MONITOR STRATEGY
| Related DTCs | P0010: VVT OCV (bank 1) range check P0020: VVT OCV (bank 2) range check |
| Required sensors / components (Main) | VVT OCV (VVT camshaft oil control valve) |
| Required sensors / components (Sub) | |
| Frequency of operation | Continuous |
| Duration | 1 second |
| MIL operation | Immediately |
| Sequence of operation | None |
TYPICAL ENABLING CONDITIONS
| The monitor will run whenever these DTCs are not present | None |
| All of the following conditions are met | |
| Starter | OFF |
| Ignition switch | ON (IG) |
| Time after turning ignition switch off to on (IG) | 0.5 seconds or more |
TYPICAL MALFUNCTION THRESHOLDS
| One of the following conditions is met | Condition A, B or C |
| A. All of the following conditions are met | |
| Battery voltage | 11 to 13 V |
| Target duty ratio | Less than 70% |
| Output signal duty ratio | 100% or more |
| B. All of the following conditions are met | |
| Battery voltage | 13 V or more |
| Target duty ratio | Less than 80% |
| Output signal duty ratio | 100% or more |
| C. All of the following conditions are met | |
| Current cut status | Not cut |
| Output signal duty ratio | 3% or less |
COMPONENT OPERATING RANGE
| VVT OCV duty ratio | More than 3%, and Less than 100% |
Scheme 671
Scheme 671: WIRING DIAGRAM
CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch on (IG) and turn the Techstream on.
- Wait 5 seconds.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Code.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0010 or P0020.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422300-S24344107222011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
CAUTION / NOTICE / HINT
If DTC P0011, P0012, P0021 or P0022 is present, check the VVT (Variable Valve Timing) system.
| Related DTCs | P0011: Advanced intake camshaft timing (bank 1) P0012: Retarded intake camshaft timing (bank 1) P0021: Advanced intake camshaft timing (bank 2) P0022: Retarded intake camshaft timing (bank 2) |
| Required sensors / components (Main) | VVT OCV, VVT Actuator |
| Required sensors / components (Related) | Crankshaft position sensor, Camshaft position sensor, ECT sensor |
| Frequency of operation | Continuous |
| Duration | Less than 10 seconds |
| MIL operation | P0011 and P0021: Immediate P0012 and P0022: 2 driving cycles |
| Sequence operation | None |
| The monitor will run whenever these DTCs are not present | P0010, P0020 (OCV bank 1, 2) P0016, P0018 (VVT system bank 1, 2 - misalignment) P0102, P0103 (MAF meter) P0115, P0117, P0118 (ECT sensor) P0125 (Insufficient ECT for closed loop) P0335 (CKP sensor) |
| Battery voltage | 11 V or more |
| Engine RPM | 500 to 4000 RPM |
| ECT | 75 to 100°C (167 to 212°F) |
| Duration of actual valve timing and target valve timing | More than 5°CA (Crankshaft angle) |
| Valve timing | No change in advanced valve timing |
| Duration of actual valve timing and target valve timing | More than 5°CA (Crankshaft angle) |
| Valve timing | No change in retarded valve timing |
If the difference between the target and actual camshaft timings is greater than the specified value, the ECM operates the VVT actuator.
Then, the ECM monitors the camshaft timing change for 5 seconds.
| Related DTCs | P0013: VVT OCV (bank 1) range check P0023: VVT OCV (bank 2) range check |
| Required sensors / components (Main) | VVT OCV (Variable Valve Timing oil control valve) |
| Required sensors / components (Sub) | |
| Frequency of operation | Continuous |
| Duration | 1 second |
| MIL operation | Immediate |
| Sequence of operation | None |
| The monitor will run whenever these DTCs are not present | None |
| All of the following conditions are met | |
| Starter | OFF |
| Ignition switch | ON |
| Time after ignition switch off to on | 0.5 seconds or more |
| Exhaust VVT oil control valve condition | No operation record |
| One of the following conditions is met | Condition A, B or C |
| A. All of the following conditions are met | |
| Battery voltage | 11 to 13 V |
| Target duty ratio | Less than 70% |
| B. All of the following conditions are met | |
| Battery voltage | 13 V or more |
| Target duty ratio | Less than 80% |
| C. All of the following conditions are met | |
| Current cut status | Not cut |
| Output signal duty ratio | Less than 3% |
| Output signal duty ratio | More than 3%, and less than 100% |
Scheme 672
Scheme 672: WIRING DIAGRAM
- Connect the Techstream to the DLC3.
- Turn the ignition switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch on (IG) and turn the Techstream on.
- Wait 5 seconds.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Code.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0013 or P0023.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422300-S24344107222011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
PROCEDURE
- PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE OIL CONTROL VALVE FOR INTAKE CAMSHAFT) Connect the Techstream to the DLC3. Start the engine and turn the tester on. Warm up the engine. Select the following menus: Powertrain/ Engine and ECT / Active Test / Control the VVT Exhaust Linear (Bank 1) or Control the VVT Exhaust Linear (Bank 2). Check the engine speed while operating the oil control valve using the tester. OK Tester Operation Specified Condition 0% (OFF) Normal engine speed 127% (ON) Engine idles roughly or stalls (soon after oil control valve switched from OFF to ON) NG --> See step 3 OK --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-422300-S41051796092011092600000)
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Disconnect the exhaust camshaft timing oil control valve connector. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 6.9 to 7.9 ohms Reconnect the camshaft timing oil control valve connector. NG --> See step 4 OK: Go to next step
- REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY. Refer to «REMOVAL»(ref-422482-S05437947002011092600000)
- CHECK HARNESS AND CONNECTOR (CAMSHAFT TIMING OIL CONTROL VALVE - ECM) Disconnect the exhaust camshaft timing oil control valve connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard resistance (Check for open) Bank 1 Bank 2 Tester Connection Condition Specified Condition B50-21 (OE1+) - B44-1 Always Below 1 ohms B50-22 (OE1-) - B44-2 Always Below 1 ohms Tester Connection Condition Specified Condition B51-21 (OE2+) - B41-1 Always Below 1 ohms B51-22 (OE2-) - B41-2 Always Below 1 ohms Standard resistance (Check for short) Bank 1 Bank 2 Tester Connection Condition Specified Condition B50-21 (OE1+) or B44-1 - Body ground Always 10 kohms or higher B50-22 (OE1-) or B44-2 - Body ground Always 10 kohms or higher Tester Connection Condition Specified Condition B51-21 (OE2+) or B41-1 - Body ground Always 10 kohms or higher B51-22 (OE2-) or B41-2 - Body ground Always 10 kohms or higher Reconnect the ECM connector. Reconnect the camshaft timing oil control valve connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (CAMSHAFT TIMING OIL CONTROL VALVE - ECM) OK --> See step 6
- REPLACE ECM. Refer to «COMPONENTS»(ref-422482-S29849271832011092600000)
If DTC P0014, P0015, P0024 or P0025 is present, check the VVT (Variable Valve Timing) system.
| Related DTCs | P0014: Advanced exhaust camshaft timing (bank 1) P0015: Retarded exhaust camshaft timing (bank 1) P0024: Advanced exhaust camshaft timing (bank 2) P0025: Retarded exhaust camshaft timing (bank 2) |
| Required Sensors / Components (Main) | VVT camshaft timing oil control valve and VVT Actuator |
| Required Sensors / Components (Related) | P0014 and P0015: Exhaust camshaft control actuator bank 1 Exhaust camshaft timing oil control valve bank 1 P0024 and P0025: Exhaust camshaft control actuator bank 2 Exhaust camshaft timing oil control valve bank 2 |
| Frequency of Operation | Continuously |
| Duration | Less than 10 seconds |
| MIL Operation | P0014 and P0024: 2 driving cycles P0015 and P0025: Immediate |
| Sequence of Operation | None |
| The monitor will run whenever these DTCs are not present | P0013, P0023 (Exhaust OCV bank 1, 2) P0017, P0019 (Exhaust VVT system bank 1, 2 - misalignment) P0102, P0103 (MAF meter) P0115, P0117, P0118 (ECT sensor) P0125 (Insufficient ECT for closed loop) P0335 (CKP sensor) |
| Battery voltage | 11 V or more |
| Engine RPM | 500 to 4000 RPM |
| Engine coolant temperature | 75 to 100°C (167 to 212°F) |
| Deviation of actual valve timing and target valve timing | More than 5 °CA (Crankshaft Angle) |
| Valve timing | No change in advanced valve timing |
| Deviation of actual valve timing and target valve timing | More than 5 °CA (Crankshaft Angle) |
| Valve timing | No change in advanced valve timing |
If the difference between the target and actual camshaft timings is greater than the specified value, the ECM operates the VVT actuator.
Then, the ECM monitors the camshaft timing change for 5 seconds.
| Related DTCs | P0016: Crankshaft position - Camshaft position misaligned at idling (bank 1) P0018: Crankshaft position - Camshaft position misaligned at idling (bank 2) |
| Required Sensors / Components (Main) | VVT actuator |
| Required Sensors / Components (Related) | Camshaft position sensor, Crankshaft position sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | Less than 60 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| The monitor will run whenever these DTCs are not present | P0010, P0020 (OCV bank 1, 2) P0102, P0103 (MAF meter) P0115, P0117, P0118 (ECT sensor) P0125 (Insufficient ECT for closed loop) P0335 (CKP sensor) |
| Engine RPM | 500 to 1000 RPM |
| One of the following conditions is met | Condition 1 or 2 |
| 1. VVT learning value at maximum retarded valve timing | Less than 18.5° CA |
| 2. VVT learning value at maximum retarded valve timing | More than 43.5° CA |
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0016 OR P0018) Connect the Techstream to the DLC3. Turn the ignition switch on (IG) and turn the tester on. Select the following menu items: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Display (DTC Output) Proceed to P0016 or P0018 A P0016 or P0018 and other DTCs B HINT: If any DTCs other than P0016 or P0018 are output, troubleshoot those DTCs first. B --> See step 10 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE OIL CONTROL VALVE FOR INTAKE CAMSHAFT) Connect the Techstream to the DLC3. Start the engine and turn the tester on. Warm up the engine. Select the following menu items: Powertrain / Engine and ECT / Active Test / Control the VVT Linear (Bank 1) or Control the VVT Linear (Bank 2). Check the engine speed while operating the oil control valve using the tester. OK Tester Operation Specified Condition 0% Normal engine idle speed 100% Engine idles roughly or stalls (soon after OCV switched from OFF to ON) NG --> See step 4 OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0016 OR P0018) Connect the Techstream to the DLC3. Turn the ignition switch on (IG) and turn the tester on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-422300-S24344107222011092600000) . Start the engine and warm it up. Drive the vehicle accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs using the tester. OK No DTC output. NG --> See step 4 OK --> END
- CHECK VALVE TIMING (CHECK FOR LOOSE AND JUMPED TEETH ON TIMING CHAIN) Remove the cylinder head covers RH and LH. Turn the crankshaft to align the timing marks of the crankshaft. Align the notch of the crankshaft pulley to the "0" position. Check if the timing marks of the camshaft pulley and camshaft bearing cap align. TEXT IN ILLUSTRATION *1 Timing Mark Turn the crankshaft clockwise 360° if the timing marks do not align. Check if they align once again. OK The timing marks of the camshaft pulley and the camshaft bearing cap align when the notch of the crankshaft pulley is in the "0" position. NG --> See step 11 OK: Go to next step
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT) Remove the intake camshaft timing oil control valve. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 6.9 to 7.9 ohms Apply the positive battery voltage to terminal 1 and the negative battery voltage to terminal 2. Check the valve operation. OK Valve moves quickly. TEXT IN ILLUSTRATION *1 Valve Moves Reinstall the camshaft timing oil control valve. NG --> See step 12 OK: Go to next step
- CHECK OIL PIPE AND OIL CONTROL VALVE FILTER Remove the oil pipe No. 1 or oil pipe assembly. Remove the oil control valve filter. Check that the filter and pipe are not clogged. TEXT IN ILLUSTRATION *1 RH Bank *2 LH Bank OK The filter and pipe are not clogged. NG --> REPLACE OIL CONTROL VALVE FILTER OR PIPE OK: Go to next step
- REPLACE CAMSHAFT TIMING GEAR ASSEMBLY NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch on (IG) and turn the tester on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-422300-S24344107222011092600000) . Start the engine and warm it up. Drive the vehicle accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs using the tester. OK No DTC output. HINT: DTC P0016 or P0018 is output when foreign objects in engine oil are caught in some parts of the system. These codes will stay output even if the system returns to normal after a short time. These foreign objects are then captured by the oil filter, thus eliminating the source of the problem. NG --> See step 9 OK --> END
- REPLACE ECM. Refer to «COMPONENTS»(ref-422482-S29849271832011092600000)
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-422300-S11996203412011092600000)
- ADJUST VALVE TIMING. Refer to «REASSEMBLY»(ref-422437-S17584641942011092600000)
- REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY. Refer to «REMOVAL»(ref-422482-S05437947002011092600000)
| Related DTCs | P0017: Exhaust valve timing misalignment at idling (bank 1) P0019: Exhaust valve timing misalignment at idling (bank 2) |
| Required Sensors / Components (Main) | Timing chain/belt |
| Required Sensors / Components (Related) | None |
| Frequency of Operation | Once per driving cycle |
| Duration | Less than 60 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| The monitor will run whenever these DTCs are not present | P0013, P0023 (Exhaust OCV bank 1, 2) P0102, P0103 (MAF meter) P0115, P0117, P0118 (ECT sensor) P0125 (Insufficient ECT for closed loop) P0335 (CKP sensor) |
| Engine RPM | 500 to 1000 RPM |
| One of the following conditions is met | Condition A, B, C or D |
| A. VVT learning value at maximum advanced valve timing (Bank 1) | Less than 77°CA |
| B. VVT learning value at maximum advanced valve timing (Bank 2) | Less than 77°CA |
| C. VVT learning value at maximum advanced valve timing (Bank 1) | More than 102°CA |
| D. VVT learning value at maximum advanced valve timing (Bank 2) | More than 102°CA |
- Connect the Techstream to the DLC3.
- Turn the ignition switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch on (IG) and turn the Techstream on [A].
- Start the engine and warm it up until the ECT reaches 75°C (167°F) or higher [B].
- Idle the engine for 5 minutes or more [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0017 or P0019.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] through [G].
- Drive the vehicle for 2 to 3 minutes [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Idle the engine for 5 minutes or more [F].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [G].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Check the DTC judgment result.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422300-S24344107222011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0017 AND P0019) Connect the Techstream to the DLC3. Turn the ignition switch on (IG) and turn the tester on. Select the following menu items: Powertrain / Engine and ECT / Trouble Code. Read the DTCs. Result Display (DTC Output) Proceed to P0017 or P0019 A P0017 or P0019 and other DTCs B HINT: If any DTCs other than P0017 or P0019 are output, troubleshoot those DTCs first. B --> See step 9 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE OIL CONTROL VALVE FOR EXHAUST CAMSHAFT) Connect the Techstream to the DLC3. Start the engine and turn the tester on. Warm up the engine. Select the following menu items: Powertrain / Engine and ECT / Active Test / Control the VVT Exhaust Linear (Bank 1) or Control the VVT Exhaust Linear (Bank 2). Check the engine speed while operating the oil control valve using the tester. OK Tester Operation Specified Condition 0% (Oil control valve OFF) Normal engine idle speed 127% (Oil control valve ON) Engine idles roughly or stalls (soon after OCV switched from OFF to ON) NG --> See step 4 OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0017 OR P0019) Connect the Techstream to the DLC3. Turn the ignition switch on (IG) and turn the tester on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-422300-S24344107222011092600000) . Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs using the tester. OK No DTC output. NG --> See step 4 OK --> END
- CHECK VALVE TIMING (CHECK FOR LOOSE AND JUMP TEETH ON TIMING CHAIN) Remove the cylinder head covers RH and LH. Turn the crankshaft to align the matchmarks of the crankshaft. Align the notch of the crankshaft pulley to the "0" position. Check if the matchmarks of the camshaft pulley and camshaft bearing cap align. TEXT IN ILLUSTRATION *1 Timing Mark Turn the crankshaft clockwise by 360° if the matchmarks do not align. Check if they align once again. OK The matchmarks of the camshaft pulley and the camshaft bearing cap align when the notch of the crankshaft pulley is in the "0" position. NG --> See step 10 OK: Go to next step
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT) Remove the exhaust camshaft timing oil control valve. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 6.9 to 7.9 ohms Apply the positive battery voltage to terminal 1 and the negative battery voltage to terminal 2. Check the valve operation. OK Valve moves quickly. TEXT IN ILLUSTRATION *1 Valve Moves Reinstall the camshaft timing oil control valve. NG --> See step 11 OK: Go to next step
- CHECK OIL CONTROL VALVE FILTER AND PIPE Remove the oil pipe No. 1 or oil pipe assembly. Remove the oil control valve filter. Check that the filter and pipe are not clogged. TEXT IN ILLUSTRATION *1 RH Bank *2 LH Bank OK The filter and pipe are not clogged. NG --> REPLACE OIL CONTROL VALVE FILTER OR PIPE OK: Go to next step
- REPLACE CAMSHAFT TIMING GEAR ASSEMBLY NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch on (IG) and turn the tester on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-422300-S24344107222011092600000) . Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Confirm that no DTC pending is set using the tester. OK No DTC output. HINT: DTC P0017 or P0019 is output when foreign objects in engine oil are caught in some parts of the system. These codes will stay registered even if the system returns to normal after a short time. These foreign objects are then captured by the oil filter, thus eliminating the source of the problem. NG --> See step 12 OK --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-422300-S11996203412011092600000)
- ADJUST VALVE TIMING. Refer to «REASSEMBLY»(ref-422437-S17584641942011092600000)
- REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY. Refer to «REMOVAL»(ref-422482-S05437947002011092600000)
- REPLACE ECM. Refer to «COMPONENTS»(ref-422482-S29849271832011092600000)
- Although the DTC titles say the oxygen sensor, these DTCs relate to the air fuel ratio sensor.
- Sensor 1 refers to the sensor mounted in front of the three-way catalytic converter and located near the engine assembly.
| Related DTCs | P0031: Air fuel ratio sensor heater (Bank 1) range check (Low current) P0032: Air fuel ratio sensor heater (Bank 1) range check (High current) P0051: Air fuel ratio sensor heater (Bank 2) range check (Low current) P0052: Air fuel ratio sensor heater (Bank 2) range check (High current) P101D: Air fuel ratio sensor heater (for bank 1) performance P103D: Air fuel ratio sensor heater (for bank 2) performance |
| Required sensors / components (Main) | Air fuel ratio sensor heater (bank 1 and bank 2) |
| Required sensors / components (Related) | |
| Frequency of operation | Continuous |
| Duration | 10 seconds |
| MIL operation | Immediate |
| Sequence operation | None |
| The monitor will run whenever these DTCs are not present | None |
| Battery voltage | 10.5 V or more |
| Heater output duty | 50% or more |
| Time after engine starts | 10 seconds or more |
| Active heater off control | Not operating |
| Active heater on control | Not operating |
| Battery voltage | 10.5 V or more |
| Heater output duty | More than 0% |
| Time after engine start | 10 seconds or more |
| Active heater off control | Not operating |
| Active heater on control | Not operating |
| Monitor runs whenever following DTCs not stored | P0031, P0051 (Air fuel ratio sensor heater) |
| Battery voltage | 10.5 V or more |
| Time after heater ON | 5 seconds or more |
| Active heater OFF control | Not operating |
| Active heater ON control | Not operating |
| Air fuel ratio sensor duty-cycle | 10 to 60% |
| Air fuel ratio sensor heater ON current | 0.8% or more |
| Both of the following conditions are met | Condition A and B |
| A. Heater output | ON |
| B. Heater current | Less than 0.8 A |
| Both of the following conditions are met | Condition A and B |
| A. Heater output | ON |
| B. Hybrid IC high current limit port | Fail |
| Air fuel ratio sensor heater current | 0.8 A or more |
| Heater output | ON |
| Hybrid IC high current limiter port | Fail |
| Hybrid IC high current limiter port | Fail |
MONITOR RESULT
Refer to CHECKING MONITOR STATUS, refer to CHECKING MONITOR STATUS .
Sensor 2 refers to the sensor mounted behind the three-way catalytic converter and located furthest from the engine assembly.
| Related DTCs | P0037: Heated oxygen sensor heater (bank 1) open/short (Low electrical current) P0038: Heated oxygen sensor heater (bank 1) open/short (High electrical current) P0057: Heated oxygen sensor heater (bank 2) open/short (Low electrical current) P0058: Heated oxygen sensor heater (bank 2) open/short (High electrical current) P0141: Heated oxygen sensor heater performance (bank 1 sensor 2) P0161: Heated oxygen sensor heater performance (bank 2 sensor 2) P102D: Heated oxygen sensor heater stuck ON (bank 1 sensor 2) P105D: Heated oxygen sensor heater stuck ON (bank 2 sensor 2) |
| Required Sensors / Components (Main) | Heated oxygen sensor heater (bank 1, 2 and 2) |
| Required Sensors / Components (Related) | Vehicle speed sensor |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds: P0037, P0057, P102D and P105D 2 seconds: P0038 and P0058 10 seconds: P0141 and P0161 |
| MIL Operation | Immediate: P0037, P0038, P0057 and P0058 2 driving cycles: P0141 and P0161 |
| Sequence of Operation | None |
| The monitor will run whenever these DTCs are not present | None |
| Battery voltage | More than 10.5 V |
| Battery voltage | More than 10.5 V |
| Engine | Running |
| Starter | OFF |
| Battery voltage | More than 10.5 V |
| One of the following conditions is met | Condition A or B |
| A. All of the following conditions are met | Conditions 1, 2, 3, 4 and 5 |
| 1. Battery voltage | 10.5 V or more |
| 2. Fuel cut | OFF |
| 3. Time after fuel cut ON to OFF | 30 seconds or more |
| 4. Accumulated heater ON time | 100 seconds or more |
| 5. Learned heater OFF current operation | Completed |
| B. Duration that rear heated oxygen sensor impedance is less than 15 kohms | 2 seconds or more |
| Monitor runs whenever following DTCs not stored | P0031, P0032, P0051, P0052 (Air fuel ratio sensor heater) P0037, P0038, P0057, P0058 (Rear oxygen sensor heater) |
| Battery voltage | 10.5 V or more |
| Engine | Running |
| Starter | OFF |
| Catalyst active A/F complete | Not operating |
| Time after heater ON | 10.5 seconds or more |
When the values for the Data List items. O2 Heater Curr Val B1S2 and O2 Heater Curr Val B2S2 are not 0 A, the heater is on.
| Heater Current - Learned heater OFF current | Less than 0.3 A |
| Both of the following conditions are met | Condition A and B |
| A. Hybrid IC high current limiter monitor input | Fail |
| B. Heater output | ON |
| Accumulated heater resistance | Varies with sensor element temperature (Example: More than 23 ohms) |
P0141 AND P0161 (HEATER PERFORMANCE MONITOR CHECK)
| Heated oxygen sensor heater ON current | 1 A or more |
| Heated oxygen sensor heater current | 0.3 to 2 A (when engine idles, heated oxygen sensor warmed up and battery voltage 11 to 14 V) |
Refer to CHECKING MONITOR STATUS, refer to CHECKING MONITOR STATUS .
- Connect the Techstream to the DLC3.
- Turn the ignition switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch on (IG) and turn the Techstream on [A].
- Start the engine and idle it for 5 minutes or more [B].
- With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 3000 RPM for 1 minute [C].
- Idle the engine for 5 minutes or more [D].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0037, P0038, P0057, P0058, P0141, P0161, P102D or P105D.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [E] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422300-S24344107222011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0101: Mass air flow meter rationality |
| Required Sensors / Components (Main) | Mass air flow meter |
| Required Sensors / Components (Related) | Crankshaft position sensor, engine coolant temperature sensor and throttle position sensor |
| Frequency of Operation | Continuous |
| Duration | 10 times |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| The monitor will run whenever these DTCs are not present | None |
| Throttle position (Throttle position sensor voltage) | 0.24 V to 2 V |
| Engine | Running |
| Battery voltage | 10.5 V or more |
| Engine coolant temperature | 70°C (158°F) or more |
| Intake air temperature sensor current (P0112, P0113) | OK |
| Engine coolant temperature sensor current (P0115, P0117, P0118) | OK |
| Crankshaft position sensor current (P0335) | OK |
| Throttle position sensor current (P0120, P0121, P0122, P0123) | OK |
| Fuel tank pressure sensor (P0452, P0453) | OK |
| EVAP leak detection pump (P2401, P2402) | OK |
| EVAP vent valve (P2419, P2420) | OK |
| Averaged air-fuel ratio | Less than -20%, or more than 20% |
| Averaged engine load | Less than 0.84 or more than 1.44 |
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0101) Connect the Techstream to the DLC3. Turn the ignition switch on (IG). Turn the tester on. Select the following menu items: Powertrain / Engine and ECT / Trouble Code. Read the DTCs. Result Display (DTC Output) Proceed to P0101 and other DTCs A P0101 B HINT: If any DTCs other than P0101 are output, troubleshoot those DTCs first. B --> See step 3 A --> See step 2
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-422300-S11996203412011092600000)
- REPLACE MASS AIR FLOW METER. Refer to «COMPONENTS»(ref-422482-S13956229462011092600000)
| Related DTCs | P0102: Mass air flow meter range check (Low voltage) P0103: Mass air flow meter range check (High voltage) |
| Required Sensors / Components (Main) | Mass air flow meter |
| Required Sensors / Components (Related) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 3 seconds |
| MIL Operation | Immediate: Engine RPM less than 4000 RPM 2 driving cycles: Engine RPM 4000 RPM or more |
| Sequence of Operation | None |
| The monitor will run whenever these DTCs are not present | None |
| Mass air flow meter voltage | Less than 0.2 V |
| Mass air flow meter voltage | More than 4.9 V |
| Mass air flow meter voltage | Between 0.2 V and 4.9 V |
Scheme 673
Scheme 673: WIRING DIAGRAM
Scheme 674
Scheme 674: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch on (IG) and turn the Techstream on [A].
- Start the engine.
- Idle the engine for 5 seconds [B].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Run the engine at an engine speed of 4000 RPM for 5 seconds [D].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0102 or P0103.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [C] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422300-S24344107222011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0111: Intake air temperature sensor rationality (After engine stop) P0111: Intake air temperature sensor rationality (After cold engine start) |
| Required Sensors / Components (Main) | Intake Air Temperature (IAT) sensor |
| Required Sensors / Components (Sub) | |
| Frequency of Operation | Once per driving cycle |
| Duration | 5 hours |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| The monitor will run whenever these DTCs are not present | None |
| Time after engine start | 10 seconds or more |
| Battery voltage | 10.5 V or more |
| IAT sensor circuit (P0112, P0113) | OK |
| ECT sensor circuit (P0115, P0117, P0118) | OK |
| MAF meter circuit (P0102, P0103) | OK |
| ECT change since engine stop | 40°C (40°F) or more |
| Accumulated MAF amount before engine stop | 2393 g or more |
| Key-off duration | 35 minutes |
| Key-off duration | 5 hours |
| Time after engine start | 10 seconds or more |
| IAT sensor circuit (P0112, P0113) | OK |
| ECT sensor circuit (P0115, P0117, P0118) | OK |
| MAF meter circuit (P0102, P0103) | OK |
| ECT | 70°C (158°F) or more |
| Accumulated MAF amount | 2393 g or more |
| One of the following conditions 1 or 2 is met | |
| 1. Duration while engine load is low | 120 seconds or more |
| 2. Duration while engine load is high | 10 seconds or more |
| Intake air temperature change | Less than 1°C (33.8°F) |
| Intake air temperature change | Less than 1°C (33.8°F) |
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0111) Connect the Techstream to the DLC3. Turn the ignition switch on (IG). Turn the tester on. Select the following menu items: Powertrain / Engine and ECT / Trouble Code. Read the DTCs. Result Display (DTC Output) Proceed to P0111 and other DTCs A P0111 B HINT: If any DTCs other than P0111 are output, troubleshoot those DTCs first. B --> See step 3 A --> See step 2
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-422300-S11996203412011092600000)
- REPLACE MASS AIR FLOW METER. Refer to «COMPONENTS»(ref-422482-S13956229462011092600000)
| Related DTCs | P0112: Intake air temperature sensor short (Low electrical voltage) P0113: Intake air temperature sensor open (High electrical voltage) |
| Required Sensors / Components (Main) | Intake air temperature sensor |
| Required sensors / Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| The monitor will run whenever these DTCs are not present | None |
| Battery voltage | 8 V or more |
| Ignition switch | ON (IG) |
| Starter | OFF |
| Intake air temperature sensor voltage | Less than 0.18 V [More than 140°C (284°F)] |
| Intake air temperature sensor voltage | More than 4.91 V [Less than -40°C (-40°F)] |
| Intake air temperature sensor voltage | 0.18 V to 4.91 V [-40 to 140°C (-40 to 284°F)] |
Scheme 675
Scheme 675: WIRING DIAGRAM
- Connect the Techstream to the DLC3.
- Turn the ignition switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch on (IG) and turn the Techstream on.
- Wait 0.5 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0112 or P0113.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422300-S24344107222011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0115: Engine coolant temperature sensor open/short (Fluctuating) P0117: Engine coolant temperature sensor short (Low electrical voltage) P0118: Engine coolant temperature sensor open (High electrical voltage) |
| Required Sensors / Components (Main) | Engine coolant temperature sensor |
| Required Sensors / Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| The monitor will run whenever these DTCs are not present | None |
| Engine coolant temperature sensor voltage | Less than 0.14 V or more than 4.91 V |
| Engine coolant temperature sensor voltage | Less than 0.14 V [More than 140°C (284°F)] |
| Engine coolant temperature sensor voltage | More than 4.91 V [Less than -40°C (-40°F)] |
| Engine coolant temperature sensor voltage | 0.14 V to 4.91 V [-40 to 140°C (-40 to 284°F)] |
Scheme 676
Scheme 676: WIRING DIAGRAM
- Connect the Techstream to the DLC3.
- Turn the ignition switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch on (IG) and turn the Techstream on.
- Wait 0.5 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0115, P0117 or P0118.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422300-S24344107222011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0116: Engine coolant temperature sensor rationality (Engine coolant temperature sensor cold start monitor) P0116: Engine coolant temperature sensor rationality (Engine coolant temperature sensor soak monitor) |
| Required Sensors / Components (Main) | Engine coolant temperature sensor |
| Required Sensors / Components (Related) | Crankshaft position sensor, intake air temperature sensor and mass air flow meter |
| Frequency of Operation | Continuous |
| Duration | 5 hours |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| The monitor will run whenever these DTCs are not present. | None |
| Battery voltage | 10.5 V or more |
| Time after engine start | 1 second or more |
| Engine coolant temperature at engine start | Less than 60°C (140°F) |
| Engine coolant temperature sensor circuit (P0115, P0117, P0118, P0125) | OK |
| Intake air temperature sensor circuit (P0112, P0113) | OK |
| Soak time | 0 second or more |
| Accumulated mass air flow | 1643 g or more |
| Engine | Running |
| Fuel cut | OFF |
| Difference between engine coolant temperature at engine start and intake air temperature | Less than 40°C (104°F) |
ENGINE COOLANT TEMPERATURE SENSOR COLD START MONITOR
| Battery voltage | 10.5 V or more |
| Engine | Running |
| Soak time | 5 hours or more |
| Engine coolant temperature at engine start | 60°C (140°F) or more |
| Accumulated mass air flow | 3047 g or more |
ENGINE COOLANT TEMPERATURE SENSOR SOAK MONITOR
| Engine coolant temperature sensor value change | Less than 5°C (41°F) |
ENGINE COOLANT TEMPERATURE SENSOR COLD START MONITOR
| Engine coolant temperature sensor value change | Less than 5°C (41°F) |
ENGINE COOLANT TEMPERATURE SENSOR SOAK MONITOR
| Engine coolant temperature | Varies with actual engine coolant temperature |
Scheme 677
Scheme 677: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch on (IG) and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp.
- Check that the coolant temperature is 60°C (140°F) or less.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch on (IG) and turn the Techstream on [A].
- Start the engine and idle it for 5 minutes or more [B]. HINT: If the engine coolant temperature does not change by 5°C (9°F) or more, the engine coolant temperature sensor is malfunctioning. It is not necessary to continue this procedure.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0116.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [D] and [E].
- Drive the vehicle at 40 km/h (25 mph) or more for a total of 5 minutes or more [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: In the event of the driving pattern being interrupted (possibly due to factors such as traffic conditions), the driving pattern can be resumed.
- Check the DTC judgment result again [E]. HINT: If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [D] and [E] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422300-S24344107222011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0166) Connect the Techstream to the DLC3. Turn the ignition switch on (IG). Turn the tester on. Select the following menu items: Powertrain / Engine and ECT / Trouble Code. Read the DTC. Result Display (DTC output) Proceed to P0116 A P0116 and other DTCs B HINT: If any DTCs other than P0116 are output, troubleshoot those DTCs first. B --> See step 3 A: Go to next step
- INSPECT THERMOSTAT Remove the thermostat, refer to «REMOVAL»(ref-422445-S32423468412011092600000) . Check the valve opening temperature of the thermostat. Standard 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat, refer to «INSTALLATION»(ref-422445-S25997123812011092600000) . NG --> See step 4 OK --> See step 5
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-422300-S11996203412011092600000)
- REPLACE THERMOSTAT. Refer to «COMPONENTS»(ref-422445-S30248110672011092600000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «COMPONENTS»(ref-422482-S02672525312011092600000)
| Related DTCs | P011B: ECT / IAT sensor correlation |
| Required Sensors / Components (Main) | ECT / IAT sensor |
| Required Sensors / Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | 7 hours or more |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| The monitor will run whenever these DTCs are not present | None |
| All of following conditions are met | Conditions 1 and 2 |
| 1. All of following conditions are met | Conditions (a), (b), (c) and (d) |
| (a) After ignition switch ON and engine not running time | Less than 20 seconds |
| (b) Soak Time | 7 hours or more |
| (c) Battery voltage | 10.5 V or more |
| (d) Time after engine start | 15 seconds or more |
| 2. Either of the following conditions is met | Conditions (a) and (b) |
| (a) After engine start minimum IAT | 10°C (14°F) or more |
| (b) Before engine start ECT | 10°C (14°F) or more |
| Engine coolant temperature sensor circuit fail (P115, P0117, P0118, P0125) | OK |
| Intake air temperature sensor circuit fail (P0112, P0113) | OK |
| Soak timer circuit fail | OK |
| Deviated ECT minus Deviated IAT | Less than -20°C (-36°F) or more than 20°C (36°F) |
Scheme 678
Scheme 678: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Turn the ignition switch off.
- With the engine stopped, leave the vehicle as is for 7.5 hours or more [B].
- Start the engine and wait 60 seconds or more [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P011B.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] through [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422300-S24344107222011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION P011B) Connect the Techstream to the DLC3. Turn the ignition switch on (IG). Turn the tester on. Enter the following menus: Powertrain / Engine and ECT / Trouble Code. Read the DTCs. Result Display (DTC Output) Proceed to P011B A P011B and other DTCs B HINT: If any DTCs other than P011B are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- READ VALUE USING TECHSTREAM (INTAKE AIR TEMPERATURE) Leave the vehicle for 7 hours or more. HINT: It is necessary to leave the vehicle for 7 hours or more to allow conditions similar to the DTC detection conditions. Connect the Techstream to the DLC3. Turn the ignition switch on (IG). Turn the tester ON. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Intake Air. Read the value displayed on the tester. OK The intake air temperature and the outside air temperature are within 10°C (50°F) of each other. HINT: Temperature readings on the vehicle's outside temperature gauge (if equipped) are not suitable for comparing to the IAT reading. The outside temperature gauge has a significant delay built in to prevent temperature swings from being displayed on its display. Use an accurate thermometer to determine the outside air temperature. NG --> See step 5 OK: Go to next step
- READ VALUE USING TECHSTREAM (COOLANT TEMPERATURE) Connect the Techstream to the DLC3. Turn the ignition switch on (IG). Turn the tester ON. Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp. OK The coolant temperature and the outside air temperature are within 10°C (50°F) of each other. HINT: If the result is not as specified, check if there are heat sources such as a block heater in the engine compartment. NG --> See step 7 OK --> See step 6
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-422300-S11996203412011092600000)
- REPLACE MASS AIR FLOW METER. Refer to «REMOVAL»(ref-422482-S26153776752011092600000)
- REPLACE ECM. Refer to «COMPONENTS»(ref-422482-S29849271832011092600000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-422482-S08695913462011092600000)
| Related DTCs | P0120: Throttle position sensor 1 range check (Fluctuating) P0121: Throttle position sensor rationality P0122: Throttle position sensor 1 range check (Low voltage) P0123: Throttle position sensor 1 range check (High voltage) P0220: Throttle position sensor 2 range check (Fluctuating) P0222: Throttle position sensor 2 range check (Low voltage) P0223: Throttle position sensor 2 range check (High voltage) P2135: Throttle position sensor range check (Correlation) |
| Required Sensors / Components (Main) | Throttle position sensor |
| Required Sensors / Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 2 seconds: P0120, P0122, P0123, P0220, P0222 and P0223 (Accelerator pedal ON) Within 2 seconds: P0121 0.5 seconds: P2135 (Condition A) 0.4 seconds: P2135 (Condition B) |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| The monitor will run whenever these DTCs are not present | None |
| Either of following conditions A or B met | |
| A. Ignition switch on (IG) | 0.012 seconds or more |
| B. Electronic throttle actuator power | ON |
P0120, P0122, P0123, P0220, P0222, P0223, P2135
| This monitor will not run whenever these DTCs are not present | None |
| Either of the following conditions is met | Condition 1 or 2 |
| 1. Ignition switch | ON (IG) |
| 2. Electric throttle motor power | ON |
| Throttle position sensor malfunction (P0120, P0122, P0123, P0220, P0222, P0223, P2135) | Not detected |
| VTA1 voltage | 0.2 V or less, or 4.535 V or more |
| Difference of throttle position sensor voltage between VTA1 and VTA2 x 0.8 | More than 1.6 V |
| Difference of throttle position sensor voltage between VTA1 and VTA2 x 0.8 | Less than 0.8 V |
| VTA1 voltage | 0.2 V or less |
| VTA1 voltage | 4.535 V or more |
| VTA2 voltage | 1.75 V or less, or 4.8 V or more |
| VTA2 voltage | 1.75 V or less |
| VTA2 voltage when VTA1 0.2 V to 2.02 V | 4.8 V or more |
| Either of following conditions A or B is met | |
| Condition A | |
| Difference between VTA1 and VTA2 voltages | 0.02 V or less |
| Condition B | |
| Both of the following conditions are met | (a) or (b) |
| (a) VTA1 voltage | 0.2 V or less |
| (b) VTA2 voltage | 1.75 V or less |
| VTA1 voltage | 0.2 to 4.535 V |
| VTA2 voltage | 1.75 to 4.8 V |
FAIL-SAFE
When any of these DTCs, as well as other DTCs relating to electronic throttle control system malfunctions, are set, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator off, and the throttle valve is returned to a 6° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing, in accordance with the accelerator pedal opening angle, to allow the vehicle to continue at a minimal speed. If the accelerator pedal is depressed slowly, the vehicle can be driven slowly.
Fail-safe mode continues until a pass condition is detected, and the ignition switch is turned off.
Scheme 679
Scheme 679: WIRING DIAGRAM
Scheme 680
Scheme 680: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch on (IG) and turn the Techstream on [A].
- Start the engine.
- With the vehicle stationary, fully depress and release the accelerator pedal [B].
- Idle the engine for 2 seconds or more [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0120, P0121, P0122, P0123, P0220, P0222, P0223 or P2135.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422300-S24344107222011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ VALUE USING TECHSTREAM (THROTTLE POS AND THROTTLE POS #2) Connect the Techstream to the DLC3. Turn the ignition switch on (IG) and turn the tester on. Select the following menu items: Powertrain / Engine and ECT / Data List / Throttle Position No. 1 and Throttle Sensor Position No. 2. Check the values displayed on the tester. Result When accelerator pedal released When accelerator pedal depressed Trouble Area Proceed to Throttle Sensor Position No. 1 Throttle Sensor Position No. 2 Throttle Sensor Position No. 1 Throttle Sensor Position No. 2 0 to 0.2 V Between 0 V and 0.2 V 0 to 0.2 V Between 0 V and 0.2 V VC circuit open A 4.5 to 5.0 V Between 4.5 V and 5.0 V 4.5 to 5.0 V Between 4.5 V and 5.0 V E2 circuit open A 0 to 0.2 V or 4.5 to 5.0 V 2.1 to 3.1 V (Fail-safe) 0 to 0.2 V or 4.5 to 5.0 V 2.1 to 3.1 V (Fail-safe) VTA1 circuit open or ground short A 0.6 to 1.4 V (Fail-safe) Between 0 V and 0.2 V, or 4.5 V and 5.0 V 0.6 to 1.4 V (Fail-safe) Between 0 V and 0.2 V, or 4.5 V and 5.0 V VTA2 circuit open or ground short A 0.5 to 1.1 V Between 2.1 V and 3.1 V 3.2 to 4.8 V (Not fail-safe) Between 4.6 V and 5.0 V (Not fail-safe) Throttle position sensor circuit normal B HINT: DTC P0121 is stored when the voltages output from VTA1 and VTA2 are not consistent with the characteristics of the sensors. Therefore, check the Freeze Frame Data when this DTC is output. Use the following formula to confirm relative fluctuations in voltage. Features of sensor output VTA2 x 0.8 is approximately equal to VTA1 + 1.11 V VTA1: Throttle Position No. 1 VTA2: Throttle position No. 2 If DTC P0121 is output, proceed to the "CHECK HARNESS AND CONNECTOR (THROTTLE POSITION SENSOR - ECM)". B --> See step 5 A: Go to next step
- CHECK HARNESS AND CONNECTOR (THROTTLE POSITION SENSOR - ECM) Disconnect the throttle body connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard resistance Check for open Check for short Tester Connection Condition Specified Condition B27-5 (VC) - B49-13 (VCTA) Always Below 1 ohms B27-6 (VTA) - B49-15 (VTA1) Always Below 1 ohms B27-4 (VTA2) - B49-16 (VTA2) Always Below 1 ohms B27-3 (E2) - B49-14 (ETA) Always Below 1 ohms Tester Connection Condition Specified Condition B27-5 (VC) or B49-13 (VCTA) - Body ground Always 10 kohms or higher B27-6 (VTA) or B49-15 (VTA1) - Body ground Always 10 kohms or higher B27-4 (VTA2) or B49-16 (VTA2) - Body ground Always 10 kohms or higher Reconnect the throttle body connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (THROTTLE POSITION SENSOR - ECM) OK: Go to next step
- INSPECT ECM (VC VOLTAGE) Turn the ignition switch on (IG). Measure the voltage according to the value(s) in the table below. Standard voltage Tester Connection Switch Condition Specified Condition B49-13 (VCTA) - B49-14 (ETA) Ignition switch on (IG) 4.5 to 5.0 V NG --> See step 6 OK: Go to next step
- REPLACE THROTTLE BODY Replace the throttle body, refer to «COMPONENTS»(ref-422482-S07398144772011092600000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (THROTTLE POSITION SENSOR DTCS) Connect the Techstream to the DLC3. Turn the ignition switch on (IG) and turn the tester on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-422300-S24344107222011092600000) . Start the engine. With the vehicle stationary, fully depress and release the accelerator pedal. Allow the engine to idle for 2 seconds or more. Select the following menu items: Powertrain / Engine and ECT / Trouble Code. Read the DTCs. Result Display (DTC Output) Proceed to P0120, P0121, P0122, P0123, P0220, P0222, P0223 and/or P2135 A No output B B --> END A --> See step 6
- REPLACE ECM. Refer to «COMPONENTS»(ref-422482-S29849271832011092600000)
| Related DTCs | P0125: Insufficient engine coolant temperature for closed-loop fuel control |
| Required Sensors / Components (Main) | Thermostat, cooling system |
| Required Sensors / Components (Related) | Engine coolant temperature sensor and mass air flow meter |
| Frequency of Operation | Continuous |
| Duration | 55 seconds: Engine coolant temperature at engine start is (closed-loop engine coolant temperature -8.33°C (47.0°F) or more 93 seconds: Engine coolant temperature at engine start is (closed-loop engine coolant temperature -19.44 (67.0°F) to (closed-loop engine coolant temperature -8.33°C (47.0°F) 20 minutes: Engine coolant temperature at engine start less than (closed-loop engine coolant temperature -19.44 (67.0°F) |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| The monitor will run whenever these DTCs are not present | None |
| Thermostat (P0128) | OK |
| Mass air flow meter (P0101, P0102, P0103) | OK |
| Intake air temperature sensor (P0112, P0113) | OK |
| Engine coolant temperature sensor (P0115, P0117, P0118) | OK |
| Time until actual engine coolant temperature reaches closed-loop fuel control enabling temperature | 55 seconds: Engine coolant temperature at engine start is (closed-loop engine coolant temperature -8.33°C (47.0°F) or more 93 seconds: Engine coolant temperature at engine start is (closed-loop engine coolant temperature -19.44 (67.0°F) to (closed-loop engine coolant temperature -8.33°C (47.0°F) 20 minutes: Engine coolant temperature at engine start less than (closed-loop engine coolant temperature -19.44 (67.0°F) |
- Leave the vehicle outside overnight.
- Connect the Techstream to the DLC3.
- Turn the ignition switch on (IG) and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp.
- Check that the engine coolant temperature is 10°C (50°F) or less.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch on (IG) and turn the Techstream on.
- Start the engine.
- Wait 21 minutes or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0125.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422300-S24344107222011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0125) Connect the Techstream to the DLC3. Turn the ignition switch on (IG). Turn the tester on. Select the following menu items: Powertrain / Engine and ECT / Trouble Code. Read the DTCs. Result Display (DTC Output) Proceed to P0125 A P0125 and other DTCs B HINT: If any DTCs other than P0125 are output, troubleshoot those DTCs first. B --> See step 5 A: Go to next step
- INSPECT THERMOSTAT Remove the thermostat, refer to «REMOVAL»(ref-422445-S32423468412011092600000) . Check the valve opening temperature of the thermostat. Standard 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat, refer to «INSTALLATION»(ref-422445-S25997123812011092600000) . NG --> See step 6 OK: Go to next step
- CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal radiator fan operation or any modifications. NG --> REPAIR OR REPLACE COOLING SYSTEM OK --> See step 4
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «COMPONENTS»(ref-422482-S02672525312011092600000)
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-422300-S11996203412011092600000)
- REPLACE THERMOSTAT. Refer to «COMPONENTS»(ref-422445-S30248110672011092600000)
This DTC relates to the thermostat.
| Related DTCs | P0128: Coolant Thermostat |
| Required Sensors / Components (Main) | Thermostat |
| Required Sensors / Components (Related) | Engine coolant temperature sensor, intake air temperature sensor, Vehicle speed sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 480 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| The monitor will run whenever these DTCs are not present | P0010, P0020 (OCV bank 1, 2) P0011, P0021 (VVT system bank 1, 2 - advance) P0012, P0022 (VVT system bank 1, 2 - retard) P0013, P0023 (Exhaust OCV bank 1, 2) P0014, P0024 (Exhaust VVT system bank 1, 2 - advance) P0015, P0025 (Exhaust VVT system bank 1, 2 - retard) P0016, P0018 (VVT system bank 1, 2 - misalignment) P0017, P0019 (Exhaust VVT system bank 1, 2 - misalignment) P0031, P0032, P0051, P0052 (A/F sensor heater) P0102, P0103 (MAF meter) P0112, P0113 (IAT sensor) P0115, P0117, P0118 (ECT sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (TP sensor) P014C, P014D, P014E, P014F (A/F sensor - slow response) P015A, P015B, P015C, P015D (A/F sensor - delayed response) P0301, P0302, P0303, P0304, P0305, P0306 (Misfire) P0335 (CKP sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) P0351, P0352, P0353, P0354, P0355, P0356 (Igniter) P0365, P0367, P0368, P0390, P0392, P0393 (Exhaust VVT sensor) P0500 (Vehicle speed sensor) P2195, P2196, P2197, P2198 (A/F sensor - rationality) P2237, P2240 (A/F sensor - open) P2238, P2241, P2252, P2255 (A/F sensor - low impedance) P2239, P2242, P2253, P2256 (A/F sensor - high impedance) |
| Battery voltage | 11 V or more |
| Either of following conditions is met | Condition 1 or 2 |
| 1. All of following conditions are met | Conditions (a), (b) and (c) |
| (a) Engine coolant temperature at engine start - Intake air temperature at engine start | 15 to 7°C (5 to 45°F) |
| (b) Engine coolant temperature at engine start | 10 to 56°C (14 to 133°F) |
| (c) Intake air temperature at engine start | 10 to 56°C (14 to 133°F) |
| 2. All of following conditions are met | Conditions (d), (e) and (f) |
| (d) Engine coolant temperature at engine start - Intake air temperature at engine start | More than 7°C (45°F) |
| (e) Engine coolant temperature at engine start | 56°C (133°F) or less |
| (f) Intake air temperature at engine start | 10°C (14°F) or more |
| Accumulated time that vehicle speed is 80 mph (128 km/h) or more | Less than 20 seconds |
| Duration that all of the following conditions 1 and 2 are met | 5 seconds or more |
| 1. Estimated engine coolant temperature | 75°C (167°F) or more |
| 2. Engine coolant temperature sensor output | Less than 75°C (167°F) |
Scheme 681
Scheme 681: CONFIRMATION DRIVING PATTERN
- Stop the engine and allow it to soak.
- Connect the Techstream to the DLC3.
- Turn the ignition switch on (IG) and turn the Techstream on [A].
- Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Coolant Temp and Intake Air.
- Check that "Coolant Temp" is 56°C (133°F) or less and "Intake Air" is between 0 and 35°C (0 and 95°F).
- Set the heater to MAX HOT with fresh air mode selected and turn the A/C off.
- Start the engine and drive the vehicle at 80 km/h (50 mph) for 15 minutes [B]. HINT: Data can be captured relatively easily by using the snapshot function in the Data List. Enter the following menus: Data List / Function / Snap-shot configuration / Record time / 5 min. Data capture can be started by using the target point function. For example, setting the target point to an engine speed of 4000 RPM and then racing the engine, etc. to raise the engine speed to a speed of 4000 RPM or more will cause data capture to start.
- After "Coolant Temp" stabilizes, check that "Coolant Temp" is 75°C (167°F) or higher [C]. HINT: If "Coolant Temp" is below 75°C (167°F) while driving the vehicle at 80 km/h (50 mph), inspect the cooling system and thermostat.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0128) Connect the Techstream to the DLC3. Turn the ignition switch on (IG). Turn the tester on. Select the following menu items: Powertrain / Engine and ECT / Trouble Code. Read the DTCs. Result Display (DTC Output) Proceed to P0128 A P0128 and other DTCs B HINT: If any DTCs other than P0128 are output, troubleshoot those DTCs first. B --> See step 5 A: Go to next step
- CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal radiator fan operation or any modifications. NG --> REPAIR OR REPLACE COOLING SYSTEM OK: Go to next step
- INSPECT THERMOSTAT Remove the thermostat, refer to «REMOVAL»(ref-422445-S32423468412011092600000) . Check the valve opening temperature of the thermostat. Standard 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat, refer to «INSTALLATION»(ref-422445-S25997123812011092600000) . NG --> See step 6 OK --> See step 4
- REPLACE ECM. Refer to «COMPONENTS»(ref-422482-S29849271832011092600000)
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-422300-S11996203412011092600000)
- REPLACE THERMOSTAT. Refer to «COMPONENTS»(ref-422445-S30248110672011092600000)
| Related DTCs | P0136: Heated oxygen sensor output voltage (Output voltage) (bank 1) P0136: Heated oxygen sensor impedance (Low) (bank 1) P0137: Heated oxygen sensor output voltage (Low voltage) (bank 1) P0137: Heated oxygen sensor impedance (High) (bank 1) P0138: Heated oxygen sensor output voltage (Extremely high) (bank 1) P0139: Heated oxygen sensor output voltage during fuel cut (bank 1) P0156: Heated oxygen sensor output voltage (Output voltage) (bank 2) P0156: Heated oxygen sensor impedance (Low) (bank 2) P0157: Heated oxygen sensor output voltage (Low voltage) (bank 2) P0157: Heated oxygen sensor impedance (High) (bank 2) P0158: Heated oxygen sensor output voltage (Extremely high) (bank 2) P0159: Heated oxygen sensor output voltage during fuel cut (bank 2) |
| Required Sensors/Components (Main) | Heated oxygen sensor (sensor 2) |
| Required Sensors/Components (Related) | Crankshaft position sensor Engine coolant temperature sensor Mass air flow meter Throttle position sensor |
| Frequency of Operation | Once per driving cycle: Active air fuel ratio control detection, Abnormal voltage during fuel cut Continuous: Other |
| Duration | 20 seconds: Heated oxygen sensor output (Output voltage, High voltage, Low voltage) 30 seconds: Heated oxygen sensor impedance (Low) 90 seconds: Heated oxygen sensor impedance (High) 10 seconds: Heated oxygen sensor voltage (Extremely high) 7 seconds: Heated oxygen sensor voltage during fuel cut |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| The monitor will run whenever these DTCs are not present | P0016, P0018 (VVT system bank 1, 2 - misalignment) P0017, P0019 (Exhaust VVT system bank 1, 2 - misalignment) P0031, P0032, P0051, P0052 (A/F sensor heater) P0037, P0038, P0057, P0058 (HO2 sensor heater) P0102, P0103 (MAF meter) P0112, P0113 (IAT sensor) P0115, P0117, P0118 (ECT sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (TP sensor) P0125 (Insufficient ECT for closed loop) P0128 (Thermostat) P0171, P0172, P0174, P0175 (Fuel system) P0301, P0302, P0303, P0304, P0305, P0306 (Misfire) P0335 (CKP sensor) P0451, P0452, P0453 (EVAP system) P0500 (Vehicle speed sensor) P2195, P2196, P2197, P2198 (A/F sensor - rationality) P2238, P2241, P2252, P2255 (A/F sensor - low impedance) |
| Battery voltage | 11 V or more |
| IAT | 10°C (14°F) or more |
| ECT | 75°C (167°F) or more |
| Atmospheric pressure | 76 kPa (570 mmHg) or more |
| Idle | OFF |
| Engine RPM | Less than 3200 RPM |
| Air fuel ratio sensor | Activated |
| Fuel system status | Closed loop |
| Engine load | 10 to 70% |
| All of the following conditions are met | Conditions 1, 2 and 3 |
| 1. Mass air flow rate | 5 to 60 g/sec. |
| 2. Front catalyst temperature (estimated) | 600 to 750°C (1112 to 1382°F) |
| 3. Rear catalyst temperature (estimated) | 100 to 900°C (212 to 1652°F) |
| Shift position | 4th or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (OUTPUT VOLTAGE, LOW OUTPUT VOLTAGE)
| Battery voltage | 11 V or more |
| Estimated sensor temperature | Less than 700°C (1292°F) |
| ECM monitor | Completed |
| DTC P0607 | Not set |
HEATED OXYGEN SENSOR IMPEDANCE (LOW)
| Battery voltage | 11 V or more |
| Estimated sensor temperature | 450°C (842°F) or higher and less than 750°C (1382°F) |
| DTC P0607 | Not set |
HEATED OXYGEN SENSOR IMPEDANCE (HIGH)
| Battery voltage | 11 V or more |
| Time after engine start | 2 seconds or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (EXTREMELY HIGH)
| Engine coolant temperature | 75°C (167°F) or more |
| Catalyst temperature | 400°C (752°F) or more |
| Fuel cut | ON |
HEATED OXYGEN SENSOR VOLTAGE DURING FUEL CUT
| Either of following conditions met | 1 or 2 |
| 1. All of following conditions (a), (b) and (c) met | |
| (a) Commanded air fuel ratio | 14.3 or less |
| (b) Rear heated oxygen sensor voltage | 0.21 to 0.59 V |
| (c) Oxygen storage capacity of catalyst | 2.0 g or more |
| 2. All of following conditions (d), (e) and (f) met | |
| (d) Commanded air fuel ratio | 14.9 or more |
| (e) Rear heated oxygen sensor voltage | 0.21 to 0.59 V |
| (f) Oxygen storage capacity | 2.0 g or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (OUTPUT VOLTAGE)
| All of following conditions (a), (b) and (c) met | |
| (a) Commanded air fuel ratio | 14.3 or less |
| (b) Rear heated oxygen sensor voltage | Less than 0.21 V |
| (c) OSC (Oxygen Storage Capacity of Catalyst) | 2.0 g or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (LOW OUTPUT VOLTAGE)
| Duration of following condition | 30 seconds or more |
| Heated oxygen sensor impedance | Less than 5 ohms |
HEATED OXYGEN SENSOR IMPEDANCE (LOW)
| Duration of following condition | 90 seconds or more |
| Heated oxygen sensor impedance | 15 kohms or more |
HEATED OXYGEN SENSOR IMPEDANCE (HIGH)
| Duration of following condition | 10 seconds or more |
| Heated oxygen sensor voltage | 1.2 V or higher |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (EXTREMELY HIGH)
| Duration until rear heated oxygen sensor voltage drops to 0.2 V after fuel cut | 7 seconds or more |
| During that heated oxygen sensor voltage from 0.35 V to 0.2 V during fuel cut | 1 second or more |
HEATED OXYGEN SENSOR VOLTAGE DURING FUEL-CUT
| Duration of following condition | 30 seconds or more |
| Heated oxygen sensor voltage | Varies between 0.1 V and 0.9 V |
Refer to CHECKING MONITOR STATUS, refer to CHECKING MONITOR STATUS .
Scheme 682
Scheme 682: WIRING DIAGRAM
P0136, P0137, P0138, P0156, P0157 and P0158
Scheme 683
Scheme 683: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch on (IG) and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- With the transmission in 4th gear or higher, drive the vehicle at 60 to 120 km/h (40 to 75 mph) for 10 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0136, P0137, P0138, P0156, P0157 or P0158.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [C] through [D].
- If no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422300-S24344107222011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 684
- Connect the Techstream to the DLC3.
- Turn the ignition switch on (IG) and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch on (IG) and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Drive the vehicle at 60 km/h (40 mph), and then decelerate the vehicle by releasing the accelerator pedal for 5 seconds or more to perform the fuel-cut [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the DTCs. HINT: If a pending DTC or current DTC is output, the system is malfunctioning. If a pending DTC or current DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0139 or P0159.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, shift the transmission to 2nd gear, and then perform steps [C] and [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422300-S24344107222011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P014C: Air fuel ratio sensor (bank 1) slow response (rich to lean) P014D: Air fuel ratio sensor (bank 1) slow response (lean to rich) P014E: Air fuel ratio sensor (bank 2) slow response (rich to lean) P014F: Air fuel ratio sensor (bank 2) slow response (lean to rich) P015A: Air fuel ratio sensor (bank 1) delayed response (rich to lean) P015B: Air fuel ratio sensor (bank 1) delayed response (lean to rich) P015C: Air fuel ratio sensor (bank 2) delayed response (rich to lean) P015D: Air fuel ratio sensor (bank 2) delayed response (lean to rich) |
| Required Sensors/Components (Main) | Air fuel ratio sensor |
| Required Sensors/Components (Related) | Vehicle speed sensor, crankshaft position sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 to 15 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not stored | None |
| Active air fuel ratio control | Performing |
| Active air fuel ratio control is performed when the following conditions are met | |
| Battery voltage | 11 V or higher |
| Engine coolant temperature | 75°C (167°F) or more |
| Idle | OFF |
| Engine speed | 1000 to 4000 RPM |
| Air fuel ratio sensor status | Activated |
| Fuel-cut | OFF |
| Engine load | 10 to 70% |
| Shift position | 2nd or higher |
| Catalyst monitor | Not yet |
| Mass air flow | 21 to 52 g/sec. |
| Rich to Lean Response rate deterioration level | 0.045 V or less |
AIR FUEL RATIO SENSOR (BANK 1, 2) SLOW RESPONSE (RICH TO LEAN)
| Lean to Rich Response rate deterioration level | 0.045 V or higher |
AIR FUEL RATIO SENSOR (BANK 1, 2) SLOW RESPONSE (LEAN TO RICH)
| Rich to Lean delay level | 200 msec or more |
AIR FUEL RATIO SENSOR (BANK 1, 2) DELAYED RESPONSE (RICH TO LEAN)
| Lean to Rich delay level | 200 msec or more |
AIR FUEL RATIO SENSOR (BANK 1, 2) DELAYED RESPONSE (LEAN TO RICH)
Refer to Checking Monitor Status, refer to CHECKING MONITOR STATUS .
Performing this confirmation pattern will activate the air fuel ratio sensor response monitor.
Scheme 685
Scheme 685: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch on (IG).
- Turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure), refer to «DTC CHECK / CLEAR»(ref-422300-S24344107222011092600000) .
- Turn the ignition switch off.
- Turn the ignition switch on (IG) and turn the Techstream on.
- Enter the following menus: Powertrain / Engine / Monitor / O2 Sensor / Details.
- Check that the RES RATE B1S1 and RES RATE B2S1 are Incomplete.
- Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or higher) [A].
- Drive the vehicle at a constant speed of between 47 and 62 mph (75 and 100 km/h) for 10 minutes [B].
- Check the monitor result values on Techstream by entering the following menus: Powertrain / Engine / Monitor / O2 Sensor / Details / RES RATE B1S1 and RES RATE B2S1.
- If the values indicated on the Techstream do not change, perform Readiness Monitor Drive Pattern for the air fuel ratio sensor and heated oxygen sensor, refer to «READINESS MONITOR DRIVE PATTERN»(ref-422300-S33364211702011092600000) .
- Note the value of the Monitor Result.
- Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read the pending DTC [C].
- If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P014C, P014D, P014E, P014F, P015A, P015B, P015C, P015D.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [B] again.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422300-S24344107222011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C OR P015D) Connect the Techstream to the DLC3. Turn the ignition switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D is output A DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D and other DTCs are output B HINT: If any DTCs other than P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D are output, troubleshoot those DTCs first. B --> See step 10 A: Go to next step
- INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE) See step 1 NG --> See step 11 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) See step 3 NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- INSPECT AIR FUEL RATIO SENSOR Check that the proper air fuel ratio sensors are installed to the vehicle. NG --> See step 12 OK: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Drive the vehicle according to the Confirmation Driving Pattern. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C OR P015D) Connect the Techstream to the DLC3. Turn the ignition switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the DTCs. RESULT Result Proceed to DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C and/or P015D are output A DTC is not output B B --> See step 13 A: Go to next step
- REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor, refer to «REMOVAL»(ref-422482-S33014230512011092600000) . NEXT: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Drive the vehicle according to the Confirmation Driving Pattern. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C OR P015D) Connect the Techstream to the DLC3. Turn the ignition switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. RESULT Result Proceed to DTC is not output A DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C and/or P015D are output B B --> See step 14 A --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-422300-S11996203412011092600000)
- REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-422482-S33014230512011092600000)
- REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-422482-S33014230512011092600000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-422300-S41051796092011092600000)
- CHECK ENGINE TO DETERMINE CAUSE OF EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO. Refer to «DTC P0171: System Too Lean (Bank 1); DTC P0172: System Too Rich (Bank 1); DTC P0174: System Too Lean (Bank 2); DTC P0175: System Too Rich (Bank 2)»(ref-422484-S09733963082011092600000)
| Related DTCs | P0171: Fuel trim Lean (bank 1) P0172: Fuel trim Rich (bank 1) P0174: Fuel trim Lean (bank 2) P0175: Fuel trim Rich (bank 2) |
| Required Sensors/Components (Main) | Fuel system |
| Required Sensors/Components (Related) | Air fuel ratio sensor Mass air flow meter Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | Less than 10 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| The monitor will run whenever these DTCs are not present | P0010, P0020 (OCV bank 1, 2) P0011, P0021 (VVT system bank 1, 2 - advance) P0012, P0022 (VVT system bank 1, 2 - retard) P0013, P0023 (Exhaust OCV bank 1, 2) P0014, P0024 (Exhaust VVT system bank 1, 2 - advance) P0015, P0025 (Exhaust VVT system bank 1, 2 - retard) P0016, P0018 (VVT system bank 1, 2 - misalignment) P0017, P0019 (Exhaust VVT system bank 1, 2 - misalignment) P0031, P0032, P0051, P0052 (A/F sensor heater) P0102, P0103 (MAF meter) P0115, P0117, P0118 (ECT sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (TP sensor) P0125 (Insufficient ECT for closed loop) P0335 (CKP sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) P0351, P0352, P0353, P0354, P0355, P0356 (Igniter) P0365, P0367, P0368, P0390, P0392, P0393 (Exhaust VVT sensor) P0500 (Vehicle speed sensor) |
| Fuel system status | Closed-loop |
| Battery voltage | 11 V or more |
| Either of following conditions 1 or 2 set | |
| 1. Engine RPM | Less than 1100 RPM |
| 2. Intake air amount per revolution | 0.22 g/rev or more |
| Catalyst monitor | No executed |
| Purge-cut | Executing |
| Either of following conditions 1 or 2 met | |
| 1. Average between short-term fuel trim and long-term fuel trim | 35% or more (varies with engine coolant temperature) |
| 2. Average between short-term fuel trim and long-term fuel trim | 35% or less (varies with engine coolant temperature) |
| Related DTCs | P0300: Multiple cylinder misfire P0301: Cylinder 1 misfire P0302: Cylinder 2 misfire P0303: Cylinder 3 misfire P0304: Cylinder 4 misfire P0305: Cylinder 5 misfire P0306: Cylinder 6 misfire |
| Required Sensors/Components (Main) | Injector, Ignition coil and spark plug |
| Required Sensors/Components (Related) | Crankshaft position, Camshaft position Engine coolant temperature and intake air temperature sensors and Mass air flow meter |
| Frequency of Operation | Continuous |
| Duration | 1000 to 4000 crankshaft revolutions: Emission related misfire 200 to 600 crankshaft revolutions: Catalyst damaged misfire |
| MIL Operation | 2 driving cycles: (MIL illuminates when misfire detected) MIL flashes immediately: When catalyst damaged misfire occur |
| Sequence of Operation | None |
| The monitor will run whenever these DTCs are not present | P0016, P0018 (VVT system bank 1, 2 - misalignment) P0017, P0019 (Exhaust VVT system bank 1, 2 - misalignment) P0102, P0103 (MAF meter) P0112, P0113 (IAT sensor) P0115, P0117, P0118 (ECT sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (TP sensor) P0125 (Insufficient ECT for closed loop) P0327, P0328, P0332, P0333 (Knock sensor) P0335 (CKP sensor) P0351, P0352, P0353, P0354, P0355, P0356 (Igniter) P0500 (Vehicle speed sensor) |
| Battery voltage | 8 V or more |
| VVT system | Not operated by scan tool |
| Engine RPM | 450 to 6500 RPM |
| Either of following conditions (a) or (b) met | |
| (a) Engine coolant temperature at engine start | More than -7°C (19°F) |
| (b) Engine coolant temperature | More than 20°C (68°F) |
| Fuel cut | OFF |
| First 1000 revolutions after engine start, or Check Mode | Crankshaft 1000 revolutions |
| Except above | Crankshaft 1000 revolutions x 4 |
MONITOR PERIOD OF EMISSION-RELATED-MISFIRE
| All of following conditions 1, 2 and 3 met | Crankshaft 200 revolutions |
| 1. Driving cycles | 1st |
| 2. Check mode | OFF |
| 3. Engine RPM | Less than 3000 RPM |
| Except above | Crankshaft 200 revolutions x 3 |
MONITOR PERIOD OF CATALYST-DAMAGED-MISFIRE (MIL BLINKS)
| The monitor will run whenever these DTCs are not present | P0016, P0018 (VVT system bank 1, 2 - misalignment) P0017, P0019 (Exhaust VVT system bank 1, 2 - misalignment) P0102, P0103 (MAF meter) P0112, P0113 (IAT sensor) P0115, P0117, P0118 (ECT sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (TP sensor) P0125 (Insufficient ECT for closed loop) P0327, P0328, P0332, P0333 (Knock sensor) P0335 (CKP sensor) P0351, P0352, P0353, P0354, P0355, P0356 (Igniter) P0500 (Vehicle speed sensor) |
| Battery voltage | 8 V or more |
| VVT system | Not operated by scan tool |
| Engine RPM | 450 to 6500 RPM |
| Engine coolant temperature | More than 65°C (149°F) |
| Fuel cut | OFF |
MISFIRE: FOR MEXICO MODELS
| First 1000 revolutions after engine start, or Check mode | Crankshaft 1000 revolutions |
| Except above | Crankshaft 1000 revolutions x 4 |
MONITOR PERIOD OF EMISSION-RELATED-MISFIRE: FOR MEXICO MODELS
| All of following conditions 1, 2 and 3 met | Crankshaft 200 revolutions |
| 1. Driving cycles | 1st |
| 2. Check mode | OFF |
| Except above | Crankshaft 200 revolutions x 3 |
MONITOR PERIOD OF CATALYST-DAMAGED-MISFIRE (MIL BLINKS): FOR MEXICO MODELS
MONITOR PERIOD OF EMISSION-RELATED-MISFIRE
| Number of misfire per 200 revolutions | 94 or more (varies with intake air amount and RPM) |
| Paired cylinder misfire (MIL blinks immediately) | Detected |
MONITOR PERIOD OF CATALYST-DAMAGED-MISFIRE (MIL BLINKS)
| Misfire rate | 26 % or more: for 1st 1000 revolutions 13 % or more: after 1st 1000 revolutions |
MONITOR PERIOD OF EMISSION-RELATED-MISFIRE: FOR MEXICO MODELS
| Number of misfire per 200 revolutions | 94 or more (varies with intake air amount and RPM) |
| Paired cylinder misfire (MIL blinks immediately) | Detected |
MONITOR PERIOD OF CATALYST-DAMAGED-MISFIRE (MIL BLINKS): FOR MEXICO MODELS
Refer to CHECKING MONITOR STATUS, refer to CHECKING MONITOR STATUS .
- Connect the Techstream to the DLC3.
- Turn the ignition switch on (IG).
- Turn the Techstream on.
- Record the DTC(s) and freeze frame data.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Using the Techstream, switch the ECM from normal mode to check mode, refer to «CHECK MODE PROCEDURE»(ref-422300-S23062665192011092600000) .
- Read the misfire counts of each cylinder (cylinder No. 1 to No. 8) with the engine idling. If any misfire count is displayed, skip the following confirmation driving pattern.
- Drive the vehicle several times with the conditions, such as engine speed and engine load, as shown in Misfire RPM and Misfire Load in the freeze frame data. HINT: In order to store misfire DTCs, it is necessary to operate the vehicle for the period of time shown in the table below with the engine speed and engine load the same as Misfire RPM and Misfire Load in the freeze frame data. Engine Speed Duration Idling 7.0 minutes or more 1000 4.0 minutes or more 2000 2.0 minutes or more 3000 1.5 minutes or more
- Check whether misfires have occurred by checking DTCs and freeze frame data. HINT: Do not turn the ignition switch off until the stored DTCs and freeze frame data have been recorded. When the ECM returns to normal mode (default), the stored DTCs, freeze frame data and other data will be cleared.
- Record the DTCs, freeze frame data and misfire counts.
- Turn the ignition switch off and wait for at least 30 seconds.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
| Related DTCs | P0327: Knock sensor (Bank 1) open/short (Low voltage) P0328: Knock sensor (Bank 1) open/short (High voltage) P0332: Knock sensor (Bank 2) open/short (Low voltage) P0333: Knock sensor (Bank 2) open/short (High voltage) |
| Required Sensors / Components (Main) | Knock sensor (Bank 1 and 2) |
| Required Sensors / Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1 second |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| The monitor will run whenever these DTCs are not present | None |
| Battery voltage | 10.5 V or more |
| Time after engine start | 5 seconds or more |
| Ignition switch | ON (IG) |
| Starter | OFF |
| Knock sensor voltage | Less than 0.5 V |
KNOCK SENSOR RANGE CHECK (LOW VOLTAGE) P0327 AND P0332
| Knock sensor voltage | More than 4.5 V |
KNOCK SENSOR RANGE CHECK (HIGH VOLTAGE) P0328 AND P0333
Scheme 686
Scheme 686: WIRING DIAGRAM
- Connect the Techstream to the DLC3.
- Turn the ignition switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch on (IG) and turn the Techstream on.
- Start the engine and wait 5 minutes.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0327, P0328, P032C, P032D, P0332, P0333, P033C or P033D.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, idle the engine for 5 minutes and check the DTC judgment result again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422300-S24344107222011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0335: Crankshaft position sensor range check/rationality P0335: Crankshaft position sensor verify pulse input |
| Required Sensors / Components (Main) | Crankshaft position sensor |
| Required Sensors / Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 4.7 seconds: Verify pulse input 0.016 seconds: Range check/rationality |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| The monitor will run whenever these DTCs are not present | None |
| Time after starter OFF to ON | 3 seconds or more |
| Battery voltage | 7 V or more |
| Number of VVT sensor signal pulse | 6 times |
| Camshaft position sensor circuit fail (P0340, P0342, P0343) | Not detected |
| Minimum battery voltage while starter ON | Less than 11 V |
P0335: CRANKSHAFT POSITION SENSOR RANGE CHECK/RATIONALITY
| Engine speed | Less than 600 RPM |
| Starter | OFF |
| Time after starter from ON to OFF | 3 seconds or more |
P0335: CRANKSHAFT POSITION SENSOR VERIFY PULSE INPUT (CASE 1)
| Starter | ON |
| Minimum battery voltage while starter ON | Less than 11 V |
P0335: CRANKSHAFT POSITION SENSOR VERIFY PULSE INPUT (CASE 2)
| Number of crankshaft position sensor signal pulse | Less than 132, or 174 or more |
CRANKSHAFT POSITION SENSOR RANGE CHECK/RATIONALITY
| Crankshaft position sensor signal | No signal |
CRANKSHAFT POSITION SENSOR VERIFY PULSE INPUT
| Crankshaft position sensor | Crankshaft position sensor output voltage fluctuates while crankshaft is revolving 34 crankshaft position sensor signals per crankshaft revolution |
Scheme 687
Scheme 687: WIRING DIAGRAM
- Connect the Techstream to the DLC3.
- Turn the ignition switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch on (IG) and turn the Techstream on.
- Start the engine.
- Idle the engine for 20 seconds or more [A].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0335, P0337 or P0338.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] through [B] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422300-S24344107222011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0340: Camshaft position sensor (Bank 1) open/short P0340: Camshaft position sensor (Bank 1) range check (Chattering) P0342: Camshaft position sensor (Bank 1) range check (low voltage) P0343: Camshaft position sensor (Bank 1) range check (high voltage) P0345: VVT sensor (Bank 2) open/short P0345: VVT position sensor (Bank 2) range check (Chattering) P0347: VVT position sensor (Bank 2) range check (low voltage) P0348: VVT position sensor (Bank 2) range check (high voltage) |
| Required Sensors / Components (Main) | VVT position sensor (Bank 1 and 2) |
| Required Sensors / Components (Related) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 5 seconds: P0340 (Engine running), P0345 4 seconds: Others |
| MIL Operation | 2 driving cycles: P0340 (Camshaft position sensor range check) Immediate: Others |
| Sequence of Operation | None |
| The monitor will run whenever these DTCs are not present | None |
| Engine speed | 600 RPM or more |
| Starter | Off |
| VVT system misalignment | Not detected |
| VVT sensor range check fail (P0342, P0343) | Not detected |
| VVT sensor voltage | 0.3 V or more, and 4.7 V or less |
P0340: VVT SENSOR (BANK 1) VERIFY PULSE INPUT (CASE 1)
| Starter | ON |
| Minimal battery voltage while starter ON | Below 11 V |
P0340: VVT SENSOR (BANK 1) VERIFY PULSE INPUT (CASE 2)
| Starter | Off |
| Ignition switch | On (IG) |
| Time after ignition switch off to on (IG) | 2 seconds or more |
| VVT sensor verify pulse input fail (P0340) | Not detected |
| Battery voltage | 8 V or more |
P0342, P0343: VVT SENSOR (BANK 1) RANGE CHECK
| Engine speed | 600 RPM or more |
| Starter | Off |
| VVT sensor range check fail (P0342, P0343, P0347, P0348) | Not detected |
| VVT sensor voltage | 0.3 V or more, and 4.7 V or less |
| Battery voltage | 8 V or more |
| Ignition switch | On (IG) |
| Time after ignition switch off to on (IG) | 0.5 seconds or more |
P0345: VVT SENSOR (BANK 2) VERIFY PULSE INPUT
| Starter | Off |
| Ignition switch | On (IG) |
| Time after ignition switch off to on (IG) | 2 seconds or more |
| VVT sensor verify pulse input fail (P0340, P0345) | Not detected |
| Battery voltage | 8 V or more |
P0347, P0348: VVT SENSOR (BANK 1) RANGE CHECK
| Camshaft position and crankshaft position alignment | Misalignment |
| VVT sensor signal | No signal |
P0340: VVT SENSOR (BANK 1) VERIFY PULSE INPUT (CASE 1)
| VVT sensor signal | No signal |
P0340: VVT SENSOR (BANK 1) VERIFY PULSE INPUT (CASE 2)
| VVT sensor voltage | Less than 0.3 V |
P0342, P0347: VVT SENSOR (BANK1, 2) RANGE CHECK (LOW VOLTAGE)
| VVT sensor voltage | More than 4.7 V |
P0343, P0348: VVT SENSOR (BANK1, 2) RANGE CHECK (HIGH VOLTAGE)
| VVT sensor signal | No signal |
P0345: VVT SENSOR (BANK 2) VERIFY PULSE INPUT
| VVT sensor voltage | 0.3 to 4.7 V |
- Connect the Techstream to the DLC3.
- Turn the ignition switch on (IG) and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch on (IG) and turn the Techstream on.
- Start the engine.
- Idle the engine for 10 seconds or more [A].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0340, P0342, P0343, P0345, P0347 or P0348.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] through [B] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422300-S24344107222011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
