Manifold Absolute Pressure (MAP) Sensor Replace Opel Antara I



Manifold Absolute Pressure (MAP) Sensor Replace

Remove

1. Disconnect the negative battery cable.
2. Disconnect the intake air temperature (IAT) sensor connector.
3. Loosen the clamp and disconnect the air cleaner outlet hose from the resonator.

4. Loosen the clamp and remove the resonator from the electronic throttle body.

5. Remove the fuel rail. Refer to Fuel Rail and Injectors Replace .
6. Disconnect the manifold absolute pressure (MAP) sensor connector.

7. Remove the MAP sensor retaining bolt.
8. Remove the MAP sensor from the intake manifold.

Install

1. Install the MAP sensor to the intake manifold.
2. Install the MAP sensor retaining bolt.

Tighten

Tighten the manifold absolute pressure sensor retaining bolt to 4 N•m (35 lb-in).

3. Install the fuel rail. Refer to Fuel Rail and Injectors Replace .
4. Connect the MAP sensor connector.
5. Install the resonator to the electronic throttle body.
6. Connect the air cleaner outlet hose to the resonator.
7. Connect the IAT sensor connector.
8. Connect the negative battery cable.
