Field Remedy: 2514
| Subject: | Engine - Impossible to start |
| Models: | Engines: | Option: |
|---|---|---|
| Antara 2007...2008 | Z20DM| Z20DMH |
| Complaint: | Customers may comment that the engine cannot be started. |
|---|---|
| Cause: | Blown fuse due to engine wiring harness short. It was found that the engine wiring harness was shorted to the bracket. |
| Production: | From Model Year 2009 on, the engine wiring harness routing was changed and a retaining clip was added to prevent the harness from shaving on the bracket. |
Remedy:
In case of customer complaint, repair the damaged wires and fix the harness with a proper retaining clip according to the following instruction.
NOTE: Not all starting issues are related to this engine wiring harness short.
Working Procedure:
1. Open hood 2. Remove beauty cover 3. Check engine wiring harness for short circuit to bracket (1)
4. Repair damaged wires
- Refer to brochure wiring harness repair
5. Insulate repaired wires and harness
6. Fix engine wiring harness to bracket
- Use appropriate retaining clip (2)
7. Install beauty cover
8. Replace blown fuse
9. Close hood
| FunctionalGroup: | J - Engine,N - Electrical Equipment |
|---|---|
| Complaint Group: | 02 - Chafing,04 - Electrical failures,13 - No/Poor Function,21 - Poor Startability |
| Trouble Code: |
