Special Service Tools
| KM-135 | Adapter |
|---|
| Measure engine oil pressure in conjunction with KM-498-B |
| KM-194-E | Spark plug key |
| Removing and installing spark plugs with WAF 16 |
| KM-263-B | Engine bridge |
| Holding the engine |
| KM-328-B | Remover |
| Removing the crankshaft needle bearing |
| KM-340-G | Valve seat milling set |
| Milling, correcting valve seat |
| KM-348 | Compressing valve springs, cylinder head dismantled |
Special Service Tools (Continued)
| KM-412 | Engine assembly stand |
|---|
| Holding dismantled engine |
| KM-412-3 | Adapter |
| Holding engine in conjunction with KM-412 |
| KM-417 | Assembly sleeves |
| Inserting crankshaft sealing ring into oil pump housing |
| KM-422 | Installer |
| Inserting sealing ring into camshaft |
| KM-427 | Remover and installer |
| Hammering the centring punches into the cylinder block |
| KM-460-B | Remover |
| Pushing the drive shafts out of the transmission |
Special Service Tools (Continued)
| KM-468-B | Holding wrench |
|---|
| Supporting the wheel hub |
| KM-470-B | Angled tightening wrench |
| Tightening the cylinder head bolts |
| KM-471 | Adapter |
| Testing the cooling system under pressure in conjunction with cooling system tester |
| KM-498-B | Oil pressure gauge |
| Checking engine oil pressure in conjunction with KM-135 |
| KM-517-B | Flywheel holder |
| Locking the flywheel |
| MKM-596-A | Measuring instrument |
| Measuring the oil temperature |
Special Service Tools (Continued)
| MKM-604-D | Torx bit and socket set |
|---|
| Removing and installing Torx bolts |
| KM-609 | Electronics Kit |
| Diagnosis of electrical and electronic systems |
| MKM-610 | Torque wrench 1/2" drive |
| Range 30 to 130 Nm |
| MKM-611 | Torque wrench 3/8" drive |
| Range 10 to 60 Nm |
| KM-634 | Remover and installer |
| Removing and installing piston bolts |
| KM-640 | Diagnostic switch |
| Triggering release of flashing code |
Special Service Tools (Continued)
| KM-652 | Flywheel holder |
|---|
| Locking flywheel or drive disc |
| KM-653-A | Adapter |
| Tensioning valve spring in conjunction with KM-348 |
| KM-658 | Installer |
| Installation of the rear crankshaft sealing ring |
| MKM-667 | Pressure and vacuum pump |
| Checking the vacuum unit for leaks |
| MKM-669 | Torque wrench 1/2" drive |
| Range 50 to 300 Nm |
| KM-726-A | Oil filter wrench |
| Removing and installing the oil filter |
Special Service Tools (Continued)
| KM-728-A | Remover, installer |
|---|
| Removing and installing the knock sensor |
| KM-734 | Guide pin |
| Centring the clutch disc |
| KM-805 | Reamer 6 mm |
| Roughening the valve guide, oversize 0.075 mm |
| KM-835-A | Installer |
| Installing the valve stem seal |
| MKM-836 | Remover |
| Removing spark plug boot |
| KM-840 | Remover |
| Removing the valve stem seal |
Special Service Tools (Continued)
| KM-845 | Suction tool |
|---|
| Removing and installing the hydraulic valve lifters |
| KM-852 | Locking tool |
| Locking the camshaft pulleys |
| MKM-874 | Precision multi-meter |
| Checking electrical/electronic components |
| MKM-883-1 | Engine bridge |
| Holding the engine (alternative to KM-263-B) |
| MKM-889 | Automatic valve spring lifter |
| Removing and installing the valve springs |
| KM-902 | Remover |
| Removing the axle shafts |
Special Service Tools (Continued)
| KM-904 | Base frame |
|---|
| Removing and installing various vehicle components with additional adapters |
| KM-911 | Flywheel holder |
| Locking flywheel or drive disc |
| KM-956-1 | Clamp with handle |
| Holding the camshaft pulleys to release/tighten the fastening bolts in conjunction with KM-6347 |
| KM-2358 | Engine-lifting straps |
| Removing and installing the engine |
| KM-6054 | Holding the engine |
| Removing and installing the engine |
| KM-6347 | Bracket |
| Holding the camshaft pulleys to release/tighten the fastening bolts in conjunction with KM-956-1 |
Special Service Tools (Continued)
| KM-J-26792 | Test spark plug |
|---|
| Testing ignition sparks |
| KM-J-34730-91 | Pressure testing unit |
| Checking the fuel pressure |
| KM-J-37228 | Separating tool |
| For removing the sheet metal oil pan |
