Engine Control System [2GR-FE] [Diagnostic Codes] [P0365-P1603]: Other Toyota Sienna III

Testing & Diagnostics 12 illustrations ~14206 words

MONITOR STRATEGY

Related DTCsP0365: VVT sensor (for exhaust side of bank 1) verify pulse input P0367: VVT sensor (for exhaust side of bank 1) range check (low voltage) P0368: VVT sensor (for exhaust side of bank 1) range check (high voltage) P0390: VVT sensor (for exhaust side of bank 2) verify pulse input P0392: VVT sensor (for exhaust side of bank 2) range check (low voltage) P0393: VVT sensor (for exhaust side of bank 2) range check (high voltage)
Required sensors/Components (Main)VVT sensor (for exhaust side of bank 1, 2)
Required sensors/Components (Related)Crankshaft position sensor
Frequency of operationContinuous
Duration4 seconds: P0367 and P0392 (VVT sensor (for exhaust side of bank 1, 2) range check [low voltage]) P0368 and P0393 (VVT sensor (for exhaust side of bank 1, 2) range check [high voltage]) 5 seconds: P0365 and P0390 (VVT sensor (for exhaust side of bank 1, 2) verify pulse input)
MIL operationImmediately
Sequence of operationNone

TYPICAL ENABLING CONDITIONS

Monitor runs whenever following DTCs are not presentNone

ALL

Engine speed600 RPM or more
StarterOFF
Exhaust VVT sensor range check fail (P0367, P0368, P0392, P0393)Not detected
Exhaust VVT sensor voltage0.3 V or more, and 4.7 V or less
Battery voltage8 V or more
Ignition switchON

P0365 AND P0390: VVT SENSOR (FOR EXHAUST SIDE OF BANK 1, 2) VERIFY PULSE INPUT

StarterOFF
Ignition switchON
Time after ignition switch off to ON2 seconds or more
Exhaust VVT sensor pulse input fail (P0365, P0390)Not detected
Battery voltage8 V or more

P0367, P0368, P0392, P0393: VVT SENSOR (FOR EXHAUST SIDE OF BANK 1, 2) RANGE CHECK (LOW VOLTAGE, HIGH VOLTAGE)

TYPICAL MALFUNCTION THRESHOLDS

Exhaust VVT sensor signalNo signal

P0365 AND P0390: VVT SENSOR (FOR EXHAUST SIDE OF BANK 1, 2) VERIFY PULSE INPUT

Exhaust VVT sensor voltageLess than 0.3 V

P0367 AND P0392: VVT SENSOR (FOR EXHAUST SIDE OF BANK 1, 2) RANGE CHECK (LOW VOLTAGE)

Exhaust VVT sensor voltageMore than 4.7 V

P0368 AND P0393: VVT SENSOR (FOR EXHAUST SIDE OF BANK 1, 2) RANGE CHECK (HIGH VOLTAGE)

COMPONENT OPERATING RANGE

VVT sensor for exhaust side voltage0.3 to 4.7 V

CONFIRMATION DRIVING PATTERN

  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
  4. Turn the ignition switch off and wait for at least 30 seconds.
  5. Turn the ignition switch to ON and turn the Techstream on [A].
  6. Start the engine.
  7. Idle the engine for 10 seconds [B].
  8. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  9. Input the DTC: P0365, P0367, P0368, P0390, P0392 or P0393.
  10. Check the DTC judgment result [C]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] and [C] again.
  11. If the test result is N/A, enter the following menus: Powertrain / Engine / Trouble Codes.
  12. Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
  13. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Related DTCsP0420: Catalyst deterioration (bank 1) P0430: Catalyst deterioration (bank 2)
Required Sensors / Components (Main)Air fuel ratio sensor and heated oxygen sensor
Required Sensors / Components (Related)Intake air temperature sensor, mass air flow meter, crankshaft position sensor and engine coolant temperature sensor
Frequency of OperationOnce per driving cycle
DurationApproximately 30 seconds
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentP0010, P0020 (Camshaft timing oil control valve assembly bank 1, 2) P0011, P0021 (VVT system bank 1, 2 - advance) P0012, P0022 (VVT system bank 1, 2 - retard) P0013, P0023 (Exhaust camshaft timing oil control valve assembly bank 1, 2) P0014, P0024 (Exhaust VVT system bank 1, 2 - advance) P0015, P0025 (Exhaust VVT system bank 1, 2 - retard) P0016, P0018 (VVT system bank 1, 2 - misalignment) P0017, P0019 (Exhaust VVT system bank 1, 2 - misalignment) P0031, P0032, P0051, P0052, P101D, P103D (Air fuel ratio sensor heater) P0037, P0038, P0057, P0058, P102D, P105D (Heated oxygen sensor heater) P0102, P0103 (Mass air flow meter) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient engine coolant temperature for closed loop) P0136, P0137, P0138, P0139, P0156, P0157, P0158, P0159, P0607 (Heated oxygen sensor) P014C, P014D, P014E, P014F, P015A, P015B, P015C, P015D, P2195, P2196, P2197, P2198, P2237, P2238, P2239, P2240, P2241, P2242, P2252, P2253, P2255, P2256 (Air fuel ratio sensor) P0171, P0172, P0174, P0175 (Fuel system) P0301, P0302, P0303, P0304, P0305, P0306 (Misfire) P0335 (Crankshaft position sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) P0351, P0352, P0353, P0354, P0355, P0356 (Igniter) P0365, P0367, P0368, P0390, P0392, P0393 (Exhaust VVT sensor) P0500 (Vehicle speed sensor)
Battery voltage11 V or more
Intake air temperature10°C (14°F) or more
Engine coolant temperature75°C (167°F) or more
Atmospheric pressure76 kPa(abs) [570 mmHg(abs)] or more
IdlingOFF
Engine speedLess than 3200 RPM
Air fuel ratio sensorActivated
Fuel system statusClosed loop
Engine load10 to 85%
All of the following conditions are metConditions 1, 2 and 3
1. Mass air flow rate5 to 75 g/sec.
2. Front catalyst temperature (estimated)560 to 860°C (1040 to 1580°F)
3. Rear catalyst temperature (estimated)430 to 860°C (806 to 1580°F)
Shift position4th or more
Oxygen storage capacity of catalystLess than 0.039 g

HINT

Performing this confirmation pattern will activate the catalyst monitor. This is very useful for verifying the completion of a repair.

Scheme 601

Scheme 601: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON.
  3. Turn the Techstream on.
  4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
  5. Turn the ignition switch off and wait for at least 30 seconds.
  6. Turn the ignition switch to ON and turn the Techstream on.
  7. Enter the following menus: Powertrain / Engine / Monitor / Current Monitor.
  8. Check that Catalyst Efficiency / Current is Incomplete.
  9. Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher [A].
  10. Drive the vehicle at approximately 60 km/h (37 mph) for 10 minutes or more [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive the vehicle while keeping the engine load as constant as possible. The monitor item will change to Complete as the catalyst efficiency monitor operates [C].
  11. Enter the following menus: Powertrain / Engine / Trouble Codes.
  12. Check if any DTCs (pending DTCs) are stored. HINT: If the monitor does not change to Complete, and no pending DTCs are stored, perform the following procedure.
  13. Drive the vehicle at a speed between 75 and 100 km/h (47 and 63 mph) for 10 minutes or more [D]. HINT: Drive the vehicle while keeping the engine load as constant as possible. The monitor item will change to Complete as the catalyst efficiency monitor operates [E].
  14. Enter the following menus: Powertrain / Engine / Trouble Codes.
  15. Check if any DTCs (pending DTCs) are stored HINT: If monitor item does not change to Complete, and no pending DTCs are stored, extend the driving time.
  16. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

MONITOR RESULT

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

PROCEDURE

  1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0420 AND/OR P0430) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0420 and/or P0430 are output A DTC P0420 and/or P0430 and other DTCs are output B HINT: If any DTCs other than P0420 or P0430 are output, troubleshoot those DTCs first. B --> See step 13 A: Go to next step
  2. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME) Connect the Techstream to the DLC3. Start the engine and warm it up. Turn the Techstream on. Run the engine at an engine speed of 2500 RPM for approximately 90 seconds. Enter the following menus: Powertrain / Engine / Active Test / Control the Injection Volume. Perform the Active Test operation with the engine idling (press the RIGHT or LEFT button to change the fuel injection volume). Monitor the voltage outputs of the air fuel ratio and heated oxygen sensors (AFS Voltage B1S1 and O2S B1S2 or AFS Voltage B2S1 and O2S B2S2) displayed on the Techstream. HINT: Change the fuel injection volume within the range of - 12% to +12%. The injection volume can be changed in fine gradations. Each sensor reacts in accordance with increases and decreases in the fuel injection volume. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. If the sensor output voltage does not change (almost no reaction) while performing the Active Test, the sensor may be malfunctioning. Standard Techstream Display (Sensor) Injection Volume Status Voltage AFS Voltage B1S1 or AFS Voltage B2S1 (Air fuel ratio) +12% Rich Less than 3.1 V AFS Voltage B1S1 or AFS Voltage B2S1 (Air fuel ratio) -12% Lean More than 3.4 V O2S B1S2 or O2S B2S2 (Heated oxygen) +12% Rich More than 0.55 V O2S B1S2 or O2S B2S2 (Heated oxygen) -12% Lean Less than 0.4 V RESULT Status AFS Voltage B1S1 or AFS Voltage B2S1 Status O2S B1S2 or O2S B2S2 Air Fuel Ratio Condition and Air Fuel Ratio and Heated Oxygen Sensor Condition Misfire Suspected Area Proceed to Lean/Rich Lean/Rich Normal - Three-way catalytic converter Gas leaks from exhaust system A Lean Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor B Rich Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor B Lean/Rich Lean Heated oxygen sensor malfunction - Heated oxygen sensor Gas leaks from exhaust system C Lean/Rich Rich Heated oxygen sensor malfunction - Heated oxygen sensor Gas leaks from exhaust system C Lean Lean Actual air fuel ratio lean May occur Extremely rich or lean actual air fuel ratio Gas leaks from exhaust system D Rich Rich Actual air fuel ratio rich - Extremely rich or lean actual air fuel ratio Gas leaks from exhaust system D Lean: During the Control the Injection Volume for A/F Sensor Active Test, the air fuel ratio sensor output voltage (AFS Voltage) is consistently more than 3.4 V, and the heated oxygen sensor output voltage (O2S) is consistently less than 0.4 V. Rich: During the Control the Injection Volume for A/F Sensor Active Test, the AFS Voltage is consistently less than 3.1 V, and the O2S is consistently more than 0.55 V. Lean/Rich: During the Control the Injection Volume for A/F Sensor Active Test, the output voltage of the heated oxygen sensor alternates correctly. B --> See step 7 C --> See step 5 D --> See step 6 A: Go to next step
  3. CHECK FOR EXHAUST GAS LEAK Inspect for exhaust gas leaks from the exhaust manifold sub-assembly and exhaust pipes. OK No gas leaks. NG --> See step 8 OK: Go to next step
  4. CHECK DTC OUTPUT (DTC P0420 AND/OR P0430) NOTE: When outputting DTC P0420 replace the exhaust manifold sub-assembly RH (TWC: Front catalyst) and the center exhaust pipe assembly (TWC: Rear catalyst) together when catalyst replacement is necessary. When outputting DTC P0430 replace the exhaust manifold sub-assembly LH (TWC: Front catalyst) and the center exhaust pipe assembly (TWC: Rear catalyst) together when catalyst replacement is necessary. HINT: Confirm the replacement parts, referring to the illustration in the Catalyst Location. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Vehicle Type Proceed to P0420 2WD A, C 4WD A, D P0430 2WD B, C 4WD B, D P0420 and P0430 2WD A, B, C 4WD A, B, D A --> See step 14 B --> See step 15 C --> See step 16 D --> See step 17
  5. CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. OK --> See step 9 NG --> See step 8
  6. CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. OK --> See step 10 NG --> See step 8
  7. REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-493957-S42556714632012081000000) . NEXT --> See step 11
  8. REPAIR OR REPLACE EXHAUST GAS LEAK POINT Repair or replace exhaust gas leak point. NEXT --> See step 11
  9. REPLACE HEATED OXYGEN SENSOR Replace the heated oxygen sensor. Refer to «REMOVAL»(ref-493957-S03684060302012081000000) . NEXT --> See step 11
  10. CHECK CAUSE OF EXTREMELY RICH OR LEARN ACTUAL AIR FUEL RATIO Check the cause of extremely rich or lean actual air fuel ratio, referring to the DTC P0171 Inspection Procedure. Refer to «INSPECTION PROCEDURE»(ref-494147-S10970187422012081000000) . NEXT: Go to next step
  11. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . Turn the ignition switch off and wait for at least 30 seconds. Start the engine. Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the pending DTCs. RESULT Result Proceed to DTC P0420 and/or P0430 is output A DTC is not output B B --> END A: Go to next step
  12. CHECK DTC OUTPUT (DTC P0420 AND/OR P0430) NOTE: When outputting DTC P0420 replace the exhaust manifold sub-assembly RH (TWC: Front catalyst) and the center exhaust pipe assembly (TWC: Rear catalyst) together when catalysts replacement is necessary. When outputting DTC P0430 replace the exhaust manifold sub-assembly LH (TWC: Front catalyst) and the center exhaust pipe assembly (TWC: Rear catalyst) together when catalysts replacement is necessary. HINT: Confirm the replacement parts, referring to the illustration in the Catalyst Location. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Vehicle Type Proceed to P0420 2WD A, C 4WD A, D P0430 2WD B, C 4WD B, D P0420 and P0430 2WD A, B, C 4WD A, B, D A --> See step 14 B --> See step 15 C --> See step 16 D --> See step 17
  13. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-493954-S26400840072012081000000)
  14. REPLACE EXHAUST MANIFOLD SUB-ASSEMBLY RH (TWC: FRONT CATALYST). Refer to «COMPONENTS»(ref-494152-S36142877652012081000000)
  15. REPLACE EXHAUST MANIFOLD SUB-ASSEMBLY LH (TWC: FRONT CATALYST). Refer to «COMPONENTS»(ref-494152-S36142877652012081000000)
  16. REPLACE CENTER EXHAUST PIPE ASSEMBLY (TWC: REAR CATALYST). Refer to «COMPONENTS»(ref-494152-S29440133042012081000000)
  17. REPLACE CENTER EXHAUST PIPE ASSEMBLY (TWC: REAR CATALYST). Refer to «COMPONENTS»(ref-494152-S30759814002012081000000)
Required Sensors/ComponentsCanister pump module
Frequency of OperationOnce per driving cycle
DurationWithin 2 minutes
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor runs whenever following DTCs not storedNone
Atmospheric pressure70 to 110 kPa(abs) [525 to 825 mmHg(abs)]
Battery voltage10.5 V or higher
Vehicle speedLess than 4 km/h (2.5 mph)
Ignition switchOFF
Time after key-off5, 7 or 9.5 hours
Canister pressure sensor malfunction (P0452, P0453)Not detected
Purge VSVNot operated by scan tool
Vent valveNot operated by scan tool
Leak detection pumpNot operated by scan tool
Both of following conditions met before key-offConditions 1 and 2
1. Duration that vehicle is driven5 minutes or more
2. EVAP purge operationPerformed
Engine coolant temperature4.4 to 35°C (40 to 95°F)
Intake air temperature4.4 to 35°C (40 to 95°F)

"Saturated" indicates that the EVAP pressure change is below 0.286 kPa(gauge) [2.14 mmHg(gauge)] in 60 seconds.

One of following conditions met
EVAP pressure just after reference pressure measurement startedHigher than -0.25 kPa(gauge) [-1.875 mmHg(gauge)]
Reference pressureBelow -4.85 kPa(gauge) [-36.384 mmHg(gauge)]
Reference pressure1.057 kPa(gauge) [-7.93 mmHg(gauge)] or higher
Reference pressureNot saturated within 360 seconds
Reference pressure difference between first and second0.9 kPa(gauge) [6.76 mmHg(gauge)] or higher

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

Note. The Evaporative System Check (Automatic Mode) consists of 6 steps performed automatically by the Techstream. It takes a maximum of approximately 24 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).

  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493953-S27327777792012081000000) .
  4. Turn the ignition switch off and wait for at least 30 seconds.
  5. Turn the ignition switch to ON and turn the Techstream on.
  6. Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Automatic Mode.
  7. After the "Evaporative System Check" is completed, check for All Readiness by entering the following menus: Powertrain / Engine / Utility / All readiness.
  8. Input the DTC: P043E, P043F, P2401, P2402 or P2419.
  9. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
  10. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493953-S27327777792012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Required Sensors/ComponentsPurge VSV Canister pump module
Frequency of OperationOnce per driving cycle
DurationWithin 15 minutes: Purge VSV stuck open/close Within 10 minutes: Purge flow
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentNone

ALL

Atmospheric pressure70 to 110 kPa(abs) [525 to 825 mmHg(abs)]
Battery voltage10.5 V or higher
Vehicle speedLess than 4 km/h (2.5 mph)
Ignition switchOFF
Time after key-off5, 7 or 9.5 hours
Canister pressure sensor malfunction (P0452, P0453)Not detected
Purge VSVNot operated by scan tool
Vent valveNot operated by scan tool
Leak detection pumpNot operated by scan tool
Both of following conditions met before key-offConditions 1 and 2
1. Duration that vehicle is driven5 minutes or more
2. EVAP purge operationPerformed
Engine coolant temperature4.4 to 35°C (40 to 95°F)
Intake air temperature4.4 to 35°C (40 to 95°F)

KEY-OFF MONITOR

EngineRunning
Engine coolant temperature4.4°C (40°F) or higher
Intake air temperature4.4°C (40°F) or higher
Canister pressure sensor malfunctionNot detected
Purge VSVNot operated by scan tool
EVAP system checkNot operated by scan tool
Battery voltage10 V or higher
Purge duty-cycle8% or more

PURGE FLOW MONITOR

EVAP pressure when vacuum introduction is completeHigher than reference pressure x 0.2

PURGE VSV STUCK OPEN

EVAP pressure change after purge VSV is openLess than 0.3 kPa(gauge) [2.25 mmHg(gauge)]

PURGE VSV STUCK CLOSED

Both of the following conditions are metConditions 1 and 2
1. EVAP pressure change when purge flow is startedLess than 0.1 kPa(gauge) [0.75 mmHg(gauge)]
2. EVAP pressure change during purge operation when vent valve closedLess than 0.15 kPa(gauge) [1.13 mmHg(gauge)]

PURGE FLOW

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493953-S27327777792012081000000) .
  4. Turn the ignition switch off and wait for at least 30 seconds.
  5. Turn the ignition switch to ON and turn the Techstream on.
  6. Start the engine and wait 15 minutes or more.
  7. Enter the following menus: Powertrain / Engine / Trouble Codes.
  8. Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
  9. Enter the following menus: Powertrain / Engine / Utility / All readiness.
  10. Input the DTC: P0441.
  11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed You should perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform the following procedure. NOTE: The Evaporative System Check (Automatic Mode) consists of 6 steps performed automatically by the Techstream. It takes a maximum of approximately 24 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).
  12. Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493953-S27327777792012081000000) .
  13. Turn the ignition switch off and wait for at least 30 seconds.
  14. Turn the ignition switch to ON and turn the Techstream on.
  15. Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Automatic Mode.
  16. After the Evaporative System Check is completed, check for All Readiness by entering the following menus: Powertrain / Engine / Utility / All Readiness.
  17. Input the DTC: P0441.
  18. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
  19. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493953-S27327777792012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Required Sensors/ComponentsCanister pump module
Frequency of OperationContinuous
Duration0.5 seconds: P0452 and P0453 Within 2 minutes: P0451 (sensor stuck) Less than 15 seconds: P0451 (sensor noise)
MIL OperationImmediate: P0452 and P0453 2 driving cycles: P0451
Sequence of OperationNone
Monitor runs whenever following DTCs not storedNone
Atmospheric pressure (absolute pressure)70 to 110 kPa(abs) [525 to 825 mmHg(abs)]
Battery voltage10.5 V or higher
Intake air temperature4.4 to 35°C (40 to 95°F)
Canister pressure sensor malfunction (P0452, P0453)Not detected
Either of following conditions metA or B
A. Engine conditionRunning
B. Time after key-off5, 7 or 9.5 hours

P0451 (NOISE MONITOR)

Monitor runs whenever following DTCs not storedNone
Battery voltage10.5 V or higher
Intake air temperature4.4 to 35°C (40 to 95°F)
Canister pressure sensor malfunction (P0452, P0453)Not detected
Atmospheric pressure (absolute pressure)70 to 110 kPa(abs) [525 to 825 mmHg(abs)]
Time after key-off5, 7 or 9.5 hours

P0451 (STUCK MONITOR)

Monitor runs whenever following DTCs not storedNone
Ignition switchON
Battery voltage8 V or higher

P0452 AND P0453

Frequency that EVAP pressure change 0.3 kPa(gauge) [2.25 mmHg(gauge)] or higher10 times or more in 10 seconds

P0451: CANISTER PRESSURE SENSOR NOISE

EVAP pressure change during reference pressure measurementBelow 0.65 kPa(gauge) [4.876 mmHg(gauge)]

P0451: CANISTER PRESSURE SENSOR FIXED/FLAT

EVAP pressureBelow 42.11 kPa(abs) [315.85 mmHg(abs)]

P0452: CANISTER PRESSURE SENSOR LOW VOLTAGE

EVAP pressureHigher than 123.761 kPa(abs) [928.28 mmHg(abs)]

P0453: CANISTER PRESSURE SENSOR HIGH VOLTAGE

Note. The Evaporative System Check (Automatic Mode) consists of 6 steps performed automatically by the Techstream. It takes a maximum of approximately 24 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).

  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Enter the following menus: Powertrain / Engine / Data List / Intake Air.
  4. Check that the intake air temperature is between 4.4 and 35°C (40 and 95°F).
  5. Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493953-S27327777792012081000000) .
  6. Turn the ignition switch off and wait for at least 30 seconds.
  7. Turn the ignition switch to ON and turn the Techstream on.
  8. Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Automatic Mode.
  9. After the Evaporative System Check is completed, check for All Readiness by entering the following menus: Powertrain / Engine / Utility / All readiness.
  10. Input the DTC: P0451, P0452 or P0453.
  11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
  12. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493953-S27327777792012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 602

Scheme 602: WIRING DIAGRAM
Required Sensors/ComponentsPurge VSV and canister pump module
Frequency of OperationOnce per driving cycle
DurationWithin 15 minutes (varies with amount of fuel in tank)
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor runs whenever following DTCs not storedNone
Atmospheric pressure70 to 110 kPa(abs) [525 to 825 mmHg(abs)]
Battery voltage10.5 V or higher
Vehicle speedLess than 4 km/h (2.5 mph)
Ignition switchOFF
Time after key-off5, 7 or 9.5 hours
Canister pressure sensor malfunction (P0452, P0453)Not detected
Purge VSVNot operated by scan tool
Vent valveNot operated by scan tool
Leak detection pumpNot operated by scan tool
Both of following conditions met before-key offConditions 1 and 2
1. Duration that vehicle is driven5 minutes or more
2. EVAP purge operationPerformed
Engine coolant temperature4.4 to 35°C (40 to 95°F)
Intake air temperature4.4 to 35°C (40 to 95°F)
EVAP pressure when vacuum introduction completeHigher than [reference pressure x 0.2]

P0455: EVAP GROSS LEAK

EVAP pressure when vacuum introduction completeBetween reference pressure and [reference pressure x 0.2]

P0456: EVAP SMALL LEAK

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

Note. The Evaporative System Check (Automatic Mode) consists of 6 steps performed automatically by the Techstream. It takes a maximum of approximately 24 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).

  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure).
  4. Turn the ignition switch off and wait for at least 30 seconds.
  5. Turn the ignition switch to ON and turn the Techstream on.
  6. Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Automatic Mode.
  7. After the Evaporative System Check is completed, check for All Readiness by entering the following menus: Powertrain / Engine / Utility / All Readiness.
  8. Input the DTC: P0455 or P0456.
  9. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
  10. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493953-S27327777792012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Related DTCsP0500: Vehicle Speed Sensor Circuit
Required sensors/components (Main)Vehicle speed sensor, combination meter assembly, skid control ECU
Required sensors/components (Sub)Park/Neutral position switch assembly, engine coolant temperature sensor, crankshaft position sensor, throttle position sensor, mass air flow meter sub-assembly
Frequency of operationContinuous
Duration2 seconds: Intake air temperature sensor is -10°C (14°F) or more 8 seconds: Intake air temperature sensor is less than -10°C (14°F)
MIL operationImmediately
Sequence of operationNone
Monitor runs whenever following DTCs are not presentNone
Time after ignition switch off to ON3 seconds or more
EngineRunning
Battery voltage8 V or more
Ignition switchON
StarterOFF
Either of the following conditions is metCondition 1 or 2
1. All of the following conditions are metCondition A, B and C
A. Engine coolant temperature20°C (68°F) or more
B. Engine coolant temperature sensor circuit fail (P0115, P0117, P0118, P0125)Not detected
C. Time after park/neutral position switch on to off10 seconds or more
2. All of the following conditions are metCondition D and E
D. Either of the following conditions is metCondition (a) or (b)
(a) Engine coolant temperatureLess than 20°C (68°F)
(b) Engine coolant temperature sensor circuit fail (P0115, P0117, P0118, P0125)Detected
E. Time after park/neutral position switch on to off30 seconds or more
One of the following condition is metCondition 3, 4, 5 or 6
3, All of the following conditions are metCondition F and G
F, Throttle position sensor voltageLess than 0.52 V
G, Engine speed2050 RPM or more
4, All or the following conditions are metCondition H and I
H, Throttle position sensor voltageLess than 0.84 V
I, Engine speed2500 RPM or more
5, All of the following conditions are metCondition J and K
J, Throttle position sensor voltageLess than 1.2 V
K, Engine speed2650 RPM or more
6, All of the following condition is metCondition L and M
L, Throttle position sensor voltage1.2 V or more
M, Engine speed2800 RPM or more
Throttle position sensor circuit fail (P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135)Not detected
Throttle position sensor learningCompleted
Fuel cut at high engine speedNot executing
Reverse inhibitOFF
Vehicle speed sensor signalNo signal

Scheme 603

Scheme 603: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
  4. Turn the ignition switch off.
  5. Turn the ignition switch to ON and turn the Techstream on [A].
  6. Start the engine.
  7. With the transaxle 3rd gear (S mode), drive the vehicle at 75 km/h (47 mph) or more for a total of 30 seconds or more [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
  8. Stop the vehicle.
  9. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  10. Input the DTC: P0500.
  11. Check the DTC judgment result [C]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
  12. If the test result is N/A, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
  13. Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
  14. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 604

Scheme 604: WIRING DIAGRAM
  1. READ VALUE USING TECHSTREAM (VEHICLE SPEED) Drive the vehicle and check whether the operation of the speedometer in the combination meter assembly is normal. HINT: The vehicle speed sensor is operating normally if the speedometer reading is normal. If the speedometer does not operate, check it by following the procedure described for a speedometer malfunction. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Vehicle Speed. Drive the vehicle. Read the value displayed on the Techstream. RESULT Result Proceed to Values displayed on Techstream and speedometer display not equal A Values displayed on Techstream and speedometer display equal B B --> See step 4 A: Go to next step
  2. CHECK COMBINATION METER SYSTEM (SPEED SIGNAL CIRCUIT) Inspect the circuits that send vehicle speed signals to this system in the meter system. Refer to «Speed Signal Circuit»(ref-494136-S29282588552012081000000) . NEXT: Go to next step
  3. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. HINT: If no DTCs (no pending DTCs) are output to the Techstream, the repair has been successfully completed. NEXT --> END
  4. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493954-S36145137532012081000000)
Related DTCsP0505: Idle speed control function
Required Sensors / Components (Main)Electronic throttle control system
Required Sensors / Components (Related)Crankshaft position sensor, engine coolant temperature sensor, and vehicle speed sensor
Frequency of OperationContinuous
Duration10 minutes (Idling after warming up)
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentP0010, P0020 (Camshaft timing oil control valve assembly bank 1, 2) P0011, P0021 (VVT system bank 1, 2 - advance) P0012, P0022 (VVT system bank 1, 2 - retard) P0013, P0023 (Exhaust camshaft timing oil control valve assembly bank 1, 2) P0014, P0024 (Exhaust VVT system bank 1, 2 - advance) P0015, P0025 (Exhaust VVT system bank 1, 2 - retard) P0016, P0018 (VVT system bank 1, 2 - misalignment) P0017, P0019 (Exhaust VVT system bank 1, 2 - misalignment) P0031, P0032, P0051, P0052, P101D, P103D (Air fuel ratio sensor heater) P0102, P0103 (Mass air flow meter) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient engine coolant temperature for closed loop) P014C, P014D, P014E, P014F, P015A, P015B, P015C, P015D, P2195, P2196, P2197, P2198, P2237, P2238, P2239, P2240, P2241, P2242, P2252, P2253, P2255, P2256 (Air fuel ratio sensor) P0171, P0172, P0174, P0175 (Fuel system) P0301, P0302, P0303, P0304, P0305, P0306 (Misfire) P0335 (Crankshaft position sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) P0351, P0352, P0353, P0354, P0355, P0356 (Igniter) P0365, P0367, P0368, P0390, P0392, P0393 (Exhaust VVT sensor) P0451, P0452, P0453 (Evaporative emission control system) P0500 (Vehicle speed sensor) P0705 (Shift lever control switch)
EngineRunning
Either of the following conditions is metCondition 1 or 2
1. Both of following A and B met
A. Engine speed - target engine speedLess than -100 RPM, or more than 150 RPM (A/C off and NSW off) Less than -100 RPM, or more than 200 RPM (A/C on or NSW on)
B. IAC flow rate learned value0.88 L/sec. or less, or 8.5 L/sec. or more for 5 seconds or more
2. Both of following C and D met
C. Frequency that both of the following conditions (a) and (b) are met5 times or more
(a). Engine speed - target engine speedLess than -100 RPM, or more than 150 RPM (A/C off and NSW off) Less than -100 RPM, or more than 200 RPM (A/C on or NSW on)
(b). Vehicle conditionStopped after being driven at 10 km/h (6.25 mph) or more
D. Either of the following conditions is metCondition (c) or (d)
(c). Amount of change of IAC flow rate learned value+4.04 L/sec. or more, or -7.52 L/sec. or less
(d). IAC flow rate learned value0.88 L/sec. or less, or 8.5 L/sec. or more

Scheme 605

Scheme 605: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
  4. Turn the ignition switch off and wait for at least 30 seconds.
  5. Turn the ignition switch to ON and turn the Techstream on [A].
  6. Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or more) with all the accessories switched off [B].
  7. Idle the engine for 5 minute or more [C].
  8. Accelerate the vehicle to 10 km/h (6.25 mph) or more, and then idle the engine [D]. HINT: In order to keep the idling stable, turn off the A/C and all other electric loads and do not perform any shift operations.
  9. Enter the following menus: Powertrain / Engine / Trouble Codes [E].
  10. Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
  11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  12. Input the DTC: P0505.
  13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, repeat step [D] 4 times, allowing 20 seconds or more between each repetition, and then check the DTC judgment result [F].
  14. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0505) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P0505 is output A DTC P0505 and other DTCs are output B HINT: If any DTCs other than P0505 are output, troubleshoot those DTCs first. B --> See step 6 A: Go to next step
  2. CHECK PCV HOSE (HOSE CONNECTIONS) Check the PCV hose connections. Refer to «COMPONENTS»(ref-494115-S38183353702012081000000) . OK PCV valve and hose are connected correctly and are not damaged. NG --> REPAIR OR REPLACE PCV HOSE OK: Go to next step
  3. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION»(ref-494151-S05436073992012081000000) . OK No leaks in intake system. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
  4. CHECK THROTTLE WITH MOTOR BODY ASSEMBLY (VISUALLY CHECK THROTTLE VALVE) Check for contamination between the throttle valve and the housing, and check that the throttle valve moves smoothly. OK Throttle valve is not contaminated with foreign objects and moves smoothly. NG --> See step 7 OK: Go to next step
  5. CONFIRM WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Read DTCs. RESULT Result Proceed to DTC P0505 is output A No DTC is output B B --> END A --> See step 8
  6. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-493954-S26400840072012081000000)
  7. REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY. Refer to «REMOVAL»(ref-493957-S09457030132012081000000)
  8. REPLACE ECM. Refer to «REMOVAL»(ref-493957-S32385345752012081000000)
Related DTCsP050A: Cold start idle air speed control system
Required Sensors/Components (Main)Throttle with motor body assembly
Required Sensors/Components (Related)Engine coolant temperature sensor Mass air flow meter
Frequency of OperationOnce per driving cycle
Duration10 seconds
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor runs whenever the following DTCs are not storedP0010, P0020 (Camshaft timing oil control valve bank 1, 2) P0011, P0021 (VVT system bank 1, 2 - advance) P0012, P0022 (VVT system bank 1, 2 - retard) P0013, P0023 (Exhaust camshaft timing oil control valve bank 1, 2) P0014, P0024 (Exhaust VVT system bank 1, 2 - advance) P0015, P0025 (Exhaust VVT system bank 1, 2 - retard) P0016, P0018 (VVT system bank 1, 2 - misalignment) P0017, P0019 (Exhaust VVT system bank 1, 2 - misalignment) P0102, P0103 (Mass air flow meter) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P014C, P014D, P014E, P014F, P015A, P015B, P015C, P015D, P2195, P2196, P2197, P2198, P2237, P2238, P2239, P2240, P2241, P2242, P2252, P2253, P2255, P2256 (Air fuel ratio sensor) P0171, P0172, P0174, P0175 (Fuel system) P0301, P0302, P0303, P0304, P0305, P0306 (Misfire) P0335 (Crankshaft position sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) P0351, P0352, P0353, P0354, P0355, P0356 (Igniter) P0365, P0367, P0368, P0390, P0392, P0393 (Exhaust VVT sensor) P0500 (Vehicle speed sensor) P0705 (Shift lever position switch)
Battery voltage8 V or higher
Time after engine start3 seconds or more
StarterOff
Engine coolant temperature at engine start10°C (14°F) or higher
Engine coolant temperature10°C (14°F) or higher, and less than 50°C (122°F)
Engine idling time3 seconds or more
Fuel-cutOff
Vehicle speedLess than 3 km/h (1.875 mph)
Time after shift position changed1 second or more
Atmospheric pressure76 kPa(abs) [570 mmHg(abs)] or higher
Accumulated mass air flowLess than 20 g (varies with engine coolant temperature)
  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
  4. Turn the ignition switch off and wait for at least 30 seconds.
  5. Turn the ignition switch to ON and turn the Techstream on [A].
  6. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp.
  7. Check that "Coolant Temp" in the Data List is within the range of -10 to 50°C (14 to 122°F).
  8. Start the engine and warm it up until the coolant temperature is the same as the coolant temperature in the freeze frame data.
  9. Idle the engine for 1 minute or more [B].
  10. Enter the following menus: Powertrain / Engine / Trouble Codes [C].
  11. Read pending DTC. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
  12. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  13. Input the DTC: P050A.
  14. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, idle the engine for 3 minutes, let the engine cool down, and then perform steps [A] through [C] again.
  15. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P050A) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P050A is output A DTC P050A and other DTCs are output B HINT: If any DTCs other than P050A are output, troubleshoot those DTCs first. B --> See step 21 A: Go to next step
  2. READ VALUE USING TECHSTREAM (FUEL TRIM) HINT: Calculate the total fuel trim values to check the characteristic deviation of the mass air flow meter. Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Short FT #1, Long FT #1, Short FT #2 and Long FT #2. Read the values displayed on the Techstream at engine idle. Add together the Short FT #1, Long FT #1, Short FT #2 and Long FT #2 values to obtain the total fuel trim. Standard Total of Short FT #1 and Long FT #1, and Short FT #2 and Long FT #2 values is between -20% and 20%. NG --> See step 5 OK: Go to next step
  3. INSPECT THROTTLE WITH MOTOR BODY ASSEMBLY (THROTTLE VALVE) Inspect that there are no deposits around the throttle valve and throttle valve condition. OK No deposits around the throttle valve and throttle valve moves smoothly. RESULT Result Proceed to NG A OK B B --> See step 15 A: Go to next step
  4. REPAIR OR REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY Repair or replace the throttle with motor body assembly. Refer to «REMOVAL»(ref-493957-S09457030132012081000000) . NEXT --> See step 14
  5. CHECK PCV SYSTEM Check the PCV hose connections. Refer to «COMPONENTS»(ref-494115-S38183353702012081000000) . OK PCV valve and hose are connected correctly and are not damaged. NG --> See step 10 OK: Go to next step
  6. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION»(ref-494151-S05436073992012081000000) . OK No leakage from intake system. NG --> See step 11 OK: Go to next step
  7. CHECK AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Visually check that the air cleaner filter element sub-assembly is not excessively contaminated with dirt or oil. OK The air cleaner filter element sub-assembly is not excessively contaminated with dirt or oil. NG --> See step 12 OK: Go to next step
  8. PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY) Operate the VVT system through the Active test, and check if the VVT system is operating normally. Perform the Active Test, referring to DTC P0011 Inspection Procedure (VVT system for intake camshaft). Refer to «PROCEDURE - Step 2»(ref-494147-S14271662752012081000000) . Perform the Active Test, referring to DTC P0014 Inspection Procedure (VVT system for exhaust camshaft). Refer to «PROCEDURE - Step 2»(ref-494147-S30504785832012081000000) . NG --> See step 13 OK: Go to next step
  9. READ VALUE USING TECHSTREAM (MAF). Refer to «PROCEDURE - Step 6»(ref-494147-S41127203492012081000000) OK --> See step 15 NG --> See step 16
  10. REPAIR OR REPLACE PCV HOSE Repair or replace PCV valve or hose. NEXT --> See step 14
  11. REPAIR OR REPLACE INTAKE SYSTEM Repair or replace the intake system. NEXT --> See step 14
  12. REPLACE AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Replace the air cleaner filter element sub-assembly. NEXT --> See step 14
  13. CHECK AND REPAIR VVT SYSTEM Check and repair the VVT system. HINT: Refer to DTC P0011 Inspection Procedure (VVT system for intake camshaft). Refer to «INSPECTION PROCEDURE»(ref-494147-S38240039062012081000000) . Refer to DTC P0014 Inspection Procedure (VVT system for exhaust camshaft). Refer to «INSPECTION PROCEDURE»(ref-494147-S26709881302012081000000) . NEXT: Go to next step
  14. CHECK WHETHER DTC OUTPUT RECURS (DTC P050A) NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10 and 50°C (14 and 122°F). Start the engine and warm it up until the engine coolant temperature is the same as the engine coolant temperature in the freeze frame data. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050A. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050A is output) B B --> See step 16 A --> END
  15. CHECK WHETHER DTC OUTPUT RECURS (DTC P050A) NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10 and 50°C (14 and 122°F). Start the engine and warm it up until the engine coolant temperature is the same as the engine coolant temperature in the freeze frame data. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050A. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050A is output) B B --> See step 16 A --> See step 22
  16. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER CONNECTOR CONNECTION) Check the connection and terminal contact pressure of connectors and wire harnesses between the mass air flow meter and ECM. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-493943-S23045644322012081000000) . HINT: Repair any problems. NEXT: Go to next step
  17. CHECK WHETHER DTC OUTPUT RECURS (DTC P050A) NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10 and 50°C (14 and 122°F). Start the engine and warm it up until the engine coolant temperature is the same as the engine coolant temperature in the freeze frame data. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050A. Check the DTC judgment result. RESULT Result Proceed to ABNORMAL (DTC P050A is output) A NORMAL (DTC is not output) B B --> END A: Go to next step
  18. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM). Refer to «PROCEDURE - Step 3»(ref-494147-S39768188982012081000000) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  19. REPLACE MASS AIR FLOW METER Replace the mass air flow meter. Refer to «REMOVAL»(ref-493957-S12273208142012081000000) . HINT: If the result of the inspection performed in step 9 indicated no problem, proceed to the next step without replacing the mass air flow meter. NEXT: Go to next step
  20. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10 and 50°C (14 and 122°F). Start the engine and warm it up until the engine coolant temperature is the same as the engine coolant temperature in the freeze frame data. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050A. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050A is output) B B --> See step 23 A --> END
  21. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-493954-S26400840072012081000000)
  22. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493954-S36145137532012081000000)
  23. REPLACE ECM. Refer to «REMOVAL»(ref-493957-S32385345752012081000000)
Related DTCsP050B: Cold start ignition timing performance
Required Sensors/Components (Main)Throttle with motor body assembly
Required Sensors/Components (Related)Engine coolant temperature sensor Mass air flow meter
Frequency of OperationOnce per driving cycle
Duration10 seconds
MIL Operation2 driving cycles
Sequence of OperationNone
Monitor runs whenever the following DTCs are not storedP0010, P0020 (Camshaft timing oil control valve bank 1, 2) P0011, P0021 (VVT system bank 1, 2 - advance) P0012, P0022 (VVT system bank 1, 2 - retard) P0013, P0023 (Exhaust camshaft timing oil control valve bank 1, 2) P0014, P0024 (Exhaust VVT system bank 1, 2 - advance) P0015, P0025 (Exhaust VVT system bank 1, 2 - retard) P0016, P0018 (VVT system bank 1, 2 - misalignment) P0017, P0019 (Exhaust VVT system bank 1, 2 - misalignment) P0102, P0103 (Mass air flow meter) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P014C, P014D, P014E, P014F, P015A, P015B, P015C, P015D, P2195, P2196, P2197, P2198, P2237, P2238, P2239, P2240, P2241, P2242, P2252, P2253, P2255, P2256 (Air fuel ratio sensor) P0171, P0172, P0174, P0175 (Fuel system) P0301, P0302, P0303, P0304, P0305, P0306 (Misfire) P0335 (Crankshaft position sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) P0351, P0352, P0353, P0354, P0355, P0356 (Igniter) P0365, P0367, P0368, P0390, P0392, P0393 (Exhaust VVT sensor) P0500 (Vehicle speed sensor) P0705 (Shift lever position switch)
Battery voltage8 V or higher
Time after engine start3 seconds or more
StarterOff
Engine coolant temperature at engine start10°C (14°F) or more
Engine coolant temperature10°C (14°F) or higher, and less than 50°C (122°F)
Engine idling time3 seconds or more
Fuel-cutOff
Vehicle speedLess than 3 km/h (1.875 mph)
Atmospheric pressure76 kPa(abs) [570 mmHg(abs)] or higher
Accumulated time when ignition timing retard is cut off8 seconds or more
  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
  4. Turn the ignition switch off and wait for at least 30 seconds.
  5. Turn the ignition switch to ON and turn the Techstream on [A].
  6. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp.
  7. Check that "Coolant Temp" in the Data List is within the range of -10 to 50°C (14 to 122°F).
  8. Start the engine and warm it up until the coolant temperature is the same as the coolant temperature in the freeze frame data.
  9. Idle the engine for 1 minute or more [B].
  10. Enter the following menus: Powertrain / Engine / Trouble Codes [C].
  11. Read pending DTC. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
  12. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  13. Input the DTC: P050B.
  14. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, idle the engine for 3 minutes, let the engine cool down, and then perform steps [A] through [C] again.
  15. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P050B) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P050B is output A DTC P050B and other DTCs are output B HINT: If any DTCs other than P050B are output, troubleshoot those DTCs first. B --> See step 21 A: Go to next step
  2. READ VALUE USING TECHSTREAM (FUEL TRIM) HINT: Calculate the total fuel trim values to check the characteristic deviation of the mass air flow meter. Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Short FT #1, Long FT #1, Short FT #2 and Long FT #2. Read the values displayed on the Techstream at engine idle. Add together the Short FT #1, Long FT #1, Short FT #2 and Long FT #2 values to obtain the total fuel trim. Standard Total of Short FT #1 and Long FT #1, and Short FT #2 and Long FT #2 values is between -20% and 20%. NG --> See step 5 OK: Go to next step
  3. INSPECT THROTTLE WITH MOTOR BODY ASSEMBLY (THROTTLE VALVE) Inspect that there are no deposits around the throttle valve and throttle valve condition. OK No deposits around the throttle valve and throttle valve moves smoothly. RESULT Result Proceed to NG A OK B B --> See step 15 A: Go to next step
  4. REPAIR OR REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY Repair or replace throttle with motor body assembly. Refer to «REMOVAL»(ref-493957-S09457030132012081000000) . NEXT --> See step 14
  5. CHECK PCV SYSTEM Check the PCV hose connections. Refer to «COMPONENTS»(ref-494115-S38183353702012081000000) . OK PCV valve and hose are connected correctly and are not damaged. NG --> See step 10 OK: Go to next step
  6. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION»(ref-494151-S05436073992012081000000) . OK No leaks from intake system. NG --> See step 11 OK: Go to next step
  7. CHECK AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Visually check that the air cleaner filter element sub-assembly is not excessively contaminated with dirt or oil. OK The air cleaner filter element sub-assembly is not excessively contaminated with dirt or oil. NG --> See step 12 OK: Go to next step
  8. PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY) Operate the VVT system through the Active test, and check if the VVT system is operating normally. Perform the Active Test, referring to DTC P0011 inspection procedure (VVT system for intake camshaft). Refer to «PROCEDURE - Step 2»(ref-494147-S14271662752012081000000) . Perform the Active Test, referring to DTC P0014 inspection procedure (VVT system for exhaust camshaft). Refer to «PROCEDURE - Step 2»(ref-494147-S30504785832012081000000) . NG --> See step 13 OK: Go to next step
  9. READ VALUE USING TECHSTREAM (MAF). Refer to «PROCEDURE - Step 6»(ref-494147-S41127203492012081000000) OK --> See step 15 NG --> See step 16
  10. REPAIR OR REPLACE PCV HOSE Repair or replace the PCV valve or hose. NEXT --> See step 14
  11. REPAIR OR REPLACE INTAKE SYSTEM Repair or replace the intake system. NEXT --> See step 14
  12. REPLACE AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Replace the air cleaner filter element sub-assembly. NEXT --> See step 14
  13. CHECK AND REPAIR VVT SENSOR Check and repair the VVT system. HINT: Refer to DTC P0011 Inspection Procedure (VVT system for intake camshaft). Refer to «INSPECTION PROCEDURE»(ref-494147-S38240039062012081000000) . Refer to DTC P0014 Inspection Procedure (VVT system for exhaust camshaft). Refer to «INSPECTION PROCEDURE»(ref-494147-S26709881302012081000000) . NEXT: Go to next step
  14. CHECK WHETHER DTC OUTPUT RECURS (DTC P050B) NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10 and 50°C (14 and 122°F) Start the engine and warm it up until the engine coolant temperature is the same as the engine coolant temperature in the freeze frame data. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050B is output) B B --> See step 16 A --> END
  15. CHECK WHETHER DTC OUTPUT RECURS (DTC P050B) NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10 and 50°C (14 and 122°F) Start the engine and warm it up until the engine coolant temperature is the same as the engine coolant temperature in the freeze frame data. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050B is output) B B --> See step 16 A --> See step 22
  16. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER CONNECTOR CONNECTION) Check the connection and terminal contact pressure of connectors and wire harnesses between the mass air flow meter and ECM. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-493943-S23045644322012081000000) . HINT: Repair any problems. NEXT: Go to next step
  17. CHECK WHETHER DTC OUTPUT RECURS (DTC P050B) NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10 and 50°C (14 and 122°F) Start the engine and warm it up until the engine coolant temperature is the same as the engine coolant temperature in the freeze frame data. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. RESULT Result Proceed to ABNORMAL (DTC P050B is output) A NORMAL (DTC is not output) B B --> END A: Go to next step
  18. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM). Refer to «PROCEDURE - Step 3»(ref-494147-S39768188982012081000000) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  19. REPLACE MASS AIR FLOW METER Replace the mass air flow meter. Refer to «REMOVAL»(ref-493957-S12273208142012081000000) . HINT: If the result of the inspection performed in step 9 indicated no problem, proceed to the next step without replacing the mass air flow meter. NEXT: Go to next step
  20. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Check that the engine coolant temperature is between -10 and 50°C (14 and 122°F). Start the engine and warm it up until the engine coolant temperature is the same as the engine coolant temperature in the freeze frame data. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050B is output) B B --> See step 23 A --> END
  21. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-493954-S26400840072012081000000)
  22. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493954-S36145137532012081000000)
  23. REPLACE ECM. Refer to «REMOVAL»(ref-493957-S32385345752012081000000)
Related DTCsP0560: ECM system voltage
Required Sensors / Components (Main)ECM
Required Sensors / Components (Related)
Frequency of OperationContinuous
Duration3 seconds
MIL OperationImmediately (MIL illuminated after next engine start)
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentNone
Stand-by RAMInitialized
Battery voltageLess than 3.5 V
  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
  4. Turn the ignition switch off and wait for at least 30 seconds.
  5. Turn the ignition switch to ON and turn the Techstream on [A].
  6. Wait 5 seconds or more.
  7. Enter the following menus: Powertrain / Engine / Trouble Codes [B].
  8. Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
  9. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  10. Input the DTC: P0560.
  11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
  12. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 606

Scheme 606: WIRING DIAGRAM
  1. INSPECT BATTERY Check that the battery is not depleted. OK Battery is not depleted NG --> REPLACE BATTERY OK: Go to next step
  2. CHECK BATTERY TERMINAL Check that the battery terminals are not loose or corroded. OK Battery terminals are not loose or corroded. NG --> REPAIR OR REPLACE BATTERY TERMINAL OK: Go to next step
  3. CHECK HARNESS AND CONNECTOR (ECM - BATTERY) Disconnect the cable from the negative (-) battery terminal. Disconnect the cable from the positive (+) battery terminal. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A39-1 (BATT) - Battery positive (+) terminal Always Below 1 ohms A39-1 (BATT) or Battery positive (+) terminal - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
  4. CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . Turn the ignition switch off and turn the Techstream off. Turn the ignition switch to ON and turn the Techstream on. Wait 5 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P0560 is output A DTC is not output B B --> See step 5 A --> See step 6
  5. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493954-S36145137532012081000000)
  6. REPLACE ECM. Refer to «REMOVAL»(ref-493957-S32385345752012081000000)
Related DTCsP0604: ECM range check
Required Sensors/Components (Main)ECM
Required Sensors/Components (Related)
Frequency of OperationContinuous
Duration6 times
MIL OperationImmediately
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentNone
RAM mirror checkFail

Note. After turning ignition switch off, waiting time may be required before disconnecting the cable from the negative (-) battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) battery terminal notices before proceeding with work. Refer to PRECAUTION .

  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
  4. Turn the Techstream off.
  5. Turn the ignition switch off.
  6. Disconnect the Techstream.
  7. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
  8. Connect the cable to the negative (-) battery terminal.
  9. Connect the Techstream to the DLC3.
  10. Turn the ignition switch to ON and turn the Techstream on.
  11. Wait 16 seconds or more.
  12. Enter the following menus: Powertrain / Engine / Trouble Codes.
  13. Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
  14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  15. Input the DTC: P0604.
  16. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
  17. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. READ DTC OUTPUT (DTC P0604) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . Turn the ignition switch off. Turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P0604 is output B B --> See step 3 A --> See step 2
  2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493954-S36145137532012081000000)
  3. REPLACE ECM. Refer to «REMOVAL»(ref-493957-S32385345752012081000000)
Related DTCP0606: ECM performance
Required sensors/Components (Main)ECM
Required sensors/Components (Related)
Frequency of OperationContinuous
DurationWithin 1 second
MIL OperationImmediately
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentNone
Battery voltage8 V or more
Ignition switchON
StarterOFF
Either of the following conditions is metCondition A or B
DMA communicationNo response
Watching from monitoring processorNot toggle
WARNINGAfter turning ignition switch off, waiting time may be required before disconnecting the cable from the negative (-) battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) battery terminal notices before proceeding with work. Refer to PRECAUTION .
  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
  4. Turn the Techstream off.
  5. Turn the ignition switch off.
  6. Disconnect the Techstream.
  7. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
  8. Connect the cable to the negative (-) battery terminal.
  9. Connect the Techstream to the DLC3.
  10. Turn the ignition switch to ON and turn the Techstream on.
  11. Wait 1 second or more.
  12. Enter the following menus: Powertrain / Engine / Trouble Codes.
  13. Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
  14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  15. Input the DTC: P0606.
  16. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
  17. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. READ OUTPUT DTC (DTC P0606) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . Turn the ignition switch off. Turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Wait 1 second or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P0606 is output B B --> See step 3 A --> See step 2
  2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493954-S36145137532012081000000)
  3. REPLACE ECM. Refer to «REMOVAL»(ref-493957-S32385345752012081000000)
Related DTCsP0607: Control module performance
Required sensors/Components (Main)ECM
Required sensors/Components (Related)Heated oxygen sensor
Frequency of operationContinuous
Duration60 seconds
MIL operationImmediately
Sequence of operationNone
Monitor runs whenever following DTCs are not presentNone
EngineRunning
Estimated heated oxygen sensor temperature450 to 800°C (842 to 1472°F)
Heated oxygen sensor transistorsFail

Scheme 607

Scheme 607: CONFIRMATION DRIVING PATTERN
  1. Stop the engine for 30 minutes or more [A].
  2. Connect the Techstream to the DLC3.
  3. Turn the ignition switch ON and turn the Techstream on.
  4. Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) [B].
  5. Turn the ignition switch off and wait for at least 30 seconds.
  6. Turn the ignition switch ON and turn the Techstream on [C].
  7. Start the engine, and wait 2 minutes [D].
  8. Warm up the engine until the engine coolant temperature is 75°C (167°F) or more [E].
  9. Idle the engine for 1 minute [F].
  10. Accelerate the vehicle to 80 km/h (50 mph) and stop the vehicle [G]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
  11. Drive the vehicle at 56 to 80 km/h (35 to 50 mph) for 5 minutes or more [H]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
  12. Enter the following menus: Powertrain / Engine / Trouble Codes [I].
  13. Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
  14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  15. Input the DTC: P0607, P0136, P0137, P0138, P0156, P0157 or P0158.
  16. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the result shows INCOMPLETE or N/A, perform steps [E] through [I] again.
  17. If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Related DTCsP060A: ECM, CPU error
Required sensors/Components (Main)ECM
Required sensors/Components (Related)
Frequency of operationContinuous
Duration
MIL operationImmediately
Sequence of operationNone
Monitor runs whenever following DTCs are not presentNone
Either of the following conditions is met1 or 2
1. All of the following conditions are met
CPU reset1 time or more
Learned throttle position - Learned accelerator pedal position0.4 V or more
Electronic throttle actuatorOFF
2. CPU reset2 times or more

Note. After turning ignition switch off, waiting time may be required before disconnecting the cable from the negative (-) battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) battery terminal notices before proceeding with work. Refer to PRECAUTION .

  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
  4. Turn the Techstream off.
  5. Turn the ignition switch off.
  6. Disconnect the Techstream.
  7. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
  8. Connect the cable to the negative (-) battery terminal.
  9. Connect the Techstream to the DLC3.
  10. Turn the ignition switch to ON and turn the Techstream on.
  11. Wait 16 seconds or more.
  12. Enter the following menus: Powertrain / Engine / Trouble Codes [B].
  13. Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
  14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  15. Input the DTC: P060A.
  16. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
  17. If the result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. READ OUTPUT DTC (DTC P060A) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . Turn the ignition switch off. Turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P060A is output B B --> See step 3 A --> See step 2
  2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493954-S36145137532012081000000)
  3. REPLACE ECM. Refer to «REMOVAL»(ref-493957-S32385345752012081000000)
Related DTCsP060B: Internal control module A/D processing performance
Required Sensors/Components (Main)ECM
Required Sensors/Components (Related)
Frequency of OperationContinuous
Duration2 times: Case 2 10 times: Case 1 30 times: Case 3 and 4
MIL OperationImmediately
Sequence of OperationNone
Monitor runs whenever the following DTCs are not storedNone
Both of the following conditions are met
Battery voltage8 V or higher
StarterOff

CASE 1 AND 4

Monitor runs whenever the following DTCs are not storedNone

CASE 2 AND 3

Internal module serial communicationFail

CASE 1

AD converterFail

CASE 2

Knock sensor circuitFail

CASE 3

Knock sensor serial communicationFail

CASE 4

Note. After turning ignition switch off, waiting time may be required before disconnecting the cable from the negative (-) battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) battery terminal notices before proceeding with work. Refer to PRECAUTION .

  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
  4. Turn the Techstream off.
  5. Turn the ignition switch off.
  6. Disconnect the Techstream.
  7. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
  8. Connect the cable to the negative (-) battery terminal.
  9. Connect the Techstream to the DLC3.
  10. Turn the ignition switch to ON and turn the Techstream on.
  11. Wait 16 seconds or more.
  12. Enter the following menus: Powertrain / Engine / Trouble Codes.
  13. Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
  14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  15. Input the DTC: P060B.
  16. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
  17. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. READ OUTPUT DTC (DTC P060B) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Wait for 16 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P060B is output B DTC P060B and P0327, P0328, P0332 or P0333 are output C B --> See step 3 C --> See step 4 A --> See step 2
  2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493954-S36145137532012081000000)
  3. REPLACE ECM. Refer to «REMOVAL»(ref-493957-S32385345752012081000000)
  4. GO TO DTC (P0327, P0328, P0332 AND P0333). Refer to «DTC P0327: Knock Sensor 1 Circuit Low Input (Bank 1 or Single Sensor); DTC P0328: Knock Sensor 1 Circuit High Input (Bank 1 or Single Sensor); DTC P0332: Knock Sensor 2 Circuit Low Input (Bank 2); DTC P0333: Knock Sensor 2 Circuit High Input (Bank 2)»(ref-494147-S14802106422012081000000)
Related DTCsP060D: Internal control module, accelerator pedal position
Required sensors/Components (Main)ECM
Required sensors/Components (Related)
Frequency of operationContinuous
Duration1 second
MIL operationImmediately
Sequence of operationNone
Monitor runs whenever following DTCs are not presentNone
Difference of main accelerator pedal position and sub accelerator pedal position0.3 V or higher

Note. After turning ignition switch off, waiting time may be required before disconnecting the cable from the negative (-) battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) battery terminal notices before proceeding with work. Refer to PRECAUTION .

  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
  4. Turn the Techstream off.
  5. Turn the ignition switch off.
  6. Disconnect the Techstream.
  7. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
  8. Connect the cable to the negative (-) battery terminal.
  9. Connect the Techstream to the DLC3.
  10. Turn the ignition switch to ON and turn the Techstream on.
  11. Wait 16 seconds or more.
  12. Enter the following menus: Powertrain / Engine / Trouble Codes.
  13. Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
  14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  15. Input the DTC: P060D.
  16. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
  17. If the result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. READ OUTPUT DTC (DTC P060D) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . Turn the ignition switch off. Turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P060D is output B B --> See step 3 A --> See step 2
  2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493954-S36145137532012081000000)
  3. REPLACE ECM. Refer to «REMOVAL»(ref-493957-S32385345752012081000000)
Related DTCsP060E: Internal control module and throttle position performance
Required Sensors/Components (Main)ECM
Required Sensors/Components (Related)
Frequency of OperationContinuous
Duration1 second: Case 1 13 times: Case 2
MIL OperationImmediate
Sequence of OperationNone
Monitor runs whenever the following DTCs are not storedNone

CASE 1

Monitor runs whenever the following DTCs are not storedNone
DMA communication errorNot detected

CASE 2

Difference of main throttle position and sub throttle position0.3 V or higher

CASE 1

Difference of main brake switch signal and sub brake switch signalDifferent

CASE 2

Note. After turning ignition switch off, waiting time may be required before disconnecting the cable from the negative (-) battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) battery terminal notices before proceeding with work. Refer to PRECAUTION .

  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
  4. Turn the Techstream off.
  5. Turn the ignition switch off.
  6. Disconnect the Techstream.
  7. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
  8. Connect the cable to the negative (-) battery terminal.
  9. Connect the Techstream to the DLC3.
  10. Turn the ignition switch to ON and turn the Techstream on.
  11. Wait 16 seconds or more.
  12. Enter the following menus: Powertrain / Engine / Trouble Codes.
  13. Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
  14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  15. Input the DTC: P060E.
  16. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
  17. If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. READ OUTPUT DTC (DTC P060E) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . Turn the Techstream off. Turn the ignition switch off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Wait for 16 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC is not output A DTC P060E is output B B --> See step 3 A --> See step 2
  2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493954-S36145137532012081000000)
  3. REPLACE ECM. Refer to «REMOVAL»(ref-493957-S32385345752012081000000)
Related DTCsP0617: Starter signal
Required Sensors/Components (Main)ST relay, park/neutral position switch assembly, ignition switch assembly
Required Sensors/Components (Related)Vehicle speed sensor, crankshaft position sensor
Frequency of OperationContinuous
Duration20 seconds
MIL OperationImmediately
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentNone
Battery voltage10.5 V or more
Vehicle speed20 km/h (12.43 mph) or more
Engine speed1000 RPM or more
StarterON

Scheme 608

Scheme 608: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
  4. Turn the ignition switch off and wait for at least 30 seconds.
  5. Turn the ignition switch to ON and turn the Techstream on [A].
  6. Idle the engine for 5 minutes or more [B].
  7. Enter the following menus: Powertrain / Engine / Trouble Codes [C].
  8. Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
  9. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  10. Input the DTC: P0617.
  11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [D] and [E].
  12. Drive the vehicle at 24 km/h (15 mph) or more for 20 seconds or more [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
  13. Check the DTC judgment result [E].
  14. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 609

Scheme 609: WIRING DIAGRAM

Scheme 610

Scheme 610
Related DTCsP062F: Internal control module EEPROM error
Required sensors/Components (Main)ECM
Required sensors/Components (Related)
Frequency of operationOnce per driving cycle
Duration3 times
MIL operationImmediately
Sequence of operationNone
Monitor runs whenever following DTCs are not presentNone
Time after engine start10 seconds or more
Battery voltage8 V or more
Ignition switchON
StarterOFF
Permanent fault code dataMismatch (3 times or more)

Note. After turning ignition switch off, waiting time may be required before disconnecting the cable from the negative (-) battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) battery terminal notices before proceeding with work. Refer to PRECAUTION .

  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
  4. Turn the Techstream off.
  5. Turn the ignition switch off.
  6. Disconnect the Techstream.
  7. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
  8. Connect the cable to the negative (-) battery terminal.
  9. Connect the Techstream to the DLC3.
  10. Turn the ignition switch to ON and turn the Techstream on.
  11. Start the engine and wait 30 seconds or more.
  12. Enter the following menus: Powertrain / Engine / Trouble Codes.
  13. Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
  14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  15. Input the DTC: P062F.
  16. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
  17. If the result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. READ OUTPUT DTC (DTC P062F) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . Turn the ignition switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and wait 30 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC is not output A DTC P062F is output B B --> See step 2 A --> See step 3
  2. REPLACE ECM. Refer to «REMOVAL»(ref-493957-S32385345752012081000000)
  3. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493954-S36145137532012081000000)
Related DTCsP0630: VIN not programmed
Required Sensors/Components (Main)ECM
Required Sensors/Components (Related)
Frequency of OperationContinuous
Duration0.325 seconds
MIL OperationImmediately
Sequence of OperationNone
Monitor runs whenever following DTCs are not presentNone
Battery voltage8 V or more
Ignition switchON
StarterOFF
VIN codeNot programmed
VIN codeProgrammed
  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
  4. Turn the ignition switch off and wait for at least 30 seconds.
  5. Turn the ignition switch to ON and turn the Techstream on.
  6. Wait 5 seconds or more.
  7. Enter the following menus: Powertrain / Engine / Trouble Codes.
  8. Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
  9. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  10. Input the DTC: P0630.
  11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
  12. If the result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. READ DTC OUTPUT Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0630 is output A DTC P0630 and other DTCs are output B If any DTCs other than P0630 are output, troubleshoot those DTCs first. NOTE: If P0630 is stored, the VIN must be input to the ECM using the Techstream. However, all DTCs are cleared automatically by the Techstream when inputting the VIN. If DTCs other than P0630 are stored, check them first. B --> See step 3 A: Go to next step
  2. INPUT VIN Input the VIN. Refer to «REGISTRATION»(ref-493954-S15033100892012081000000) . NEXT --> END
  3. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-493954-S26400840072012081000000)
Related DTCsP0657: Electronic throttle control system power supply
Required sensors/Components (Main)ECM
Required sensors/Components (Related)Throttle actuator
Frequency of operationOnce per driving cycle
Duration
MIL operationImmediately
Sequence of operationNone
Monitor runs whenever following DTCs are not presentNone
Throttle actuator power supply voltage7 V or more
Ignition switchON to off
Electric throttle actuator power supplyON

Note. After turning ignition switch off, waiting time may be required before disconnecting the cable from the negative (-) battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) battery terminal notices before proceeding with work. Refer to PRECAUTION .

  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
  4. Turn the ignition switch off
  5. Turn the Techstream off
  6. Disconnect the Techstream.
  7. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
  8. Connect the cable to the negative (-) battery terminal.
  9. Turn the ignition switch to ON.
  10. Wait 10 seconds or more.
  11. Turn the ignition switch off.
  12. Wait 15 seconds or more.
  13. Connect the Techstream to the DLC3.
  14. Turn the ignition switch to ON.
  15. Turn the Techstream on
  16. Wait 5 seconds or more.
  17. Enter the following menus: Powertrain / Engine / Trouble Codes [B].
  18. Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
  19. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  20. Input the DTC: P0657.
  21. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
  22. If the result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
  1. READ DTC OUTPUT (DTC P0657) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . Turn the ignition switch off. Turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Turn the ignition switch to ON. Wait 10 seconds or more. Turn the ignition switch off. Wait 15 seconds or more. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Wait 5 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Check for DTCs. RESULT Result Proceed to DTC is not output A DTC P0657 is output B B --> See step 3 A --> See step 2
  2. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493954-S36145137532012081000000)
  3. REPLACE ECM. Refer to «REMOVAL»(ref-493957-S32385345752012081000000)
Related DTCsP0705: Park/neutral position switch/verify switch input
Required sensors/Components (Main)Park/neutral position switch assembly
Required sensors/Components (Related)
Frequency of operationContinuous
Duration2 seconds: Case 1 and 3 60 seconds: Case 2
MIL operation2 driving cycles
Sequence of operationNone
Monitor runs whenever following DTCs are not presentNone
All of the following conditions are met
Battery voltage10.5 V or more
Ignition switchON
StarterOff

ALL

One of the following conditions is met(a), (b), (c) or (d)
(a) Park position switchOn
(b) Neutral position switchOn
(c) Park/neutral position switchOn
(d) R range position switchOn

CASE 3

Any two of the following conditions are met1, 2 and 3
1, One of the following conditions is met(a), (b) or (c)
(a) Park position switchOn
(b) Neutral position switchOn
(c) Park/neutral position switchOn
2, R range position switchOn
3, D range position switchOn

CASE 1

All of the following conditions are met
Park position switchOff
Neutral position switchOff
Park/neutral position switchOff
R range position switchOff
D range position switchOff

CASE 2

S/M range position switchOn

CASE 3

Park/neutral position switchThe park/neutral position switch assembly sends only one signal to the ECM.
  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
  4. Turn the ignition switch off and wait for at least 30 seconds.
  5. Turn the ignition switch to ON and turn the Techstream on [A].
  6. Move the shift lever to R and wait 2 seconds or more.
  7. Move the shift lever to N and wait 2 seconds or more.
  8. Move the shift lever to D and wait 2 seconds or more.
  9. Move the shift lever to S and wait 2 seconds or more.
  10. Move the shift lever to P and wait 2 seconds or more.
  11. Wait 1 minute or more.
  12. Enter the following menus: Powertrain / Engine / Trouble Codes [B].
  13. Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
  14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  15. Input the DTC: P0705.
  16. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
  17. If the result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 611

Scheme 611: WIRING DIAGRAM
Related DTCsP0724: Stop light switch/Rationality
Required sensors/Components (Main)Stop light switch assembly
Required Sensors/Components (Related)Speed sensor
Frequency of operationContinuous
DurationGO and STOP 5 times
MIL operation2 driving cycles
Sequence of operationNone
Monitor runs whenever following DTCs are not presentNone
Ignition switchON
StarterOFF
Battery voltage8 V or more
GO: Vehicle speed30 km/h (18.65 mph) or more
STOP: Vehicle speedLess than 3 km/h (1.86 mph)
Stop light switch statusON stuck

Scheme 612

Scheme 612: CONFIRMATION DRIVING PATTERN
  1. Connect the Techstream to the DLC3.
  2. Turn the ignition switch to ON and turn the Techstream on.
  3. Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
  4. Turn the ignition switch off and wait for at least 30 seconds.
  5. Turn the ignition switch to ON and turn the Techstream on [A].
  6. Wait 5 seconds after clear the DTCs.
  7. Enter the following menus: Powertrain / Engine / Trouble Codes [B].
  8. Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
  9. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
  10. Input the DTC: P0724.
  11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [C] through [E].
  12. Start the engine [C].
  13. Accelerate the vehicle to 30 km/h (18.65 mph) or more, depress the brake pedal and decelerate the vehicle to 3 km/h (1.86 mph) or less [D]. Repeat step [D] 5 times. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
  14. Check the DTC judgment result [E].
  15. If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
