Block Diagram
CAN abbreviations
| 30 | Battery positive (terminal 30) | W446 | Antenna amplifier |
|---|---|---|---|
| 31 | Ground (terminal 31) |
Function Table
Wiring harness plug X1 = 18-pin
Wiring harness plug X2 = GPS antenna
| Terminal | Description | Source | Destination |
|---|---|---|---|
| X1-10 | Ground (terminal 31) | Ground | GPS |
| X1-12 | Battery positive (terminal 30) | IPBEC | GPS |
| X1-15 | Diagnosis information | DIAG GPS | GPS DIAG |
| X1-17 X1-18 MSCAN | General CRP status | CRP | GPS |
| X1-17 X1-18 MSCAN | Engine and vehicle speed signal | DIS | GPS |
| X1-17 X1-18 MSCAN | General GPS status | GPS | CRP DIS |
| X1-17 X1-18 MSCAN | Display of GPS information | GPS | DIS |
| X2-S1 | GPS antenna | W446 | GPS |
Functional Description
The GPS control unit calculates the current position of the vehicle.
It is installed as optional equipment in conjunction with the audio systems CART2007/CCRT2008 and makes the Onstar service available to the carphone units.
The positioning data of the vehicle are made available to the call centre via an SMS message.
