MONITOR STRATEGY
| Related DTCs | P0300: Multiple cylinder misfire P0301: Cylinder 1 misfire P0302: Cylinder 2 misfire P0303: Cylinder 3 misfire P0304: Cylinder 4 misfire P0305: Cylinder 5 misfire P0306: Cylinder 6 misfire |
| Required Sensors / Components (Main) | Fuel injector assembly, ignition coil assembly, spark plug |
| Required Sensors / Components (Related) | Crankshaft, camshaft, engine coolant temperature and intake air temperature sensors and mass air flow meter sub-assembly |
| Frequency of Operation | Continuous |
| Duration | 1000 to 4000 crankshaft revolutions: Emission related misfire 200 to 600 crankshaft revolutions: Catalyst damaged misfire |
| MIL Operation | 2 driving cycles: Emission related misfire MIL flashes immediately: Catalyst damaged misfire |
| Sequence of Operation | None |
TYPICAL ENABLING CONDITIONS
| Monitor runs whenever following DTCs are not present | P0016, P0018 (VVT system bank 1, 2 - misalignment) P0102, P0103 (Mass air flow meter) P0107, P0108 (Manifold absolute pressure) P0112, P0113 (Intake air temperature sensor) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient engine coolant temperature for closed loop) P0327, P0328, P0332, P0333 (Knock sensor) P0335 (Crankshaft position sensor) P0351, P0352, P0353, P0354, P0355, P0356 (Igniter) |
| Battery voltage | 8 V or more |
| VVT system | Not operated by scan tool |
| Engine speed | 750 to 6200 RPM |
| Either of the following conditions is met | Condition (a) or (b) |
| (a) Engine coolant temperature at engine start | More than -7°C (19°F) |
| (b) Engine coolant temperature | More than 20°C (68°F) |
| Fuel cut | OFF |
| First 1000 revolutions after engine start, or check mode | Crankshaft 1000 revolutions |
| Except above | Crankshaft 1000 revolutions x 4 |
MONITOR PERIOD OF EMISSION-RELATED-MISFIRE
| All of the following conditions 1, 2 and 3 are met | Crankshaft 200 revolutions |
| 1. Driving cycle | 1st |
| 2. Check mode | OFF |
| 3. Engine speed | Less than 2500 RPM |
| Except above (MIL blinks immediately) | Crankshaft 200 revolutions x 3 |
MONITOR PERIOD OF CATALYST-DAMAGE-MISFIRE (MIL BLINKS)
TYPICAL MALFUNCTION THRESHOLDS
MONITOR PERIOD OF EMISSION-RELATED-MISFIRE
| Number of misfire per 200 revolutions | 97 or more (varies with intake air amount and engine speed) |
| Paired cylinders misfire (MIL blinks immediately) | Detected |
MONITOR PERIOD OF CATALYST-DAMAGE-MISFIRE (MIL BLINKS)
MONITOR RESULT
Refer to Checking Monitor Status, refer to CHECKING MONITOR STATUS .
Scheme 1043
Scheme 1043: WIRING DIAGRAM
CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch ON.
- Turn the Techstream on.
- Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) .
- Record the DTC(s) and freeze frame data.
- Using the Techstream, switch the ECM from normal mode to check mode, refer to «CHECK MODE PROCEDURE»(ref-426655-S34553543612011101200000) .
- Read the misfire counts of each cylinder (Cylinder #1 (to #6) Misfire Count) with the engine idling. If any misfire count is displayed, skip the following confirmation driving pattern.
- Drive the vehicle several times with the conditions, such as engine speed and engine load, shown in Misfire RPM and Misfire Load in the Data List. HINT: In order to store misfire DTCs, it is necessary to operate the vehicle for the period of time shown in the table below, using the Misfire RPM and Misfire Load in the Data List. Engine Speed Duration Idling 5 minutes or more 1000 4 minutes or more 1500 3 minutes or more 2500 2 minutes or more
- Check whether misfires have occurred by checking DTCs and freeze frame data. HINT: Do not turn the ignition switch off until the stored DTC(s) and freeze frame data have been recorded. When the ECM returns to normal mode (default), the stored DTC(s), freeze frame data and other data will be cleared.
- Record the DTC(s), freeze frame data and misfire counts.
- Turn the ignition switch off and wait for at least 5 seconds.
| Related DTCs | P0327: Knock sensor (bank 1 sensor 1) range check (Low voltage) P0328: Knock sensor (bank 1 sensor 1) range check (High voltage) P0332: Knock sensor (bank 2 sensor 2) range check (Low voltage) P0333: Knock sensor (bank 2 sensor 2) range check (High voltage) |
| Required Sensors/Components (Main) | Knock control sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1 second |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Battery voltage | 10.5 V or more |
| Time after engine start | 5 seconds or more |
| Ignition switch | ON |
| Knock sensor voltage | Less than 0.5 V |
KNOCK SENSOR RANGE CHECK (LOW VOLTAGE): P0327 AND P0332
| Knock sensor voltage | More than 4.5 V |
KNOCK SENSOR RANGE CHECK (HIGH VOLTAGE): P0328 AND P0333
COMPONENT OPERATING RANGE
| Knock sensor voltage | 0.5 to 4.5 V |
Scheme 1044
Scheme 1044: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure), refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) .
- Turn the ignition switch off.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) .
- Start the engine and wait 10 seconds.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the DTC [B]. HINT: If a DTC is not output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0327, P0328, P0332 or P0333.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, idle the engine for 5 minutes and check the DTC judgment result again [C].
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the judgment result [C]. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 1045
Scheme 1045: WIRING DIAGRAM
| Related DTCs | P0335: Crankshaft position sensor verify pulse input P0335: Crankshaft position sensor range check/rationality |
| Required Sensors / Components (Main) | Crankshaft position sensor |
| Required Sensors / Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1.85 seconds |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Lost communication with hybrid control module (U0293) | Not detected |
| Hybrid control module judge | Engine running |
| Monitor runs whenever following DTCs are not present | Camshaft position sensor circuit fail (P0340, P0342, P0343) |
| Time after starter OFF to ON | 2.5 seconds or more |
| Battery voltage | 7 V or more |
| Number of VVT sensor signal pulse | 6 times |
CRANKSHAFT POSITION SENSOR RANGE CHECK/RATIONALITY
| Engine speed | 600 RPM or less |
| Starter | OFF |
| Time after starter ON to OFF | 3 seconds or more |
CRANKSHAFT POSITION SENSOR VERIFY PULSE INPUT (CASE 1)
| Ignition switch | ON |
| Time after ignition switch off to ON | More than 0.5 seconds |
CRANKSHAFT POSITION SENSOR VERIFY PULSE INPUT (CASE 2)
| Number of crankshaft position sensor signal pulse | 132 or less, or 219 or more |
CRANKSHAFT POSITION SENSOR RANGE CHECK/RATIONALITY
| Crankshaft position sensor signal | No signal |
CRANKSHAFT POSITION SENSOR VERIFY PULSE INPUT
| Crankshaft position sensor | Crankshaft position sensor output voltage fluctuates while crankshaft is revolving 34 crankshaft position sensor signals per crankshaft revolution |
Scheme 1046
Scheme 1046: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure), refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) .
- Turn the ignition switch off.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) .
- Start the engine.
- Idle the engine for 20 seconds or more [B].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the DTC [C]. HINT: If a DTC is not output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0335 or P0339.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [C] again.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows NORMAL, the system is normal. f the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 1047
Scheme 1047: WIRING DIAGRAM
| Related DTCs | P0340: VVT sensor (Bank 1) verify pulse input P0342: VVT sensor (Bank 1) range check (low voltage) P0343: VVT sensor (Bank 1) range check (high voltage) P0345: VVT sensor (Bank 2) verify pulse input P0347: VVT sensor (Bank 2) range check (low voltage) P0348: VVT sensor (Bank 2) range check (high voltage) |
| Required Sensors / Components (Main) | VVT sensor (Bank 1 and 2) |
| Required Sensors / Components (Related) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 4 seconds: P0342 and P0347 (VVT sensor (bank 1, 2) range check (low voltage) P0343 and P0348 (VVT sensor (bank 1, 2) range check (high voltage) 5 seconds: P0340 (VVT sensor (bank 1) verify pulse input) P0345 (VVT sensor (bank 2) verify pulse input) |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Engine speed | 600 RPM or more |
| Starter | Off |
| VVT system misalignment | Not detected |
| VVT sensor range check fail (P0342, P0343) | Not detected |
| VVT sensor voltage | 0.3 V or more, and 4.7 V or less |
| Hybrid control module judge | Engine running |
| Lost communication with hybrid control module (U0293) | Not detected |
P0340: VVT SENSOR (BANK 1) VERIFY PULSE INPUT
| Starter | Off |
| Ignition switch | ON |
| Time after ignition switch off to ON | 2 seconds or more |
| VVT sensor verify pulse input fail (P0340) | Not detected |
| Battery voltage | 8 V or more |
P0342, P0343: VVT SENSOR (BANK 1) RANGE CHECK
| Engine speed | 600 RPM or more |
| Starter | Off |
| VVT sensor range check fail (P0342, P0343, P0347, P0348) | Not detected |
| VVT sensor voltage | 0.3 V or more, and 4.7 V or less |
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Time after ignition switch off to ON | 0.5 seconds or more |
| Hybrid control module judge | Engine running |
| Lost communication with hybrid control module (U0293) | Not detected |
P0345: VVT SENSOR (BANK 2) VERIFY PULSE INPUT
| Starter | Off |
| Ignition switch | ON |
| Time after ignition switch off to ON | 2 seconds or more |
| VVT sensor verify pulse input fail (P0340, P0345) | Not detected |
| Battery voltage | 8 V or more |
P0347, P0348: VVT SENSOR (BANK 1) RANGE CHECK
| Camshaft position and crankshaft position alignment | Misalignment |
| VVT sensor signal | No signal |
P0340: VVT SENSOR (BANK 1) VERIFY PULSE INPUT
| VVT sensor voltage | Less than 0.3 V |
P0342, P0347: VVT SENSOR (BANK 1, 2) RANGE CHECK (LOW VOLTAGE)
| VVT sensor signal | No signal |
P0345: VVT SENSOR (BANK 2) VERIFY PULSE INPUT
| VVT sensor voltage | More than 4.7 V |
P0343, P0348: VVT SENSOR (BANK 1, 2) RANGE CHECK (HIGH VOLTAGE)
| VVT sensor voltage | 0.3 to 4.7 V |
Scheme 1048
Scheme 1048: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure), refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) .
- Turn the ignition switch off.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) .
- Start the engine.
- Idle the engine for 10 seconds or more [B].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the DTC [C]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0340, P0342, P0343, P0345, P0347 or P0348.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [C] again.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0351: Igniter (cylinder 1) range check/functional check P0352: Igniter (cylinder 2) range check/functional check P0353: Igniter (cylinder 3) range check/functional check P0354: Igniter (cylinder 4) range check/functional check P0355: Igniter (cylinder 5) range check/functional check P0356: Igniter (cylinder 6) range check/functional check |
| Required Sensors/Components (Main) | Igniter (Cylinder 1 to 6) |
| Required Sensors/Components (Related) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 0.256 seconds |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | Lost communication with hybrid control module (U0293) |
| Hybrid control module judge | Engine running |
| Either of the following conditions A or B is met | |
| A. Engine speed | 1500 RPM or less |
| B. Starter | OFF |
| Either of the following conditions C or D is met | |
| C. Both of the following conditions (a) and (b) are met | |
| (a) Engine speed | 500 RPM or less |
| (b) Battery voltage | 6 V or more |
| D. All of the following conditions (c), (d) and (e) are met | |
| (c) Engine speed | More than 500 RPM |
| (d) Battery voltage | 10 V or more |
| (e) Number of sparks after CPU reset | 5 sparks or more |
| All of the following conditions A and B are met | |
| A. Ignition signal fail counter | More than 2 times |
| B. Ignition signal fail count after condition A is met | More than 2 times |
| Confirmed ignition signal input when ignition signal is on to off | 2 times |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure), refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) .
- Turn the ignition switch off.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) .
- Start the engine.
- Idle the engine for 10 seconds [B].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the DTC [C]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0351, P0352, P0353, P0354, P0355 or P0356.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [C] again.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 1049
Scheme 1049: WIRING DIAGRAM
Scheme 1050
| Related DTC | P0401: EGR valve high flow rate / low flow rate |
| Required sensors / components (Main) | EGR valve assembly, manifold absolute pressure sensor |
| Required sensors / components (Related) | Engine coolant temperature sensor, vehicle speed sensor |
| Frequency of operation | Once per driving cycle |
| Duration | 3 seconds |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Time after engine started | 3 seconds or more |
| Time after engine fuel cut | 1400 msec or more |
| Engine speed | 850 to 1600 RPM |
| Vehicle speed | 12.5 mph (20 km/h) or more |
| Engine speed change (/65 msec.) | 20 to 20 RPM |
| Time after engine load becomes stable | More than 1.2 sec |
| Engine coolant temperature | 75°C (167°F) or more |
| Battery voltage | 11 V or more |
| Intake air temperature | 10°C (14°F) or more |
| Atmospheric pressure | 76 kPa (570 mmHg) or more |
| Manifold pressure change | Less than 0.7 kPa (5.25 mmHg) |
| At engine speed | 950 RPM |
Scheme 1051
Scheme 1051: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure), refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) .
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) .
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more [B]. HINT: The A/C switch and all accessory switches should be off and shift lever in P or N.
- Drive the vehicle at 37 mph (60 km/h) for 5 minutes or more [C].
- Idle the engine for 30 seconds or more [D].
- Accelerate the vehicle to 37 mph (60 km/h) then select the S4 range with the shift lever in S [E].
- Perform fuel cut operation for 5 seconds or more, with the accelerator pedal fully released [F]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: When fuel cut is operating "Idle Fuel Cut" in Data List is ON.
- Enter the following menus: Powertrain / Engine and ECT / Monitor / Exhaust Gas Recirculation/VVT / Status2 [G].
- Check that the Exhaust Gas Recirculation/VVT / Status2 monitor is Complete. HINT: If the monitor is Incomplete, perform the driving pattern again.
- Select the menus: Powertrain / Engine and ECT / Monitor / Exhaust Gas Recirculation/VVT/Details.
- Check the Details (EGR FLOW INSUFFICIENCY). HINT: Make sure that the value is between MIN and MAX.
- If the monitor is still Incomplete, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Power train / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0401.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the DTC judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, accelerate the vehicle again at 37 mph (60 km/h) the select the S4 range, perform fuel cut operation for 5 seconds or more with the accelerator pedal fully released, and check the DTC judgment result.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0403: EGR valve circuit range check |
| Required sensors / components (Main) | EGR valve assembly |
| Required sensors / components (Related) | |
| Frequency of operation | Continuous |
| Duration | 0.5 seconds |
| MIL operation | Immediately |
| Sequence of operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Engine | Running |
| Battery voltage | 10.5 V or more |
| Time after ignition switch off to ON | More than 0.5 seconds |
| Vehicle speed | 12 mph (20 km/h) or more |
| Monitor runs whenever following DTCs are not present | None |
| One of the following conditions is met | Conditions A, B, C or D |
| A. All of the conditions are met | Conditions 1 and 2 |
| 1. EGR1 output terminal voltage | Low voltage |
| 2. Either of the following conditions is met | Conditions (a) or (b) |
| (a) Step motor | Driving |
| (b) Step motor phase 1 | Not operating |
| B. All of the following conditions are met | Conditions 3 and 4 |
| 3. EGR2 output terminal voltage | Low voltage |
| 4. Either of the following conditions is met | Conditions (c) or (d) |
| (c) Step motor | Driving |
| (d) Step motor phase 2 | Not operating |
| C. All of the following conditions are met | Conditions 5 and 6 |
| 5. EGR3 output terminal voltage | Low voltage |
| 6. Either of the following conditions is met | Conditions (e) or (f) |
| (e) Step motor | Driving |
| (f) Step motor phase 3 | Not operating |
| D. All of the following conditions are met | Conditions 7 and 8 |
| 7. EGR4 output terminal voltage | Low voltage |
| 8. Either of the following conditions is met | Conditions (g) or (h) |
| (g) Step motor | Driving |
| (h) Step motor phase 4 | Not operating |
Scheme 1052
Scheme 1052: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure), refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) .
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) .
- Start the engine and warm it up [B].
- Drive the vehicle at 12 mph (20 km/h) or more for 10 minutes [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the DTC [D]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0403.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [C] again.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 1053
Scheme 1053: WIRING DIAGRAM
| Related DTCs | P0420: Catalyst deterioration P0430: Catalyst deterioration |
| Required Sensors / Components (Main) | Air fuel ratio sensor and heated oxygen sensor |
| Required Sensors / Components (Related) | Intake air temperature sensor, mass air flow meter sub-assembly, crankshaft position sensor and engine coolant temperature sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | About 30 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | P0010, P0020 (Camshaft timing oil control valve assembly bank 1, 2) P0011, P0021 (VVT system bank 1, 2 - advance) P0012, P0022 (VVT system bank 1, 2 - retard) P0016, P0018 (VVT system bank 1, 2 - misalignment) P0031, P0032, P0051, P0052, P101D, P103D (Air fuel ratio sensor heater) P0037, P0038, P0057, P0058, P102D, P105D (Heated oxygen sensor heater) P0102, P0103 (Mass air flow meter) P0107, P0108 (Manifold absolute pressure) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient engine coolant temperature for closed loop) P0136, P0137, P0138, P0139 (Heated oxygen sensor bank 1) P014C, P014D, P014E, P014F (Air fuel ratio sensor - slow response) P015A, P015B, P015C, P015D (Air fuel ratio sensor - delayed response) P0156, P0157, P0158, P0159 (Heated oxygen sensor bank 2) P0171, P0172, P0174, P0175 (Fuel system) P0301, P0302, P0303, P0304, P0305, P0306 (Misfire) P0335 (Crankshaft position sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) P0351, P0352, P0353, P0354, P0355, P0356 (Igniter) P0607 (Heated oxygen sensor - sensor 2) P2195, P2196, P2197, P2198 (Air fuel ratio sensor - rationality) P219A, P219B (Air fuel ratio sensor - imbalance) P2237, P2240 (Air fuel ratio sensor - open) P2238, P2241, P2252, P2255 (Air fuel ratio sensor - low impedance) P2239, P2242, P2253, P2256 (Air fuel ratio sensor - high impedance) |
| Battery voltage | 11 V or more |
| Intake air temperature | 10°C (14°F) or more |
| Engine coolant temperature | 75°C (167°F) or more |
| Atmospheric pressure | 76 kPa (570 mmHg) or more |
| Idle | OFF |
| Engine speed | Less than 3200 RPM |
| Air fuel ratio sensor | Activated |
| Fuel system status | Closed loop |
| Engine load | 10 to 70% |
| All of the following conditions are met | Conditions 1, 2 and 3 |
| 1. Mass air flow rate | 3 to 63 gm/s |
| 2. Front catalyst temperature (estimated) | 530 to 770°C (986 to 1418°F) |
| 3. Rear catalyst temperature (estimated) | 400 to 675°C (752 to 1247°F) |
| Oxygen storage capacity of catalyst | Less than 0.08 g (0.0001764 lb) |
Performing this confirmation pattern will activate the catalyst monitor. This is very useful for verifying the completion of a repair.
Scheme 1054
Scheme 1054: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure), refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) .
- Turn the ignition switch off.
- Turn the ignition switch to ON and turn the Techstream on.
- Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) .
- Enter the following menus: Powertrain / Engine and ECT / Monitor.
- Check that Catalyst / Status2 is Incomplete.
- Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or more) [A].
- Drive the vehicle at between 40 mph and 70 mph (64 km/h and 113 km/h) for at least 10 minutes or more [B].
- The monitor items will change to Complete as catalyst monitor operates.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
- Check if any DTCs (pending DTCs) are set.
If Catalyst does not change to Complete, and no pending DTCs are set, extend the driving time.
Refer to Checking Monitor Status, refer to CHECKING MONITOR STATUS .
PROCEDURE
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0420 AND/OR P0430) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0420 and/or P0430 are output A DTC P0420 and/or P0430 and other DTCs are output B HINT: If any DTCs other than P0420 or P0430 are output, troubleshoot those DTCs first. B --> See step 13 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (AIR FUEL RATIO CONTROL) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) . Start the engine. Warm up the engine at an engine speed of 2500 RPM for approximately 90 seconds. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume for A/F Sensor. Perform the Control the Injection Volume for A/F Sensor operation with the engine idling (press the RIGHT or LEFT button to change the fuel injection volume). Monitor the voltage outputs of the air fuel ratio and heated oxygen sensors (AFS Voltage B1S1 and O2S B1S2 or AFS Voltage B2S1 and O2S B2S2) displayed on the Techstream. HINT: The Control the Injection Volume for A/F Sensor operation lowers the fuel injection volume by 12.5% or increases the injection volume by 25%. Each sensor reacts in accordance with increases and decreases in the fuel injection volume. Techstream Display (Sensor) Injection Volume Status Voltage AFS Voltage B1S1 or AFS Voltage B2S1 (Air fuel ratio) +25% Rich Less than 3.1 V AFS Voltage B1S1 or AFS Voltage B2S1 (Air fuel ratio) -12.5% Lean More than 3.4 V O2S B1S2 or O2S B2S2 (Heated oxygen) +25% Rich More than 0.55 V O2S B1S2 or O2S B2S2 (Heated oxygen) -12.5% Lean Less than 0.4 V Result Status AFS Voltage B1S1 or AFS Voltage B2S1 Status O2S B1S2 or O2S B2S2 Air Fuel Ratio Condition and Air Fuel Ratio and Heated Oxygen Sensor Condition Misfire Suspected Trouble Area Proceed to Lean/Rich Lean/Rich Normal - Three-way catalytic converter Gas leaks from exhaust system EGR valve assembly A Lean Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor B Rich Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor B Lean/Rich Lean Heated oxygen sensor malfunction - Heated oxygen sensor Gas leaks from exhaust system C Lean/Rich Rich Heated oxygen sensor malfunction - Heated oxygen sensor Gas leaks from exhaust system C Lean Lean Actual air fuel ratio lean May occur Extremely rich or lean actual air fuel ratio Gas leaks from exhaust system EGR valve assembly D Rich Rich Actual air fuel ratio rich - Extremely rich or lean actual air fuel ratio Gas leaks from exhaust system EGR valve assembly D Lean: During the Control the Injection Volume for A/F Sensor Active Test, the air fuel ratio sensor output voltage (AFS Voltage) is consistently more than 3.4 V, and the heated oxygen sensor output voltage (O2S) is consistently less than 0.4 V. Rich: During the Control the Injection Volume for A/F Sensor Active Test, the AFS Voltage is consistently less than 3.1 V, and the O2S is consistently more than 0.55 V. Lean/Rich: During the Control the Injection Volume for A/F Sensor Active Test, the output voltage of the heated oxygen sensor alternates correctly. B --> See step 14 C --> See step 9 D --> See step 10 A: Go to next step
- INSPECT FOR EXHAUST GAS LEAK Inspect for exhaust gas leaks from the exhaust manifold sub-assembly and exhaust pipes. OK No gas leaks. NG --> REPAIR OR REPLACE EXHAUST GAS LEAK POINT OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) . Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position. Confirm the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when Active Test is completed. OK MAP and idling condition change in response to EGR step position as follows. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition Steady idling Idling changes from steady to rough idling or engine stall MAP (Data List) 20 to 40 kPa (150 to 300 mmHg) (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, then there is probably a malfunction in EGR valve. Result Result Proceed to Outside standard range A Within standard range B B --> See step 6 A: Go to next step
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly, refer to «REMOVAL»(ref-426771-S16321691292011101200000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. Reinstall the EGR valve assembly, refer to «INSTALLATION»(ref-426771-S21548001202011101200000) . NG --> See step 15 OK: Go to next step
- CHECK DTC OUTPUT (DTC P0420 AND/OR P0430) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0420 is output A DTC P0430 is output B DTCs P0420 and P0430 are output A and B B --> See step 8 A: Go to next step
- REPLACE EXHAUST MANIFOLD SUB-ASSEMBLY RH (TWC: FRONT CATALYST) Replace the exhaust manifold sub-assembly RH (TWC: Front catalyst), refer to «REMOVAL»(ref-426788-S35747099552011101200000) . NEXT --> See step 16
- REPLACE EXHAUST MANIFOLD SUB-ASSEMBLY LH (TWC: FRONT CATALYST) Replace the exhaust manifold sub-assembly LH (TWC: Front catalyst), refer to «REMOVAL»(ref-426788-S35747099552011101200000) . NEXT --> See step 16
- INSPECT FOR EXHAUST GAS LEAK Inspect for exhaust gas leaks from the exhaust manifold sub-assembly and exhaust pipes. OK No gas leaks. NG --> REPAIR OR REPLACE EXHAUST GAS LEAK POINT OK --> See step 17
- INSPECT FOR EXHAUST GAS LEAK Inspect for exhaust gas leaks from the exhaust manifold sub-assembly and exhaust pipes. OK No gas leaks. NG --> REPAIR OR REPLACE EXHAUST GAS LEAK POINT OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) . Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position. Confirm the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when Active Test is completed. OK MAP and idling condition change in response to EGR step position as follows. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition Steady idling Idling changes from steady to rough idling or engine stall MAP (Data List) 20 to 40 kPa (150 to 300 mmHg) (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, then there is probably a malfunction in EGR valve. Result Result Proceed to Outside standard range A Within standard range B B --> See step 18 A: Go to next step
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly, refer to «REMOVAL»(ref-426771-S16321691292011101200000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. Reinstall the EGR valve assembly, refer to «INSTALLATION»(ref-426771-S21548001202011101200000) . NG --> See step 15 OK --> See step 18
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-426655-S36857909882011101200000)
- REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-426780-S22078568692011101200000)
- REPLACE EGR VALVE ASSEMBLY. Refer to «REMOVAL»(ref-426771-S16321691292011101200000)
- REPLACE CENTER EXHAUST PIPE ASSEMBLY (TWC: REAR CATALYST). Refer to «REMOVAL»(ref-426788-S35747099552011101200000)
- REPLACE HEATED OXYGEN SENSOR. Refer to «REMOVAL»(ref-426780-S22627534832011101200000)
- CHECK ENGINE TO DETERMINE CAUSE OF EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO. Refer to «DTC P0171: System Too Lean (Bank 1); DTC P0172: System Too Rich (Bank 1); DTC P0174: System Too Lean (Bank 2); DTC P0175: System Too Rich (Bank 2)»(ref-426784-S41984111852011101200000)
| Related DTCs | P043E: Reference orifice low-flow (built-in canister pump module) P043F: Reference orifice high-flow (built-in canister pump module) P2401: Leak detection pump stuck off P2402: Leak detection pump stuck on P2419: Vent valve stuck open (vent) |
| Required Sensors / Components | Canister pump module |
| Frequency of Operation | Once per driving cycle |
| Duration | Within 2 minutes |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever these DTCs are not present | Pressure sensor of canister pump module malfunction (P0452 and P0453) Fuel tank pressure sensor malfunction (P1452 and P1453) |
| EVAP key-off monitor runs when all of the following conditions are met | |
| Atmospheric pressure | 70 to 111 kPa (525 to 833 mmHg) |
| Battery voltage | 10.5 V or more |
| Vehicle speed | Less than 2.5 mph (4 km/h) |
| Ignition switch | Off |
| Engine condition | Not running |
| Key-OFF duration | 5 or 7 or 9.5 hours |
| Purge VSV | Not operated by scan tool |
| Vent valve | Not operated by scan tool |
| Leak detection pump | Not operated by scan tool |
| Both of the following conditions are met before Key-OFF | Conditions 1 and 2 |
| 1. Duration that vehicle is being driven | 5 minutes or more |
| 2. Purge flow | Executed |
| Engine coolant temperature | 4.4 to 35°C (40 to 95°F) |
| Intake air temperature | 4.4 to 35°C (40 to 95°F) |
Key-off monitor sequence 1 to 15
| Next sequence is run if the following condition is met | |
| Atmospheric pressure change | Less than 0.3 kPa (gauge) (2.25 mmHg (gauge) per second |
1. ATMOSPHERIC PRESSURE MEASUREMENT
| Next sequence is run if all of the following conditions are met | Condition 1, 2 and 3 |
| 1. Canister pressure when reference pressure measurement started | 1 kPa (gauge) (-7.5 mmHg (gauge) or less |
| 2. Reference pressure | 4.75 to -0.957 kPa (gauge) (-35.62 to -7.18 mmHg (gauge) |
| 3. Reference pressure | Saturated |
2. FIRST REFERENCE PRESSURE MEASUREMENT
| Next sequence is run if the following condition is met | |
| Canister pressure change after vent valve ON (Closed) | 0.3 kPa (gauge) (2.25 mmHg (gauge) or more |
3. VENT VALVE CLOSE STUCK CHECK
| Next sequence is run if the both of the following conditions are met | Condition 1 and 2 |
| 1. Vacuum introduction time | 15 minutes or less |
| 2. Canister pressure | Saturated |
4. VACUUM INTRODUCTION FOR CANISTER
| Next sequence is run if the following condition is met | |
| Canister pressure change for 10 seconds after purge VSV ON (Open). | 0.3 kPa (gauge) (2.25 mmHg (gauge) or more |
5. PURGE VSV STUCK CLOSED CHECK
| Next sequence is run if all of the following conditions are met | Condition 1, 2, 3 and 4 |
| 1. Canister pressure when reference pressure measurement started | 1 kPa (gauge) (-7.5 mmHg (gauge) or less |
| 2. Reference pressure | 4.75 to -0.957 kPa (gauge) (-35.62 to -7.18 mmHg (gauge) |
| 3. Reference pressure | Saturated |
| 4. Reference pressure difference between the first and second | Less than 0.9 kPa (gauge) (6.75 mmHg (gauge) |
6. SECOND REFERENCE PRESSURE MEASUREMENT
| One of the sequence 8 or 9 is run if the following condition is met | |
| Canister pressure when vacuum introduction for canister was complete | Second reference pressure or less |
| Sequence 14 is run if all of the following conditions are met | Conditions 1 and 2 |
| 1. Fuel tank pressure when EVAP monitor started | 2 kPa (gauge) (-15 mmHg (gauge) or less, or 3 kPa (gauge) (22.5 mmHg (gauge) or more |
| 2. Fuel tank pressure change while TCV and vent valve are open | 0.5 kPa (gauge) (3.75 mmHg (gauge) or more |
8. FUEL TANK CLOSED VALVE (TCV) STUCK CLOSED CHECK
| Next sequence is run if both of the following conditions are met | Conditions 1 and 2 |
| 1. Fuel tank pressure when EVAP monitor started | 2 to 3 kPa (gauge) (-15 to 22.5 mmHg (gauge) |
| 2. Vacuum introduction time | 15 minutes or less |
9. VACUUM INTRODUCTION FOR FUEL TANK
| Next sequence is run if the following condition is met | |
| Fuel tank pressure change when vacuum introduction for fuel tank | 0.5 kPa (gauge) (3.75 mmHg (gauge) or more |
10. TCV STUCK CLOSED CHECK
| Next sequence is run if the following condition is met | |
| Fuel tank pressure change when TCV closed | 0.35 kPa (gauge) (2.6 mmHg (gauge) or more |
11. FUEL TANK PRESSURE SENSOR STUCK CHECK
| Next sequence is run if all of the following conditions are met | Conditions 1, 2, 3, and 4 |
| 1. Fuel tank pressure when 1.9 seconds after reference pressure measurement began | 1 kPa (gauge) (-7.5 mmHg (gauge) or less |
| 2. Reference pressure | 4.75 to -0.957 kPa (gauge) (-35.62 to -7.18 mmHg (gauge) |
| 3. Reference pressure | Saturated |
| 4. Reference pressure difference between the second and third | Less than 0.9 kPa (gauge) (6.75 mmHg (gauge) |
12 THIRD REFERENCE PRESSURE MEASUREMENT
| Sequence 15 is run if the following condition is met | |
| Fuel tank pressure when vacuum introduction for fuel tank was complete | Less than third reference pressure |
| Next sequence is run if the following condition is met | |
| Fuel tank pressure change while TCV and vent valve are open | Less than 0.35 kPa (gauge) (2.6 mmHg (gauge) |
14. FUEL TANK PRESSURE SENSOR STUCK CHECK
| Monitor is complete if the following condition is met | |
| Atmospheric pressure difference between sequence 1 and 8 | Less than 0.3 kPa (gauge) (2.25 mmHg (gauge) |
15. ATMOSPHERIC PRESSURE MEASUREMENT
| Following values are values when atmospheric pressure is 100 kPa (760 mmHg) | |
| One of the following conditions is met | |
| Canister pressure when 1.9 seconds after reference pressure measurement began | More than -1 kPa (-7.5 mmHg) |
| Reference pressure (vary with atmospheric pressure) | Less than -4.85 kPa (-36.38 mmHg) |
| Reference pressure (vary with atmospheric pressure) | 1.057 kPa (-7.93 mmHg) or more |
| Reference pressure (vary with atmospheric pressure) | Not saturated |
| Reference pressure difference between the first and second | 0.9 kPa (6.75 mmHg) or more |
Scheme 1055
Scheme 1055: CONFIRMATION DRIVING PATTERN
Note. The Evaporative System Check (Automatic Mode) consists of 8 steps performed automatically by the Techstream. It takes a maximum of approximately 18 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or more, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure), refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) .
- Turn the ignition switch off.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode [A].
- After the Evaporative System Check is completed, check for DTCs by entering the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
- Read the Pending DTC [B]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Input the DTC: P043E, P043F, P2401, P2402 or P2419.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [A] again.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Refer to Checking Monitor Status, refer to CHECKING MONITOR STATUS .
| Required Sensors/Components | Purge VSV and canister pump module |
| Frequency of Operation | Once per driving cycle |
| Duration | Within 15 minutes |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | Pressure sensor of canister pump module malfunction (P0450, P0451, P0453) |
| Engine | Running |
| Engine coolant temperature | 4.4°C (40°F) or more |
| Intake air temperature | 4.4°C (40°F) or more |
| Purge VSV | Not operated by scan tool |
| EVAP system check | Not operated by scan tool |
| Battery voltage | 10 V or more |
| Purge duty cycle | 8% or more |
| Monitor runs whenever these DTCs are not present | Pressure sensor of canister pump module malfunction (P0452 and P0453) Fuel tank pressure sensor malfunction (P1452 and P1453) |
| EVAP key-off monitor runs when all of the following conditions are met | |
| Atmospheric pressure | 70 to 111 kPa (525 to 833 mmHg) |
| Battery voltage | 10.5 V or more |
| Vehicle speed | Less than 2.5 mph (4 km/h) |
| Ignition switch | Off |
| Engine condition | Not running |
| Key-OFF duration | 5 or 7 or 9.5 hours |
| Purge VSV | Not operated by scan tool |
| Vent valve | Not operated by scan tool |
| Leak detection pump | Not operated by scan tool |
| Both of the following conditions are met before Key-OFF | Conditions 1 and 2 |
| 1. Duration that vehicle is being driven | 5 minutes or more |
| 2. Purge flow | Executed |
| Engine coolant temperature | 4.4 to 35°C (40 to 95°F) |
| Intake air temperature | 4.4 to 35°C (40 to 95°F) |
Key-off monitor sequence 1 to 15
| Next sequence is run if the following condition is met | |
| Atmospheric pressure change | Less than 0.3 kPa (gauge) (2.25 mmHg (gauge) per second |
1. ATMOSPHERIC PRESSURE MEASUREMENT
| Next sequence is run if all of the following conditions are met | Condition 1, 2 and 3 |
| 1. Canister pressure when reference pressure measurement started | 1 kPa (gauge) (-7.5 mmHg (gauge) or less |
| 2. Reference pressure | 4.75 to -0.957 kPa (gauge) (-35.62 to -7.18 mmHg (gauge) |
| 3. Reference pressure | Saturated |
2. FIRST REFERENCE PRESSURE MEASUREMENT
| Next sequence is run if the following condition is met | |
| Canister pressure change after vent valve ON (Closed) | 0.3 kPa (gauge) (2.25 mmHg (gauge) or more |
3. VENT VALVE CLOSE STUCK CHECK
| Next sequence is run if the both of the following conditions are met | Condition 1 and 2 |
| 1. Vacuum introduction time | 15 minutes or less |
| 2. Canister pressure | Saturated |
4. VACUUM INTRODUCTION FOR CANISTER
| Next sequence is run if the following condition is met | |
| Canister pressure change for 10 seconds after purge VSV ON (Open). | 0.3 kPa (gauge) (2.25 mmHg (gauge) or more |
5. PURGE VSV STUCK CLOSED CHECK
| Next sequence is run if all of the following conditions are met | Condition 1, 2, 3 and 4 |
| 1. Canister pressure when reference pressure measurement started | 1 kPa (gauge) (-7.5 mmHg (gauge) or less |
| 2. Reference pressure | 4.75 to -0.957 kPa (gauge) (-35.62 to -7.18 mmHg (gauge) |
| 3. Reference pressure | Saturated |
| 4. Reference pressure difference between the first and second | Less than 0.9 kPa (gauge) (6.75 mmHg (gauge) |
6. SECOND REFERENCE PRESSURE MEASUREMENT
| One of the sequence 8 or 9 is run if the following condition is met | |
| Canister pressure when vacuum introduction for canister was complete | Second reference pressure or less |
| Sequence 14 is run if all of the following conditions are met | Conditions 1 and 2 |
| 1. Fuel tank pressure when EVAP monitor started | 2 kPa (gauge) (-15 mmHg (gauge) or less, or 3 kPa (gauge) (22.5 mmHg (gauge) or more |
| 2. Fuel tank pressure change while TCV and vent valve are open | 0.5 kPa (gauge) (3.75 mmHg (gauge) or more |
8. FUEL TANK CLOSED VALVE (TCV) STUCK CLOSED CHECK
| Next sequence is run if both of the following conditions are met | Conditions 1 and 2 |
| 1. Fuel tank pressure when EVAP monitor started | 2 to 3 kPa (gauge) (-15 to 22.5 mmHg (gauge) |
| 2. Vacuum introduction time | 15 minutes or less |
9. VACUUM INTRODUCTION FOR FUEL TANK
| Next sequence is run if the following condition is met | |
| Fuel tank pressure change when vacuum introduction for fuel tank | 0.5 kPa (gauge) (3.75 mmHg (gauge) or more |
10. TCV STUCK CLOSED CHECK
| Next sequence is run if the following condition is met | |
| Fuel tank pressure change when TCV closed | 0.35 kPa (gauge) (2.6 mmHg (gauge) or more |
11. FUEL TANK PRESSURE SENSOR STUCK CHECK
| Next sequence is run if all of the following conditions are met | Conditions 1, 2, 3, and 4 |
| 1. Fuel tank pressure when 1.9 seconds after reference pressure measurement began | 1 kPa (gauge) (-7.5 mmHg (gauge) or less |
| 2. Reference pressure | 4.75 to -0.957 kPa (gauge) (-35.62 to -7.18 mmHg (gauge) |
| 3. Reference pressure | Saturated |
| 4. Reference pressure difference between the second and third | Less than 0.9 kPa (gauge) (6.75 mmHg (gauge) |
12 THIRD REFERENCE PRESSURE MEASUREMENT
| Sequence 15 is run if the following condition is met | |
| Fuel tank pressure when vacuum introduction for fuel tank was complete | Less than third reference pressure |
| Next sequence is run if the following condition is met | |
| Fuel tank pressure change while TCV and vent valve are open | Less than 0.35 kPa (gauge) (2.6 mmHg (gauge) |
14. FUEL TANK PRESSURE SENSOR STUCK CHECK
| Monitor is complete if the following condition is met | |
| Atmospheric pressure difference between sequence 1 and 8 | Less than 0.3 kPa (gauge) (2.25 mmHg (gauge) |
15. ATMOSPHERIC PRESSURE MEASUREMENT
| Both of the following conditions are met | Conditions 1 and 2 |
| 1. Canister pressure change when purge operation is started | Less than 0.1 kPa (0.75 mmHg) |
| 2. Canister pressure change during operation when vent valve is closed | Less than 0.5 kPa (3.75 mmHg) |
| Canister pressure when vacuum introduction for canister was completed | Higher than reference pressure x 0.2 |
| Canister pressure change for 10 seconds after purge VSV ON (open) | Less than 0.3 kPa (2.25 mmHg) |
Scheme 1056
Scheme 1056: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure), refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) .
- Turn the ignition switch off.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) .
- Start the engine and wait 15 minutes or more [B].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes/ Pending.
- Read the pending DTC [C]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All readiness.
- Input the DTC: P0441.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit NOTE: The Evaporative System Check (Automatic Mode) consists of 8 steps performed automatically by the Techstream. It takes a maximum of approximately 18 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or more, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear the DTC operation), refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) .
- Turn the ignition switch off.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode [D].
- After the Evaporative System is completed, check for DTC by entering the following menus: Powertrain / Engine and ECT / Trouble Codes / pending.
- Read the pending DTC [E]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0441.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [D].
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Refer to Checking Monitor Status, refer to CHECKING MONITOR STATUS .
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO P0441) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTC. Result Result Proceed to DTC P0441 is output A DTC P0441 and other DTCs are output B B --> See step 4 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) . Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position. Confirm the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when Active Test is completed. OK MAP and idling condition change in response to EGR step position as follows. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition Steady idling Idling changes from steady to rough idling or engine stall MAP (Data List) 20 to 40 kPa (150 to 300 mmHg) (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, then there is probably a malfunction in EGR valve. Result Result Proceed to Outside standard range A Within standard range B B --> See step 6 A: Go to next step
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly, refer to «REMOVAL»(ref-426771-S16321691292011101200000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. Reinstall the EGR valve assembly, refer to «INSTALLATION»(ref-426771-S21548001202011101200000) . NG --> See step 5 OK --> See step 6
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-426655-S36857909882011101200000)
- REPLACE EGR VALVE ASSEMBLY. Refer to «REMOVAL»(ref-426771-S16321691292011101200000)
- GO TO EVAP SYSTEM. Refer to «EVAP System»(ref-426777-S34215481402011101200000)
| Related DTCs | P0451: Evaporative emission control system canister pressure sensor noise P0451: Evaporative emission control system canister pressure sensor stuck P0452: Evaporative emission control system canister pressure sensor/switch low input P0453: Evaporative emission control system canister pressure sensor/switch high input |
| Required Sensors / Components | Canister pump module |
| Frequency of Operation | Once per driving cycle: P0451 sensor stuck Continuous: P0451 sensor noising, P0452 and P0453 |
| Duration | Less than 15 seconds: P0451 (Pressure sensor noise) Within 2 minutes: P0451 (Pressure sensor stuck) 0.5 seconds: P0452, P0453 |
| MIL Operation | Immediately: P0452, P0453 2 driving cycles: P0451 |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | Pressure sensor of canister pump module malfunction (P0452, P0453) |
| Atmospheric pressure | 70 to 111 kPa (525 to 832 mmHg) |
| Battery voltage | 10.5 V or more |
| Intake air temperature | 4.4 to 50°C (40 to 122°F) |
| Either of the following conditions 1 or 2 is met | |
| 1. Engine condition | Running |
| 2. Time after key-off | 5, 7 or 9.5 hours |
| Ignition switch | ON |
| Battery voltage | 8 V or more |
| Frequency that canister pressure change is 0.3 kPa (2.25 mmHg) or more | 10 times or more in 10 seconds |
| EVAP pressure | Less than 42.11 kPa (316 mmHg) |
P0452: CANISTER PRESSURE SENSOR LOW VOLTAGE
| EVAP pressure | More than 123.761 kPa (928.5 mmHg) |
P0453: CANISTER PRESSURE SENSOR HIGH VOLTAGE
Note. The Evaporative System Check (Automatic Mode) consists of 8 steps performed automatically by the Techstream. It takes a maximum of approximately 18 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 50°C (122°F) or more, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 50°C (122°F).
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Data List / Intake Air.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure), refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) .
- Turn the ignition switch off.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode [A].
- After the Evaporative System Check is completed, check for DTCs by entering the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
- Read the pending DTC [B]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- After the Evaporative System Check is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All readiness.
- Input the DTC: P0451, P0452 or P0453.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] again.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 1057
Scheme 1057: WIRING DIAGRAM
| Related DTCs | P0505: Idle speed control function |
| Required Sensors / Components (Main) | Electronic throttle control system |
| Required Sensors / Components (Related) | Crankshaft position sensor, engine coolant temperature sensor, and vehicle speed sensor |
| Frequency of Operation | Continuous |
| Duration | 10 minutes (Idling after warming up) |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | P0010, P0020 (Camshaft timing oil control valve assembly bank 1, 2) P0011, P0021 (VVT system bank 1, 2 - advance) P0012, P0022 (VVT system bank 1, 2 - retard) P0016, P0018 (VVT system bank 1, 2 - misalignment) P0031, P0032, P0051, P0052, P101D, P103D (Air fuel ratio sensor heater) P0102, P0103 (Mass air flow meter) P0107, P0108 (Manifold absolute pressure) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient engine coolant temperature for closed loop) P014C, P014D, P014E, P014F (Air fuel ratio sensor - slow response) P015A, P015B, P015C, P015D (Air fuel ratio sensor - delayed response) P0171, P0172, P0174, P0175 (Fuel system) P0301, P0302, P0303, P0304, P0305, P0306 (Misfire) P0335 (Crankshaft position sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) P0351, P0352, P0353, P0354, P0355, P0356 (Igniter) P0401 (EGR system) P0451, P0452, P0453, P1451, P1452, P1453 (Evaporative emission control system) P2195, P2196, P2197, P2198 (Air fuel ratio sensor - rationality) P219A, P219B (Air fuel ratio sensor - imbalance) P2237, P2240 (Air fuel ratio sensor - open) P2238, P2241, P2252, P2255 (Air fuel ratio sensor - low impedance) P2239, P2242, P2253, P2256 (Air fuel ratio sensor - high impedance) |
| Engine | Running |
| Either of the following conditions is met | Condition 1 or 2 |
| 1. Both of following conditions (a) and (b) | |
| (a) Engine speed - target engine speed | Less than -100 RPM, or more than 200 RPM (A/C ON or NSW ON) Less than -100 RPM, or more than 150 RPM (A/C OFF and NSW OFF) |
| (b) IAC flow rate learning value | 1.3 L/sec. or less, or 8.5 L/sec. or more for 5 second |
| 2. Both of following conditions (c) and (d) | |
| (c) Frequency that both of following conditions 1) and 2) | 5 time or more |
| (d) Either of following conditions | 3) or 4) |
| 3) Amount of change of IAC flow rate learning value | +2.31 L/sec. or more or -3.96 L/sec. or less |
| 4) IAC flow rate learning value | 1.3 L/sec. or less, or 8.5 L/sec. or more |
Scheme 1058
Scheme 1058: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp.
- Make sure that the coolant temperature is 60°C (140°F) or less [A]. HINT: If the coolant temperature is 60°C (140°F) or more, the engine may stop when idling. Make sure to keep the coolant temperature at 60°C (140°F) or less during the driving pattern.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure), refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) .
- Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) .
- Start the engine and drive the vehicle until the coolant temperature reaches 70°C (158°F) [B].
- Stop the vehicle (0 mph (0 km/h) [C].
- Accelerate the vehicle to 28 to 31 mph (45 to 50 km/h) or more, and then idle the engine [D]. HINT: If the vehicle speed reaches more than 31 mph (50 km/h), the engine may stop while decelerating.
- Stop the vehicle (0 mph (0 km/h) [E].
- Repeat steps [D] and [E] for 4 times or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
- Read the pending DTC [F]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0505.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, repeat steps [D] and [E] for 4 times or more, and then check the DTC judgment result.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If a permanent DTC is not output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0505) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0505 is output A DTC P0505 and other DTCs are output B HINT: If any DTCs other than P0505 are output, troubleshoot those DTCs first. B --> See step 9 A: Go to next step
- CHECK PCV HOSE (HOSE CONNECTIONS) Check the PCV hose connections, refer to «ON-VEHICLE INSPECTION - Step 2»(ref-426783-S09075010392011101200000) . OK PCV hose is connected correctly and is not damaged. NG --> REPAIR OR REPLACE PCV HOSE OK: Go to next step
- CHECK INTAKE SYSTEM Check the intake system for vacuum leaks, refer to «ON-VEHICLE INSPECTION - Step 1»(ref-426782-S32913494442011101200000) . OK No leaks in intake system. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
- CHECK THROTTLE WITH MOTOR BODY ASSEMBLY (VISUALLY CHECK THROTTLE VALVE) Check for contamination between the throttle valve and the housing. And check that the throttle valve moves smoothly. OK Throttle valve is not contaminated with foreign objects and moves smoothly. NG --> See step 10 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) . Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position. Confirm the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when Active Test is completed. OK MAP and idling condition change in response to EGR step position as follows. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition Steady idling Idling changes from steady to rough idling or engine stall MAP (Data List) 20 to 40 kPa (150 to 300 mmHg) (EGR valve fully open) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, then there is probably a malfunction in EGR valve. Result Result Proceed to Outside standard range A Within standard range B B --> See step 7 A: Go to next step
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly, refer to «REMOVAL»(ref-426771-S16321691292011101200000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. Reinstall the EGR valve assembly, refer to «INSTALLATION»(ref-426771-S21548001202011101200000) . NG --> See step 11 OK: Go to next step
- REPLACE ECM. Refer to «REMOVAL»(ref-426780-S20256408682011101200000)
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTC, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) . Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read the pending DTCs. RESULT Result Proceed to DTC P0505 is output A DTC is not output B B --> END A --> See step 7
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-426655-S36857909882011101200000)
- REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY. Refer to «REMOVAL»(ref-426780-S24526827482011101200000)
- REPLACE EGR VALVE ASSEMBLY. Refer to «REMOVAL»(ref-426771-S16321691292011101200000)
| Related DTCs | P050A: Idle speed control problem at cold |
| Required Sensors / Components (Main) | Mass air flow meter sub-assembly |
| Required Sensors / Components (Related) | Engine coolant temperature sensor, throttle position sensor, vehicle speed sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | P0010, P0020 (Camshaft timing oil control valve assembly bank 1, 2) P0011, P0021 (VVT system bank 1, 2 - advance) P0012, P0022 (VVT system bank 1, 2 - retard) P0016, P0018 (VVT system bank 1, 2 - misalignment) P0102, P0103 (Mass air flow meter) P0107, P0108 (Manifold absolute pressure) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient engine coolant temperature for closed loop) P014C, P014D, P014E, P014F (Air fuel ratio sensor - slow response) P015A, P015B, P015C, P015D (Air fuel ratio sensor - delayed response) P0171, P0172, P0174, P0175 (Fuel system) P0301, P0302, P0303, P0304, P0305, P0306 (Misfire) P0335 (Crankshaft position sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) P0351, P0352, P0353, P0354, P0355 (Igniter) P0401 (EGR system) P2195, P2196, P2197, P2198 (Air fuel ratio sensor - rationality) P219A, P219B (Air fuel ratio sensor - imbalance) P2237, P2240 (Air fuel ratio sensor - open) P2238, P2241, P2252, P2255 (Air fuel ratio sensor - low impedance) P2239, P2242, P2253, P2256 (Air fuel ratio sensor - high impedance) |
| Battery voltage | 8 V or more |
| Time after engine start | 3 seconds or more |
| Starter | OFF |
| Engine coolant temperature at engine start | 10°C (14°F) or more |
| Engine coolant temperature | 10 to 50°C (14 to 122°F) |
| Engine idling time | 0 seconds or more |
| Fuel-cut | OFF |
| Vehicle speed | Less than 37.5 mph (60.0 km/h) |
| Atmospheric pressure | 76 kPa (570 mmHg) or more |
| Accumulated mass air flow (intake air amount in neutral position) | Less than 107.5 g (0.2416 lb) (varies with engine coolant temperature) |
Scheme 1059
Scheme 1059: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure), refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) .
- Turn the ignition switch off.
- Turn the ignition switch ON and turn the Techstream on [A].
- Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) .
- Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Coolant Temp.
- Check that "Coolant Temp" in the Data List are within the range of -10 to 50°C (14 to 122°F).
- Start the engine and warm it up until the coolant temperature is the same as the coolant temperature in the freeze frame data.
- Idle the engine for 1 minute or more [B].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
- Read the pending DTC [C]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P050A.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, idle the engine for 3 minutes, let the engine cool down, and then perform steps [A] through [B].
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the DTC judgment result. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P050A) Connect the Techstream to the DLC3. Turn the ignition switch ON. Turn the Techstream on. Enter the following the menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P050A is output A DTC P050A and other DTCs are output B HINT: If any DTCs other than P050A are output, troubleshoot those DTCs first. B --> See step 25 A: Go to next step
- READ VALUE USING TECHSTREAM (FUEL TRIM) HINT: Calculate the total fuel trim values to check the characteristic deviation of the mass air flow meter sub-assembly. Connect the Techstream to the DLC3. Turn the ignition switch ON and turn the Techstream on. Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) . Start the engine. Enter the following menus: Powertrain / Engine and ECT / Data List / A/F Control System / Short FT #1 and Long FT #1, or Short FT #2 and Long FT #2. Read the values displayed on the Techstream. Add together the Short FT #1 and Long FT #1, or Short FT #2 and Long FT #2 values to obtain the total fuel trim. OK Total of Short FT #1 and Long FT #1, or Short FT #2 and Long FT #2 values is between -20% and 20%. NG --> See step 7 OK: Go to next step
- INSPECT THROTTLE WITH MOTOR BODY ASSEMBLY Check for deposits around the throttle valve and throttle valve condition. OK No deposits around throttle valve and throttle valve moves smoothly. NG --> See step 6 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the ignition switch ON. Turn the Techstream on. Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) . Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position. Confirm the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during Active Test. Be sure to return the EGR valve to step 0 when Active Test is completed. OK MAP and idling condition change in response to EGR step position as follows. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition Steady idling Idling changes from steady to rough idling or engine stall MAP (Data List) 20 to 40 kPa (150 to 300 mmHg) (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, then there is probably a malfunction in EGR valve. OK --> See step 19 NG --> See step 5
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly, refer to «REMOVAL»(ref-426771-S16321691292011101200000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. Reinstall the EGR valve assembly, refer to «INSTALLATION»(ref-426771-S21548001202011101200000) . OK --> See step 19 NG --> See step 17
- REPAIR OR REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY Repair or replace the throttle with motor body assembly, refer to «REMOVAL»(ref-426780-S24526827482011101200000) . NEXT --> See step 19
- CHECK PCV HOSE Check the PCV hose connections, refer to «ON-VEHICLE INSPECTION - Step 2»(ref-426783-S09075010392011101200000) . OK PCV hose is connected correctly and is not damaged. NG --> See step 14 OK: Go to next step
- CHECK INTAKE SYSTEM Check the intake system for vacuum leaks, refer to «ON-VEHICLE INSPECTION - Step 1»(ref-426782-S32913494442011101200000) . OK No leaks in intake system. NG --> See step 15 OK: Go to next step
- INSPECT AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Visually check that the air cleaner filter element sub-assembly is not excessively contaminated with dirt or oil. OK Air cleaner filter element is not excessively contaminated with dirt or oil. NG --> See step 16 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the ignition switch ON. Turn the Techstream on. Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) . Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position. Confirm the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during Active Test. Be sure to return the EGR valve to step 0 when Active Test is completed. OK MAP and idling condition change in response to EGR step position as follows. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition Steady idling Idling changes from steady to rough idling or engine stall MAP (Data List) 20 to 40 kPa (150 to 300 mmHg) (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, then there is probably a malfunction in EGR valve. OK --> See step 12 NG --> See step 11
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly, refer to «REMOVAL»(ref-426771-S16321691292011101200000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. Reinstall the EGR valve assembly, refer to «INSTALLATION»(ref-426771-S21548001202011101200000) . NG --> See step 17 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT SYSTEM (BANK 1 OR BANK 2) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) . Warm up the engine. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Linear (Bank 1) or Control the VVT Linear (Bank 2). Check the engine speed while operating the camshaft timing oil control valve assembly using the Techstream. OK Techstream Operation Engine Condition 0% Normal engine speed 100% Engine idles roughly or stalls (soon after camshaft timing oil control valve assembly switched from off to on) NG --> See step 18 OK: Go to next step
- READ VALUE USING TECHSTREAM (MAF) Connect the Techstream to the DLC3. Turn the ignition switch ON. Turn the Techstream on. Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) . Start the engine. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / MAF and Coolant Temp. Allow the engine to idle until Coolant Temp reaches 75°C (167°F) or higher. Read MAF with the engine speed at 2500 RPM. Standard Between 6 gm/s and 17 gm/s (shift lever: P). HINT: when the vehicle is stopped, the engine is being raced with the accelerator pedal depressed 60% or more OK --> See step 19 NG --> See step 20
- REPAIR OR REPLACE PCV HOSE Repair or replace the PCV hose. NEXT --> See step 19
- REPAIR OR REPLACE INTAKE SYSTEM Repair or replace the intake system. NEXT --> See step 19
- REPLACE AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Replace the air cleaner filter element sub-assembly. NEXT --> See step 19
- REPLACE EGR VALVE ASSEMBLY Replace the EGR valve assembly, refer to «REMOVAL»(ref-426771-S16321691292011101200000) . NEXT --> See step 19
- CHECK AND REPAIR VVT SYSTEM Check and repair the VVT system. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS NOTE: In this operation, the engine must be cold (approximately the same level as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch ON. Turn the Techstream on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . Turn the ignition switch off and wait for 30 seconds. Turn the ignition switch ON and turn the Techstream on. Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) . Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14°F and 122°F). Start the engine. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050A. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050A is output) B B --> See step 20 A --> See step 26
- CHECK HARNESS AND CONNECTOR Check the connection and terminal contact pressure of connectors and wire harnesses between the mass air flow meter sub-assembly and ECM, refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-426649-S19284667942011101200000) . HINT: Repair any problems. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch ON. Turn the Techstream on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . Turn the ignition switch off and wait for 30 seconds. Turn the ignition switch on and turn the Techstream on. Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) . Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14°F and 122°F). Start the engine. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Check the judgment result. RESULT Result Proceed to ABNORMAL (DTC P050A is output) A NORMAL (DTC is not output) B B --> END A: Go to next step
- CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY - ECM) Disconnect the mass air flow meter sub-assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B62-5 (VG) - B57-121 (VG) Always Below 1 ohms B62-4 (E2G) - B57-120 (E2G) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B62-5 (VG) or B57-121 (VG) - Body ground Always 10 kohms or higher TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Mass Air Flow Meter Sub-assembly) *b Front view of wire harness connector (to ECM) Reconnect the mass air flow meter sub-assembly connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- REPLACE MASS AIR FLOW METER SUB-ASSEMBLY Replace the mass air flow meter sub-assembly, refer to «REMOVAL»(ref-426780-S31143574432011101200000) . HINT: If the result of the inspection performed in step 13 indicated no problem, proceed to the next step without replacing the mass air flow meter sub-assembly. NEXT: Go to next step
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED NOTE: In this operation, the engine must be cold (approximately the same level as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch ON. Turn the Techstream on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . Turn the ignition switch off and wait for 30 seconds. Turn the ignition switch ON and turn the Techstream on. Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) . Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14°F and 122°F). Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050A. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050A is output) B B --> See step 27 A --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-426655-S36857909882011101200000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-426655-S18110562592011101200000)
- REPLACE ECM. Refer to «REMOVAL»(ref-426780-S20256408682011101200000)
| Related DTCs | P050B: Idle ignition timing problem at cold |
| Required Sensors / Components (Main) | Mass air flow meter sub-assembly |
| Required Sensors / Components (Related) | Engine coolant temperature sensor, throttle position sensor, vehicle speed sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | P0010, P0020 (Camshaft timing oil control valve assembly bank 1, 2) P0011, P0021 (VVT system bank 1, 2 - advance) P0012, P0022 (VVT system bank 1, 2 - retard) P0016, P0018 (VVT system bank 1, 2 - misalignment) P0102, P0103 (Mass air flow meter) P0107, P0108 (Manifold absolute pressure) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient engine coolant temperature for closed loop) P014C, P014D, P014E, P014F (Air fuel ratio sensor - slow response) P015A, P015B, P015C, P015D (Air fuel ratio sensor - delayed response) P0171, P0172, P0174, P0175 (Fuel system) P0301, P0302, P0303, P0304, P0305, P0306 (Misfire) P0335 (Crankshaft position sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) P0351, P0352, P0353, P0354, P0355, P0356 (Igniter) P0401 (EGR system) P2195, P2196, P2197, P2198 (Air fuel ratio sensor - rationality) P219A, P219B (Air fuel ratio sensor - imbalance) P2237, P2240 (Air fuel ratio sensor - open) P2238, P2241, P2252, P2255 (Air fuel ratio sensor - low impedance) P2239, P2242, P2253, P2256 (Air fuel ratio sensor - high impedance) |
| Battery voltage | 8 V or more |
| Time after engine start | 3 seconds or more |
| Starter | OFF |
| Engine coolant temperature at engine start | 10°C (14°F) or more |
| Engine coolant temperature | 10 to 50°C (14 to 122°F) |
| Engine idling time | 0 seconds or more |
| Fuel-cut | OFF |
| Vehicle speed | Less than 37.5 mph (60.5 km/h) |
| Atmospheric pressure | 76 kPa (570 mmHg) or more |
| Accumulated time when ignition timing retard is cut off | 5 seconds or more |
- Connect the Techstream to the DLC3.
- Turn the ignition switch ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure), refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) .
- Turn the ignition switch off.
- Turn the ignition switch ON and turn the Techstream on [A].
- Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Coolant Temp.
- Check that "Coolant Temp" in the Data List is within the range of -10 to 50°C (14 to 122°F).
- Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) .
- Start the engine and warm it up until the coolant temperature is the same as the coolant temperature in the freeze frame data.
- Idle the engine for 1 minute or more [B].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
- Read the pending DTC [C]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P050B.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, idle the engine for 3 minutes, let the engine cool down, and then perform steps [A] through [B].
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the DTC judgment result. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P050B) Connect the Techstream to the DLC3. Turn the ignition switch ON. Turn the Techstream on. Enter the following the menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P050B is output A DTC P050B and other DTCs are output B HINT: If any DTCs other than P050B are output, troubleshoot those DTCs first. B --> See step 25 A: Go to next step
- READ VALUE USING TECHSTREAM (FUEL TRIM) HINT: Calculate the total fuel trim values to check the characteristic deviation of the mass air flow meter sub-assembly. Connect the Techstream to the DLC3. Turn the ignition switch ON and turn the Techstream on. Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) . Start the engine. Enter the following menus: Powertrain / Engine and ECT / Active Test / Short FT #1 and Long FT #1, or Short FT #2 and Long FT #2. Read the values displayed on the Techstream. Add together the Short FT #1 and Long FT #1, or Short FT #2 and Long FT #2 values to obtain the total fuel trim. OK Total of Short FT #1 and Long FT #1, or Short FT #2 and Long FT #2 values is between -20% and 20%. NG --> See step 7 OK: Go to next step
- INSPECT THROTTLE WITH MOTOR BODY ASSEMBLY Check for deposits around the throttle valve and throttle valve condition. OK No deposits around throttle valve and throttle valve moves smoothly. NG --> See step 6 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the ignition switch ON. Turn the Techstream on. Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) . Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position. Confirm the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when Active Test is completed. OK MAP and idling condition change in response to EGR step position as follows. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition Steady idling Idling changes from steady to rough idling or engine stall MAP (Data List) 20 to 40 kPa (150 to 300 mmHg) (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, then there is probably a malfunction in EGR valve. OK --> See step 19 NG --> See step 5
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly, refer to «REMOVAL»(ref-426771-S16321691292011101200000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. Reinstall the EGR valve assembly, refer to «INSTALLATION»(ref-426771-S21548001202011101200000) . OK --> See step 19 NG --> See step 17
- REPAIR OR REPLACE THROTTLE WITH MOTOR BODY ASSEMBLY Repair or replace the throttle with motor body assembly, refer to «REMOVAL»(ref-426780-S24526827482011101200000) . NEXT --> See step 19
- CHECK PCV HOSE Check the PCV hose connections, refer to «ON-VEHICLE INSPECTION - Step 2»(ref-426783-S09075010392011101200000) . OK PCV hose is connected correctly and is not damaged. NG --> See step 14 OK: Go to next step
- CHECK INTAKE SYSTEM Check the intake system for vacuum leaks, refer to «ON-VEHICLE INSPECTION - Step 1»(ref-426782-S32913494442011101200000) . OK No leaks in intake system. NG --> See step 15 OK: Go to next step
- INSPECT AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Visually check that the air cleaner filter element sub-assembly is not excessively contaminated with dirt or oil. OK Air cleaner filter element sub-assembly is not excessively contaminated with dirt or oil. NG --> See step 16 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE EGR STEP POSITION) Connect the Techstream to the DLC3. Turn the ignition switch ON. Turn the Techstream on. Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) . Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more. HINT: The A/C switch and all accessory switches should be off. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the EGR Step Position. Confirm the Throttle Idle Position is ON and check the engine idling condition and MAP values in the Data List while performing the Active Test. HINT: Do not leave the EGR valve open for 10 seconds or more during the Active Test. Be sure to return the EGR valve to step 0 when Active Test is completed. OK MAP and idling condition change in response to EGR step position as follows. Standard - EGR Step Position (Active Test) 0 Steps 0 to 30 Steps Idling condition Steady idling Idling changes from steady to rough idling or engine stall MAP (Data List) 20 to 40 kPa (150 to 300 mmHg) (EGR valve is fully closed) MAP value is at least +10 kPa (75 mmHg) higher than when EGR valve is fully closed HINT: During Active Test, if the idling condition does not change in response to EGR step position, then there is probably a malfunction in EGR valve. OK --> See step 12 NG --> See step 11
- INSPECT EGR VALVE ASSEMBLY Remove the EGR valve assembly, refer to «REMOVAL»(ref-426771-S16321691292011101200000) . Check if the EGR valve is stuck open. OK EGR valve is tightly closed. Reinstall the EGR valve assembly, refer to «INSTALLATION»(ref-426771-S21548001202011101200000) . NG --> See step 17 OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT SYSTEM BANK 1 OR BANK 2) Connect the Techstream to the DLC3. Start the engine and turn the Techstream on. Turn the Techstream on. Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) . Warm up the engine. Turn the A/C on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Linear (Bank 1) or Control the VVT Linear (Bank 2). Check the engine speed while operating the camshaft timing oil control valve assembly using the Techstream. OK Techstream Operation Engine Condition 0% Normal engine speed 100% Engine idles roughly or stalls NG --> See step 18 OK: Go to next step
- READ VALUE USING TECHSTREAM (MAF) Connect the Techstream to the DLC3. Turn the ignition switch ON. Turn the Techstream on. Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) . Start the engine. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / MAF and Coolant Temp. Allow the engine to idle until Coolant Temp reaches 75°C (167°F) or higher. Read MAF with the engine speed at 2500 RPM. Standard Between 6 gm/s and 17 gm/s (shift lever: P). HINT: when the vehicle is stopped, the engine is being raced with the accelerator pedal depressed 60% or more OK --> See step 19 NG --> See step 20
- REPAIR OR REPLACE PCV HOSE Repair or replace the PCV hose. NEXT --> See step 19
- REPAIR OR REPLACE INTAKE SYSTEM Repair or replace the intake system. NEXT --> See step 19
- REPLACE AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Replace the air cleaner filter element sub-assembly. NEXT --> See step 19
- REPLACE EGR VALVE ASSEMBLY Replace the EGR valve assembly, refer to «REMOVAL»(ref-426771-S16321691292011101200000) . NEXT --> See step 19
- CHECK AND REPAIR VVT SYSTEM Check and repair the VVT system. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS NOTE: In this operation, the engine must be cold (the same level as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch ON. Turn the Techstream on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . Turn the ignition switch off. Turn the ignition switch ON and turn the Techstream on. Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) . Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14 and 122°F) Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050B is output) B B --> See step 20 A --> See step 26
- CHECK HARNESS AND CONNECTOR Check the connection and terminal contact pressure of connectors and wire harnesses between the mass air flow meter sub-assembly and ECM, refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-426649-S19284667942011101200000) . HINT: Repair any problems. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS NOTE: In this operation, the engine must be cold (approximately the same as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch ON. Turn the Techstream on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . Turn the ignition switch off and wait for 30 seconds. Turn the ignition switch on and turn the Techstream on. Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) . Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14°F and 122°F). Start the engine. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Check the judgment result. RESULT Result Proceed to ABNORMAL (DTC P050B is output) A NORMAL (DTC is not output) B B --> END A: Go to next step
- CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER SUB-ASSEMBLY - ECM) Disconnect the mass air flow meter sub-assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B62-5 (VG) - B57-121 (VG) Always Below 1 ohms B62-4 (E2G) - B57-120 (E2G) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B62-5 (VG) or B57-121 (VG) - Body ground Always 10 kohms or higher TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Mass Air Flow Meter Sub-assembly) *b Front view of wire harness connector (to ECM) Reconnect the mass air flow meter sub-assembly connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- REPLACE MASS AIR FLOW METER SUB-ASSEMBLY Replace the mass air flow meter sub-assembly, refer to «REMOVAL»(ref-426780-S31143574432011101200000) . HINT: If the result of the inspection performed in step 13 indicated no problem, proceed to the next step without replacing the mass air flow meter sub-assembly. NEXT: Go to next step
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED NOTE: In this operation, the engine must be cold (approximately the same level as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch ON. Turn the Techstream on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . Turn the ignition switch off and wait for 30 seconds. Turn the ignition switch ON and turn the Techstream on. Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) . Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp. Check that the engine coolant temperature is between -10°C and 50°C (14°F and 122°F). Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P050B. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P050B is output) B B --> See step 27 A --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-426655-S36857909882011101200000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-426655-S18110562592011101200000)
- REPLACE ECM. Refer to «REMOVAL»(ref-426780-S20256408682011101200000)
| Related DTCs | P0560: ECM system voltage |
| Required Sensors / Components (Main) | ECM |
| Required Sensors / Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 3 seconds |
| MIL Operation | Immediately (MIL illuminated after next engine start) |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Stand-by RAM | Initialized |
| ECM power source | Less than 3.5 V |
Scheme 1060
Scheme 1060: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure), refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) .
- Turn the ignition switch off.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Wait 5 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the DTC [B]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0560.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] again.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Read Pending DTCs. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 1061
Scheme 1061: WIRING DIAGRAM
| Related DTCs | P0604: ECM range check |
| Required Sensors/Components (Main) | ECM |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 6 times |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
Scheme 1062
Scheme 1062: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure), refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) .
- Turn the ignition switch off.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 16 seconds or more [A].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the DTC [B]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0604.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] again.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ DTC OUTPUT (DTC P0604) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . Turn the ignition switch off. Turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P0604 is output B B --> See step 3 A --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-426655-S18110562592011101200000)
- REPLACE ECM. Refer to «REMOVAL»(ref-426780-S20256408682011101200000)
| Related DTC | P0606: ECM performance |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | Within 1 second |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Battery voltage | 8 V or more |
| Ignition switch | On (IG) |
| Either of the following conditions is met | Condition A or B |
| DMA communication | No response |
| Watching from monitoring processor | Not toggle |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure), refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) .
- Turn the ignition switch off.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 16 seconds or more [A].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the DTC [B]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0606.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] again.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ OUTPUT DTC (DTC P0606) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . Turn the ignition switch off. Turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Wait 1 second or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P0606 is output B B --> See step 3 A --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-426655-S18110562592011101200000)
- REPLACE ECM. Refer to «REMOVAL»(ref-426780-S20256408682011101200000)
| Related DTCs | P0607: Control module performance |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | Heated oxygen sensor |
| Frequency of operation | Continuous |
| Duration | 60 seconds |
| MIL operation | Immediately |
| Sequence of operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Engine | Running |
| Estimated heated oxygen sensor temperature | 450 to 750°C (842 to 1382°F) |
| Heated oxygen sensor transistors | Fail |
Scheme 1063
Scheme 1063: CONFIRMATION DRIVING PATTERN
- Stop the engine for 30 minutes or more [A].
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure), refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) .
- Turn the ignition switch off.
- Turn the ignition switch to ON and turn the Techstream on [B].
- Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) .
- Start the engine, and wait 2 minutes [C].
- Warm up the engine until the engine coolant temperature is 75°C (167°F) or more [D].
- Idle the engine for 1 minute [E].
- Accelerate the vehicle to 50 mph (80 km/h) and stop the vehicle [F].
- Drive the vehicle at 35 to 50 mph (56 to 80 km/h) for 5 minutes or more [G].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
- Read the pending DTC [H]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0607, P0136, P0137, P0138, P0156, P0157 or P0158.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] through [I].
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 1064
- CHECK ANY OTHER DTCS OUTPUT Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0607 and P0136, P0137, P0138, P0156, P0157 or P0158 are output A DTC P0607 is output B B --> See step 3 A: Go to next step
- INSPECT DTC (P0136, P0137, P0138, P0156, P0157 OR P0158) Inspect the P0136, P0137, P0138, P0156, P0157 or P0158 flowchart. HINT: If P0136 or P0156 is output, troubleshoot for that DTC first, refer to «INSPECTION PROCEDURE»(ref-426784-S20225166722011101200000) . Then proceed to "Inspect ECM". If P0137 or P0157 is output, troubleshoot for that DTC first, refer to «INSPECTION PROCEDURE»(ref-426784-S20225166722011101200000) . Then proceed to "Inspect ECM". If P0138 or P0158 is output, troubleshoot for that DTC first, refer to «INSPECTION PROCEDURE»(ref-426784-S20225166722011101200000) . Then proceed to "Inspect ECM". If DTC P0607 and P0136, P0137, P0138, P0156, P0157 or P0158 are output, the output voltage of the heated oxygen sensor may remain close to 0 V or become high (around 1 V or more). NEXT --> See step 6
- CHECK FOR EXHAUST GAS LEAK Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) . Allow the engine to idle and rev the engine. Check for exhaust gas leaks around the heated oxygen sensor. If any exhaust gas leaks are present, repair it and proceed to "Perform Confirmation Driving Pattern". If no exhaust gas leaks are present, proceed to "Perform Confirmation Driving Pattern". HINT: If no exhaust gas leaks are present, a malfunction in the heated oxygen sensor circuit is suspected. If any exhaust gas leaks are present around the heated oxygen sensor, noise appears in the output voltage of the heated oxygen sensor. NEXT: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) . Warm up the engine until the engine coolant temperature becomes 75°C (167°F) or more. Perform the driving pattern. Accelerate the vehicle until 50 mph (80 km/h) and stop the vehicle. Drive the vehicle between 38 to 50 mph (60 to 80 km/h) for 5 minutes. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0607 and P0136, P0137, P0138, P0156, P0157 or P0158 are output A DTC P0607 is output B DTC is not output C B --> See step 7 C --> See step 6 A: Go to next step
- INSPECT DTC (P0136, P0137, P0138, P0156, P0157 OR P0158) Inspect the P0136, P0137, P0138, P0156, P0157 or P0158 flowchart. HINT: If P0136 or P0156 is output, troubleshoot for that DTC first, refer to «INSPECTION PROCEDURE»(ref-426784-S20225166722011101200000) . Then proceed to "Inspect ECM". If P0137 or P0157 is output, troubleshoot for that DTC first, refer to «INSPECTION PROCEDURE»(ref-426784-S20225166722011101200000) . Then proceed to "Inspect ECM". If P0138 or P0158 is output, troubleshoot for that DTC first, refer to «INSPECTION PROCEDURE»(ref-426784-S20225166722011101200000) . Then proceed to "Inspect ECM". If DTC P0607 and P0136, P0137, P0138, P0156, P0157 or P0158 are output, the output voltage of the heated oxygen sensor may remain close to 0 V or become high (around 1 V or more). NEXT: Go to next step
- INSPECT ECM Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . Turn the ignition switch off and wait for 30 minutes. Turn the ignition switch to ON and turn the Techstream on. Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) . Start the engine and allow it to idle for 2 minutes. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P0607 is output B B --> See step 7 A --> END
- REPLACE ECM. Refer to «REMOVAL»(ref-426780-S20256408682011101200000)
| Related DTCs | P060A: ECM, CPU error |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | |
| Frequency of operation | Continuous |
| Duration | Within 1 second |
| MIL operation | Immediately |
| Sequence of operation | None |
| Monitor runs whenever following DTCs are not present | None |
| All of the following conditions are met | Condition A and B |
| A. Either of the following conditions is met | Condition 1 or 2 |
| 1. All of the following conditions are met | Condition a, b and c |
| (a) CPU reset | 1 time or more |
| (b) Learned throttle position - Learned accelerator pedal position | 2.6 V or more |
| (c) Electronic throttle actuator | OFF |
| 2. CPU reset | 2 times or more |
| B. CPU reset | Occurred |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure), refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) .
- Turn the ignition switch off.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the DTC [B]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P060A.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] again.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ OUTPUT DTC (DTC P060A) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . Turn the ignition switch off. Turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P060A is output B B --> See step 3 A --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-426655-S18110562592011101200000)
- REPLACE ECM. Refer to «REMOVAL»(ref-426780-S20256408682011101200000)
| Related DTCs | P060B: ECM main CPU communication error |
| Required sensors/components (Main) | ECM |
| Required sensors/components (Related) | |
| Frequency of operation | Once per driving cycle |
| Duration | Within 1 second |
| MIL operation | Immediately |
| Sequence of operation | None |
| Monitor runs whenever following DTCs are not present | None |
| One of the following conditions is met | (a), (b) or (c) |
| (a) Internal control module serial communication | Fail |
| (b) AD converter | Fail |
| (c) Knock control sensor circuit | Fail |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure), refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) .
- Turn the ignition switch off.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the DTC [B]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P060B.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] again.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ OUTPUT DTC (DTC P060B) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . Turn the ignition switch off. Turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Wait 16 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P060B is output B DTC P060B and P0327, P0328, P0332 and P0333 are output C B --> See step 3 C --> See step 4 A --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-426655-S18110562592011101200000)
- REPLACE ECM. Refer to «REMOVAL»(ref-426780-S20256408682011101200000)
- GO TO DTC (P0327, P0328, P0332 AND P0333). Refer to «DTC P0327: Knock Sensor 1 Circuit Low Input (Bank 1 or Single Sensor); DTC P0328: Knock Sensor 1 Circuit High Input (Bank 1 or Single Sensor); DTC P0332: Knock Sensor 2 Circuit Low Input (Bank 2); DTC P0333: Knock Sensor 2 Circuit High Input (Bank 2)»(ref-426785-S32646555372011101200000)
| Related DTCs | P060E: Internal control module, throttle position |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | |
| Frequency of operation | Continuous |
| Duration | 1 second |
| MIL operation | Immediately |
| Sequence of operation | None |
| Monitor runs whenever following DTCs are not present | None |
| DMA communication error | Not detected |
| One of the following conditions is met | Condition 1 or 2 |
| 1. Difference of main throttle position and sub throttle position | 0.3 V or more |
| 2. Difference of main brake switch signal and sub brake switch signal | Different |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure), refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) .
- Turn the ignition switch off.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the DTC [B]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P060E.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] again.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ OUTPUT DTC (DTC P060E) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . Turn the ignition switch off. Turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Wait 30 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P060E is output B B --> See step 3 A --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-426655-S18110562592011101200000)
- REPLACE ECM. Refer to «REMOVAL»(ref-426780-S20256408682011101200000)
| Related DTCs | P062F: Internal control module EEPROM error |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | |
| Frequency of operation | Once per driving cycle |
| Duration | 11 seconds |
| MIL operation | Immediately |
| Sequence of operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Time after engine start | 10 seconds or more |
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Permanent fault code data | Mismatch (3 times or more) |
Scheme 1065
Scheme 1065: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure), refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) .
- Turn the ignition switch off.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Wait 30 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the DTC [B]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P062F.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] again.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ OUTPUT DTC (DTC P062F) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . Turn the ignition switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Wait 30 seconds or more. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P062F is output B B --> See step 2 A --> See step 3
- REPLACE ECM. Refer to «REMOVAL»(ref-426780-S20256408682011101200000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-426655-S18110562592011101200000)
| Related DTCs | P0630: VIN not programmed |
| Required Sensors / Components (Main) | ECM |
| Required Sensors / Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.325 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| The monitor will run whenever these DTCs are not present | None |
| Battery voltage | 8 V or more |
| Ignition switch | ON (IG) |
| Starter | OFF |
Scheme 1066
Scheme 1066: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch ON and turn the Techstream on.
- Wait 5 seconds or more [A].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the DTCs [B]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0630.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ CURRENT DTC Connect the Techstream to the DLC3. Turn the ignition switch ON and turn the Techstream on. Select the following menu items: Powertrain / Engine and ECT / Trouble Code. Read the DTCs. Result Display (DTC Output) Proceed to P0630 A P0630 and other DTCs B If any DTCs other than P0630 are output, troubleshoot those DTCs first. NOTE: If P0630 is set, the VIN must be input to the ECM using the Techstream. However, all DTCs are cleared automatically by the tester when inputting the VIN. B --> See step 4 A: Go to next step
- INPUT VIN WITH TECHSTREAM HINT: Refer to "REGISTRATION", refer to «REGISTRATION»(ref-426655-S09017672872011101200000) . NEXT: Go to next step
- READ CURRENT DTC Connect the Techstream to the DLC3. Turn the ignition switch ON and turn the Techstream on. Select the following menu items: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs again. Result DTC is not output (P0630). NG --> See step 5 OK --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-426655-S36857909882011101200000)
- REPLACE ECM. Refer to «REMOVAL»(ref-426780-S20256408682011101200000)
| Related DTCs | P0657: Electronic throttle control system power supply |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | Throttle actuator |
| Frequency of operation | Once per driving cycle |
| Duration | 1 second or more |
| MIL operation | Immediately |
| Sequence of operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Throttle actuator power supply voltage | 7 V or more |
| Ignition switch | ON to off |
| Electric throttle actuator power supply | ON |
Scheme 1067
Scheme 1067: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure), refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) .
- Turn the Techstream off.
- Turn the ignition switch off.
- Disconnect the Techstream.
- Disconnect the cable from the negative (-) battery terminal and wait for 1 minute.
- Connect the cable to the negative (-) battery terminal.
- Turn the ignition switch to ON.
- Wait 10 seconds or more.
- Turn the ignition switch off.
- Wait 15 seconds or more.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 5 seconds or more [A].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the DTCs [B]. HINT: If a DTC is output, the system is malfunctioning. If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0657.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ DTC OUTPUT (DTC P0657) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . Turn the ignition switch off. Turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Turn the ignition switch to ON for 10 seconds. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P0657 is output B B --> See step 3 A --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-426655-S18110562592011101200000)
- REPLACE ECM. Refer to «REMOVAL»(ref-426780-S20256408682011101200000)
| Related DTC | P106A: Evaporative emission system pressure sensor - manifold absolute pressure correlation |
| Required Sensors/Components (Main) | Canister pressure sensor Manifold absolute pressure sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | Less than 65 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | P0107, P0108 (Manifold absolute pressure) P0401 (EGR system) P0452, P0453 (EVAP system, Evaporative emission system pressure sensor) |
| Arrive at after engine stop | 50 minutes |
| Time after ECM started by soak-timer | 60 seconds or more |
| Battery voltage | 10.5 V or more |
| Intake air temperature | 10°C (14°F) or more |
| Engine coolant temperature | 10°C (14°F) or more |
| Judgment counter | 5 times |
| Judgment time | Every 260 msec. |
| Fail counter | 3 times or more |
| Difference between EVAP pressure and manifold absolute pressure | 7.23 kPa (54.23 mmHg) or more |
Scheme 1068
Scheme 1068: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure), refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) .
- Put the engine in inspection mode, refer to «INSPECTION MODE PROCEDURE»(ref-426649-S00975887492011101200000) .
- Start the engine and idle it for 10 seconds [B].
- Turn the ignition switch off.
- Allow the engine to cool down for 55 minutes [C].
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
- Read Pending DTCs [D]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P106A.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] through [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO P106A) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTC. Result Result Proceed to DTC P106A is output A DTC P106A and other DTCs are output B B --> See step 7 A: Go to next step
- READ VALUE USING TECHSTREAM (VAPOR PRESSURE PUMP) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Vapor Pressure Pump. Read the value. HINT: Refer to the Vapor Pressure Pump value of other vehicles in the workshop and check the difference in pressure. If other vehicles are not available, compare the Vapor Pressure Pump value with the current atmospheric pressure*. *: Standard atmospheric pressure is 101 kPa (760 mmHg) at sea level. The atmospheric pressure decreases by approximately 1 kPa (7.5 mmHg) for every 100 m of elevation increase. Atmospheric pressure is also affected by weather conditions. The Atmosphere pressure listed in the Data List cannot be used as a reference for this check. Standard +/- 3.5 kPa (+/- 26.25 mmHg) or less. NG --> See step 4 OK: Go to next step
- READ VALUE USING TECHSTREAM (MAP) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / MAP and Vapor Pressure Pump. Read the value. Standard +/- 3.5 kPa (+/- 26.25 mmHg) or less. OK --> See step 6 NG --> See step 5
- REPLACE CANISTER Replace canister, refer to «REMOVAL»(ref-426771-S12975672052011101200000) . NEXT --> See step 6
- REPLACE MANIFOLD ABSOLUTE PRESSURE SENSOR Replace manifold absolute pressure sensor, refer to «REMOVAL»(ref-426780-S33332903882011101200000) . NEXT --> See step 6
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the ignition switch to ON and the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List. Data List / MAP and Vapor Pressure Pump Check that the difference between the MAP and Vapor Pressure Pump values in the Data List is +/- 3.5 kPa (+/- 26.25 mmHg) or less. NEXT --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-426655-S36857909882011101200000)
| Related DTCs | P1420: Canister small leak P1421: Canister gross leak |
| Required Sensors/Components | Purge VSV and canister pump module |
| Frequency of Operation | Once per driving cycle |
| Duration | Within 15 minutes (varies with the amount of fuel in tank) |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever these DTCs are not present | None |
| EVAP key-off monitor runs when all of the following conditions are met | |
| Atmospheric pressure | 70 to 111 kPa (525 to 833 mmHg) |
| Battery voltage | 10.5 V or more |
| Vehicle speed | Less than 2.5 mph (4 km/h) |
| Ignition switch | Off |
| Engine condition | Not running |
| Key-OFF duration | 5 or 7 or 9.5 hours |
| Pressure sensor of canister pump module malfunction (P0452 and P0453) | Not detected |
| Fuel tank pressure sensor malfunction (P1452 and P1453) | Not detected |
| Purge VSV | Not operated by scan tool |
| Vent valve | Not operated by scan tool |
| Leak detection pump | Not operated by scan tool |
| Both of the following conditions are met before Key-OFF | Conditions 1 and 2 |
| 1. Duration that vehicle is being driven | 5 minutes or more |
| 2. Purge flow | Executed |
| Engine coolant temperature | 4.4 to 35°C (40 to 95°F) |
| Intake air temperature | 4.4 to 35°C (40 to 95°F) |
Key-off monitor sequence 1 to 15
| Next sequence is run if the following condition is met | |
| Atmospheric pressure change | Less than 0.3 kPa (gauge) (2.25 mmHg (gauge) per second |
1. ATMOSPHERIC PRESSURE MEASUREMENT
| Next sequence is run if all of the following conditions are met | Condition 1, 2 and 3 |
| 1. Canister pressure when reference pressure measurement started | 1 kPa (gauge) (-7.5 mmHg (gauge) or less |
| 2. Reference pressure | 4.75 to -0.957 kPa (gauge) (-35.62 to -7.18 mmHg (gauge) |
| 3. Reference pressure | Saturated |
2. FIRST REFERENCE PRESSURE MEASUREMENT
| Next sequence is run if the following condition is met | |
| Canister pressure change after vent valve ON (Closed) | 0.3 kPa (gauge) (2.25 mmHg (gauge) or more |
3. VENT VALVE CLOSE STUCK CHECK
| Next sequence is run if the both of the following conditions are met | Condition 1 and 2 |
| 1. Vacuum introduction time | 15 minutes or less |
| 2. Canister pressure | Saturated |
4. VACUUM INTRODUCTION FOR CANISTER
| Next sequence is run if the following condition is met | |
| Canister pressure change for 10 seconds after purge VSV ON (Open). | 0.3 kPa (gauge) (2.25 mmHg (gauge) or more |
5. PURGE VSV STUCK CLOSED CHECK
| Next sequence is run if all of the following conditions are met | Condition 1, 2, 3 and 4 |
| 1. Canister pressure when reference pressure measurement started | 1 kPa (gauge) (-7.5 mmHg (gauge) or less |
| 2. Reference pressure | 4.75 to -0.957 kPa (gauge) (-35.62 to -7.18 mmHg (gauge) |
| 3. Reference pressure | Saturated |
| 4. Reference pressure difference between the first and second | Less than 0.9 kPa (gauge) (6.75 mmHg (gauge) |
6. SECOND REFERENCE PRESSURE MEASUREMENT
| One of the sequence 8 or 9 is run if the following condition is met | |
| Canister pressure when vacuum introduction for canister was complete | Second reference pressure or less |
| Sequence 14 is run if all of the following conditions are met | Conditions 1 and 2 |
| 1. Fuel tank pressure when EVAP monitor started | 2 kPa (gauge) (-15 mmHg (gauge) or less, or 3 kPa (gauge) (22.5 mmHg (gauge) or more |
| 2. Fuel tank pressure change while TCV and vent valve are open | 0.5 kPa (gauge) (3.75 mmHg (gauge) or more |
8. FUEL TANK CLOSED VALVE (TCV) STUCK CLOSED CHECK
| Next sequence is run if both of the following conditions are met | Conditions 1 and 2 |
| 1. Fuel tank pressure when EVAP monitor started | 2 to 3 kPa (gauge) (-15 to 22.5 mmHg (gauge) |
| 2. Vacuum introduction time | 15 minutes or less |
9. VACUUM INTRODUCTION FOR FUEL TANK
| Next sequence is run if the following condition is met | |
| Fuel tank pressure change when vacuum introduction for fuel tank | 0.5 kPa (gauge) (3.75 mmHg (gauge) or more |
10. TCV STUCK CLOSED CHECK
| Next sequence is run if the following condition is met | |
| Fuel tank pressure change when TCV closed | 0.35 kPa (gauge) (2.6 mmHg (gauge) or more |
11. FUEL TANK PRESSURE SENSOR STUCK CHECK
| Next sequence is run if all of the following conditions are met | Conditions 1, 2, 3, and 4 |
| 1. Fuel tank pressure when 1.9 seconds after reference pressure measurement began | 1 kPa (gauge) (-7.5 mmHg (gauge) or less |
| 2. Reference pressure | 4.75 to -0.957 kPa (gauge) (-35.62 to -7.18 mmHg (gauge) |
| 3. Reference pressure | Saturated |
| 4. Reference pressure difference between the second and third | Less than 0.9 kPa (gauge) (6.75 mmHg (gauge) |
12 THIRD REFERENCE PRESSURE MEASUREMENT
| Sequence 15 is run if the following condition is met | |
| Fuel tank pressure when vacuum introduction for fuel tank was complete | Less than third reference pressure |
| Next sequence is run if the following condition is met | |
| Fuel tank pressure change while TCV and vent valve are open | Less than 0.35 kPa (gauge) (2.6 mmHg (gauge) |
14. FUEL TANK PRESSURE SENSOR STUCK CHECK
| Monitor is complete if the following condition is met | |
| Atmospheric pressure difference between sequence 1 and 8 | Less than 0.3 kPa (gauge) (2.25 mmHg (gauge) |
15. ATMOSPHERIC PRESSURE MEASUREMENT
| Canister pressure when vacuum introductions for canister complete | Between conditions 1 and 2 |
| Condition 1 | Higher than second reference pressure |
| Condition 2 | Lower than reference pressure x 0.2 |
| Canister pressure when vacuum introduction for canister was complete | Higher than reference pressure x 0.2 |
Refer to Checking Monitor Status, refer to CHECKING MONITOR STATUS .
Scheme 1069
Scheme 1069: CONFIRMATION DRIVING PATTERN
Note. The Evaporative System Check (Automatic Mode) consists of 9 steps performed automatically by the Techstream. It takes a maximum of approximately 18 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or more, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).
- Connect the Techstream to the DLC3.
- Turn the ignition switch ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode [A].
- After the Evaporative System Check is completed, check for DTCs by entering the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
- Read the Pending DTC [B]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All readiness.
- Input the DTC: P1420 or P1421.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [A] again.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P1422: Fuel tank small leak P1423: Fuel tank gross leak |
| Required Sensors/Components | Fuel tank and canister pump module |
| Frequency of Operation | Once per driving cycle |
| Duration | Within 15 minutes (varies with the amount of fuel in tank) |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever these DTCs are not present | None |
| EVAP key-off monitor runs when all of the following conditions are met | |
| Atmospheric pressure | 70 to 111 kPa (525 to 833 mmHg) |
| Battery voltage | 10.5 V or more |
| Vehicle speed | Less than 2.5 mph (4 km/h) |
| Ignition switch | Off |
| Engine condition | Not running |
| Key-OFF duration | 5 or 7 or 9.5 hours |
| Pressure sensor of canister pump module malfunction (P0452 and P0453) | Not detected |
| Fuel tank pressure sensor malfunction (P1452 and P1453) | Not detected |
| Purge VSV | Not operated by scan tool |
| Vent valve | Not operated by scan tool |
| Leak detection pump | Not operated by scan tool |
| Both of the following conditions are met before Key-OFF | Conditions 1 and 2 |
| 1. Duration that vehicle is being driven | 5 minutes or more |
| 2. Purge flow | Executed |
| Engine coolant temperature | 4.4 to 35°C (40 to 95°F) |
| Intake air temperature | 4.4 to 35°C (40 to 95°F) |
Key-off monitor sequence 1 to 15
| Next sequence is run if the following condition is met | |
| Atmospheric pressure change | Less than 0.3 kPa (gauge) (2.25 mmHg (gauge) per second |
1. ATMOSPHERIC PRESSURE MEASUREMENT
| Next sequence is run if all of the following conditions are met | Condition 1, 2 and 3 |
| 1. Canister pressure when reference pressure measurement started | 1 kPa (gauge) (-7.5 mmHg (gauge) or less |
| 2. Reference pressure | 4.75 to -0.957 kPa (gauge) (-35.62 to -7.18 mmHg (gauge) |
| 3. Reference pressure | Saturated |
2. FIRST REFERENCE PRESSURE MEASUREMENT
| Next sequence is run if the following condition is met | |
| Canister pressure change after vent valve ON (Closed) | 0.3 kPa (gauge) (2.25 mmHg (gauge) or more |
3. VENT VALVE CLOSE STUCK CHECK
| Next sequence is run if the both of the following conditions are met | Condition 1 and 2 |
| 1. Vacuum introduction time | 15 minutes or less |
| 2. Canister pressure | Saturated |
4. VACUUM INTRODUCTION FOR CANISTER
| Next sequence is run if the following condition is met | |
| Canister pressure change for 10 seconds after purge VSV ON (Open). | 0.3 kPa (gauge) (2.25 mmHg (gauge) or more |
5. PURGE VSV STUCK CLOSED CHECK
| Next sequence is run if all of the following conditions are met | Condition 1, 2, 3 and 4 |
| 1. Canister pressure when reference pressure measurement started | 1 kPa (gauge) (-7.5 mmHg (gauge) or less |
| 2. Reference pressure | 4.75 to -0.957 kPa (gauge) (-35.62 to -7.18 mmHg (gauge) |
| 3. Reference pressure | Saturated |
| 4. Reference pressure difference between the first and second | Less than 0.9 kPa (gauge) (6.75 mmHg (gauge) |
6. SECOND REFERENCE PRESSURE MEASUREMENT
| One of the sequence 8 or 9 is run if the following condition is met | |
| Canister pressure when vacuum introduction for canister was complete | Second reference pressure or less |
| Sequence 14 is run if all of the following conditions are met | Conditions 1 and 2 |
| 1. Fuel tank pressure when EVAP monitor started | 2 kPa (gauge) (-15 mmHg (gauge) or less, or 3 kPa (gauge) (22.5 mmHg (gauge) or more |
| 2. Fuel tank pressure change while TCV and vent valve are open | 0.5 kPa (gauge) (3.75 mmHg (gauge) or more |
8. FUEL TANK CLOSED VALVE (TCV) STUCK CLOSED CHECK
| Next sequence is run if both of the following conditions are met | Conditions 1 and 2 |
| 1. Fuel tank pressure when EVAP monitor started | 2 to 3 kPa (gauge) (-15 to 22.5 mmHg (gauge) |
| 2. Vacuum introduction time | 15 minutes or less |
9. VACUUM INTRODUCTION FOR FUEL TANK
| Next sequence is run if the following condition is met | |
| Fuel tank pressure change when vacuum introduction for fuel tank | 0.5 kPa (gauge) (3.75 mmHg (gauge) or more |
10. TCV STUCK CLOSED CHECK
| Next sequence is run if the following condition is met | |
| Fuel tank pressure change when TCV closed | 0.35 kPa (gauge) (2.6 mmHg (gauge) or more |
11. FUEL TANK PRESSURE SENSOR STUCK CHECK
| Next sequence is run if all of the following conditions are met | Conditions 1, 2, 3, and 4 |
| 1. Fuel tank pressure when 1.9 seconds after reference pressure measurement began | 1 kPa (gauge) (-7.5 mmHg (gauge) or less |
| 2. Reference pressure | 4.75 to -0.957 kPa (gauge) (-35.62 to -7.18 mmHg (gauge) |
| 3. Reference pressure | Saturated |
| 4. Reference pressure difference between the second and third | Less than 0.9 kPa (gauge) (6.75 mmHg (gauge) |
12 THIRD REFERENCE PRESSURE MEASUREMENT
| Sequence 15 is run if the following condition is met | |
| Fuel tank pressure when vacuum introduction for fuel tank was complete | Less than third reference pressure |
| Next sequence is run if the following condition is met | |
| Fuel tank pressure change while TCV and vent valve are open | Less than 0.35 kPa (gauge) (2.6 mmHg (gauge) |
14. FUEL TANK PRESSURE SENSOR STUCK CHECK
| Monitor is complete if the following condition is met | |
| Atmospheric pressure difference between sequence 1 and 8 | Less than 0.3 kPa (gauge) (2.25 mmHg (gauge) |
15. ATMOSPHERIC PRESSURE MEASUREMENT
| Fuel tank pressure when vacuum introduction for fuel tank was complete | Between conditions 1 and 2 |
| Condition 1 | Higher than second reference pressure |
| Condition 2 | Lower than reference pressure x 0.2 |
P1422: FUEL TANK SMALL LEAK
| Fuel tank pressure when vacuum introduction for fuel tank was complete | Higher than reference pressure x 0.2 |
P1423: FUEL TANK GROSS LEAK
Refer to Checking Monitor Status, refer to CHECKING MONITOR STATUS .
Note. The Evaporative System Check (Automatic Mode) consists of 9 steps performed automatically by the Techstream. It takes a maximum of approximately 18 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or more, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).
- Connect the Techstream to the DLC3.
- Turn the ignition switch on and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch on and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Utility / Evaporative System Check / Automatic Mode [A].
- After the Evaporative System Check is completed, check for DTCs by entering the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending.
- Read the Pending DTC [B]. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All readiness.
- Input the DTC: P1422 or P1423.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [A] again.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-426655-S13741789592011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
