Common Rail Pressure Sensor Replace Opel Antara I

Common Rail Pressure Sensor Replace

Important: Do not allow smoking or the use of open flames in the area where work on the fuel system is taking place. Anytime work is being done on the fuel system, disconnect the negative battery cable, except for those tests where battery voltage is required.

Remove

1. Remove the common rail assembly. Refer to Fuel Common Rail Replace .
2. Clean interface area of the rail pressure sensor using proper degreases materials and compressed air for drying.

Note: Cleaning material must not penetrate the electric connector.

3. Remove the rail pressure sensor with the gasket if equipped.

Note: Put a cap on the injection pump pipe connector to avoid contamination from dust as soon as the fuel pipes are removed. A little dust may clog the injectors.

Install

Important: Do not blow air using an air gun onto pipe connectors of the injectors, the injection pump and the common rail pipe threads. If contaminated, wipe clean with an oilpaper.

Important: Do not wipe clean with a towel onto the pipes connectors of the injectors, the injection pump and the common rail pipe threads. If contaminated, wipe clean with an oilpaper.

1. Inspect and clean the thread and the sealing surface of the rail.
2. Inspect and clean thread of the rail pressure sensor.
3. Lubricate thread (a) and bite edge (b) of the rail pressure sensor using a suitable lubricant (Only apply a thin lubrication film).

4. Install the rail pressure sensor to the common rail.

Tighten

Tighten the rail pressure sensor to 70 N•m (51.6 lb-ft).

5. Do the fuel priming. Refer to Fuel Priming .
6. If replaced reset the Zero Fuel Connection (ZFC) EEPRM values by using scan tool.
