operation. HINT: While "Control the ACM Inhibit" is ON, the front engine mounting insulator assembly operates repeatedly. Inspect for vacuum leaks. Disconnect the vacuum hose from the front engine mounting insulator assembly. Using a vacuum pump, apply vacuum of 80 kPa (600 mmHg, 24 in.Hg) and wait for 1 minute. Check that there is no change in the needle movement of the vacuum pump gauge. OK Vacuum pressure holds. Check that there is no fluid leakage caused by a break in the diaphragm. Reconnect the vacuum hose.

Scheme 175

Scheme 176

Scheme 177

1. REMOVE RADIATOR ASSEMBLY AND FAN ASSEMBLY WITH MOTOR Refer to «REMOVAL»(ref-494109-S09806151582012081000000)
2. REMOVE TRANSVERSE ENGINE MOUNTING BRACKET HINT: Securely support the automatic transaxle using a jack. Remove the 3 bolts, nut and the transverse engine mounting bracket.
3. REMOVE FRONT ENGINE MOUNTING INSULATOR ASSEMBLY Disconnect the duty vacuum switching valve connector. Disengage the wire harness clamp. Remove the 3 nuts and the front engine mounting insulator assembly.

Scheme 178

Scheme 179

1. INSTALL TRANSVERSE ENGINE MOUNTING BRACKET Set the front engine mounting insulator in place using the 3 bolt holes. Install the transverse engine mounting bracket to the front engine mounting insulator assembly. Install the bolt to the transverse engine mounting bracket. Torque: 87 N*m (887 kgf*cm, 64 ft.*lbf) Install the 2 bolts and the nut. Torque: 64 N*m (653 kgf*cm, 47 ft.*lbf)
2. INSTALL FRONT ENGINE MOUNTING INSULATOR ASSEMBLY Install the front engine mounting insulator assembly with the 3 nuts. Torque: 52 N*m (530 kgf*cm, 38 ft.*lbf) Connect the duty vacuum switching valve connector. Engage the wire harness clamp.
3. INSTALL RADIATOR ASSEMBLY AND FAN ASSEMBLY WITH MOTOR Refer to «INSTALLATION»(ref-494109-S20292795892012081000000)

Scheme 180

1. INSPECT ACCELERATOR PEDAL SENSOR ASSEMBLY Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Accel Sensor Out No. 1 and Accel Sensor Out No. 2. Read the values displayed on the Techstream. Standard Voltage Tester Display Condition Specified Condition Accel Sensor Out No. 1 Accelerator pedal is released 0.5 to 1.1 V Accelerator pedal is fully depressed 2.6 to 4.5 V Accel Sensor Out No. 2 Accelerator pedal is released 1.2 to 2.0 V Accelerator pedal is fully depressed 3.4 to 4.8 V If the result is not as specified, check the accelerator pedal sensor assembly, wire harness or ECM.

Scheme 181

1. REMOVE ACCELERATOR PEDAL SENSOR ASSEMBLY Disconnect the accelerator pedal sensor assembly connector. Remove the 2 nuts and the accelerator pedal sensor assembly. NOTE: Avoid physical shocks to the accelerator pedal sensor assembly. Do not disassemble the accelerator pedal sensor assembly.

Note. Perform the MAF meter inspection according to the following procedure. Only replace the MAF meter when the MAF value in the Data List (with the engine stopped) is not within the normal operating range or there is foreign matter on the MAF meter platinum hot wire (heater).

1. INSPECT MASS AIR FLOW METER Read the values using the Techstream (MAF). NOTE: Perform the inspection with the vehicle indoors and on a level surface. Perform the inspection of the MAF meter while it is installed to the air cleaner case (installed to the vehicle). During the test, do not use an exhaust air duct on the exhaust pipe. Connect the Techstream to the DLC3. Turn the ignition switch to ON (do not run the engine). Enter the following menus: Powertrain / Engine / Data List / MAF. Wait for 30 seconds, and read the values on the Techstream. Standard Tester Display Condition Specified Condition MAF Engine not running 30 seconds after ignition switch turned to ON 0.53 gm/sec or less If the result is not as specified, replace the MAF meter. If the result is within the specified range, remove and inspect the MAF meter. See step 1 .

Scheme 182

1. REMOVE WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY Refer to «REMOVAL»(ref-494141-S07171082372012081000000)
2. REMOVE FRONT OUTER COWL TOP PANEL SUB-ASSEMBLY . Refer to «REMOVAL - Step 10»(ref-494142-S07546098752012081000000)
3. REMOVE MASS AIR FLOW METER Disconnect the mass air flow meter connector. Remove the 2 screws and the mass air flow meter.

Scheme 183

Scheme 184

1. INSPECT MASS AIR FLOW METER Perform a visual check for any foreign matter on the platinum hot wire (heater) of the mass air flow meter shown in the illustration. TEXT IN ILLUSTRATION *1 Platinum Hot Wire (Heater) OK There is no foreign matter. If the result is not as specified, replace the mass air flow meter. Measure the resistance according to the value(s) in the table below. TEXT IN ILLUSTRATION *a Component without harness connected (Mass Air Flow Meter) Standard Resistance Tester Connection Condition Specified Condition 1 (THA) - 2 (E2) -20°C (-4°F) 13.6 to 18.4 kohms 1 (THA) - 2 (E2) 20°C (68°F) 2.21 to 2.69 kohms 1 (THA) - 2 (E2) 60°C (140°F) 0.49 to 0.67 kohms If the result is not as specified, replace the mass air flow meter.
