Fuel Return Line Assembly Replace Opel Antara I



Fuel Return Line Assembly Replace

Warning: Do not allow smoking or the use of open flames in the area where work on the fuel system is taking place. Whenever work is being done on the fuel system, disconnect the negative battery cable, except for those tests where battery voltage is required.

Remove

1. Remove the injector return hose.

Important: Do not pull the clip out but push it and simultaneously disconnect the injector return hoses. If removed from the injector, it is impossible to reuse the clip.

2. Disconnect the injection pump return hose.
3. Disconnect the common rail return hose.
4. Remove the junction block retaining bolts.
5. Remove the fuel return line assembly.

Install

1. Install the fuel return line assembly.
2. Connect the common rail return hose. Note: Press injector return line by hand from above and vertically down to the injector until you hear the connection piece snaps in place.
3. Connect the injection pump return hose.

4. Install the junction block.

Tighten

Tighten the junction block retaining bolts to 11 N•m (97.4 lb-in).
