MONITOR STRATEGY
| Related DTCs | P0010: Camshaft timing oil control valve assembly (for intake side of bank 1) range check P0020: Camshaft timing oil control valve assembly (for intake side of bank 2) range check |
| Required sensors / components (Main) | Camshaft timing oil control valve assembly (for intake side) |
| Required sensors / components (Related) | |
| Frequency of operation | Continuous |
| Duration | 1 second |
| MIL operation | Immediately |
| Sequence of operation | None |
TYPICAL ENABLING CONDITIONS
| Monitor runs whenever following DTCs are not present | None |
| All of the following conditions are met | |
| Starter | OFF |
| Ignition switch | ON |
| Time after ignition switch off to ON | 0.5 seconds or more |
TYPICAL MALFUNCTION THRESHOLDS
| One of the following conditions is met | A, B, or C |
| A. All of the following conditions are met | |
| Battery voltage | 11 V or more, and less than 13 V |
| Target duty cycle | Less than 70% |
| Output duty cycle | 100% or more |
| B. All of the following conditions are met | |
| Battery voltage | 13 V or more |
| Target duty cycle | Less than 80% |
| Output duty cycle | 100% or more |
| C. Both of the following conditions are met | |
| Current cut status | Not cut |
| Output duty cycle | 3% or less |
COMPONENT OPERATING RANGE
| Output duty cycle | More than 3%, and less than 100% |
CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Wait 5 seconds.
- Enter the following menus: Powertrain / Engine / Trouble Code.
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0010 or P0020.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 665
Scheme 665: WIRING DIAGRAM
PROCEDURE
- CHECK DTC (DTC P0010 OR P0020) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P0010 is output A DTC P0020 is output B B --> See step 3 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT SYSTEM (BANK 1)) Check the engine speed while operating the camshaft timing oil control valve assembly (for intake side of bank 1) using the Techstream. Refer to «ON-VEHICLE INSPECTION»(ref-493957-S40895437272012081000000) . NG --> See step 4 OK --> See step 6
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT SYSTEM (BANK 2)) Check the engine speed while operating the camshaft timing oil control valve assembly (for intake side of bank 2) using the Techstream. Refer to «ON-VEHICLE INSPECTION»(ref-493957-S40895437272012081000000) . NG --> See step 4 OK --> See step 6
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE SIDE) Inspect the camshaft timing oil control valve assembly (for intake side). Refer to «INSPECTION»(ref-493957-S04256368282012081000000) . NG --> See step 7 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE SIDE) - ECM) Disconnect the camshaft timing oil control valve assembly (for intake side) connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B18-1 - B1-58 (OC1+) Always Below 1 ohms B18-2 - B1-57 (OC1-) Always Below 1 ohms B19-1 - B1-52 (OC2+) Always Below 1 ohms B19-2 - B1-51 (OC2-) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B18-1 or B1-58 (OC1+) - Body ground Always 10 kohms or higher B18-2 or B1-57 (OC1-) - Body ground Always 10 kohms or higher B19-1 or B1-52 (OC2+) - Body ground Always 10 kohms or higher B19-2 or B1-51 (OC2-) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 8
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493954-S36145137532012081000000)
- REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE SIDE). Refer to «REMOVAL»(ref-493957-S17304517712012081000000)
- REPLACE ECM. Refer to «REMOVAL»(ref-493957-S32385345752012081000000)
| Related DTCs | P0011: Advanced camshaft timing (bank 1) P0012: Retarded camshaft timing (bank 1) P0021: Advanced camshaft timing (bank 2) P0022: Retarded camshaft timing (bank 2) |
| Required Sensors/Components (Main) | Camshaft timing oil control valve assembly (for intake side) Camshaft timing gear assembly |
| Required Sensors/Components (Related) | Crankshaft position sensor, VVT sensor and engine coolant temperature sensor |
| Frequency of Operation | Continuous |
| Duration | Within 10 seconds |
| MIL Operation | Advanced camshaft timing: Immediately Retarded camshaft timing: 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | P0010, P0020 (Camshaft timing oil control valve bank 1, 2) P0016, P0018 (VVT system bank 1, 2 - misalignment) P0102, P0103 (Mass air flow meter) P0115, P0117, P0118 (Engine coolant temperature sensor) P0125 (Insufficient engine coolant temperature for closed loop control) P0335 (Crankshaft position sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) |
| Battery voltage | 11 V or more |
| Engine speed | 500 to 4000 RPM |
| Engine coolant temperature | 75 to 100°C (167 to 212°F) |
| Both of the following conditions are met | |
| Deviation of actual valve timing and target valve timing | More than 5°CA (Crankshaft Angle) for 5 seconds or more after the VVT hold duty ratio learned value reaches the upper or lower limit. |
| Valve timing | No change at advanced valve timing |
| Both of the following conditions are met | |
| Deviation of actual valve timing and target valve timing | More than 5°CA (Crankshaft Angle) for 5 seconds or more after the VVT hold duty ratio learned value reaches the upper or lower limit. |
| Valve timing | No change at retarded valve timing |
MONITOR RESULT
Refer to the Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
Scheme 666
Scheme 666: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more [B].
- Drive the vehicle at approximately 60 km/h (37 mph) for 10 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Idle the engine for 3 minutes or more [D].
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0011, P0012, P0021 or P0022.
- Check the DTC judgment result [E]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [F] through [H].
- Repeat the pattern of accelerating the vehicle from rest to approximately 60 km/h (37 mph) and then decelerating the vehicle 10 to 15 times [F]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Depress the accelerator pedal by a large amount.
- Idle the engine for 3 minutes or more [G].
- Enter the following menus: Powertrain / Engine / Trouble Codes [H].
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Check the DTC judgment result again. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform the following procedure.
- Perform universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If permanent DTC is not output, the system is normal.
| Related DTCs | P0013: Camshaft timing oil control valve assembly (for exhaust side of bank 1) range check P0023: Camshaft timing oil control valve assembly (for exhaust side of bank 2) range check |
| Required sensors/Components (Main) | Camshaft timing oil control valve assembly (for exhaust side) |
| Required sensors/Components (Related) | |
| Frequency of operation | Continuous |
| Duration | 1 second |
| MIL operation | Immediately |
| Sequence of operation | None |
| Monitor runs whenever following DTCs are not present | None |
| All of the following conditions are met | |
| Starter | OFF |
| Ignition switch | ON |
| Time after ignition switch off to ON | 0.5 seconds or more |
| One of the following conditions is met | A, B or C |
| A. All of the following conditions are met | |
| Battery voltage | 11 V or more, and less than 13 V |
| Target duty cycle | Less than 70% |
| Output duty cycle | 100% or more |
| B. All of the following conditions are met | |
| Battery voltage | 13 V or more |
| Target duty cycle | Less than 80% |
| Output duty cycle | 100% or more |
| C. Both of the following conditions are met | |
| Current cut status | Not cut |
| Output duty cycle | 3% or less |
| Output duty cycle | More than 3%, and less than 100% |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Wait 5 seconds.
- Enter the following menus: Powertrain / Engine / Trouble Code.
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0013 or P0023.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 667
Scheme 667: WIRING DIAGRAM
- CHECK DTC (DTC P0013 OR P0023) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0013 is output A DTC P0023 is output B B --> See step 3 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT EXHAUST LINEAR (BANK 1)) Check the engine speed while operating the camshaft timing oil control valve assembly (for exhaust side of bank 1) using the Techstream. Refer to «ON-VEHICLE INSPECTION»(ref-493957-S40895437272012081000000) . NG --> See step 4 OK --> See step 6
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT EXHAUST LINEAR (BANK 2)) Check the engine speed while operating the camshaft timing oil control valve assembly (for exhaust side of bank 2) using the Techstream. Refer to «ON-VEHICLE INSPECTION»(ref-493957-S40895437272012081000000) . NG --> See step 4 OK --> See step 6
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST SIDE) Inspect the camshaft timing oil control valve assembly (for exhaust side). Refer to «INSPECTION»(ref-493957-S04256368282012081000000) . NG --> See step 7 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST SIDE) - ECM) Disconnect the camshaft timing oil control valve assembly (for exhaust side) connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B38-1 - B1-56 (OE1+) Always Below 1 ohms B38-2 - B1-55 (OE1-) Always Below 1 ohms B35-1 - B1-50 (OE2+) Always Below 1 ohms B35-2 - B1-49 (OE2-) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B38-1 or B1-56 (OE1+) - Body ground Always 10 kohms or higher B38-2 or B1-55 (OE1-) - Body ground Always 10 kohms or higher B35-1 or B1-50 (OE2+) - Body ground Always 10 kohms or higher B35-2 or B1-49 (OE2-) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 8
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493954-S36145137532012081000000)
- REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST SIDE). Refer to «REMOVAL»(ref-493957-S17304517712012081000000)
- REPLACE ECM. Refer to «REMOVAL»(ref-493957-S32385345752012081000000)
| Related DTCs | P0014: Advanced camshaft timing (bank 1) P0015: Retarded camshaft timing (bank 1) P0024: Advanced camshaft timing (bank 2) P0025: Retarded camshaft timing (bank 2) |
| Required sensors/components (Main) | Camshaft timing oil control valve assembly (for exhaust side) Camshaft timing exhaust gear assembly |
| Required sensors/components (Related) | Crankshaft position sensor, VVT sensor and engine coolant temperature sensor |
| Frequency of operation | Continuous |
| Duration | Within 10 seconds |
| MIL operation | Advanced camshaft timing: 2 driving cycles Retarded camshaft timing: Immediately |
| Sequence of operation | None |
| Monitor runs whenever following DTCs are not present | P0013, P0023 (Exhaust camshaft timing oil control valve bank 1, 2) P0017, P0019 (Exhaust VVT system bank 1, 2 - misalignment) P0102, P0103 (Mass air flow meter) P0115, P0117, P0118 (Engine coolant temperature sensor) P0125 (Insufficient engine coolant temperature for closed loop control) P0335 (Crankshaft position sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) |
| Battery voltage | 11 V or more |
| Engine speed | 500 to 4000 RPM |
| Engine coolant temperature | 75 to 100°C (167 to 212°F) |
| Both of the following conditions are met | |
| Deviation of actual valve timing and target valve timing | More than 5°CA (Crankshaft Angle) for 5 seconds or more after the VVT hold duty ratio learned value reaches the upper or lower limit. |
| Valve timing | No change at advanced valve timing |
| Both of the following conditions are met | |
| Deviation of actual valve timing and target valve timing | More than 5°CA (Crankshaft Angle) for 5 seconds or more after the VVT hold duty ratio learned value reaches the upper or lower limit. |
| Valve timing | No change at retarded valve timing |
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
Scheme 668
Scheme 668: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more [B].
- Drive the vehicle at approximately 60 km/h (37 mph) for 10 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Idle the engine for 3 minutes or more [D].
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0014, P0015, P0024 or P0025.
- Check the DTC judgment result [E]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [F] through [H].
- Repeat the pattern of accelerating the vehicle from rest to approximately 60 km/h (37 mph) and then decelerating the vehicle 10 to 15 times [F]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Depress the accelerator pedal by a large amount.
- Idle the engine for 3 minutes or more [G].
- Enter the following menus: Powertrain / Engine / Trouble Codes [H].
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Check the DTC judgment result again. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform the following procedure.
- Perform universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If permanent DTC is not output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0014, P0015, P0024 OR P0025) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P0014, P0015, P0024 or P0025 is output A DTC P0014, P0015, P0024 or P0025 and other DTCs are output B HINT: If any DTCs other than P0014, P0015, P0024 or P0025 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT EXHAUST LINEAR (BANK 1 OR 2)) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Exhaust Linear (Bank 1) or Control the VVT Exhaust Linear (Bank 2). Check the engine speed while operating the camshaft timing oil control valve assembly (for exhaust camshaft) using the Techstream. OK Techstream Operation Engine Condition 0% Normal engine speed 100% Engine idles roughly or stalls HINT: Refer to "Data List / Active Test" [VVT Ex OCV Duty #1, VVT Ex Chg Angle #1, VVT Ex OCV Duty #2 and VVT Ex Chg Angle #2]. Refer to «DATA LIST / ACTIVE TEST»(ref-493954-S11583093352012081000000) . NG --> See step 6 OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0014, P0015, P0024 OR P0025) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P0014, P0015, P0024 or P0025. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P0014, P0015, P0024 or P0025 is output) B B --> See step 6 A --> See step 5
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-493954-S26400840072012081000000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493954-S36145137532012081000000)
- CHECK VALVE TIMING (CHECK FOR LOOSE OR JUMPED TEETH ON TIMING CHAIN) Remove the cylinder head cover sub-assemblies RH and LH. Turn the crankshaft to align the matchmarks of the crankshaft. Align the notch of the crankshaft pulley to the "0" position. Check if the timing marks of the camshaft pulley and camshaft bearing cap align. TEXT IN ILLUSTRATION *a Timing Mark Turn the crankshaft clockwise 360° if the timing marks do not align. Check if they align once again. OK The timing marks of the camshaft pulley and the camshaft bearing cap align when the notch of the crankshaft pulley is in the "0" position. NG --> See step 11 OK: Go to next step
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST SIDE) Inspect the camshaft timing oil control valve assembly (for exhaust side). Refer to «INSPECTION»(ref-493957-S04256368282012081000000) . NG --> See step 12 OK: Go to next step
- INSPECT OIL CONTROL VALVE FILTER AND OIL PIPE Remove the No. 1 oil pipe or No. 2 oil pipe. TEXT IN ILLUSTRATION *1 No. 2 oil pipe *2 No. 1 oil pipe Remove the oil control valve filter RH or oil control valve filter LH. Check that the oil control valve filter and oil pipe are not clogged. OK The oil control valve filter and oil pipe are not clogged. NG --> See step 13 OK: Go to next step
- REPLACE CAMSHAFT TIMING EXHAUST GEAR ASSEMBLY (BANK 1 OR 2) Replace the camshaft timing exhaust gear assembly (bank 1 or bank 2). Refer to «REMOVAL»(ref-494105-S24168900872012081000000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P0014, P0015, P0024 or P0025. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P0014, P0015, P0024 or P0025 is output) B HINT: DTC P0014, P0015, P0024 or P0025 is output when foreign objects in engine oil are caught in some parts of the system. These codes will remain stored even if the system returns to normal after a short time. These foreign objects may then be captured by the oil filter, thus eliminating the source of the problem. B --> See step 14 A --> END
- ADJUST VALVE TIMING. Refer to «INSTALLATION»(ref-494105-S37944614382012081000000)
- REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST SIDE). Refer to «REMOVAL»(ref-493957-S17304517712012081000000)
- REPLACE OIL CONTROL VALVE FILTER OR OIL PIPE. Refer to «DISASSEMBLY»(ref-494105-S28256061492012081000000)
- REPLACE ECM. Refer to «REMOVAL»(ref-493957-S32385345752012081000000)
| Related DTCs | P0016: Crankshaft position - Camshaft position misaligned at idling (bank 1) P0018: Crankshaft position - Camshaft position misaligned at idling (bank 2) |
| Required Sensors / Components (Main) | VVT actuator |
| Required Sensors / Components (Related) | VVT sensor, crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | Within 1 minute |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | P0010, P0020 (Camshaft timing oil control valve bank 1, 2) P0102, P0103 (Mass air flow meter) P0115, P0117, P0118 (Engine coolant temperature sensor) P0125 (Insufficient engine coolant temperature for closed loop control) P0335 (Crankshaft position sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) |
| Engine speed | 500 to 1000 RPM |
| One of the following conditions is met | Condition A, B, C or D |
| A. VVT learning value at maximum retarded valve timing (bank 1) | Less than 18.5°CA (Crankshaft angle) |
| B. VVT learning value at maximum retarded valve timing (bank 2) | Less than 18.5°CA (Crankshaft angle) |
| C. VVT learning value at maximum retarded valve timing (bank 1) | More than 43.5°CA (Crankshaft angle) |
| D. VVT learning value at maximum retarded valve timing (bank 2) | More than 43.5°CA (Crankshaft angle) |
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0016 OR P0018) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P0016 or P0018 is output A DTC P0016 or P0018 and other DTCs are output B HINT: If any DTCs other than P0016 or P0018 are output, troubleshoot those DTCs first. B --> See step 8 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT LINER (BANK 1 OR 2)) HINT: If the VVT system can be operated through the Active Test, it can be assumed that the VVT system is operating normally. Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Linear (Bank 1) or Control the VVT Linear (Bank 2) / VVT Change Angle #1 or VVT Change Angle #2. Perform the Active Test. Check that the displacement angle varies. OK Displacement angle varies. NG --> See step 4 OK: Go to next step
- ADJUST VALVE TIMING Adjust valve timing. Refer to «INSTALLATION»(ref-494105-S37944614382012081000000) . NEXT --> See step 7
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE SIDE) Inspect the camshaft timing oil control valve assembly (for intake side). Refer to «INSPECTION»(ref-493957-S04256368282012081000000) . NG --> See step 9 OK: Go to next step
- INSPECT OIL CONTROL VALVE FILTER AND OIL PIPE Remove the No. 1 oil pipe or No. 2 oil pipe. TEXT IN ILLUSTRATION *1 No. 2 oil pipe *2 No. 1 oil pipe Remove the oil control valve filter RH or oil control valve filter LH. Check that the oil control valve filter and oil pipe are not clogged. OK The oil control valve filter and oil pipe are not clogged. NG --> See step 10 OK: Go to next step
- REPLACE CAMSHAFT TIMING GEAR ASSEMBLY (BANK 1 OR 2) Replace the camshaft timing gear assembly (bank 1 or bank 2). Refer to «REMOVAL»(ref-494105-S24168900872012081000000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P0016 or P0018. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P0016 or P0018 is output) B HINT: DTC P0016 or P0018 is output when foreign objects in engine oil are caught in some parts of the system. These codes will remain stored even if the system returns to normal after a short time. These foreign objects may then be captured by the oil filter, thus eliminating the source of the problem. B --> See step 11 A --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-493954-S26400840072012081000000)
- REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE SIDE). Refer to «REMOVAL»(ref-493957-S17304517712012081000000)
- REPLACE OIL PIPE OR OIL CONTROL VALVE FILTER. Refer to «DISASSEMBLY»(ref-494105-S28256061492012081000000)
- REPLACE ECM. Refer to «REMOVAL»(ref-493957-S32385345752012081000000)
| Related DTCs | P0017: Exhaust valve timing misalignment at idling (bank 1) P0019: Exhaust valve timing misalignment at idling (bank 2) |
| Required Sensors/Components (Main) | Camshaft timing exhaust gear assembly |
| Required Sensors/Components (Related) | VVT sensor, crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | Within 1 minute |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | P0013, P0023 (Exhaust camshaft timing oil control valve bank 1, 2) P0102, P0103 (Mass air flow meter) P0115, P0117, P0118 (Engine coolant temperature sensor) P0125 (Insufficient engine coolant temperature for closed loop) P0335 (Crankshaft position sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) |
| Engine speed | 500 to 1000 RPM |
| One of the following conditions is met | Condition A, B, C or D |
| A. VVT learning value at maximum advanced valve timing (bank 1) | Less than 77°CA (Crankshaft angle) |
| B. VVT learning value at maximum advanced valve timing (bank 2) | Less than 77°CA (Crankshaft angle) |
| C. VVT learning value at maximum advanced valve timing (bank 1) | More than 102°CA (Crankshaft angle) |
| D. VVT learning value at maximum advanced valve timing (bank 2) | More than 102°CA (Crankshaft angle) |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more [B].
- Idle the engine for 5 minutes or more [C].
- Enter the following menus: Powertrain / Engine / Trouble Codes [D].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0017 or P0019.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the result shows INCOMPLETE or N/A, perform steps [E] through [G].
- Drive the vehicle for 2 to 3 minutes [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Idle the engine for 5 minutes or more [F].
- Enter the following menus: Powertrain / Engine / Trouble Codes [G].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Check the DTC judgment result.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0017 OR P0019) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P0017 or P0019 is output A DTC P0017 or P0019 and other DTCs are output B HINT: If any DTCs other than P0017 or P0019 are output, troubleshoot those DTCs first. B --> See step 8 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT EXHAUST LINEAR (BANK 1 OR 2)) HINT: If the VVT system can be operated through the Active Test, it can be assumed that the VVT system is operating normally. Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Exhaust Linear (Bank 1) or Control the VVT Exhaust Linear (Bank 2) / VVT Ex Chg Angle #1 or VVT Ex Chg Angle #2. Perform the Active Test. Check that the displacement angle varies. OK Displacement angle varies. NG --> See step 4 OK: Go to next step
- ADJUST VALVE TIMING Adjust valve timing. Refer to «INSTALLATION»(ref-494105-S37944614382012081000000) . NG --> See step 7 OK: Go to next step
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST SIDE) Inspect the camshaft timing oil control valve assembly (for exhaust side). Refer to «INSPECTION»(ref-493957-S04256368282012081000000) . NG --> See step 9 OK: Go to next step
- INSPECT OIL CONTROL VALVE FILTER AND OIL PIPE Remove the No. 1 oil pipe or No. 2 oil pipe. TEXT IN ILLUSTRATION *1 No. 2 oil pipe *2 No. 1 oil pipe Remove the oil control valve filter RH or oil control valve filter LH. Check that the oil control valve filter and oil pipe are not clogged. OK The oil control valve filter and oil pipe are not clogged. NG --> See step 10 OK: Go to next step
- REPLACE CAMSHAFT TIMING EXHAUST GEAR ASSEMBLY (BANK 1 OR 2) Replace the camshaft timing exhaust gear assembly (bank 1 or bank 2). Refer to «REMOVAL»(ref-494105-S24168900872012081000000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P0017 or P0019. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P0017 or P0019 is output) B HINT: DTC P0017 or P0019 is output when foreign objects in engine oil are caught in some parts of the system. These codes will remain stored even if the system returns to normal after a short time. These foreign objects may then be captured by the oil filter, thus eliminating the source of the problem. B --> See step 11 A --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-493954-S26400840072012081000000)
- REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST SIDE). Refer to «REMOVAL»(ref-493957-S17304517712012081000000)
- REPLACE OIL PIPE OR OIL CONTROL VALVE FILTER. Refer to «DISASSEMBLY»(ref-494105-S28256061492012081000000)
- REPLACE ECM. Refer to «REMOVAL»(ref-493957-S32385345752012081000000)
| Related DTCs | P0031: Air fuel ratio sensor heater (bank 1 sensor 1) heater current (Low electrical current) P0032: Air fuel ratio sensor heater (bank 1 sensor 1) heater current (High electrical current) P0051: Air fuel ratio sensor heater (bank 2 sensor 1) heater current (Low electrical current) P0052: Air fuel ratio sensor heater (bank 2 sensor 1) heater current (High electrical current) P101D: Air fuel ratio sensor (bank 1 sensor 1) heater performance P103D: Air fuel ratio sensor (bank 2 sensor 1) heater performance |
| Required sensors/Components (Main) | Air fuel ratio sensor heater |
| Required sensors/Components (Related) | |
| Frequency of operation | Continuous |
| Duration | 1 second: P101D and P103D 10 seconds: P0031 and P0051 10.24 seconds: P0032 and P0052 |
| MIL operation | Immediately |
| Sequence of operation | None |
| Monitor runs whenever following DTCs are not present | None |
| All of the following conditions are met | |
| Battery voltage | 10.5 V or higher |
| Time after heater on | 5 seconds or more |
| Active heater off control | Not operating |
| Active heater on control | Not operating |
| Air fuel ratio sensor heater performance fail (P101D, P103D) | Not detected |
| Heater output duty cycle | 30% or higher |
| All of the following conditions are met | |
| Battery voltage | 10.5 V or higher |
| Time after heater on | 5 seconds or more |
| Heater output duty cycle | Higher than 0% |
| Active heater off control | Not operating |
| Active heater on control | Not operating |
| All of the following conditions are met | |
| Battery voltage | 10.5 V or higher |
| Time after heater on | 5 seconds or more |
| Air fuel ratio sensor heater low current fail (P0031, P0051) | Not detected |
| Heater output duty cycle | 10% or higher, and less than 60% |
| Heater on current | 0.8 A or higher |
| Active heater off control | Not operating |
| Active heater on control | Not operating |
| Heater on current | Less than 0.8 A |
| Both of the following conditions are met | |
| Heater output | ON |
| Hybrid IC high current limiter monitor input | Fail |
| All of the following conditions are met | |
| Hybrid IC high current limiter monitor input | Fail |
| Heater off current | Higher than 11 A |
| Heater on current | 0.8 A or more |
| Both of the following conditions are met | |
| Heater output | ON |
| Hybrid IC high current limiter monitor input | Pass |
| Heater off current | 11 A or less |
Scheme 669
Scheme 669: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and idle it for 5 minutes or more [B].
- With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 3000 RPM for 1 minute [C].
- Idle the engine for 5 minutes or more [D].
- Enter the following menus: Powertrain / Engine / Trouble Codes [E].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0031, P0032, P0051, P0052, P101D or P103D.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit
- If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [E] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0037: Heated oxygen sensor heater (bank 1 sensor 2) heater current (Low electrical current) P0038: Heated oxygen sensor heater (bank 1 sensor 2) heater current (High electrical current) P0057: Heated oxygen sensor heater (bank 2 sensor 2) heater current (Low electrical current) P0058: Heated oxygen sensor heater (bank 2 sensor 2) heater current (High electrical current) P0141: Heated oxygen sensor heater performance (bank 1 sensor 2) P0161: Heated oxygen sensor heater performance (bank 2 sensor 2) P102D: Heated oxygen sensor (bank 1 sensor 2) heater performance P105D: Heated oxygen sensor (bank 2 sensor 2) heater performance |
| Required sensors/Components (Main) | Heated oxygen sensor heater |
| Required sensors/Components (Related) | |
| Frequency of operation | Continuous: P0037, P0038, P0057, P0058, P102D and P105D Once per driving cycle: P0141 and P0161 |
| Duration | 0.5 seconds: P0037, P0057, P102D and P105D Within 3 seconds: P0038 and P0058 10 seconds: P0141 and P0161 |
| MIL operation | Immediately: P0037, P0038, P0057, P0058, P102D and P105D 2 driving cycles: P0141 and P0161 |
| Sequence of operation | None |
| Monitor runs whenever following DTCs are not stored | None |
| All of the following conditions are met | |
| Battery voltage | 10.5 V or higher |
| Engine | Running |
| Starter | Off |
| Catalyst active air fuel ratio control | Not operating |
| Time after heater on | 10 seconds or more |
| Learned heater off current operation | Completed |
| Learned heater off current operation | Succeeded |
| Heated oxygen sensor heater high current fail (P0038, P0058) | Not detected |
| Heater on current - Learned heater off current | 0.3 A or less |
| Heater output | ON |
| All of the following conditions are met | |
| Battery voltage | 10.5 V or higher |
| Engine | Running |
| Starter | OFF |
| Catalyst active air fuel ratio control | Not operating |
| Time after heater on | 10 seconds or more |
| Learned heater off current operation | Completed |
| Heater off current | Higher than 3.5 A |
| Hybrid IC high current limiter monitor input | Fail |
| Heated oxygen sensor heater high current fail (P0038 P0058) | Not detected |
| All of the following conditions are met | |
| Battery voltage | 10.5 V or higher |
| Engine | Running |
| Starter | OFF |
| Catalyst active air fuel ratio control | Not operating |
| Time after heater on | 10 seconds or more |
| Learned heater off current operation | Completed |
| All of the following conditions are met | |
| Heated oxygen sensor heater circuit fail (P0037, P0038, P0057, P0058, P102D and P105D) | Not detected |
| Battery voltage | 10.5 V or higher |
| Fuel cut | OFF |
| Time after fuel cut on to off | 30 seconds or more |
| Accumulated heater on time | 100 seconds or more |
| Learned heater off current operation | Completed |
| Duration that rear heated oxygen sensor impedance is less than 15 kohms | 2 seconds or more |
| All of the following conditions are met | |
| Battery voltage | 10.5 V or higher |
| Engine | Running |
| Starter | OFF |
| Catalyst active air fuel ratio control | Not operating |
| Time after heater on | 10 seconds or more |
| Learned heater off current operation | Completed |
| Oxygen sensor heater low current fail (P0037, P0057) | Not detected |
| Oxygen sensor heater high current fail (P0038, P0058) | Not detected |
| Heater on current - learned heater off current | 0.3 A or less |
| Heater on current | 1 A or less |
| Both of the following conditions are met | |
| Hybrid IC high current limiter monitor input | Fail |
| Heater output | ON |
| Heater resistance | Varies with sensor element temperature (Example: Higher than 23 ohms) |
| Heater on current | Higher than 1 A |
| Heated oxygen sensor heater current | 0.3 to 1 A (when engine idles, heated oxygen sensor warmed up and battery voltage 11 to 14 V) |
Scheme 670
Scheme 670: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and idle it for 5 minutes or more [B].
- With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 3000 RPM for 1 minute [C].
- Idle the engine for 5 minutes or more [D].
- Enter the following menus: Powertrain / Engine / Trouble Codes [E].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0037, P0038, P0057, P0058, P102D or P105D.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit
- If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [E] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0101: Mass air flow meter rationality |
| Required Sensors / Components (Main) | Mass air flow meter |
| Required Sensors / Components (Related) | Crankshaft position sensor, engine coolant temperature sensor and throttle position sensor, VVT sensor |
| Frequency of Operation | Continuous |
| Duration | 10 times |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Throttle position (Throttle position sensor voltage) | 0.2 V or higher, and less than 2 V |
| Time after engine start | 5 seconds or more |
| Battery voltage | 10.5 V or more |
| Engine coolant temperature | 70°C (158°F) or more |
| Estimated load | 30% or more and less than 70% |
| Mass air flow meter sensor circuit fail (P0102, P0103) | Not detected |
| Intake air temperature sensor circuit fail (P0112, P0113) | Not detected |
| Engine coolant temperature sensor circuit fail (P0115, P0117, P0118) | Not detected |
| Throttle position sensor circuit fail (P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135) | Not detected |
| Canister pressure sensor circuit fail (P0452, P0453) | Not detected |
| Crankshaft position sensor circuit fail (P0335) | Not detected |
| EVAP leak detection pump fail (P2401, P2402) | Not detected |
| EVAP vent valve fail (P2419, P2420) | Not detected |
| Both of the following conditions 1 and 2 met | 1 and 2 |
| 1, Averaged engine load value ratio | Less than 0.85%, or more than 1.15% (varies with estimated engine load) |
| 2, Averaged air fuel ratio | Less than -20 %, or more than 20 % |
Scheme 671
Scheme 671: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Start the engine and warm it up until the engine coolant temperature reaches 70°C (158°F) or more [A].
- Drive the vehicle at approximately 80 km/h (50 mph) to 112 km/h (70 mph) for 5 minutes or more [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive while keeping the engine load as stable as possible.
- Enter the following menus: Powertrain / Engine / Trouble Codes [C].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0101.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [C] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0101) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0101 is output A DTC P0101 and other DTCs are output B HINT: If any DTCs other than P0101 are output, troubleshoot those DTCs first. B --> See step 6 A: Go to next step
- CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. OK No leaks from intake system. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
- CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. Refer to «COMPONENTS»(ref-494115-S38183353702012081000000) . OK PCV valve and hose are connected correctly and are not damaged. NG --> REPAIR OR REPLACE PCV HOSE OK: Go to next step
- REPLACE MASS AIR FLOW METER Replace the mass air flow meter. Refer to «REMOVAL»(ref-493957-S12273208142012081000000) . NEXT: Go to next step
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P0101. Check the DTC judgment. RESULT Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit NEXT --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-493954-S26400840072012081000000)
| Related DTCs | P0102: Mass air flow meter range check (Low voltage) P0103: Mass air flow meter range check (High voltage) |
| Required Sensors/Components (Main) | Mass air flow meter |
| Required Sensors/Components (Related) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 3 seconds |
| MIL Operation | Immediately: Engine speed less than 4000 RPM 2 driving cycles: Engine speed 4000 RPM or more |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Mass air flow meter voltage | Less than 0.2 V |
| Mass air flow meter voltage | More than 4.9 V |
| Mass air flow meter voltage | 0.2 V or more, and 4.9 V or less |
Scheme 672
Scheme 672: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- Idle the engine for 5 seconds [B].
- Enter the following menus: Powertrain / Engine / Trouble Codes [C].
- Read pending DTC. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Run the engine at an engine speed of 4000 RPM for 5 seconds [D].
- Enter the following menus: Powertrain / Engine / Trouble Codes [E].
- Read pending DTC. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0102 or P0103.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [E] again.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 673
Scheme 673: WIRING DIAGRAM
| Related DTCs | P0111: Intake air temperature sensor rationality (After engine stop) P0111: Intake air temperature sensor rationality (After cold engine start) |
| Required Sensors/Components (Main) | Intake air temperature sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| All of the following conditions are met | |
| Time after engine start | 10 seconds or more |
| Battery voltage | 10.5 V or higher |
| Engine coolant temperature at ECM started by internal engine off timer | 40°C (-40°F) or higher |
| Engine coolant temperature before engine stop | 70°C (158°F) or higher |
| Time that mass air flow is low before engine stop | 2100 seconds more |
| Accumulated mass air flow amount in previous driving cycle | 2906 g or more |
| Key off duration | 30 minutes |
| Intake air temperature sensor circuit fail (P0112, P0113) | Not detected |
| Engine coolant temperature sensor circuit fail (P0115, P0117, P0118) | Not detected |
| Mass air flow sensor circuit fail (P0102, P0103) | Not detected |
| All of the following conditions are met | |
| Key-off duration | 5 hours or more |
| Time after engine start | 10 seconds or more |
| Engine coolant temperature | 70°C (158°F) or more |
| Accumulated mass air flow amount | 2906 g or more |
| Either of the following conditions 1 or 2 is met | |
| 1. Duration while engine load is low | 120 seconds or more |
| 2. Duration while engine load is high | 10 seconds or more |
| Intake air temperature sensor circuit fail (P0112, P0113) | Not detected |
| Engine coolant temperature sensor circuit fail (P0115, P0117, P0118) | Not detected |
| Mass air flow sensor circuit fail (P0102, P0103) | Not detected |
| Intake air temperature change | Less than 1°C (1.8°F) |
| Intake air temperature change | Less than 1°C (1.8°F) |
Scheme 674
Scheme 674: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Idle the engine for 5 minutes or more [C]. HINT: During steps [A] through [C], if the change in the intake air temperature is less than 1°C (1.8°F), the intake air temperature sensor (mass air flow meter) is malfunctioning. It is not necessary to continue this procedure.
- Enter the following menus: Powertrain / Engine / Trouble Codes [D].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0111.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the result shows INCOMPLETE or N/A, perform steps [E] and [F].
- Drive the vehicle at 40 km/h (25 mph) or more for a total of 5 minutes or more [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Check the DTC judgment result again [F]. HINT: If the judgment result shows INCOMPLETE or N/A, perform steps [E] and [F] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0111) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0111 and other DTCs are output A DTC P0111 is output B HINT: If any DTCs other than P0111 are output, troubleshoot those DTCs first. B --> See step 3 A --> See step 2
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-493954-S26400840072012081000000)
- REPLACE MASS AIR FLOW METER. Refer to «REMOVAL»(ref-493957-S12273208142012081000000)
| Related DTCs | P0112: Intake air temperature sensor range check (Low voltage) P0113: Intake air temperature sensor range check (High voltage) |
| Required Sensors/Components (Main) | Intake air temperature sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Starter | OFF |
| Intake air temperature sensor voltage | Less than 0.18 V [Higher than 128°C (262°F)] |
| Intake air temperature sensor voltage | Higher than 4.91 V [Less than -55°C (-67°F)] |
| Intake air temperature sensor voltage | 0.18 to 4.91 V [-55 to 128°C (-67 to 262°F)] |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 0.5 seconds or more [A].
- Enter the following menus: Powertrain / Engine / Trouble Codes [B].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0112 or P0113.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 675
Scheme 675: WIRING DIAGRAM
| Related DTCs | P0115: Engine coolant temperature sensor range check (Chattering) P0117: Engine coolant temperature sensor range check (Low voltage) P0118: Engine coolant temperature sensor range check (High voltage) |
| Required Sensors/Components (Main) | Engine coolant temperature sensor |
| Required Sensors/Components (Sub) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Engine coolant temperature sensor voltage | Less than 0.14 V, or higher than 4.91 V [Higher than 135°C (275°F), or less than -60°C (-76°F)] |
| Engine coolant temperature sensor voltage | Less than 0.14 V [Higher than 135°C (275°F)] |
| Engine coolant temperature sensor voltage | Higher than 4.91 V [Less than -60°C (-76°F)] |
| Engine coolant temperature sensor voltage | 0.14 to 4.91 V [-60 to 135°C (-76 to 275°F)] |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 0.5 seconds or more [A].
- Enter the following menus: Powertrain / Engine / Trouble Codes [B].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0115, P0117 or P0118.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 676
Scheme 676: WIRING DIAGRAM
| Related DTCs | P0116: Engine coolant temperature sensor cold start monitor P0116: Engine coolant temperature sensor soak monitor |
| Required Sensors/Components (Main) | Engine coolant temperature sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Battery voltage | 10.5 V or more |
| Time after engine start | 1 second or more |
| Engine coolant temperature at engine start | Less than 60°C (140°F) |
| Engine coolant temperature sensor circuit fail (P0115, P0117, P0118, P0125) | Not detected |
| Intake air temperature sensor circuit fail (P0112, P0113) | Not detected |
| Thermostat fail (P0128) | Not detected |
| Soak timer circuit fail (P2610) | Not detected |
| Soak time | 0 seconds or more |
| Accumulated mass air flow | 3480 g or more |
| Fuel cut | OFF |
| Difference between engine coolant temperature at engine start and intake air temperature | Less than 40°C (72°F) |
ENGINE COOLANT TEMPERATURE SENSOR COLD START MONITOR
| Monitor runs whenever following DTCs are not present | None |
| Battery voltage | 10.5 V or more |
| Engine | Running |
| Engine coolant temperature sensor circuit fail (115, P0117, P0118, P0125) | Not detected |
| Intake air temperature sensor circuit fail (P0112, P0113) | Not detected |
| Thermostat fail (P0128) | Not detected |
| Soak time | 5 hours or more |
| Either of the following conditions is met | (a) or (b) |
| (a) Engine coolant temperature | 60°C (140°F) or more |
| (b) Accumulated mass air flow | 2073 g or more |
ENGINE COOLANT TEMPERATURE SENSOR SOAK MONITOR
| Engine coolant temperature sensor value change | Less than 5°C (9°F) |
ENGINE COOLANT TEMPERATURE SENSOR COLD START MONITOR
| Difference between current engine coolant temperature sensor value and previous engine coolant temperature sensor value when engine stopped | Less than 5°C (9°F) |
ENGINE COOLANT TEMPERATURE SENSOR SOAK MONITOR
| Engine coolant temperature | Engine coolant temperature sensor value changes in accordance with actual engine coolant temperature |
Scheme 677
Scheme 677: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine / Data List / Coolant Temp.
- Check that the coolant temperature is 60°C (140°F) or less.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and idle it for 5 minutes or more [B]. HINT: If the engine coolant temperature does not change by 5°C (9°F) or more, the engine coolant temperature sensor is malfunctioning. It is not necessary to continue this procedure.
- Enter the following menus: Powertrain / Engine / Trouble Codes [C].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0116.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows INCOMPLETE or N/A, perform steps [D] and [E].
- Drive the vehicle at 40 km/h (25 mph) or more for a total of 5 minutes or more [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: In the event of the drive pattern being interrupted (possibly due to factors such as traffic conditions), the drive pattern can be resumed.
- Check the DTC judgment result again [E]. HINT: If the judgment result shows INCOMPLETE or N/A, perform steps [D] and [E] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTC OUTPUT (IN ADDITION TO DTC P0116) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P0116 is output A DTC P0116 and other DTCs are output B HINT: If any DTCs other than P0116 are output, troubleshoot those DTCs first. B --> See step 3 A: Go to next step
- INSPECT THERMOSTAT Check the valve opening temperature of the thermostat. Refer to «INSPECTION»(ref-494109-S09408373642012081000000) . NG --> See step 4 OK --> See step 5
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-493954-S26400840072012081000000)
- REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-494109-S02337212902012081000000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-493957-S36534567122012081000000)
| Related DTCs | P011B: Engine coolant temperature/Intake air temperature sensor correlation |
| Required Sensors / Components (Main) | Engine coolant temperature, intake air temperature sensor |
| Required Sensors / Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Both of the following conditions are met | Conditions 1 and 2 |
| 1. All of the following conditions are met | Conditions (a), (b), (c) and (d) |
| (a) After ignition switch ON and engine not running time | Less than 20 seconds |
| (b) Soak Time | 7 hours or more |
| (c) Battery voltage | 10.5 V or more |
| (d) Time after engine start | 15 seconds or more |
| 2. Either of the following conditions is met | Condition (a) and (b) |
| (a) Minimum intake air temperature after engine start | 10°C (14°F) or more |
| (b) Engine coolant temperature before engine start | 10°C (14°F) or more |
| Engine coolant temperature sensor circuit fail (P0115, P0117, P0118, P0125) | Not detected |
| Intake air temperature sensor circuit fail (P0112, P0113) | Not detected |
| Soak timer circuit fail (P2610) | Not detected |
| Engine coolant temperature and intake air temperature deviation | Less than -20°C (-36°F) or more than 20°C (36°F) |
Scheme 678
Scheme 678: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) [A].
- Turn the ignition switch off and wait for at least 30 seconds.
- With the engine stopped, leave the vehicle as is for 7.5 hours or more [B].
- Start the engine and wait 60 seconds or more [C].
- Enter the following menus: Powertrain / Engine / Trouble Codes [D].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P011B.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows INCOMPLETE or N/A, perform steps [A] through [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO P011B) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P011B is output A DTC P011B and other DTCs are output B HINT: If any DTCs other than P011B are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- READ VALUE USING TECHSTREAM (INTAKE AIR) Leave the vehicle for 7 hours or more. HINT: It is necessary to leave the vehicle for 7 hours or more to allow conditions similar to the DTC detection conditions. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Intake Air. Read the value displayed on the Techstream. Standard Difference between the intake air temperature and the actual outside air temperature is within 10°C (18°F). HINT: Intake air temperature readings on the vehicle outside temperature gauge (if equipped) are not suitable for comparing to the intake air temperature reading. The outside temperature gauge has a significant delay built in to prevent swings in the temperature display. Use an accurate thermometer to determine the outside air temperature. NG --> See step 5 OK: Go to next step
- READ VALUE USING TECHSTREAM (COOLANT TEMP) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Read the value displayed on the Techstream. Standard Difference between the coolant temperature and the actual outside air temperature is within 10°C (18°F). HINT: If the result is not as specified, check that there are no heat sources such as a block heater in the engine compartment. NG --> See step 7 OK --> See step 6
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-493954-S26400840072012081000000)
- REPLACE MASS AIR FLOW METER. Refer to «REMOVAL»(ref-493957-S12273208142012081000000)
- REPLACE ECM. Refer to «REMOVAL»(ref-493957-S32385345752012081000000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-493957-S36534567122012081000000)
| Related DTCs | P0120: Throttle position sensor 1 range check (Chattering) P0121: Throttle position sensor rationality P0122: Throttle position sensor 1 range check (Low voltage) P0123: Throttle position sensor 1 range check (High voltage) P0220: Throttle position sensor 2 range check (Chattering) P0222: Throttle position sensor 2 range check (Low voltage) P0223: Throttle position sensor 2 range check (High voltage) P2135: Throttle position sensor range check (Correlation) |
| Required Sensors/Components (Main) | Throttle position sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 2 seconds: P0120, P0122, P0123, P0220, P0222 and P0223 Within 2 seconds: P0121 0.5 seconds: P2135 (Condition A) 0.4 seconds: P2135 (Condition B) |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Either of the following conditions A or B is met | |
| A. Ignition switch ON | 0.012 seconds or more |
| B. Electronic throttle actuator power | ON |
P0120, P0122, P0123, P0220, P0222, P0223, P02135
| Monitor runs whenever following DTCs are not present | None |
| Either of the following conditions A or B is met | |
| A. Ignition switch | ON |
| B. Electric throttle motor power | ON |
| Throttle position sensor malfunction (P0120, P0122, P0123, P0220, P0222, P0223, P2135) | Not detected |
| VTA1 voltage | 0.2 V or less, or 4.54 V or higher |
| Either of the following conditions is met | |
| Difference of learned throttle position sensor opener position voltage between VTA2 and VTA1 | Higher than 1.6 V |
| Difference of learned throttle position sensor opener position voltage between VTA2 and VTA1 | Less than 0.8 V |
| VTA1 voltage | 0.2 V or less |
| VTA1 voltage | 4.54 V or higher |
| Either of the following conditions A or B is met | |
| A. VTA2 voltage | 1.75 V or less |
| B. VTA2 voltage when VTA1 0.2 V or higher, and 2.02 V or less | 4.8 V or higher |
| VTA2 voltage | 1.75 V or less |
| VTA2 voltage when VTA1 0.2 V or higher, and 2.02 V or less | 4.8 V or higher |
| Difference between VTA1 and VTA2 voltages | 0.02 V or less |
| VTA1 voltage | 0.2 V or less |
| VTA2 voltage | 1.75 V or less |
| VTA1 voltage | Higher than 0.2 V, and less than 4.54 V |
| VTA2 voltage | Higher than 1.75, and less than 4.8 V |
Scheme 679
Scheme 679: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- With the vehicle stationary, fully depress and release the accelerator pedal [B].
- Idle the engine for 2 seconds or more [C].
- Enter the following menus: Powertrain / Engine / Trouble Codes [D].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0120, P0121, P0122, P0123, P0220, P0222, P0223 or P2135.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the result shows INCOMPLETE or N/A, perform steps [B] through [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
FAIL-SAFE
When any of these DTCs or other DTCs relating to electronic throttle control system malfunctions are stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 6° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing, in accordance with the accelerator pedal opening angle, to allow the vehicle to continue at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.
Fail-safe mode continues until a pass condition is detected, and the ignition switch is then turned off.
Scheme 680
Scheme 680: WIRING DIAGRAM
| Related DTCs | P0125: Insufficient engine coolant temperature for closed loop fuel control |
| Required Sensors/Components (Main) | Engine coolant temperature sensor, thermostat, cooling system |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | 65 seconds: Closed-loop engine coolant temperature - 8.33°C (46.99°F) or more 117 seconds: Closed-loop engine coolant temperature - 19.44°C (66.99°F) or more to less than closed-loop engine coolant temperature - 8.33°C (46.99°F) 1200 seconds: Less than closed-loop engine coolant temperature - 19.44°C (66.99°F) |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Thermostat fail (P0128) | Not detected |
| Intake air temperature sensor circuit fail (P0112, P0113) | Not detected |
| Engine coolant temperature sensor circuit fail (P0115, P0117, P0118) | Not detected |
| Mass air flow meter sensor circuit fail (P0101, P0102, P0103) | Not detected |
| Time until actual engine coolant temperature reaches closed loop fuel control enabling temperature | 65 seconds: Closed-loop engine coolant temperature - 8.33°C (46.99°F) or more 117 seconds: Closed-loop engine coolant temperature - 19.44°C (66.99°F) or more to less than closed-loop engine coolant temperature - 8.33°C (44.99°F) 1200 seconds: Less than closed-loop engine coolant temperature - 19.44°C (66.99°F) |
- Leave the vehicle outside overnight.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine / Data List / Coolant Temp.
- Check that the engine coolant temperature is 5°C (41°F) or less.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- After starting the engine, wait 21 minutes or more [B].
- Enter the following menus: Powertrain / Engine / Trouble Codes [C].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0125.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0125) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0125 is output A DTC P0125 and other DTCs are output B HINT: If any DTCs other than P0125 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- INSPECT THERMOSTAT Inspect the thermostat (thermostat opening temperature). Refer to «INSPECTION»(ref-494109-S09408373642012081000000) . NG --> See step 5 OK: Go to next step
- CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal radiator fan operation or any modifications. NG --> REPAIR OR REPLACE COOLING SYSTEM OK --> See step 6
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-493954-S26400840072012081000000)
- REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-494109-S02337212902012081000000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-493957-S36534567122012081000000)
| Related DTCs | P0128: Coolant thermostat |
| Required Sensors / Components (Main) | Thermostat, engine coolant temperature sensor |
| Required Sensors / Components (Related) | Intake air temperature sensor, vehicle speed sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 550 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | P0010, P0020 (Camshaft timing oil control valve bank 1, 2) P0011, P0021 (VVT system bank 1, 2 - advance) P0012, P0022 (VVT system bank 1, 2 - retard) P0013, P0023 (Exhaust oil control valve bank 1, 2) P0014, P0024 (Exhaust VVT system bank 1, 2 - advance) P0015, P0025 (Exhaust VVT system bank 1, 2 - retard) P0016, P0018 (VVT system bank 1, 2 - misalignment) P0017, P0019 (Exhaust VVT system bank 1, 2 - misalignment) P0031, P0032, P0051, P0052, P101D, P103D (Air fuel ratio sensor heater) P0102, P0103 (Mass air flow meter) P0112, P0113 (Intake air temperature sensor) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P014C, P014D, P014E, P014F, P015A, P015B, P015C, P015D, P2195, P2196, P2197, P2198, P2237, P2238, P2239, P2240, P2241, P2242, P2252, P2253, P2255, P2256 (Air fuel ratio sensor) P0171, P0172, P0174, P0175 (Fuel system) P0301, P0302, P0303, P0304, P0305, P0306 (Misfire) P0335 (Crankshaft position sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) P0351, P0352, P0353, P0354, P0355, P0356 (Igniter) P0365, P0367, P0368, P0390, P0392, P0393 (Exhaust VVT sensor) P0500 (Vehicle speed sensor) |
| Battery voltage | 11 V or more |
| Either of the following conditions is met | Condition 1 or 2 |
| 1. All of the following conditions are met | Conditions (a), (b) and (c) |
| (a) Engine coolant temperature at engine start - intake air temperature at engine start | 15 to 7°C (-27 to 12.6°F) |
| (b) Engine coolant temperature at engine start | 10 to 56°C (14 to 133°F) |
| (c) Intake air temperature at engine start | 10 to 56°C (14 to 133°F) |
| 2. All of the following conditions are met | Conditions (d), (e) and (f) |
| (d) Engine coolant temperature at engine start - intake air temperature at engine start | More than 7°C (12.6°F) |
| (e) Engine coolant temperature at engine start | 56°C (133°F) or less |
| (f) Intake air temperature at engine start | 10°C (14°F) or more |
| Accumulated time that vehicle speed is 128 km/h (80 mph) or more | Less than 20 seconds |
| Duration that all of the following conditions 1 and 2 are met | 5 seconds or more |
| 1. Estimated engine coolant temperature | 75°C (167°F) or more |
| 2. Engine coolant temperature sensor output | Less than 75°C (167°F) |
Scheme 681
Scheme 681: CONFIRMATION DRIVING PATTERN
- Stop the engine and allow it to soak.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Enter the following menu items: Powertrain / Engine / Data List / Coolant Temp and Intake Air.
- Check that "Coolant Temp" is 56°C (133°F) or less and "Intake Air" is between 0 and 35°C (32 and 95°F).
- Set the heater to MAX HOT with fresh air mode selected and turn the A/C off.
- Start the engine and drive the vehicle at 80 km/h (50 mph) for 15 minutes [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Data can be captured relatively easily by using the snapshot function in the Data List. Enter the following menu: Data List / Function / Snap-shot configuration / Record time / 5 min. Data capture can be started by using the target point function. For example, setting the target point to an engine speed of 4000 RPM and then racing the engine, etc. to raise the engine speed to a speed of 4000 RPM or more will cause data capture to start.
- After "Coolant Temp" stabilizes, check that "Coolant Temp" is 75°C (167°F) or higher [C]. HINT: If "Coolant Temp" is below 75°C (167°F) while driving the vehicle at 80 km/h (50 mph), inspect the cooling system and thermostat.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0128) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P0128 is output A DTC P0128 and other DTCs are output B HINT: If any DTCs other than P0128 are output, troubleshoot those DTCs first. B --> See step 5 A: Go to next step
- CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal radiator fan operation or any modifications. NG --> REPAIR OR REPLACE COOLING SYSTEM OK: Go to next step
- INSPECT THERMOSTAT Check the valve opening temperature of the thermostat. Refer to «INSPECTION»(ref-494109-S09408373642012081000000) . NG --> See step 6 OK --> See step 4
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-493957-S36534567122012081000000)
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-493954-S26400840072012081000000)
- REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-494109-S02337212902012081000000)
| Related DTCs | P0136: Heated oxygen sensor (bank 1) voltage check (voltage malfunction) P0136: Heated oxygen sensor (bank 1) circuit continuity check (circuit short) P0137: Heated oxygen sensor (bank 1) voltage check (low voltage) P0137: Heated oxygen sensor (bank 1) circuit continuity check (circuit open) P0138: Heated oxygen sensor (bank 1) circuit continuity check (out of range) P0139: Heated oxygen sensor (bank 1) response rate during fuel cut P0156: Heated oxygen sensor (bank 2) voltage check (voltage malfunction) P0156: Heated oxygen sensor (bank 2) circuit continuity check (circuit short) P0157: Heated oxygen sensor (bank 2) voltage check (low voltage) P0157: Heated oxygen sensor (bank 2) circuit continuity check (circuit open) P0158: Heated oxygen sensor (bank 2) circuit continuity check (out of range) P0159: Heated oxygen sensor (bank 2) response rate during fuel cut |
| Required Sensors/Components (Main) | Heated oxygen sensor (sensor 2) |
| Required Sensors/Components (Related) | Crankshaft position sensor Engine coolant temperature sensor Mass air flow meter Throttle position sensor Air fuel ratio sensor |
| Frequency of Operation | Once per driving cycle: Active air fuel ratio control detection, heated oxygen sensor abnormal voltage during fuel cut. Continuous: Other |
| Duration | 20 seconds: Heated oxygen sensor voltage check 30 seconds: Heated oxygen sensor circuit continuity check (circuit short) 90 seconds: Heated oxygen sensor circuit continuity check (circuit open) 10 seconds: Heated oxygen sensor circuit continuity check (out of range) 7 seconds: Heated oxygen sensor response rate during fuel cut |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | P0016, P0018 (VVT system - misalignment) P0017, P0019 (Exhaust VVT system - misalignment) P0031, P0032, P0051, P0052, P101D, P103D (Air fuel ratio sensor heater) P0037, P0038, P0057, P0058, P102D, P105D (Heated oxygen sensor heater) P0102, P0103 (Mass air flow meter) P0112, P0113 (Intake air temperature sensor) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient engine coolant temperature for closed loop fuel control) P0128 (Thermostat) P014C, P014D, P014E, P014F, P015A, P015B, P015C, P015D, P2195, P2196, P2197, P2198, P2237, P2238, P2239, P2240, P2241, P2242, P2252, P2253, P2255, P2256 (Air fuel ratio sensor) P0171, P0172, P0174, P0175 (Fuel system) P0301, P0302, P0303, P0304, P0305, P0306 (Misfire) P0335 (Crankshaft position sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) P0451, P0452, P0453 (EVAP system) P0500 (Vehicle speed sensor) |
| Battery voltage | 11 V or higher |
| Intake air temperature | 10°C (14°F) or higher |
| Engine coolant temperature | 75°C (167°F) or higher |
| Atmospheric pressure | 76 kPa(abs) [570 mmHg(abs)] or higher |
| Idling | Off |
| Engine speed | Less than 3200 RPM |
| Air fuel ratio sensor status | Activated |
| Fuel system status | Closed loop |
| Engine load | 10% or higher, and less than 85% |
| Shift position | 4th or higher |
P0136, P0137, P0156 AND P0157: HEATED OXYGEN SENSOR VOLTAGE CHECK (VOLTAGE MALFUNCTION AND LOW VOLTAGE)
| Battery voltage | 11 V or higher |
| Estimated sensor temperature | Less than 700°C (1292°F) |
| ECM monitor | Completed |
| DTC P0607 | Not stored |
P0136 AND P0156: HEATED OXYGEN SENSOR CIRCUIT CONTINUITY CHECK (CIRCUIT SHORT)
| Battery voltage | 11 V or higher |
| Estimated sensor temperature | 450°C (842°F) or higher, and less than 750°C (1382°F) |
| DTC P0607 | Not stored |
P0137 AND P0157: HEATED OXYGEN SENSOR CIRCUIT CONTINUITY CHECK (CIRCUIT OPEN)
| Battery voltage | 11 V or higher |
| Time after engine start | 2 seconds or more |
P0138 AND P0158: HEATED OXYGEN SENSOR CIRCUIT CONTINUITY CHECK (OUT OF RANGE)
| Engine coolant temperature | 75°C (167°F) or higher |
| Catalyst temperature | 400°C (752°F) or higher |
| Fuel cut | On |
P0139 AND P0159: HEATED OXYGEN SENSOR RESPONSE RATE DURING FUEL CUT
| All of following conditions (a), (b) and (c) met | |
| (a) OSC (Oxygen Storage Capacity) of catalyst | 1.9 g or more |
| (b) Heated oxygen sensor voltage | 0.21 V or higher, and less than 0.59 V |
| (b) Commanded air fuel ratio | 14.3 or less |
P0136 AND P0156: HEATED OXYGEN SENSOR VOLTAGE CHECK (VOLTAGE MALFUNCTION)
| All of following conditions (a), (b) and (c) met | |
| (a) OSC (Oxygen Storage Capacity) of catalyst | 1.9 g or more |
| (b) Heated oxygen sensor voltage | Less than 0.21 V |
| (c) Commanded air fuel ratio | 14.3 or less |
P0137 AND P0157: HEATED OXYGEN SENSOR VOLTAGE CHECK (LOW VOLTAGE)
| Duration of following condition | 30 seconds or more |
| Heated oxygen sensor impedance | Less than 5 ohms |
P0136 AND P0156: HEATED OXYGEN SENSOR CIRCUIT CONTINUITY CHECK (CIRCUIT SHORT)
| Duration of following condition | 90 seconds or more |
| Heated oxygen sensor impedance | 15 kohms or higher |
P0137 AND P0157: HEATED OXYGEN SENSOR CIRCUIT CONTINUITY CHECK (CIRCUIT OPEN)
| Duration of following condition | 10 seconds or more |
| Heated oxygen sensor voltage | 1.2 V or higher |
P0138 AND P0158: HEATED OXYGEN SENSOR CIRCUIT CONTINUITY CHECK (OUT OF RANGE)
| Either of the following conditions is met | |
| Total airflow volume reached after start of fuel-cut while heated oxygen sensor voltage remains at 0.2 V or higher | More than 11.3 g |
| Duration until rear heated oxygen sensor voltage drops from 0.35 V to 0.2 V during fuel cut | 1 second or more |
P0139 AND P0159: HEATED OXYGEN SENSOR RESPONSE RATE DURING FUEL CUT
- This confirmation driving pattern is used in the "Perform Confirmation Driving Pattern" procedure of the following diagnostic troubleshooting procedure.
- Performing this confirmation driving pattern will activate the heated oxygen sensor monitor (The catalyst monitor is performed simultaneously). This is very useful for verifying the completion of a repair.
P0136, P0137, P0138, P0156, P0157 and P0158
Scheme 682
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- With the shift lever in D, drive the vehicle at 60 to 120 km/h (37 to 75 mph) for 10 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0136, P0137, P0138, P0156, P0157 or P0158.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [C] and [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 683
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Drive the vehicle at 60 km/h (37 mph), and then decelerate the vehicle by releasing the accelerator pedal for 10 seconds or more to perform the fuel-cut [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine / Trouble Codes [D].
- Read pending DTCs. HINT: If a pending DTC or current DTC is output, the system is malfunctioning. If a pending DTC or current DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0139 or P0159.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, drive the vehicle with the shift lever in S, and then perform steps [C] and [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 684
Scheme 684: WIRING DIAGRAM
| Related DTCs | P014C: Air fuel ratio sensor (bank 1 sensor 1) slow response (rich to lean) P014D: Air fuel ratio sensor (bank 1 sensor 1) slow response (lean to rich) P014E: Air fuel ratio sensor (bank 2 sensor 1) slow response (rich to lean) P014F: Air fuel ratio sensor (bank 2 sensor 1) slow response (lean to rich) P015A: Air fuel ratio sensor (bank 1 sensor 1) delayed response (rich to lean) P015B: Air fuel ratio sensor (bank 1 sensor 1) delayed response (lean to rich) P015C: Air fuel ratio sensor (bank 2 sensor 1) delayed response (rich to lean) P015D: Air fuel ratio sensor (bank 2 sensor 1) delayed response (lean to rich) |
| Required Sensors/Components (Main) | Air fuel ratio sensor (bank 1, 2 sensor 1) |
| Required Sensors/Components (Related) | Vehicle speed sensor, crankshaft position sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 to 15 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not stored | None |
| Active air fuel ratio control | Performing |
| Active air fuel ratio control is performed when the following conditions are met | |
| Battery voltage | 11 V or higher |
| Engine coolant temperature | 75°C (167°F) or more |
| Idle | OFF |
| Engine speed | 1000 to 4000 RPM |
| Air fuel ratio sensor status | Activated |
| Fuel-cut | OFF |
| Engine load | 10 to 70% |
| Shift position | 2nd or higher |
| Catalyst monitor | Not yet |
| Mass air flow | 5 to 10 g/sec. |
| Rich to Lean Response rate deterioration level | 0.048 V or less |
P014C AND P014E: AIR FUEL RATIO SENSOR (BANK 1, 2) RESPONSE RATE (RICH TO LEAN RESPONSE RATE)
| Lean to Rich Response rate deterioration level | 0.04 V or higher |
P014D AND P014F: AIR FUEL RATIO SENSOR (BANK 1, 2) RESPONSE RATE (LEAN TO RICH RESPONSE RATE)
| Rich to Lean delay level | 200 msec. or more |
P015A AND P015C: AIR FUEL RATIO SENSOR (BANK 1, 2) RESPONSE RATE (RICH TO LEAN DELAY)
| Lean to Rich delay level | 200 msec. or more |
P015B AND P015D: AIR FUEL RATIO SENSOR (BANK 1, 2) RESPONSE RATE (LEAN TO RICH DELAY)
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
Performing this confirmation pattern will activate the air fuel ratio sensor response monitor.
Scheme 685
Scheme 685: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine / Monitor / Current Monitor.
- Check the monitor item O2 Sensor is incomplete. HINT: The test values for the test items RL RES RATE B1S1, LR RES RATE B1S1, RL DELAY B1S1, LR DELAY B1S1, RL RES RATE B2S1, LR RES RATE B2S1, RL DELAY B2S1 and LR DELAY B2S1 do not exist in the Detail of O2 Sensor monitor at this time (the initial value of "0.000" is indicated in each test item).
- Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or higher) [A].
- Drive the vehicle at a constant speed between 75 and 100 km/h (47 and 62 mph) for 10 minutes [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Check that the monitor item O2 Sensor becomes Complete. HINT: Check the test values on the Techstream by entering the following menus: Powertrain / Engine / Monitor / O2 Sensor / Details / RL RES RATE B1S1, LR RES RATE B1S1, RL DELAY B1S1, LR DELAY B1S1, RL RES RATE B2S1, LR RES RATE B2S1, RL DELAY B2S1 and LR DELAY B2S1.
- If the monitor item O2 Sensor does not become Complete (if the test values indicated on the Techstream do not change), perform Readiness Monitor Drive Pattern for the A/F sensor and heated oxygen sensor. Refer to «READINESS MONITOR DRIVE PATTERN»(ref-493954-S18488984142012081000000) .
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read pending DTC [C].
- If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or N/A, perform step [B] again.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C OR P015D) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D is output A DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D and other DTCs are output B HINT: If any DTCs other than P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D are output, troubleshoot those DTCs first. B --> See step 10 A: Go to next step
- INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE) Inspect the air fuel ratio sensor. Refer to «INSPECTION»(ref-493957-S21412865022012081000000) . NG --> See step 11 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) Disconnect the air fuel ratio sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard resistance (Check for Open) Tester Connection Condition Specified Condition B14-1 (HA1A) - B1-22 (HA1A) Always Below 1 ohms B14-3 (A1A+) - B1-126 (A1A+) Always Below 1 ohms B14-4 (A1A-) - B1-125 (A1A-) Always Below 1 ohms B13-1 (HA2A) - B1-20 (HA2A) Always Below 1 ohms B13-3 (A2A+) - B1-103 (A2A+) Always Below 1 ohms B13-4 (A2A-) - B1-102 (A2A-) Always Below 1 ohms Standard resistance (Check for Short) Tester Connection Condition Specified Condition B14-1 (HA1A) or B1-22 (HA1A) - Body ground Always 10 kohms or higher B14-3 (A1A+) or B1-126 (A1A+) - Body ground Always 10 kohms or higher B14-4 (A1A-) or B1-125 (A1A-) - Body ground Always 10 kohms or higher B13-1 (HA2A) or B1-20 (HA2A) - Body ground Always 10 kohms or higher B13-3 (A2A+) or B1-103 (A2A+) - Body ground Always 10 kohms or higher B13-4 (A2A-) or B1-102 (A2A-) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- INSPECT AIR FUEL RATIO SENSOR Check that the proper air fuel ratio sensors are installed to the vehicle. NG --> See step 12 OK: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Drive the vehicle according to the Confirmation Driving Pattern. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C OR P015D) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the DTCs. RESULT Result Proceed to DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C and/or P015D are output A DTC is not output B B --> See step 13 A: Go to next step
- REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-493957-S42556714632012081000000) . NEXT: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Drive the vehicle according to the Confirmation Driving Pattern. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C OR P015D) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read pending DTCs. RESULT Result Proceed to DTC is not output A DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C and/or P015D are output B B --> See step 14 A --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-493954-S26400840072012081000000)
- REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-493957-S42556714632012081000000)
- REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-493957-S42556714632012081000000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-493954-S36145137532012081000000)
- CHECK ENGINE TO DETERMINE CAUSE OF EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO. Refer to «INSPECTION PROCEDURE»(ref-494147-S10970187422012081000000)
| Related DTCs | P0171: Fuel trim Lean (bank 1) P0172: Fuel trim Rich (bank 1) P0174: Fuel trim Lean (bank 2) P0175: Fuel trim Rich (bank 2) |
| Required Sensors/Components (Main) | Fuel system |
| Required Sensors/Components (Related) | Air fuel ratio sensor Mass air flow meter Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | Within 10 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0010, P0020 (Camshaft timing oil control valve bank 1, 2) P0011, P0021 (VVT system bank 1, 2 - advance) P0012, P0022 (VVT System bank 1, 2 - retard) P0013, P0023 (Exhaust oil control valve bank 1, 2) P0014, P0024 (Exhaust VVT system bank 1, 2 - advance) P0015, P0025 (Exhaust VVT system bank 1, 2 - retard) P0016, P0018 (VVT system - misalignment) P0017, P0019 (Exhaust VVT system bank 1, 2 - misalignment) P0031, P0032, P0051, P0052, P101D, P103D (Air fuel ratio sensor heater) P0102, P0103 (Mass air flow meter) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P0335 (Crankshaft position sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) P0351, P0352, P0353, P0354, P0355, P0356 (Igniter) P0365, P0367, P0368, P0390, P0392, P0393 (Exhaust VVT sensor) P0500 (Vehicle speed sensor) |
| Fuel system status | Closed loop |
| Battery voltage | 11 V or more |
| Either of following conditions 1 or 2 set | |
| 1. Engine speed | Less than 1100 RPM |
| 2. Intake air amount per revolution | 0.22 g/rev or more |
| Catalyst monitor | Not executed |
| Purge-cut | Executing |
| Either of following conditions 1 or 2 met | |
| 1. Average between short-term fuel trim and long-term fuel trim | 35% or more (varies with engine coolant temperature) |
| 2. Average between short-term fuel trim and long-term fuel trim | 35% or less (varies with engine coolant temperature) |
Scheme 686
Scheme 686: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher with all the accessories switched off [B].
- With the engine warmed up, idle the engine for 2 minutes or more [C].
- Drive the vehicle at a speed between 60 and 135 km/h (37 and 85 mph) for 5 minutes or more [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine / Trouble Codes [E].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0300: Multiple cylinder misfire P0301: Cylinder 1 misfire P0302: Cylinder 2 misfire P0303: Cylinder 3 misfire P0304: Cylinder 4 misfire P0305: Cylinder 5 misfire P0306: Cylinder 6 misfire |
| Required Sensors/Components (Main) | Crankshaft position sensor Camshaft position sensor |
| Required Sensors/Components (Related) | Engine coolant temperature Intake air temperature sensor Mass air flow meter |
| Frequency of Operation | Continuous |
| Duration | 1000 crankshaft revolutions (soon after engine is started: 1 time, other 4 times) (Emissions-related misfire) 200 crankshaft revolutions (1 or 3 times) (Catalyst-damaging misfire) |
| MIL Operation | 2 driving cycles: Emissions-related misfire MIL flashes immediately: Catalyst-damaging misfire |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0016, P0018 (VVT system bank 1, 2 - misalignment) P0017, P0019 (Exhaust VVT System bank 1, 2 - Misalignment) P0102, P0103 (Mass air flow meter) P0112, P0113 (Intake air temperature sensor) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P0327, P0328, P0332, P0333 (Knock control sensor) P0335 (Crankshaft position sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) P0351, P0352, P0353, P0354, P0355, P0356 (Igniter) P0500 (Vehicle Speed Sensor) P0705 (Shift lever position switch) |
| Battery voltage | 8 V or more |
| VVT system | Not operated by scan tool |
| Engine speed | 450 to 6500 RPM |
| Either of following conditions (a) or (b) met | |
| (a) Engine coolant temperature at engine start | More than -7°C (19°F) |
| (b) Engine coolant temperature | More than 20°C (68°F) |
| Fuel cut | OFF |
| First 1000 revolutions after engine start, or Check Mode | Crankshaft 1000 revolutions |
| Except above | Crankshaft 1000 revolutions x 4 |
MONITOR PERIOD OF EMISSION-RELATED-MISFIRE
| All of the following conditions 1, 2, 3 and 4 are met | Crankshaft 200 revolutions x 3 |
| Except above (MIL blinks immediately) | Crankshaft 200 revolutions |
| 1. Driving cycles | 1st |
| 2. Check mode | OFF |
| 3. Engine speed | Less than 2400 RPM |
| 4. Intake air amount per revolution | Less than 1.3 g/rev |
MONITOR PERIOD OF CATALYST-DAMAGED-MISFIRE (MIL BLINKS)
| Monitor runs whenever following DTCs are not present | P0016, P0018 (VVT system bank 1, 2 - misalignment) P0017, P0019 (Exhaust VVT system bank 1, 2 - misalignment) P0102, P0103 (Mass air flow meter) P0112, P0113 (Intake air temperature sensor) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient engine coolant temperature for closed loop) P0327, P0328, P0332, P0333 (Knock sensor) P0335 (Crankshaft position sensor) P0340 (VVT sensor) P0351, P0352, P0353, P0354, P0355, P0356 (Igniter) P0500 (Vehicle speed sensor) P0705 (Shift lever position switch) |
| Battery voltage | 8 V or more |
| VVT system | Not operated by scan tool |
| Engine speed | 450 to 6500 RPM |
| Either of the following conditions is met | Condition (a) or (b) |
| (a) Engine coolant temperature at engine start | More than -7°C (19°F) |
| (b) Engine coolant temperature | More than 20°C (68°F) |
| Fuel cut | OFF |
| First 1000 revolutions after engine start, or check mode | Crankshaft 1000 revolutions |
| Except above | Crankshaft 1000 revolutions x 4 |
MONITOR PERIOD OF EMISSION-RELATED-MISFIRE
| All of the following conditions 1 and 2 are met | Crankshaft 200 revolutions |
| 1. Driving cycle | 1st |
| 2. Check mode | OFF |
| Except above (MIL blinks immediately) | Crankshaft 200 revolutions x 3 |
MONITOR PERIOD OF CATALYST-DAMAGE-MISFIRE (MIL BLINKS)
MONITOR PERIOD OF EMISSION-RELATED-MISFIRE
| Number of misfire per 200 revolutions | 94 or more (varies with intake air amount and RPM) |
MONITOR PERIOD OF CATALYST-DAMAGED-MISFIRE (MIL BLINKS)
| Misfire rate (for Mexico model) | 33.2 % or more: for 1st 1000 revolutions 16.6 % or more: after 1st 1000 revolutions |
MONITOR PERIOD OF EMISSION-RELATED-MISFIRE
| Number of misfire per 200 revolutions | 94 or more (varies with intake air amount and engine speed) |
| Paired cylinders misfire (MIL blinks immediately) | Detected |
MONITOR PERIOD OF CATALYST-DAMAGE-MISFIRE (MIL BLINKS)
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Record the DTC(s) and freeze frame data.
- Clear DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
- Using the Techstream, switch the ECM from normal mode to check mode. Refer to «CHECK MODE PROCEDURE»(ref-493954-S16555611792012081000000) .
- Read the misfire counts of each cylinder, Cylinder #1 Misfire Count to Cylinder #6 Misfire Count, with the engine idling. If any misfire count is displayed, skip the following confirmation driving pattern.
- Drive the vehicle so that the vehicle conditions displayed in Misfire RPM and Misfire Load of the Data List are the same as the freeze frame data. Perform this step several times. HINT: In order to store misfire DTCs, it is necessary to operate the vehicle for the period of time shown in the table below, confirm the Misfire RPM and Misfire Load in the Data List. Engine speed Duration Idling 5 minutes or more 1000 4 minutes or more 2000 3 minutes or more 3000 2 minutes or more
- Check whether misfires have occurred by checking DTCs and freeze frame data. HINT: Do not turn the ignition switch off until the output DTC(s) and freeze frame data have been recorded. When the ECM returns to normal mode (default), the stored DTC(s), freeze frame data and other data are cleared.
- Record the DTC(s), freeze frame data and misfire counts.
- Turn the ignition switch off and wait for at least 30 seconds.
- Clear DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
Scheme 687
Scheme 687: WIRING DIAGRAM
| Related DTCs | P0327: Knock sensor (bank 1) range check (Low voltage) P0328: Knock sensor (bank 1) range check (High voltage) P0332: Knock sensor (bank 2) range check (Low voltage) P0333: Knock sensor (bank 2) range check (High voltage) |
| Required Sensors/Components (Main) | Knock sensor (bank 1, 2) |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1 second |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Battery voltage | 10.5 V or more |
| Time after engine start | 5 seconds or more |
| Ignition switch | ON |
| Starter | OFF |
| Knock sensor voltage | Less than 0.5 V |
KNOCK SENSOR RANGE CHECK (LOW VOLTAGE): P0327 AND P0332
| Knock sensor voltage | More than 4.5 V |
KNOCK SENSOR RANGE CHECK (HIGH VOLTAGE): P0328 AND P0333
| Knock sensor voltage | 0.5 to 4.5 V |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and wait 10 seconds.
- Enter the following menus: Powertrain / Engine / Trouble Codes [B].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0327, P0328, P0332 or P0333.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows INCOMPLETE or N/A, idle the engine for 5 minutes and check the DTC judgment result again [C].
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 688
Scheme 688: WIRING DIAGRAM
| Related DTCs | P0335: Crankshaft position sensor verify pulse input P0335: Crankshaft position sensor range check/rationality |
| Required Sensors / Components (Main) | Crankshaft position sensor |
| Required Sensors / Components (Related) | VVT sensor |
| Frequency of Operation | Continuous |
| Duration | 15 seconds: Verify pulse input (case 1) 4.7 seconds: Verify pulse input (case 2) Within 1 second: Range check/rationality |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Time after starter OFF to ON | 3 seconds or more |
| Battery voltage | 7 V or more |
| Minimum battery voltage while starter ON | Less than 11 V |
| Camshaft position sensor circuit fail (P0340, P0342, P0343) | Not detected |
P0335: CRANKSHAFT POSITION SENSOR RANGE CHECK/RATIONALITY
| Engine speed (Top dead center) | 600 RPM or higher |
| Engine speed (30°CA) | 600 RPM or higher |
| Starter | OFF |
| Time after starter ON to OFF | 3 seconds or more |
P0335: CRANKSHAFT POSITION SENSOR VERIFY PULSE INPUT (CASE 1)
| Starter | ON |
| Minimum battery voltage starter ON | Less than 11 V |
P0335: CRANKSHAFT POSITION SENSOR VERIFY PULSE INPUT (CASE 2)
| Number of crankshaft position sensor signal pulse | 132 times or less, or 174 times or more |
P0335: CRANKSHAFT POSITION SENSOR RANGE CHECK/RATIONALITY
| Engine speed signal | No signal |
P0335: CRANKSHAFT POSITION SENSOR VERIFY PULSE INPUT
| Crankshaft position sensor | Crankshaft position sensor output voltage fluctuates while crankshaft is revolving 34 crankshaft position sensor signals per crankshaft revolution |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- Idle the engine for 20 seconds or more [B].
- Enter the following menus: Powertrain / Engine / Trouble Codes [C].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0335 or P0339.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [C] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 689
Scheme 689: WIRING DIAGRAM
| Related DTCs | P0340: VVT sensor (for intake side of bank 1) verify pulse input P0342: VVT sensor (for intake side of bank 1) range check (low voltage) P0343: VVT sensor (for intake side of bank 1) range check (high voltage) P0345: VVT sensor (for intake side of bank 2) verify pulse input P0347: VVT sensor (for intake side of bank 2) range check (low voltage) P0348: VVT sensor (for intake side of bank 2) range check (high voltage) |
| Required Sensors / Components (Main) | VVT sensor (for intake side of bank 1, 2) |
| Required Sensors / Components (Related) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 4 seconds: P0340 (VVT sensor (for intake side of bank 1) verify pulse input (case 2)) P0342 and P0347 (VVT sensor (for intake side of bank 1, 2) range check (low voltage)) P0343 and P0348 (VVT sensor (for intake side of bank 1, 2) range check (high voltage)) 5 seconds: P0340 (VVT sensor (for intake side of bank 1) verify pulse input (case 1)) P0345 (VVT sensor (for intake side of bank 2) verify pulse input) |
| MIL Operation | 2 driving cycles: P0340 (VVT sensor (bank 1) verify pulse input (case 2)) Immediately: Others |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Engine speed | 600 RPM or more |
| Starter | Off |
| VVT system misalignment | Not detected |
| VVT sensor range check fail (P0342, P0343) | Not detected |
| VVT sensor voltage | 0.3 V or more, and 4.7 V or less |
P0340: VVT SENSOR (FOR INTAKE SIDE OF BANK 1) VERIFY PULSE INPUT (CASE 1)
| Starter | After off to ON timing |
| Minimal battery voltage while starter ON | Below 11 V |
P0340: VVT SENSOR (FOR INTAKE SIDE OF BANK 1) VERIFY PULSE INPUT (CASE 2)
| Starter | Off |
| Ignition switch | ON |
| Time after ignition switch off to ON | 2 seconds or more |
| VVT sensor verify pulse input fail (P0340) | Not detected |
| Battery voltage | 8 V or more |
P0342, P0343: VVT SENSOR (FOR INTAKE SIDE OF BANK 1) RANGE CHECK
| Engine speed | 600 RPM or more |
| Starter | Off |
| VVT sensor range check fail (P0342, P0343, P0347, P0348) | Not detected |
| VVT sensor voltage | 0.3 V or more, and 4.7 V or less |
| Battery voltage | 8 V or more |
| Ignition switch | ON |
P0345: VVT SENSOR (FOR INTAKE SIDE OF BANK 2) VERIFY PULSE INPUT
| Starter | Off |
| Ignition switch | ON |
| Time after ignition switch off to ON | 2 seconds or more |
| VVT sensor verify pulse input fail (P0340, P0345) | Not detected |
| Battery voltage | 8 V or more |
P0347, P0348: VVT SENSOR (FOR INTAKE SIDE OF BANK 2) RANGE CHECK
| Camshaft position and crankshaft position alignment | Misalignment |
| VVT sensor signal | No signal |
P0340: VVT SENSOR (FOR INTAKE SIDE OF BANK 1) VERIFY PULSE INPUT (CASE 1)
| VVT sensor signal | No signal |
P0340: VVT SENSOR (FOR INTAKE SIDE OF BANK 1) VERIFY PULSE INPUT (CASE 2)
| VVT sensor voltage | Less than 0.3 V |
P0342, P0347: VVT SENSOR (FOR INTAKE SIDE OF BANK1, 2) RANGE CHECK (LOW VOLTAGE)
| VVT sensor voltage | More than 4.7 V |
P0343, P0348: VVT SENSOR (FOR INTAKE SIDE OF BANK1, 2) RANGE CHECK (HIGH VOLTAGE)
| VVT sensor signal | No signal |
P0345: VVT SENSOR (FOR INTAKE SIDE OF BANK 2) VERIFY PULSE INPUT
| VVT sensor voltage | 0.3 to 4.7 V |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- Idle the engine for 10 seconds or more [B].
- Enter the following menus: Powertrain / Engine / Trouble Codes [C].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0340.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [C] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0351: Igniter (cylinder 1) range check/functional check P0352: Igniter (cylinder 2) range check/functional check P0353: Igniter (cylinder 3) range check/functional check P0354: Igniter (cylinder 4) range check/functional check P0355: Igniter (cylinder 5) range check/functional check P0356: Igniter (cylinder 6) range check/functional check |
| Required Sensors/Components (Main) | Igniter (Cylinder 1 to 6) |
| Required Sensors/Components (Related) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Spark cut | Not operating |
| Either of the following conditions A or B is met | |
| A. Engine speed | 1500 RPM or less |
| B. Starter | OFF |
| Either of the following conditions C or D is met | |
| C. Both of the following conditions (a) and (b) are met | |
| (a) Engine speed | 500 RPM or less |
| (b) Battery voltage | 6 V or more |
| D. All of the following conditions (c), (d) and (e) are met | |
| (c) Engine speed | More than 500 RPM |
| (d) Battery voltage | 10 V or more |
| (e) Number of sparks after CPU reset | 5 sparks or more |
| All of the following conditions are met | A, B, C and D |
| A. Ignition signal fail counter | More than 2 times |
| B. Time after condition A is met | 0.256 seconds or more |
| C. Ignition signal fail count after condition B is met | More than 2 times |
| D. Ignition switch | ON |
| Confirmed ignition signal input when ignition signal is on to off | 2 times |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- Idle the engine for 10 seconds [B].
- Enter the following menus: Powertrain / Engine / Trouble Codes [C].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0351, P0352, P0353 or P0354.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the result shows INCOMPLETE or N/A, perform steps [B] through [C] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-493954-S40015553512012081000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 690
Scheme 690: WIRING DIAGRAM
Scheme 691
