MONITOR STRATEGY
| Related DTCs | P0010 Camshaft Timing Oil Control Valve Range Check |
| Required Sensors/Components (Main) | Camshaft timing oil control valve assembly |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1 second |
| MIL Operation | Immediate |
| Sequence of Operation | None |
TYPICAL ENABLING CONDITIONS
| Monitor runs whenever following DTCs not present | None |
| All of the following conditions are met | |
| Starter | OFF |
| Ignition switch | ON |
| Time after ignition switch OFF to ON | 0.5 seconds or more |
| Either of the following conditions is met | A or B |
| A. All of the following conditions are met | (a), (b) and (c) |
| (a). Battery voltage | 11 to 13 V |
| (b). CPU commanded Duty | Less than 70% |
| (c). Current cut status | Not cut |
| B. All of the following conditions are met | (a), (b) and (c) |
| (a). Battery voltage | 13 V or more |
| (b). CPU commanded Duty | Less than 80% |
| (c). Current cut status | Not cut |
TYPICAL MALFUNCTION THRESHOLDS
| VVT oil control valve condition | Not operation record |
COMPONENT OPERATING RANGE
| VVT oil control valve condition | Operation record |
Scheme 299
Scheme 299: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure)
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 5 seconds [A].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0010.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 300
Scheme 300: WIRING DIAGRAM
| Related DTCs | P0011: Advanced Camshaft Timing P0012: Retarded Camshaft Timing |
| Required Sensors/Components (Main) | Camshaft timing oil control valve assembly and VVT controller |
| Required Sensors/Components (Related) | Crankshaft position sensor Camshaft position sensor Engine coolant temperature sensor |
| Frequency of Operation | Continuous |
| Duration | Within 10 seconds |
| MIL Operation | Advanced camshaft timing: Immediate Retarded camshaft timing: 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0010 (Camshaft Timing Oil Control Valve) P0016 (VVT System - Misalignment) P0102, P0103 (Mass Air Flow Meter) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) |
| Battery voltage | 11 V or higher |
| Engine speed | 400 to 4000 RPM |
| Engine coolant temperature | 75 to 100°C (167 to 212°F) |
| Both of following conditions are met | |
| Deviation of actual valve timing and target valve timing | More than 5°CA (Crankshaft Angle) for 5 seconds or more after the VVT hold duty ratio learned value reaches the upper or lower limit. |
| Valve timing | No change at advanced valve timing |
| Both of following conditions are met | |
| Deviation of actual valve timing and target valve timing | More than 5°CA (Crankshaft Angle) for 5 seconds or more after the VVT hold duty ratio learned value reaches the upper or lower limit. |
| Valve timing | No change at retarded valve timing |
MONITOR RESULT
Refer to Checking Monitor Status, refer to CHECKING MONITOR STATUS .
Scheme 301
Scheme 301: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Drive the vehicle at approximately 37 mph (60 km/h) for 10 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Idle the engine for 3 minutes or more [D].
- Enter the following menus: Powertrain / Engine / Trouble Codes [E].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0011, P0012.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [F] through [H].
- Repeat the pattern of accelerating the vehicle from rest to approximately 37 mph (60 km/h) and then decelerating the vehicle 10 to 15 times [F]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Depress the accelerator pedal by a large amount.
- Idle the engine for 3 minutes or more [G].
- Enter the following menus: Powertrain / Engine / Trouble Codes [H].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Check the DTC judgment result again. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform the following procedure.
- Perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0013: Exhaust Camshaft Timing Oil Control Valve Range Check |
| Required Sensors/Components (Main) | Exhaust camshaft timing oil control valve |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1 second |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| All of following conditions met | |
| Starter | OFF |
| Ignition switch | ON |
| Time after ignition switch off to ON | 0.5 seconds or more |
| One of following conditions met | Condition A, B or C |
| A. All of following conditions met | Condition (a), (b) and (c) |
| (a) Battery voltage | 11 to 13 V |
| (b) Target duty ratio | Less than 70% |
| (c) Output signal duty ratio | 100% or more |
| B. All of following conditions met | Condition (a), (b) and (c) |
| (a) Battery voltage | 13 V or more |
| (b) Target duty ratio | Less than 80% |
| (c) Output signal duty ratio | 100% or more |
| C. All of following conditions met | Condition (a) and (b) |
| (a) Current cut status | Not cut |
| (b) Output signal duty ratio | 3% or less |
| Camshaft timing oil control valve duty ratio | 3 to 100 % |
CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 5 seconds [A].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0013.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 302
Scheme 302: WIRING DIAGRAM
| Related DTCs | P0014: Advanced Camshaft Timing P0015: Retarded Camshaft Timing |
| Required Sensors/Components (Main) | Camshaft timing oil control valve and VVT controller |
| Required Sensors/Components (Related) | Crankshaft position sensor Camshaft position sensor Engine coolant temperature sensor |
| Frequency of Operation | Continuous |
| Duration | Within 10 seconds |
| MIL Operation | Advanced camshaft timing: 2 driving cycles Retarded camshaft timing: Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0013 (Exhaust Camshaft Timing Oil Control Valve) P0017 (Exhaust VVT System - Misalignment) P0102, P0103 (Mass Air Flow Meter) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) |
| Battery voltage | 11 V or higher |
| Engine speed | 500 to 4000 RPM |
| Engine coolant temperature | 75 to 100°C (167 to 212°F) |
| Both of following conditions are met | |
| Deviation of actual valve timing and target valve timing | More than 5°CA (Crankshaft Angle) for 5 seconds or more after the VVT hold duty ratio learned value reaches the upper or lower limit. |
| Valve timing | No change at advanced valve timing |
| Both of following conditions are met | |
| Deviation of actual valve timing and target valve timing | More than 5°CA (Crankshaft Angle) for 5 seconds or more after the VVT hold duty ratio learned value reaches the upper or lower limit. |
| Valve timing | No change at retarded valve timing |
Refer to Checking Monitor Status, refer to CHECKING MONITOR STATUS .
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Drive the vehicle at approximately 37 mph (60 km/h) for 10 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Idle the engine for 3 minutes or more [D].
- Enter the following menus: Powertrain / Engine / Trouble Codes [E].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0014, P0015.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [F] through [H].
- Repeat the pattern of accelerating the vehicle from rest to approximately 37 mph (60 km/h) and then decelerating the vehicle 10 to 15 times [F]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Depress the accelerator pedal by a large amount.
- Idle the engine for 3 minutes or more [G].
- Enter the following menus: Powertrain / Engine / Trouble Codes [H].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Check the DTC judgment result again. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform the following procedure.
- Perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
PROCEDURE
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0014 OR P0015) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0014 or P0015 is output A DTC P0014 or P0015 and other DTCs are output B HINT: If any DTCs other than P0014 or P0015 are output, troubleshoot those DTCs first. B --> See step 10 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Turn the A/C switch on. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Exhaust Linear (Bank 1). Check the engine speed while operating the camshaft timing oil control valve assembly (for exhaust camshaft) using the Techstream. Result Techstream Operation Specified Condition 0% Normal engine speed 100% Engine idles roughly or stalls NG --> See step 4 OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0014 OR P0015) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Start the engine. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. Result Result Proceed to DTC is not output A DTC P0014 or P0015 is output B HINT: DTC P0014 or P0015 may be stored when foreign objects in the engine oil are caught in some parts of the system. The DTC will remain stored even if the system returns to normal after a short time. These foreign objects may then be captured by the oil filter. B --> See step 4 A --> See step 9
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT) Remove the camshaft timing oil control valve assembly (for exhaust camshaft). Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 6.9 to 7.9 ohms Connect the positive (+) battery terminal to terminal 1 and connect the negative (-) battery terminal to terminal 2. Check the valve operation. OK Valve moves quickly. Reinstall the camshaft timing oil control valve assembly (for exhaust camshaft). NG --> See step 11 OK: Go to next step
- CHECK VALVE TIMING (CHECK FOR LOOSE TIMING CHAIN AND JUMPED TEETH) See step 5 NG --> See step 16 OK: Go to next step
- INSPECT CAMSHAFT TIMING GEAR ASSEMBLY (FOR EXHAUST CAMSHAFT) Inspect the camshaft timing gear assembly (for exhaust camshaft), refer to «INSPECTION - Step 7»(ref-422438-S32073342502011092600000) . NG --> See step 13 OK: Go to next step
- INSPECT OIL CONTROL VALVE FILTER Remove the oil control valve filter, refer to «DISASSEMBLY - Step 38»(ref-422438-S26750129822011092600000) . Check that the filter is not clogged. OK Filter is not clogged. Reinstall the oil control valve filter, refer to «REASSEMBLY - Step 19»(ref-422438-S14574295882011092600000) . NG --> See step 12 OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0014 OR P0015) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Start the engine. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. Result Result Proceed to DTC is not output A DTC P0014 or P0015 is output B HINT: DTC P0014 or P0015 may be stored when foreign objects in the engine oil are caught in some parts of the system. The DTC will remain stored even if the system returns to normal after a short time. These foreign objects may then be captured by the oil filter. B --> See step 14 A --> See step 15
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-422301-S08892066442011092600000)
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-422301-S13330058002011092600000)
- REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT). Refer to «REMOVAL»(ref-422454-S26671936412011092600000)
- REPLACE OIL CONTROL VALVE FILTER. Refer to «DISASSEMBLY»(ref-422438-S12954146562011092600000)
- REPLACE CAMSHAFT TIMING GEAR ASSEMBLY (FOR EXHAUST CAMSHAFT). Refer to «REMOVAL»(ref-422438-S35369468752011092600000)
- REPLACE ECM. Refer to «REMOVAL»(ref-422454-S15687586072011092600000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «REMOVAL»(ref-422454-S15687586072011092600000)
- ADJUST VALVE TIMING. Refer to «REASSEMBLY»(ref-422438-S39800685212011092600000)
| Related DTCs | P0016: Camshaft Timing Misalignment at Idling (for Intake Side) P0017: Camshaft Timing Misalignment at Idling (for Exhaust Side) |
| Required Sensors/Components (Main) | VVT controller (camshaft timing gear assembly) |
| Required Sensors/Components (Related) | Camshaft position sensor Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | Less than 1 minute |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0010 (Camshaft Timing Oil Control Valve) P0102, P0103 (Mass Air Flow Meter) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) |
| Engine speed | 500 to 1000 RPM |
| Monitor runs whenever following DTCs not stored | P0013 (Exhaust Camshaft Timing Oil Control Valve) P0102, P0103 (Mass Air Flow Meter) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) |
| Engine speed | 500 to 1000 RPM |
| One of following conditions is met | |
| VVT learned value at maximum retarded valve timing | Less than 22°CA (crankshaft angle) |
| VVT learned value at maximum retarded valve timing | More than 47°CA (crankshaft angle) |
| One of following conditions is met | |
| VVT learned value at maximum advanced valve timing | Less than 82.5°CA (crankshaft angle) |
| VVT learned value at maximum advanced valve timing | More than 107.5°CA (crankshaft angle) |
Scheme 303
Scheme 303: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Idle the engine for 5 minutes or more [C].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0016 or P0017.
- Check the DTC judgment result [D]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] through [G].
- Drive the vehicle for 2 to 3 minutes [E].
- Idle the engine for 5 minutes or more [F].
- Check the DTC judgment result [G].
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs [G]. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0031: Air Fuel Ratio Sensor Heater Open/Short (Low Electrical Current) P0032: Air Fuel Ratio Sensor Heater Open/Short (High Electrical Current) P101D: Air Fuel Ratio Sensor Heater Performance |
| Required Sensors/Components (Main) | Air fuel ratio sensor heater |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 10 seconds: P0031 10.24 seconds: P0032 1 second: P101D |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Battery voltage | 10.5 V or more |
| Time after heater ON | 5 seconds or more |
| Active heater OFF control | Not operating |
| Active heater ON control | Not operating |
| Heater output duty | 10% or more |
| Monitor runs whenever following DTCs not stored | None |
| Battery voltage | 10.5 V or more |
| Time after heater ON | 5 seconds or more |
| Heater output duty | More than 0% |
| Active heater OFF control | Not operating |
| Active heater ON control | Not operating |
| Monitor runs whenever following DTCs not stored | None |
| Battery voltage | 10.5 V or more |
| Time after heater ON | 5 seconds or more |
| Air fuel ratio sensor heater duty-cycle ratio | 10 to 60% |
| Air fuel ratio sensor heater ON current | 0.8 A or more |
| Active heater OFF control | Not detected |
| Active heater ON control | Not detected |
| Air fuel ratio sensor heater range check low current fail (P0031) | Not detected |
| Air fuel ratio sensor heater ON current | Less than 0.8 A |
| All of the following conditions are met | 1 and 2 |
| 1. Air fuel ratio sensor heater output | ON |
| 2. Hybrid IC high current limiter port | Fail |
| Air fuel ratio sensor heater OFF current | More than 11 A |
| Active heater OFF control flag for ON stuck | Operating |
| Hybrid IC high current limiter port | Fail |
| Air fuel ratio sensor heater ON current | 0.8 A or more |
| All of the following conditions are met | 1 and 2 |
| 1. Air fuel ratio sensor heater output | ON |
| 2. Hybrid IC high current limiter monitor input | Pass |
| Air fuel ratio sensor heater OFF current | 11 A or less |
Scheme 304
Scheme 304: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and idle it for 5 minutes or more [B].
- With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 3000 RPM for 1 minute [C].
- Idle the engine for 5 minutes or more [D].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0031, P0032 or P101D.
- Check the DTC judgment result [E]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit
- If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [E] again.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0037: Heated Oxygen Sensor Heater (Bank 1 Sensor 2) Open/Short (Low Electrical Current) P0038: Heated Oxygen Sensor Heater (Bank 1 Sensor 2) Open/Short (High Electrical Current) P0141: Heated Oxygen Sensor Heater Performance (Bank 1 Sensor 2) P102D: Heated Oxygen Sensor Heater ON Stuck (Bank 1 Sensor 2) |
| Required Sensors/Components (Main) | Heated oxygen sensor heater (bank 1 sensor 2) |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous: P0037, P0038, P102D Once per driving cycle: P0141 |
| Duration | 0.5 seconds: P0037 Within 3 seconds: P0038 10 seconds: P0141 0.5 seconds: P102D |
| MIL Operation | Immediate: P0037, P0038, P102D 2 driving cycles: P0141 |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Battery voltage | 10.5 V or higher |
| Engine | Running |
| Starter | OFF |
| Catalyst active air fuel ratio control | Not operating |
| Time after heater ON | 10 seconds or more |
| Learned heater OFF current operation completed flag | ON |
| Learned heater OFF current get flag | ON |
| Heated oxygen sensor heater high current fail (P0038) | Not detected |
| Monitor runs whenever following DTCs not stored | None |
| Battery voltage | 10.5 V or higher |
| Engine | Running |
| Starter | OFF |
| Catalyst active air fuel ratio control | Not operating |
| Time after heater ON | 10 seconds or more |
| Learned heater OFF current operation completed flag | ON |
| Heated oxygen sensor heater OFF current | Higher than 3.5 A |
| Hybrid IC high current limiter port | Fail |
| Heated oxygen sensor heater high current fail (P0038) | Not detected |
| Monitor runs whenever following DTCs not stored | None |
| Battery voltage | 10.5 V or higher |
| Engine | Running |
| Starter | OFF |
| Catalyst active air fuel ratio control | Not operating |
| Time after heater ON | 10 seconds or more |
| Learned heater OFF current operation completed flag | ON |
| Monitor runs whenever following DTCs not stored | None |
| Heated oxygen sensor heater circuit fail (P0031, P0032, P101D, P0037, P0038, P102D) | Not detected |
| Battery voltage | 10.5 V or higher |
| Fuel cut | OFF |
| Time after fuel cut ON to OFF | 30 seconds or more |
| Accumulated heater ON time | 100 seconds or more |
| Learned heater OFF current operation completed flag | ON |
| Duration that rear heated oxygen sensor impedance is less than 15 kohms | 2 seconds or more |
| Monitor runs whenever following DTCs not stored | None |
| Battery voltage | 10.5 V or higher |
| Engine | Running |
| Starter | OFF |
| Catalyst active air fuel ratio control | Not operating |
When the values for the Data List items O2 Heater Curr Val B1S2 are not 0 A, the heater is on.
| Heater ON current - Learned heater OFF current | 0.3 A or less |
| Heated oxygen sensor heater ON current | 1 A or less |
| Hybrid IC high current limiter port | Fail |
| Heated oxygen sensor heater output | ON |
| Accumulated heater resistance | Varies with sensor element temperature (Example: Higher than 23 ohms) |
| Heated oxygen sensor heater ON current | Higher than 1 A |
| Heated oxygen sensor heater current | 0.4 to 1 A (when engine idles, heated oxygen sensor warmed up and battery voltage 11 to 14 V) |
- Refer to Checking Monitor Status, refer to «CHECKING MONITOR STATUS»(ref-422301-S30249129982011092600000) .
Scheme 305
Scheme 305: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and idle it for 5 minutes or more [B].
- With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 3000 RPM for 1 minute [C].
- Idle the engine for 5 minutes or more [D].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0037, P0038, P0141 or P102D.
- Check the DTC judgment result [E]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit
- If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [E] again.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0101: Mass Air Flow Meter Rationality |
| Required Sensors/Components (Main) | Mass air flow meter |
| Required Sensors/Components (Related) | Crankshaft position sensor Camshaft position sensor Engine coolant temperature sensor Throttle position sensor |
| Frequency of Operation | Continuous |
| Duration | 10 times |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Throttle position (throttle position sensor voltage) | 0.24 to 2 V |
| Time after engine starts | 5 seconds or more |
| Battery voltage | 10.5 V or higher |
| Engine coolant temperature | 70°C (158°F) or higher |
| Estimated load | 30 to 70% |
| Mass air flow meter circuit fail (P0102, P0103) | Not detected |
| Intake air temperature circuit fail (P0112, P0113) | Not detected |
| Engine coolant temperature circuit fail (P0115, P0117, P0118) | Not detected |
| Crankshaft position sensor circuit fail (P0335) | Not detected |
| Throttle position sensor circuit fail (P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135) | Not detected |
| EVAP system pressure sensor circuit fail (P0452, P0453) | Not detected |
| Leak detection pump fail (P2401, P2402) | Not detected |
| EVAP vent valve fail (P2419, P2420) | Not detected |
| Both of following conditions 1 and 2 met | |
| 1. Average engine load value ratio | Less than 0.811 or more than 1.162 (varies with estimated engine load) |
| 2. Average air fuel ratio | Less than -20% or more than 20% |
Scheme 306
Scheme 306: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Start the engine and warm it up until the engine coolant temperature reaches 70°C (158°F) or higher [A].
- Drive the vehicle at approximately 50 mph (80 km/h) to 70 mph (112 km/h) for 5 minutes or more [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive while keeping the engine load as stable as possible.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0101.
- Check the DTC judgment result [C]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [C] again.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0101) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0101 is output A DTC P0101 and other DTCs are output B HINT: If any DTCs other than P0101 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- CHECK INTAKE SYSTEM Check the intake system for vacuum leakage, refer to «ON-VEHICLE INSPECTION»(ref-422457-S02988803912011092600000) . OK No leakage from intake system. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
- CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. OK PCV hose is connected correctly and is not damaged. NG --> REPAIR OR REPLACE PCV HOSE OK --> See step 5
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-422301-S13330058002011092600000)
- REPLACE MASS AIR FLOW METER. Refer to «REMOVAL»(ref-422454-S17733953542011092600000)
| Related DTCs | P0102: Mass Air Flow Meter Range Check (Low Voltage) P0103: Mass Air Flow Meter Range Check (High Voltage) |
| Required Sensors/Components (Main) | Mass air flow meter |
| Required Sensors/Components (Related) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 3 seconds |
| MIL Operation | Immediate: Engine speed less than 4000 RPM 2 driving cycles: Engine speed 4000 RPM or more |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Mass air flow meter voltage | Less than 0.2 V |
| Mass air flow meter voltage | More than 4.9 V |
| Mass air flow meter voltage | 0.2 V or more, and 4.9 V or less |
Scheme 307
Scheme 307: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- Idle the engine for 5 seconds [B].
- Enter the following menus: Powertrain / Engine / Trouble Codes / Pending [C].
- Read the Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Run the engine at an engine speed of 4000 RPM or more for 5 seconds [D].
- Enter the following menus: Powertrain / Engine / Trouble Codes / Pending [E].
- Read the Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0102 or P0103.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [D] again.
- If the no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 308
Scheme 308: WIRING DIAGRAM
| Related DTCs | P0111: Intake Air Temperature Sensor Rationality (After Engine Stop) P0111: Intake Air Temperature Sensor Rationality (After Cold Engine Start) |
| Required Sensors/Components (Main) | Intake air temperature sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 seconds or more |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Time after engine start | 10 seconds or more |
| Battery voltage | 10.5 V or higher |
| Engine coolant temperature at ECM started by soak timer | 40°C (-40°F) or higher |
| Engine coolant temperature before engine stop | 70°C (158°F) or higher |
| Time that mass air flow is low before engine stop | 2100 seconds |
| Accumulated mass air flow amount before engine stop | 2580 g or more |
| Key-off duration | 30 minutes |
| Mass air flow meter circuit fail (P0102, P0103) | Not detected |
| Engine coolant temperature sensor circuit (P0115, P0117, P0118) | Not detected |
| Intake air temperature circuit fail (P0112, P0113) | Not detected |
| Key-off duration | 5 hours or more |
| Time after engine start | 10 seconds or more |
| Engine coolant temperature | 70°C (158°F) or higher |
| Accumulated mass air flow amount | 2580 g or more |
| Either of the following conditions 1 or 2 is met | |
| 1. Duration while engine load is low | 120 seconds or more |
| 2. Duration while engine load is high | 10 seconds or more |
| Mass air flow meter circuit fail (P0102, P0103) | Not detected |
| Engine coolant temperature sensor circuit fail (P0115, P0117, P0118) | Not detected |
| Intake air temperature circuit fail (P0112, P0113) | Not detected |
| Intake air temperature change | Below 1°C (2°F) |
| Intake air temperature change | Below 1°C (2°F) |
Scheme 309
Scheme 309: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Idle the engine for 5 minutes or more [C]. HINT: During steps [A] through [C], if the change in the intake air temperature is below 1°C (2°F), the intake air temperature sensor (mass air flow meter) is malfunctioning. It is not necessary to continue this procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0111.
- Check the DTC judgment result [D]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] and [F].
- Drive the vehicle at 25 mph (40 km/h) or more for a total of 5 minutes or more [E].
- Check the DTC judgment result again [F]. HINT: If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] and [F] again.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0111) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0111 and other DTCs are output A DTC P0111 is output B HINT: If any DTCs other than P0111 are output, troubleshoot those DTCs first. B --> See step 3 A --> See step 2
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-422301-S13330058002011092600000)
- REPLACE MASS AIR FLOW METER. Refer to «REMOVAL»(ref-422454-S17733953542011092600000)
| Related DTCs | P0112: Intake Air Temperature Sensor Range Check (Low Voltage) P0113: Intake Air Temperature Sensor Range Check (High Voltage) |
| Required Sensors/Components (Main) | Intake air temperature sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Starter | OFF |
| Intake air temperature sensor voltage [Intake air temperature] | Less than 0.18 V [140°C (284°F) or higher] |
| Intake air temperature sensor voltage [Intake air temperature] | More than 4.91 V [Below -40°C (-40°F)] |
| Intake air temperature sensor voltage [Intake air temperature] | 0.18 to 4.91 V [-40 to 140°C (-40 to 284°F)] |
Scheme 310
Scheme 310: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 0.5 seconds or more [A].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0112 or P0113.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 311
Scheme 311: WIRING DIAGRAM
| Related DTCs | P0115: Engine Coolant Temperature Sensor Range Check (Fluctuating) P0117: Engine Coolant Temperature Sensor Range Check (Low Voltage) P0118: Engine Coolant Temperature Sensor Range Check (High Voltage) |
| Required Sensors/Components (Main) | Engine coolant temperature sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Engine coolant temperature sensor voltage | Less than 0.14 V, or higher than 4.91 V |
| Engine coolant temperature sensor voltage [Engine coolant temperature] | Less than 0.14 V [Higher than 140°C (284°F)] |
| Engine coolant temperature sensor voltage [Engine coolant temperature] | More than 4.91 V [Below -40°C (-40°F)] |
| Engine coolant temperature sensor voltage [Engine coolant temperature] | 0.14 to 4.91 V [-40 to 140°C (-40 to 284°F)] |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 0.5 seconds or more [A].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0115, P0117 or P0118.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 312
Scheme 312: WIRING DIAGRAM
| Related DTCs | P0116: Engine Coolant Temperature Sensor Cold Start Monitor P0116: Engine Coolant Temperature Sensor Soak Monitor |
| Required Sensors/Components (Main) | Engine coolant temperature sensor |
| Required Sensors/Components (Related) | None |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 seconds or more |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Battery voltage | 10.5 V or higher |
| Time after engine start | 1 second or more |
| Engine coolant temperature at engine start | Below 60°C (140°F) |
| Soak time | 0 seconds or more |
| Accumulated mass air flow | 931 g or more |
| Fuel cut | OFF |
| Intake air temperature sensor circuit fail (P0112, P0113) | Not detected |
| Engine coolant temperature circuit fail (P0115, P0117, P0118, P0125) | Not detected |
| Difference between engine coolant temperature at engine start and intake air temperature | Below 40°C (72°F) |
ENGINE COOLANT TEMPERATURE SENSOR COLD START MONITOR
| Battery voltage | 10.5 V or higher |
| Engine | Running |
| Soak time | 5 hours or more |
| Either condition (a) or (b) met | |
| (a) Engine coolant temperature | 60°C (140°F) or higher |
| (b) Accumulated mass air flow | 1993 g or more |
| Intake air temperature sensor circuit fail (P0112, P0113) | Not detected |
| Engine coolant temperature circuit fail (P0115, P0117, P0118, P0125) | Not detected |
ENGINE COOLANT TEMPERATURE SENSOR SOAK MONITOR
| Engine coolant temperature sensor value change | Below 5°C (9°F) |
ENGINE COOLANT TEMPERATURE SENSOR COLD START MONITOR
| Difference between current engine coolant temperature sensor value and previous engine coolant temperature sensor value when engine stopped | Below 5°C (9°F) |
ENGINE COOLANT TEMPERATURE SENSOR SOAK MONITOR
| Engine coolant temperature | Engine coolant temperature sensor value changes in accordance with actual engine coolant temperature |
Scheme 313
Scheme 313: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp.
- Check that the engine coolant temperature is 60°C (140°F) or less.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and idle it for 5 minutes or more [B]. HINT: If the engine coolant temperature does not change by 5°C (9°F) or higher, the engine coolant temperature sensor is malfunctioning. It is not necessary to continue this procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0116.
- Check the DTC judgment result [C]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [D] and [E].
- Drive the vehicle at 25 mph (40 km/h) or more for a total of 5 minutes or more [D]. HINT: In the event of the drive pattern being interrupted (possibly due to factors such as traffic conditions), the drive pattern can be resumed.
- Check the DTC judgment result again [E]. HINT: If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [D] and [E] again.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0116) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0116 is output A DTC P0116 and other DTCs are output B HINT: If any DTCs and other than P0116 are output, troubleshoot those DTCs first. B --> See step 3 A: Go to next step
- INSPECT THERMOSTAT Remove the thermostat, refer to «REMOVAL»(ref-422446-S32239753552011092600000) . Measure the valve opening temperature of the thermostat. Standard value 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat, refer to «INSTALLATION»(ref-422446-S12179336882011092600000) . NG --> See step 4 OK --> See step 5
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-422301-S13330058002011092600000)
- REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-422446-S32239753552011092600000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-422454-S38543213272011092600000)
| Related DTCs | P011B: Engine Coolant Temperature/Intake Air Temperature Sensor Correlation |
| Required Sensors/Components (Main) | Engine coolant temperature sensor Intake air temperature sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | 7 hours or more |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| The monitor will run whenever these DTCs are not stored | None |
| Both of following conditions met | Conditions 1 and 2 |
| 1. All of following conditions met | Conditions (a), (b), (c) and (d) |
| (a) Time after ignition switch ON and engine not running | Less than 20 seconds |
| (b) Soak Time | 7 hours or more |
| (c) Battery voltage | 10.5 V or higher |
| (d) Time after engine start | 15 seconds or more |
| 2. Either of the following conditions is met | Conditions (a) and (b) |
| (a) Minimum intake air temperature after engine start | 10°C (14°F) or higher |
| (b) Average engine coolant temperature before engine start | 10°C (14°F) or higher |
| Soak timer circuit fail (P2610) | Not detected |
| Engine coolant temperature circuit fail (P0115, P0117, P0118, P0125) | Not detected |
| Intake air temperature circuit fail (P0112, P0113) | Not detected |
| Deviated engine coolant temperature and intake air temperature | Below -20°C (-36°F) or higher than 20°C (36°F) |
Scheme 314
Scheme 314: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- With the engine stopped, leave the vehicle as is for 7.5 hours or more [B].
- Start the engine and wait 60 seconds or more [C].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P011B.
- Check the DTC judgment result [D]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] through [D] again.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO P011B) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P011B is output A DTC P011B and other DTCs are output B HINT: If any DTCs other than P011B are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- READ VALUE USING TECHSTREAM (INTAKE AIR TEMPERATURE) Leave the vehicle for 7 hours or more. HINT: It is necessary to leave the vehicle for 7 hours or more to create conditions similar to the DTC detection conditions. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Intake Air. Read the value displayed on the Techstream. OK Difference between the intake air temperature and the actual outside air temperature is within 10°C (18°F). HINT: Temperature readings on the outside temperature gauge of the vehicle (if equipped) are not suitable for comparing to the intake air temperature reading. The outside temperature gauge has a significant delay built in to prevent swings in the temperature display. Use an accurate thermometer to determine the outside air temperature. NG --> See step 5 OK: Go to next step
- READ VALUE USING TECHSTREAM (COOLANT TEMPERATURE) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp. Read the value displayed on the Techstream. OK The difference between the coolant temperature and the actual outside air temperature is within 10°C (18°F). HINT: If the result is not as specified, check that there are no heat sources such as a block heater in the engine compartment. NG --> See step 7 OK --> See step 6
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-422301-S13330058002011092600000)
- REPLACE MASS AIR FLOW METER. Refer to «REMOVAL»(ref-422454-S17733953542011092600000)
- REPLACE ECM. Refer to «REMOVAL»(ref-422454-S15687586072011092600000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-422454-S38543213272011092600000)
| Related DTCs | P0120: Throttle Position Sensor 1 Range Check (Fluctuating) P0121: Throttle Position Sensor Rationality P0122: Throttle Position Sensor 1 Range Check (Low Voltage) P0123: Throttle Position Sensor 1 Range Check (High Voltage) P0220: Throttle Position Sensor 2 Range Check (Fluctuating) P0222: Throttle Position Sensor 2 Range Check (Low Voltage) P0223: Throttle Position Sensor 2 Range Check (High Voltage) P2135: Throttle Position Sensor Range Check (Correlation) |
| Required Sensors/Components (Main) | Throttle position sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 2 seconds: P0120, P0122, P0123, P0220, P0222 and P0223 Within 2 seconds: P0121 0.5 seconds: P2135 Case 1 0.4 seconds: P2135 Case 2 |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Either of following conditions met | |
| A. Ignition switch ON | 0.012 seconds or more |
| B. Electronic throttle actuator power | ON |
P0120, P0122, P0123, P0220, P0222, P0223, P2135
| Monitor runs whenever following DTCs not stored | None |
| Either of following conditions A or B met | |
| A. Ignition switch | ON |
| B. Electric throttle motor power | ON |
| Throttle position sensor circuit fail (P0120, P0122, P0123, P0220, P0222, P0223, P2135) | Not detected |
| VTA1 voltage | 0.2 V or less, or 4.54 V or higher |
| Either of following conditions met | |
| Difference of throttle position sensor voltage between VTA1 and VTA2 x 0.8 | Higher than 1.6 V |
| Difference of throttle position sensor voltage between VTA1 and VTA2 x 0.8 | Below 0.8 V |
| VTA1 voltage | 0.2 V or less |
| VTA1 voltage | 4.54 V or higher |
| Either of following conditions met | |
| A. VTA2 voltage | 1.75 V or less |
| B. VTA2 voltage when VTA1 0.2 V or higher, and 2.02 V or less | 4.8 V or higher |
| VTA2 voltage | 1.75 V or less |
| VTA2 voltage when VTA1 0.2 V or higher, and 2.02 V or less | 4.8 V or higher |
| Difference between VTA1 and VTA2 voltages | 0.02 V or less |
| VTA1 voltage | 0.2 V or less |
| VTA2 voltage | 1.75 V or less |
| VTA1 voltage | More than 0.2 V, and less than 4.54 V |
| VTA2 voltage | More than 1.75 V, and less than 4.8 V |
Scheme 315
Scheme 315: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- With the vehicle stationary, fully depress and release the accelerator pedal [B].
- Idle the engine for 2 seconds or more [C].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0120, P0121, P0122, P0123, P0220, P0222, P0223 or P2135.
- Check the DTC judgment result [D]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [D] again.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
FAIL-SAFE
When any of these DTCs as well as other DTCs relating to Electronic Throttle Control System (ETCS) malfunctions are stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 6° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing, in accordance with the accelerator pedal angle, to allow the vehicle to continue at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.
Fail-safe mode continues until a pass condition is detected, and the ignition switch is then turned off.
Scheme 316
Scheme 316: WIRING DIAGRAM
| Related DTCs | P0125: Insufficient Engine Coolant Temperature for Closed Loop Fuel Control |
| Required Sensors/Components (Main) | Engine coolant temperature sensor Thermostat Cooling system |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | 54 seconds: Engine coolant temperature at engine start is 1.67°C (35°F) or more 101 seconds: Engine coolant temperature at engine start is -9.44 to 1.67°C (15 to 35°F) 1200 seconds: Engine coolant temperature at engine start is less than -9.44°C (15°F) |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Thermostat fail (P0128) | Not detected |
| Intake air temperature sensor circuit fail (P0112, P0113) | Not detected |
| Engine coolant temperature sensor circuit fail (P0115, P0117, P0118) | Not detected |
| Mass air flow meter sensor circuit fail (P0101, P0102, P103) | Not detected |
| Time until actual engine coolant temperature reaches closed loop fuel control enabling temperature | 54 seconds: Engine coolant temperature at engine start is 1.67°C (35°F) or more 101 seconds: Engine coolant temperature at engine start is -9.44 to 1.67°C (15 to 35°F) 1200 seconds: Engine coolant temperature at engine start is less than -9.44°C (15°F) |
Scheme 317
Scheme 317: CONFIRMATION DRIVING PATTERN
- Leave the vehicle outside overnight.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp.
- Check that the engine coolant temperature is 10°C (50°F) or less.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- After starting the engine, wait 21 minutes or more [B].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0125.
- Check the DTC judgment result [C]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0125) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0125 is output A DTC P0125 and other DTCs are output B HINT: If any DTCs other than P0125 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- INSPECT THERMOSTAT Remove the thermostat, refer to «REMOVAL»(ref-422446-S32239753552011092600000) . Check the valve opening temperature of the thermostat. Standard value 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat, refer to «INSTALLATION»(ref-422446-S12179336882011092600000) . NG --> See step 5 OK: Go to next step
- CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal cooling fan operation or any modifications. NG --> REPAIR OR REPLACE COOLING SYSTEM OK --> See step 6
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-422301-S13330058002011092600000)
- REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-422446-S32239753552011092600000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-422454-S38543213272011092600000)
| Related DTCs | P0128: Coolant Thermostat |
| Required Sensors/Components (Main) | Thermostat Engine coolant temperature sensor |
| Required Sensors/Components (Related) | Intake air temperature sensor Vehicle speed sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 900 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0010 (Camshaft Timing Oil Control Valve) P0011 (VVT System - Advance) P0012 (VVT System - Retard) P0016 (VVT System - Misalignment) P0013 (Exhaust Camshaft Timing Oil Control Valve) P0014 (Exhaust VVT System - Advance) P0015 (Exhaust VVT System - Retard) P0017 (Exhaust VVT System - Misalignment) P0031, P0032, P0101D (Air Fuel Ratio Sensor Heater) P2195, P2196, P2237, P2238, P2239, P2252, P2253, P2A00 (Air Fuel Ratio Sensor) P0102, P0103 (Mass Air Flow Sensor) P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0171, P0172 (Fuel System) P0301 - P0304 (Misfire) P0335 (Crankshaft Position Sensor) P0340, P0342, P0343 (Camshaft Position Sensor) P0365, P0367, P0368 (Exhaust Camshaft Position Sensor) P0351 - P0354 (Igniter) P0500 (Vehicle Speed Sensor) |
| Battery voltage | 11 V or higher |
| Either of following conditions 1 or 2 met | |
| 1. All of following conditions met | |
| Engine coolant temperature at engine start - Intake air temperature at engine start | 15 to 7°C (-27 to 12.6°F) |
| Engine coolant temperature at engine start | 10 to 56°C (14 to 133°F) |
| Intake air temperature at engine start | 10 to 56°C (14 to 133°F) |
| 2. All of following conditions met | |
| Engine coolant temperature at engine start - Intake air temperature at engine start | Higher than 7°C (12.6°F) |
| Engine coolant temperature at engine start | 56°C (133°F) or less |
| Intake air temperature at engine start | 10°C (14°F) or higher |
| Accumulated time at vehicle speed of 80 mph (128 km/h) or more | Less than 20 seconds |
| Duration that both of following conditions met | 5 seconds or more |
| (a) Estimated engine coolant temperature | 75°C (167°F) or higher |
| (b) Engine coolant temperature sensor output | Below 75°C (167°F) |
Scheme 318
Scheme 318: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp and Intake Air.
- Stop the engine and allow it to soak.
- Connect the Techstream to the DLC3.
- Turn the ignition switch ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp and Intake Air.
- Check if "Coolant Temp" is 56°C (133°F) or less and "Intake Air" is between 0 and 35°C (32 and 95°F). [A]
- Set the heater to MAX HOT with fresh air mode selected and turn the A/C off.
- Start the engine and drive the vehicle for 15 minutes at 50 mph (80 km/h). [B] HINT: Data can be captured relatively easily by using the snapshot function in the Data List. Enter the following menus: Data List / Function / Snap-shot configuration / Record time / 5 min. Data capture can be started by using the target point. For example, setting the target point to an engine speed of 4000 RPM and then racing the engine, etc. to raise the engine speed to a speed of 4000 RPM or more will cause data capture to start.
- After driving the vehicle at 50 mph (80 km/h) and "Coolant Temp" stabilizes, check that "Coolant Temp" is 75°C (167°F) or higher. [C] HINT: If "Coolant Temp" is below 75°C (167°F) while driving the vehicle at 50 mph (80 km/h), inspect the cooling system and thermostat.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0128) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0128 is output A DTC P0128 and other DTCs are output B HINT: If any DTCs other than P0128 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal cooling fan operation or any modifications. NG --> REPAIR OR REPLACE COOLING SYSTEM OK: Go to next step
- INSPECT THERMOSTAT Remove the thermostat, refer to «REMOVAL»(ref-422446-S32239753552011092600000) . Check the valve opening temperature of the thermostat. Standard value 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat, refer to «INSTALLATION»(ref-422446-S12179336882011092600000) . NG --> See step 5 OK --> See step 6
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-422301-S13330058002011092600000)
- REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-422446-S32239753552011092600000)
- REPLACE ECM. Refer to «REMOVAL»(ref-422454-S15687586072011092600000)
| Related DTCs | P0136: Heated Oxygen Sensor Output Voltage (Output Voltage) P0136: Heated Oxygen Sensor Impedance (Low) P0137: Heated Oxygen Sensor Output Voltage (Low Voltage) P0137: Heated Oxygen Sensor Impedance (High) P0138: Heated Oxygen Sensor Output Voltage (Extremely High) P0139: Heated Oxygen Sensor Output Voltage During Fuel Cut |
| Required Sensors/Components (Main) | Heated oxygen sensor (bank 1 sensor 2) |
| Required Sensors/Components (Related) | Crankshaft position sensor Engine coolant temperature sensor Mass air flow meter Throttle position sensor |
| Frequency of Operation | Once per driving cycle: Active air fuel ratio control detection, Heated oxygen sensor voltage during fuel-cut Continuous: Other |
| Duration | 20 seconds: Heated oxygen sensor output (Output voltage and Low voltage) 30 seconds: Heated oxygen sensor impedance (Low) 90 seconds: Heated oxygen sensor impedance (High) 10 seconds: Heated oxygen sensor voltage (Extremely high) 7 seconds: Heated oxygen sensor voltage during fuel cut |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0016 (VVT System - Misalignment) P0017 (Exhaust VVT System - Misalignment) P0031, P0032, P101D (Air Fuel Ratio Sensor Heater) P0037, P0038, P102D (Heated Oxygen Sensor Heater) P2195, P2196, P2237, P2238, P2239, P2252, P2253, P2A00 (Air Fuel Ratio Sensor) P0102, P0103 (Mass Air Flow Meter) P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0128 (Thermostat) P0171, P0172 (Fuel System) P0301 - P0304 (Misfire) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) P0451, P0452, P0453 (EVAP System) P0500 (Vehicle Speed Sensor) |
| Battery voltage | 11 V or higher |
| Intake air temperature | 10°C (14°F) or higher |
| Engine coolant temperature | 75°C (167°F) or higher |
| Atmospheric pressure | 76 kPa (570 mmHg) or higher |
| Idling | OFF |
| Engine speed | Less than 4000 RPM |
| Air fuel ratio sensor status | Activated |
| Fuel system status | Closed loop |
| Engine load | 10 to 80% |
| All of the following conditions (a), (b) and (c) met | |
| (a). Mass air flow rate | 2.5 to 60 gm/sec |
| (b). Front catalyst temperature (estimated) | 510 to 840°C (950 to 1544°F) |
| (c). Rear catalyst temperature (estimated) | 370 to 770°C (698 to 1418°F) |
| Shift position | 5th or higher |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (OUTPUT VOLTAGE AND LOW VOLTAGE)
| Battery voltage | 11 V or higher |
| Estimated rear heated oxygen sensor temperature | Below 700°C (1292°F) |
| ECM monitor | Completed |
| DTC P0607 | Not detected |
HEATED OXYGEN SENSOR IMPEDANCE (LOW)
| Battery voltage | 11 V or higher |
| Estimated rear heated oxygen sensor temperature | 450 to 750°C (842 to 1382°F) |
| DTC P0607 | Not detected |
HEATED OXYGEN SENSOR IMPEDANCE (HIGH)
| Battery voltage | 11 V or higher |
| Time after engine start | 2 seconds or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (EXTREMELY HIGH)
| Engine coolant temperature | 75°C (167°F) or higher |
| Estimated catalyst temperature | 400°C (752°F) or higher |
| Fuel cut | ON |
HEATED OXYGEN SENSOR VOLTAGE DURING FUEL CUT
| All of following conditions (a), (b) and (c) met | |
| (a) Commanded air fuel ratio | 14.4 or less |
| (b) Heated oxygen sensor voltage | 0.21 to 0.69 V |
| (c) OSC (Oxygen Storage Capacity of Catalyst) | 2.0 g or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (OUTPUT VOLTAGE)
| All of following conditions (a), (b) and (c) met | |
| (a) Commanded air fuel ratio | 14.4 or less |
| (b) Heated oxygen sensor voltage | Below 0.21 V |
| (c) OSC (Oxygen Storage Capacity of Catalyst) | 2.0 g or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (LOW OUTPUT VOLTAGE)
| Duration of following condition | 30 seconds or more |
| Heated oxygen sensor impedance | Below 5 ohms |
HEATED OXYGEN SENSOR IMPEDANCE (LOW)
| Duration of following condition | 90 seconds or more |
| Heated oxygen sensor impedance | 15 kohms or higher |
HEATED OXYGEN SENSOR IMPEDANCE (HIGH)
| Duration of following condition | 10 seconds or more |
| Heated oxygen sensor voltage | 1.2 V or higher |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (EXTREMELY HIGH)
| One of following conditions is met | |
| Duration until rear heated oxygen sensor voltage drops to 0.2 V during fuel cut | 7 seconds or more |
| Duration that rear heated oxygen sensor voltage drops from 0.35 V to 0.2 V during fuel cut | 1 second or more |
HEATED OXYGEN SENSOR VOLTAGE DURING FUEL-CUT
| Duration of following condition | 30 seconds or more |
| Heated oxygen sensor voltage | Varies between 0.1 V and 0.9 V |
Refer to Checking Monitor Status, refer to CHECKING MONITOR STATUS .
Scheme 319
Scheme 319: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- With the transmission in 4th gear or higher, drive the vehicle at 37 to 75 mph (60 to 120 km/h) for 10 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0136, P0137 or P0138.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [C] through [D].
- If no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 320
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Drive the vehicle at 37 mph (60 km/h), and then decelerate the vehicle by releasing the accelerator pedal for 5 seconds or more to perform the fuel-cut [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC or current DTC is output, the system is malfunctioning. If a pending DTC or current DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0139.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, shift the transmission to 2nd gear, and then perform steps [C] and [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 321
Scheme 321: WIRING DIAGRAM
| Related DTCs | P0171: Fuel trim lean P0172: Fuel trim rich |
| Required Sensors/Components (Main) | Fuel system |
| Required Sensors/Components (Related) | Air fuel ratio sensor Mass air flow meter Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | Within 10 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0010 (Camshaft Timing Oil Control Valve) P0011 (VVT System - Advance) P0012 (VVT System - Retard) P0016 (VVT System - Misalignment) P0013 (Exhaust Camshaft Timing Oil Control Valve) P0014 (Exhaust VVT System - Advance) P0015 (Exhaust VVT System - Retard) P0017 (Exhaust VVT System - Misalignment) P0031, P0032, P101D (Air Fuel Ratio Sensor Heater) P0102, P0103 (Mass Air Flow Meter) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0335 (Crankshaft Position Sensor) P0340, P0342, P0343 (Camshaft Position Sensor) P0365, P0367, P0368 (Exhaust Camshaft Position Sensor) P0351 - P0354 (Igniter) P0500 (Vehicle Speed Sensor) |
| Fuel system status | Closed loop |
| Battery voltage | 11 V or higher |
| Either of following conditions 1 or 2 met | |
| 1. Engine speed | Less than 800 RPM |
| 2. Engine load | 11.52% or more |
| Catalyst monitor | Not executed |
| Purge-cut | Executing |
| Either of following conditions 1 or 2 met | |
| 1. Average between short-term fuel trim and long-term fuel trim | 35% or more (varies with engine coolant temperature) |
| 2. Average between short-term fuel trim and long-term fuel trim | 35% or less (varies with engine coolant temperature) |
Scheme 322
Scheme 322: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or higher) with all the accessories switched off [B].
- With the engine warmed up, idle the engine for 2 minutes or more [C].
- Drive the vehicle at between 37 and 84 mph (60 and 135 km/h) for 5 minutes or more [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes [E].
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0171 OR P0172) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0171 or P0172 is output A DTC P0171 or P0172 and other DTCs are output B HINT: If any DTCs other than P0171 or P0172 are output, troubleshoot those DTCs first. B --> See step 23 A: Go to next step
- CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. OK PCV hose is connected correctly and is not damaged. NG --> REPAIR OR REPLACE PCV HOSE OK: Go to next step
- CHECK INTAKE SYSTEM Check the intake system for vacuum leaks, refer to «ON-VEHICLE INSPECTION»(ref-422457-S02988803912011092600000) . OK No leakage from intake system. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine at an engine speed of 2500 RPM for approximately 90 seconds. Enter the following menus: Powertrain / Engine / Active Test / Control the Injection Volume / All Data / AFS Voltage B1S1. Perform the Control the Injection Volume operation with the engine idling. Monitor the voltage outputs of the air fuel ratio sensor and the heated oxygen sensor (AFS Voltage B1 S1 and O2S B1 S2) displayed on the Techstream. HINT: Change the fuel injection volume within the range of -12.0% and +12.0%. The injection volume can be changed in fine gradations. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. Standard Techstream Display (Sensor) Injection Volume Status Voltage AFS Voltage B1 S1 (Air fuel ratio) +12% Rich Below 3.1 V -12% Lean Higher than 3.4 V O2S B1 S2 (Heated oxygen) +12% Rich Higher than 0.55 V -12% Lean Below 0.4 V Result Status AFS Voltage B1 S1 Status O2S B1 S2 Air Fuel Ratio Condition and Air Fuel Ratio Sensor Condition Misfire Suspected Trouble Area Proceed to Lean Lean Actual air fuel ratio lean May occur PCV valve and hose PCV hose connections Fuel injector blockage Gas leak from exhaust system Intake system Fuel pressure Mass air flow meter Engine coolant temperature sensor A Rich Rich Actual air fuel ratio rich - Fuel injector leak or blockage Gas leak from exhaust system Ignition system Fuel pressure Mass air flow meter Engine coolant temperature sensor Lean Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor B Rich Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor Lean: During Control the Injection Volume for A/F Sensor, the air fuel ratio sensor output voltage (AFS Voltage B1 S1) is consistently higher than 3.4 V, and the heated oxygen sensor output voltage (O2S B1 S2) is consistently below 0.4 V. Rich: During Control the Injection Volume for A/F Sensor, the AFS Voltage B1 S1 is consistently below 3.1 V, and the O2S B1 S2 is consistently higher than 0.55 V. Lean/Rich: During Control the Injection Volume for A/F Sensor of the Active Test, the output voltage of the heated oxygen sensor alternates correctly. HINT: Refer to "Data List / Active Test" [AFS Voltage B1S1, O2S B1S2], refer to «DATA LIST / ACTIVE TEST»(ref-422301-S24251007742011092600000) . B --> See step 11 A: Go to next step
- READ VALUE USING TECHSTREAM (COOLANT TEMP) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp. Read the Data List twice, when the engine is both cold and warmed up. Standard value With cold engine: Same as ambient air temperature. With warm engine: Between 75°C and 100°C (167 °F and 212 °F). NG --> See step 24 OK: Go to next step
- READ VALUE USING TECHSTREAM (MAF) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / MAF and Coolant Temp. Allow the engine to idle until Coolant Temp reaches 75°C (167°F) or higher. Read MAF with the engine speed at 3000 RPM. Standard Between 8.5 g/sec. and 12.5 g/sec. (shift lever: Neutral position, A/C: Off). NG --> See step 16 OK: Go to next step
- CHECK FUEL PRESSURE Check the fuel pressure, refer to «ON-VEHICLE INSPECTION - Step 2»(ref-422461-S27554927852011092600000) . NG --> REPAIR OR REPLACE FUEL SYSTEM OK: Go to next step
- CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. NG --> REPAIR OR REPLACE EXHAUST SYSTEM OK: Go to next step
- CHECK FOR SPARK AND IGNITION See step 8 NG --> REPAIR OR REPLACE IGNITION SYSTEM OK: Go to next step
- INSPECT FUEL INJECTOR ASSEMBLY (INJECTION AND VOLUME) Check the ignition and volume, refer to «INSPECTION»(ref-422456-S33717048052011092600000) . OK --> See step 15 NG --> See step 25
- INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE) See step 1 NG --> See step 26 OK: Go to next step
- CHECK TERMINAL VOLTAGE (POWER SOURCE OF AIR FUEL RATIO SENSOR) See step 2 NG --> See step 21 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) See step 3 NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (AIR FUEL RATIO SENSOR - ECM) OK: Go to next step
- REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor, refer to «REMOVAL»(ref-422454-S13686551372011092600000) . NEXT: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0171 or P0172 is output A DTC is not output B B --> END A: Go to next step
- CHECK HARNESS AND CONNECTOR Check the connection and terminal contact pressure of connectors and wire harness between the mass air flow meter and ECM, refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-422289-S37007492172011092600000) . HINT: Repair any problems. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0171 OR P0172) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0171 or P0172 is output A DTC is not output B B --> END A: Go to next step
- CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) Disconnect the mass air flow meter connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B10-5 (VG) - B50-11 (VG) Always Below 1 ohms B10-4 (E2G) - B50-5 (E2G) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B10-5 (VG) or B50-11 (VG) - Body ground Always 10 kohms or higher Reconnect the mass air flow meter connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (MASS AIR FLOW METER - ECM) OK: Go to next step
- REPLACE MASS AIR FLOW METER Replace the mass air flow meter, refer to «REMOVAL»(ref-422454-S17733953542011092600000) . HINT: If the result of the inspection performed in step 6 indicated no problem, proceed to the next step without replacing the mass air flow meter. NEXT: Go to next step
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P0171 or P0172 is output B B --> See step 27 A --> END
- CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - EFI MAIN NO. 2 RELAY) See step 6 NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- INSPECT ENGINE ROOM JUNCTION BLOCK ASSEMBLY (EFI MAIN NO. 2 RELAY) Inspect the engine room junction block assembly, refer to «INSPECTION - Step 1»(ref-422454-S38925277372011092600000) . NG --> See step 28 OK --> REPAIR OR REPLACE HARNESS OR CONNECTOR (BATTERY - EFI MAIN MO. 2 RELAY)
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-422301-S13330058002011092600000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-422454-S38543213272011092600000)
- REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL»(ref-422456-S31838584772011092600000)
- REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-422454-S13686551372011092600000)
- REPLACE ECM. Refer to «REMOVAL»(ref-422454-S15687586072011092600000)
- REPLACE ENGINE ROOM JUNCTION BLOCK ASSEMBLY. Refer to «REMOVAL»(ref-422454-S33968218332011092600000)
| Related DTCs | P0300: Multiple Cylinder Misfire P0301: Cylinder 1 Misfire P0302: Cylinder 2 Misfire P0303: Cylinder 3 Misfire P0304: Cylinder 4 Misfire |
| Required Sensors/Components (Main) | Crankshaft position sensor Camshaft position sensor |
| Required Sensors/Components (Related) | Engine coolant temperature Intake air temperature sensor Mass air flow meter |
| Frequency of Operation | Continuous |
| Duration | 1000 to 4000 crankshaft revolutions: Emission-related misfire 200 to 600 crankshaft revolutions: Catalyst-damaging misfire |
| MIL Operation | 2 driving cycles: Emission-related misfire MIL flashes immediately: Catalyst-damaging misfire |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0016 (VVT System - Misalignment) P0017 (Exhaust VVT System - Misalignment) P0102, P0103 (Mass Air Flow Meter) P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0327, P0328 (Knock Sensor) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) P0351 - P0354 (Igniter) P0500 (Vehicle Speed Sensor) P0705 (Shift Lever Position Switch) |
| Battery voltage | 8 V or higher |
| VVT system | Not operated by scan tool |
| Engine speed | 400 to 6100 RPM |
| Either of following conditions (a) or (b) met | |
| (a) Engine coolant temperature at engine start | Higher than -7°C (19°F) |
| (b) Engine coolant temperature | Higher than 20°C (68°F) |
| Fuel cut | OFF |
| First 1000 revolutions after engine start, or during check mode | Crankshaft 1000 revolutions |
| Except above | Crankshaft 1000 revolutions x 4 |
MONITOR PERIOD OF EMISSION-RELATED MISFIRE
| All of following conditions 1, 2 and 3 met | Crankshaft 200 revolutions |
| 1. Driving cycles | 1st |
| 2. Check mode | OFF |
| 3. Engine speed | Less than 2300 RPM |
| Except above (MIL blinks immediately) | Crankshaft 200 revolutions x 3 |
MONITOR PERIOD OF CATALYST-DAMAGING MISFIRE (MIL BLINKS)
| Misfire rate | 0.99% or more |
MONITOR PERIOD OF EMISSION-RELATED MISFIRE
| Number of misfires per 200 revolutions | 124 or more (varies with intake air amount and RPM) |
MONITOR PERIOD OF CATALYST-DAMAGING MISFIRE (MIL BLINKS)
Refer to Checking Monitor Status, refer to CHECKING MONITOR STATUS .
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Record the DTC(s) and freeze frame data.
- Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure).
- Using the Techstream, switch the ECM from normal mode to check mode, refer to «CHECK MODE PROCEDURE»(ref-422301-S14568931162011092600000) .
- Read the misfire counts of each cylinder, Cylinder #1 Misfire Count to Cylinder #4 Misfire Count, with the engine idling. If any misfire count is displayed, skip the following confirmation driving pattern.
- Drive the vehicle so that the vehicle conditions displayed in Misfire RPM and Misfire Load of the Data List are the same as the freeze frame data. Perform this step several times. HINT: In order to store misfire DTCs, it is necessary to operate the vehicle for the period of time shown in the table below, confirm the Misfire RPM and Misfire Load in the Data List. Engine speed Duration Idling 7.0 minutes or more 1000 4.0 minutes or more 2000 2.0 minutes or more 3000 1.5 minutes or more
- Check whether misfires have occurred by checking DTCs and freeze frame data. HINT: Do not turn the ignition switch off until the output DTC(s) and freeze frame data have been recorded. When the ECM returns to normal mode (default), the stored DTC(s), freeze frame data and other data are cleared.
- Record the DTC(s), freeze frame data and misfire counts.
- Turn the ignition switch off and wait for at least 15 seconds.
- Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure).
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO MISFIRE DTCS) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. HINT: Write down the output DTCs. Result Result Proceed to P0300, P0301, P0302, P0303 and/or P0304 A P0300, P0301, P0302, P0303 and/or P0304 and other DTCs B HINT: If any DTCs other than P0300, P0301, P0302, P0303 and P0304 are output, troubleshoot those DTCs first. B --> See step 39 A: Go to next step
- CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. OK PCV hose is correctly connected and is not damaged. NG --> REPAIR OR REPLACE PCV HOSE OK: Go to next step
- READ VALUE USING TECHSTREAM (MISFIRE RPM AND MISFIRE LOAD) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Misfire / Misfire RPM and Misfire Load. Read and note the Misfire RPM and Misfire Load values. HINT: The Misfire RPM and Misfire Load values indicate the vehicle conditions under which the misfire occurred. NEXT: Go to next step
- READ VALUE USING TECHSTREAM (CATALYST OT MF F/C) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Catalyst OT MF F/C. Read the value displayed on the Techstream. Result Data List Techstream Display Proceed to Catalyst OT MF F/C Avail A Not Avl B B --> See step 6 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Prohibit the Catalyst OT Misfire prevent F/C. Perform the Active Test. NOTE: When performing the Active Test, make sure the vehicle is stopped and the engine is either idling or being revved within 3000 RPM. NEXT: Go to next step
- READ VALUE USING TECHSTREAM (CYLINDER #1 (to #4) MISFIRE COUNT) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . Enter the following menus: Powertrain / Engine / Data List / All Data / Cylinder #1 (to #4) Misfire Count. Allow the engine to idle. Read each value for Cylinder #1 (to #4) Misfire Count displayed on the Techstream. If no misfire counts occur in any cylinders, perform the following procedures: Move the shift lever in D. Check Cylinder #1 (to #4) Misfire Count. If misfire counts are still not displayed, perform procedure "A" and "B", and then check the misfire counts again. Procedure A: Drive the vehicle while satisfying the Misfire RPM and Misfire Load values noted in the "Read Value Using Techstream (Misfire RPM and Misfire Load)" procedure above. Procedure B: Read the Cylinder #1 (to #4) Misfire Count or the DTCs output on the Techstream. Result Result (Misfire Count) Proceed to Most misfires occur in only 1 or 2 cylinders A 3 cylinders or more have equal misfire counts B HINT: If it is difficult to reproduce misfires for each cylinder, check the Data List item called Misfire Margin. Try to find vehicle driving conditions that lower the Misfire Margin value. Values above 30% are considered normal. If the freeze frame data record of the engine coolant temperature is below 75°C (167°F), the misfire may be detected only when the engine is cold. If the freeze frame data record of the Engine Run Time is below 120 seconds, the misfire may be detected immediately after the engine is started. B --> See step 19 A: Go to next step
- INSPECT SPARK PLUG Inspect the spark plug of the misfiring cylinder, refer to «ON-VEHICLE INSPECTION - Step 2»(ref-422440-S39986225172011092600000) . NG --> See step 40 OK: Go to next step
- CHECK FOR SPARK AND IGNITION Perform a spark test, refer to «INSTALLATION»(ref-422462-S07303336132011092600000) . WARNING: Always disconnect all the injector connectors. NOTE: Do not crank the engine for more than 2 seconds. OK Spark jumps across electrode gap. NG --> See step 36 OK: Go to next step
- CHECK CYLINDER COMPRESSION PRESSURE Measure the cylinder compression pressure of the misfiring cylinder, refer to «ON-VEHICLE INSPECTION - Step 9»(ref-422438-S22544883302011092600000) . NG --> CHECK ENGINE TO DETERMINE CAUSE OF LOW COMPRESSION OK: Go to next step
- CHECK FUEL INJECTOR ASSEMBLY (POWER SOURCE). Refer to «PROCEDURE - Step 1»(ref-422453-S40827507612011092600000) NG --> See step 41 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (FUEL INJECTOR - ECM). Refer to «PROCEDURE - Step 3»(ref-422453-S40827507612011092600000) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (FUEL INJECTOR - ECM) OK: Go to next step
- CHECK FUEL INJECTOR OF MISFIRING CYLINDER Check the injector injection (whether fuel volume is high or low, and whether injection pattern is poor), refer to «INSPECTION»(ref-422456-S33717048052011092600000) . NG --> See step 42 OK: Go to next step
- CHECK INTAKE SYSTEM Check the intake system for vacuum leaks, refer to «ON-VEHICLE INSPECTION»(ref-422457-S02988803912011092600000) . OK No leaks from intake system. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
- CHECK INTAKE AIR CONTROL VALVE (FOR TUMBLE CONTROL VALVE) Check the intake air control valve for tumble control valve, refer to «ON-VEHICLE INSPECTION - Step 3»(ref-422457-S33275328762011092600000) . NG --> See step 43 OK: Go to next step
- CHECK FUEL PRESSURE Check the fuel pressure, refer to «ON-VEHICLE INSPECTION - Step 2»(ref-422461-S27554927852011092600000) . NG --> See step 38 OK: Go to next step
- READ VALUE USING TECHSTREAM (COOLANT TEMP) See step 5 NG --> See step 44 OK: Go to next step
- READ VALUE USING TECHSTREAM (MAF) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / MAF and Coolant Temp. Allow the engine to idle until Coolant Temp reaches 75°C (167°F) or higher. Read MAF with the engine speed at 3000 RPM. Standard Between 8.5 g/sec. and 12.5 g/sec. (shift lever: Neutral position, A/C: Off). NG --> See step 31 OK: Go to next step
- CHECK VALVE TIMING See step 5 OK --> See step 31 NG --> See step 45
- CHECK INTAKE SYSTEM Check the intake system for vacuum leaks, refer to «ON-VEHICLE INSPECTION»(ref-422457-S02988803912011092600000) . OK No leaks from intake system. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
- CHECK INTAKE AIR CONTROL VALVE (FOR TUMBLE CONTROL VALVE) Check the intake air control valve for tumble control valve, refer to «ON-VEHICLE INSPECTION - Step 3»(ref-422457-S33275328762011092600000) . NG --> See step 43 OK: Go to next step
- CHECK FUEL PRESSURE Check the fuel pressure, refer to «ON-VEHICLE INSPECTION - Step 2»(ref-422461-S27554927852011092600000) . NG --> See step 38 OK: Go to next step
- READ VALUE USING TECHSTREAM (COOLANT TEMP) See step 5 NG --> See step 44 OK: Go to next step
- READ VALUE USING TECHSTREAM (MAF) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / MAF and Coolant Temp. Allow the engine to idle until Coolant Temp reaches 75°C (167°F) or higher. Read MAF with the engine speed at 3000 RPM. Standard Between 8.5 g/sec. and 12.5 g/sec. (shift lever: Neutral position, A/C: Off). NG --> See step 31 OK: Go to next step
- CHECK VALVE TIMING See step 5 NG --> See step 45 OK: Go to next step
- INSPECT SPARK PLUG Inspect the spark plug of the misfiring cylinder, refer to «ON-VEHICLE INSPECTION - Step 2»(ref-422440-S39986225172011092600000) . NG --> See step 40 OK: Go to next step
- CHECK FOR SPARK AND IGNITION Perform a spark test, refer to «INSTALLATION»(ref-422462-S07303336132011092600000) . WARNING: Always disconnect all the injector connectors. NOTE: Do not crank the engine for more than 2 seconds. OK Spark jumps across electrode gap. NG --> See step 36 OK: Go to next step
- CHECK CYLINDER COMPRESSION PRESSURE Measure the cylinder compression pressure of the misfiring cylinder, refer to «ON-VEHICLE INSPECTION - Step 9»(ref-422438-S22544883302011092600000) . NG --> CHECK ENGINE TO DETERMINE CAUSE OF LOW COMPRESSION OK: Go to next step
- CHECK FUEL INJECTOR ASSEMBLY (POWER SOURCE). Refer to «PROCEDURE - Step 1»(ref-422453-S40827507612011092600000) NG --> See step 41 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (FUEL INJECTOR - ECM). Refer to «PROCEDURE - Step 3»(ref-422453-S40827507612011092600000) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (FUEL INJECTOR - ECM) OK: Go to next step
- CHECK FUEL INJECTOR OF MISFIRING CYLINDER Check the injector injection (whether fuel volume is high or low, and whether injection pattern is poor), refer to «INSPECTION»(ref-422456-S33717048052011092600000) . NG --> See step 42 OK: Go to next step
- CHECK HARNESS AND CONNECTOR Check the connection and terminal contact pressure of connectors and wire harnesses between the mass air flow meter and ECM, refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-422289-S37007492172011092600000) . HINT: Repair any problems. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P0300, P0301, P0302, P0303 or P0304. Check the DTC judgment result. RESULT Result Proceed to ABNORMAL (DTC P0300, P0301, P0302, P0303 or P0304 is output) A NORMAL (DTC is not output) B B --> END A: Go to next step
- CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) Disconnect the mass air flow meter connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B10-5 (VG) - B50-11 (VG) Always Below 1 ohms B10-4 (E2G) - B50-5 (E2G) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B10-5 (VG) or B50-11 (VG) - Body ground Always 10 kohms or higher Reconnect the mass air flow meter connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (MASS AIR FLOW METER - ECM) OK: Go to next step
- REPLACE MASS AIR FLOW METER Replace the mass air flow meter, refer to «REMOVAL»(ref-422454-S17733953542011092600000) . HINT: If the results of the inspections performed in steps 17 and 23 indicated no problem, proceed to the next step without replacing the mass air flow meter. NEXT: Go to next step
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P0300, P0301, P0302, P0303 or P0304. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P0300, P0301, P0302, P0303 or P0304 is output) B B --> See step 46 A --> END
- CHANGE TO NORMAL SPARK PLUG AND CHECK SPARK OF MISFIRING CYLINDER Change the installed spark plug to a spark plug that functions normally. Perform a spark test. WARNING: Always disconnect all injector connectors. NOTE: Do not crank the engine for more than 2 seconds. Install the spark plug to the ignition coil and connect the ignition coil connector. Disconnect the injector connector. Ground the spark plug. Check if sparks occur while the engine is being cranked. OK Sparks jump across electrode gap. NG --> See step 37 OK --> See step 40
- CHANGE TO NORMAL IGNITION COIL AND CHECK SPARK OF MISFIRING CYLINDER Change the ignition coil to a ignition coil that functions normally. Perform a spark test. WARNING: Always disconnect all injector connectors. NOTE: Do not crank the engine for more than 2 seconds. Install the spark plug into the ignition coil and connect the ignition coil connector. Disconnect the injector connector. Ground the spark plug. Check if sparks occur while the engine is being cranked. OK Sparks jump across electrode gap. NG --> See step 46 OK --> See step 47
- CHECK FUEL LINE Check the fuel lines for leaks or blockage. NG --> REPAIR OR REPLACE FUEL LINE OK --> See step 48
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-422301-S13330058002011092600000)
- REPLACE SPARK PLUG. Refer to «REMOVAL»(ref-422462-S01956674162011092600000)
- GO TO FUEL INJECTOR CIRCUIT. Refer to «Fuel Injector Circuit»(ref-422453-S21382194122011092600000)
- REPLACE FUEL INJECTOR. Refer to «REMOVAL»(ref-422456-S31838584772011092600000)
- REPLACE INTAKE AIR CONTROL VALVE (FOR TUMBLE CONTROL VALVE). Refer to «REMOVAL»(ref-422463-S40838264112011092600000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-422454-S38543213272011092600000)
- ADJUST VALVE TIMING. Refer to «REASSEMBLY»(ref-422438-S39800685212011092600000)
- REPLACE ECM. Refer to «REMOVAL»(ref-422454-S15687586072011092600000)
- REPLACE IGNITION COIL. Refer to «REMOVAL»(ref-422462-S01956674162011092600000)
- REPLACE FUEL PUMP. Refer to «REMOVAL»(ref-422456-S28943871842011092600000)
| Related DTCs | P0327: Knock Sensor Range Check (Low Voltage) P0328: Knock Sensor Range Check (High Voltage) |
| Required Sensors/Components (Main) | Knock sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1 second |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Battery voltage | 10.5 V or higher |
| Time after engine start | 5 seconds or more |
| Knock sensor voltage | Below 0.5 V |
KNOCK SENSOR RANGE CHECK (LOW VOLTAGE) P0327
| Knock sensor voltage | Higher than 4.5 V |
KNOCK SENSOR RANGE CHECK (HIGH VOLTAGE) P0328
Scheme 323
Scheme 323: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and wait 5 seconds.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0327 or P0328.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows INCOMPLETE or UNKNOWN, idle the engine for 5 minutes and check the DTC judgment result again [C].
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 324
Scheme 324: WIRING DIAGRAM
| Related DTCs | P0335: Crankshaft Position Sensor Range Check or Rationality |
| Required Sensors/Components (Main) | Crankshaft position sensor |
| Required Sensors/Components (Related) | Camshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 15 seconds: Verify pulse input case 1 4.7 seconds: Verify pulse input case 2 Within 1 second: Range check/rationality |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Time after starter OFF to ON | 3 seconds or more |
| Number of camshaft position sensor signal pulses | 6 times |
| Battery voltage | 7 V or higher |
| Minimum battery voltage while starter ON | Below 11 V |
| Camshaft position sensor circuit (P0340, P0342, P0343) | Not detected |
P0335: CRANKSHAFT POSITION SENSOR RANGE CHECK/RATIONALITY
| Monitor runs whenever following DTCs not stored | None |
| Starter | OFF |
| Engine speed | 600 RPM or less |
| Time after starter from ON to OFF | 3 seconds or more |
P0355: CRANKSHAFT POSITION SENSOR VERIFY PULSE INPUT (CASE 1)
| Monitor runs whenever following DTCs not stored | None |
| Starter | ON |
| Minimum battery voltage while starter ON | Below 11 V |
P0355: CRANKSHAFT POSITION SENSOR VERIFY PULSE INPUT (CASE 2)
| Number of crankshaft position sensor signal pulses | 132 times or less, and 174 times or more |
P0335: CRANKSHAFT POSITION SENSOR RANGE CHECK/RATIONALITY
| Engine speed signal | No signal |
P0355: CRANKSHAFT POSITION SENSOR VERIFY PULSE INPUT
| Crankshaft position sensor | Crankshaft position sensor output voltage fluctuates while crankshaft revolving 34 crankshaft position sensor signals per crankshaft revolution |
Scheme 325
Scheme 325: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- Idle the engine for 20 seconds or more [B].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0335 or P0339.
- Check the DTC judgment result [C]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [C] again.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 326
Scheme 326: WIRING DIAGRAM
| Related DTCs | P0340: Camshaft Position Sensor Range Check/Rationality P0340: Camshaft Position Verify Pulse Input P0342: Camshaft Position Sensor Range Check (Low Voltage) P0343: Camshaft Position Sensor Range Check (High Voltage) |
| Required Sensors/Components (Main) | Camshaft position sensor |
| Required Sensors/Components (Related) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 4 seconds: Camshaft position sensor verify pulse input case 1 (P0340), Camshaft position sensor range check (P0342, P0343) 5 seconds: Camshaft position verify pulse input case 2 (P0340) |
| MIL Operation | 2 driving cycles: Camshaft position sensor verify pulse input case 1 (P0340) Immediate: Camshaft position verify pulse input case 2 (P0340), Camshaft position sensor range check (P0342, P0343) |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Starter | ON and not starter ON again |
| Minimum battery voltage while starter ON | Below 11 V |
P0340: CAMSHAFT POSITION SENSOR VERIFY PULSE INPUT CASE 1
| Monitor runs whenever following DTCs not stored | None |
| Engine speed | 600 RPM or more |
| Starter | OFF |
| Camshaft position sensor voltage | 0.3 to 4.7 V |
| VVT system misalignment | Not detected |
| Camshaft position sensor range check fail (P0342, P0343) | Not detected |
P0340: CAMSHAFT POSITION SENSOR VERIFY PULSE INPUT CASE 2
| Monitor runs whenever following DTCs not stored | None |
| Starter | OFF |
| Ignition switch | ON |
| Time after ignition switch turned from off to ON | 2 seconds |
| Battery voltage | 8 V or higher |
| Camshaft position sensor verify pulse input fail (P0340) | Not detected |
P0342, P0343: CAMSHAFT POSITION SENSOR RANGE CHECK
| Camshaft position sensor signal | No signal |
P0340: CAMSHAFT POSITION SENSOR VERIFY PULSE INPUT CASE 1
| All of the following conditions are met | |
| Camshaft position and crankshaft position phase | Misaligned |
| Camshaft position sensor signal | No signal |
P0340: CAMSHAFT POSITION SENSOR VERIFY PULSE INPUT CASE 2
| Camshaft position sensor voltage | Below 0.3 V |
P0342: CAMSHAFT POSITION SENSOR RANGE CHECK
| Camshaft position sensor voltage | Higher than 4.7 V |
P0343: CAMSHAFT POSITION SENSOR RANGE CHECK
| Camshaft position sensor voltage | 0.3 to 4.7 V |
Scheme 327
Scheme 327: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- Idle the engine for 10 seconds or more [B].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0340, P0342 or P0343.
- Check the DTC judgment result [C]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [C] again.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0351: Igniter (Cylinder 1) Malfunction P0352: Igniter (Cylinder 2) Malfunction P0353: Igniter (Cylinder 3) Malfunction P0354: Igniter (Cylinder 4) Malfunction |
| Required Sensors/Components (Main) | Igniter |
| Required Sensors/Components (Related) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 0.256 seconds for 2 times |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| All of the following conditions are met | Condition A, B, C and D |
| A. Spark cut | Not operating |
| B. Either of following conditions met | |
| (a) Engine speed | 1500 RPM or less |
| (b) Starter | OFF |
| C. Either of following conditions met | |
| Both of following conditions met | |
| (a) Engine speed | 500 RPM or less |
| (b) Battery voltage | 6 V or higher |
| D. All of following conditions met | |
| (a) Engine speed | More than 500 RPM |
| (b) Battery voltage | 10 V or higher |
| (c) Number of sparks after CPU reset | 5 sparks or more |
| All of the following conditions are met | Condition A, B and C |
| A. Ignition signal fail counter | More than 2 times |
| B. Time after condition A is met | 0.256 seconds or more |
| C. Ignition signal fail counter after B conditions is met | More than 2 times |
| Confirmed ignition signal input when ignition signal is on to off | 2 times |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- Idle the engine for 10 seconds or more [B].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0351, P0352, P0353 or P0354.
- Check the DTC judgment result [C]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [C] again.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 328
Scheme 328: WIRING DIAGRAM
- CHECK HARNESS AND CONNECTOR (IG2 RELAY - IGNITION COIL, IGNITION COIL - BODY GROUND) Disconnect the ignition coil connectors. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B30-4 (GND) - Body ground Always Below 1 ohms B59-4 (GND) - Body ground Always Below 1 ohms B32-4 (GND) - Body ground Always Below 1 ohms B60-4 (GND) - Body ground Always Below 1 ohms Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition B30-1 (+B) - B30-4 (GND) Ignition switch ON 11 to 14 V B59-1 (+B) - B59-4 (GND) Ignition switch ON 11 to 14 V B32-1 (+B) - B32-4 (GND) Ignition switch ON 11 to 14 V B60-1 (+B) - B60-4 (GND) Ignition switch ON 11 to 14 V Reconnect the ignition coil connectors. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (IG2 RELAY - IGNITION COIL, IGNITION COIL - BODY GROUND) OK: Go to next step
- CHECK HARNESS AND CONNECTOR (IGNITION COIL - ECM) Disconnect the ignition coil connectors. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B30-2 (IGF) - B48-16 (IGF1) Always Below 1 ohms B59-2 (IGF) - B48-16 (IGF1) Always Below 1 ohms B32-2 (IGF) - B48-16 (IGF1) Always Below 1 ohms B60-2 (IGF) - B48-16 (IGF1) Always Below 1 ohms Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B30-3 (IGT1) - B48-2 (IGT1) Always Below 1 ohms B59-3 (IGT2) - B48-3 (IGT2) Always Below 1 ohms B32-3 (IGT3) - B48-4 (IGT3) Always Below 1 ohms B60-3 (IGT4) - B48-5 (IGT4) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B30-2 (IGF) or B48-16 (IGF1) - Body ground Always 10 kohms or higher B59-2 (IGF) or B48-16 (IGF1) - Body ground Always 10 kohms or higher B32-2 (IGF) or B48-16 (IGF1) - Body ground Always 10 kohms or higher B60-2 (IGF) or B48-16 (IGF1) - Body ground Always 10 kohms or higher Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B30-3 (IGT1) or B48-2 (IGT1) - Body ground Always 10 kohms or higher B59-3 (IGT2) or B48-3 (IGT2) - Body ground Always 10 kohms or higher B32-3 (IGT3) or B48-4 (IGT3) - Body ground Always 10 kohms or higher B60-3 (IGT4) or B48-5 (IGT4) - Body ground Always 10 kohms or higher Reconnect the ECM connector. Reconnect the ignition coil connectors. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0351, P0352, P0353 OR P0354) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . Shuffle the arrangement of the ignition coils with igniters (among No. 1 to No. 4 cylinders). NOTE: Do not shuffle the connectors. Perform a simulation test. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to Same DTC output A Different ignition coil DTC output B B --> See step 4 A --> See step 5
- REPLACE IGNITION COIL. Refer to «REMOVAL»(ref-422462-S01956674162011092600000)
- REPLACE ECM. Refer to «REMOVAL»(ref-422454-S15687586072011092600000)
| Related DTCs | P0365: Exhaust Camshaft Position Sensor Verify Pulse Input P0367: Exhaust Camshaft Position Sensor Range Check (Low Voltage) P0368: Exhaust Camshaft Position Sensor Range Check (High Voltage) |
| Required Sensors/Components (Main) | Exhaust camshaft position sensor |
| Required Sensors/Components (Related) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 5 seconds: Exhaust camshaft position sensor verify pulse input (P0365) 4 seconds: Exhaust camshaft position sensor range check (P0367, P0368) |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Engine speed | 600 RPM or more |
| Exhaust camshaft position sensor range check fail (P0367, P0368) | Not detected |
| Ignition switch | ON |
| Starter | OFF |
| Battery voltage | 8 V or higher |
| Exhaust camshaft position sensor voltage | 0.3 to 4.7 V |
P0365: EXHAUST CAMSHAFT POSITION SENSOR VERIFY PULSE INPUT
| Monitor runs whenever following DTCs not stored | None |
| Starter | OFF |
| Ignition switch | ON |
| Time after ignition switch turned from off to ON | 2 seconds or more |
| Exhaust camshaft position sensor verify pulse input fail (P0365) | Not detected |
| Battery voltage | 8 V or higher |
P0367, P0368: EXHAUST CAMSHAFT POSITION SENSOR RANGE CHECK
| Exhaust camshaft position signal | No signal |
P0365: EXHAUST CAMSHAFT POSITION SENSOR RANGE CHECK (RUNNING)
| Exhaust camshaft position sensor voltage | Below 0.3 V |
P0367: EXHAUST CAMSHAFT POSITION SENSOR RANGE CHECK (LOW VOLTAGE)
| Exhaust camshaft position sensor voltage | Higher than 4.7 V |
P0368: EXHAUST CAMSHAFT POSITION SENSOR RANGE CHECK (HIGH VOLTAGE)
| Exhaust camshaft position sensor voltage | 0.3 to 4.7 V |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- Idle the engine for 10 seconds or more [B].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0365, P0367 or P0368.
- Check the DTC judgment result [C]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [C] again.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs, refer to «DTC CHECK / CLEAR»(ref-422301-S01463917032011092600000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
