WIRING DIAGRAM
Refer to DTC P1603. Refer to WIRING DIAGRAM .
Refer to DTC P2009. Refer to WIRING DIAGRAM .
Refer to DTC P2009. Refer to WIRING DIAGRAM .
Refer to DTC P2102. Refer to WIRING DIAGRAM .
Refer to DTC P2102. Refer to WIRING DIAGRAM .
Refer to DTC P2120. Refer to WIRING DIAGRAM .
Refer to DTC P0031. Refer to WIRING DIAGRAM .
Scheme 307
Scheme 308
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Start the engine and warm it up until the ECT reaches 75°C (167°F) or higher [A].
- On the Techstream, enter the following menus to check the fuel-cut status: Powertrain / Engine / Data List / Idle Fuel Cut.
- Drive the vehicle at a speed between 60 and 120 km/h (37 and 75 mph) for at least 10 minutes [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Shift the transmission to 2nd gear [C].
- Accelerate the vehicle to 64 km/h (40 mph) or more by depressing the accelerator pedal for at least 10 seconds [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Soon after performing step [D] above, release the accelerator pedal for at least 4 seconds without depressing the brake pedal in order to execute fuel-cut control [E]. HINT: Fuel-cut is performed when the following conditions are met: Accelerator pedal is fully released. Engine speed is 2500 RPM or more (fuel injection returns at 1000 RPM).
- Allow the vehicle to decelerate until the vehicle speed decreases to less than 10 km/h (6 mph).
- Repeat steps [C] through [E] above at least 3 times in one driving cycle.
- Enter the following menus: Powertrain / Engine / Trouble Codes [F].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P2195 or P2196.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [F] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493953-S27327777792012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Refer to DTC P0031. Refer to WIRING DIAGRAM .
Refer to DTC P0031. Refer to WIRING DIAGRAM .
Refer to DTC P0451. Refer to WIRING DIAGRAM .
