The D13A engine is a new DOHC diesel engine introduced for the Agila-B. The D13A engine is similar to the Z13DTJ engine.
The main features of the D13A engine are as follows:
- DOHC 16 valve technology
- Hydraulic automatic adjustment of valve clearance
- Chain driven twin camshafts
- Common rail fuel system
- Diesel particulate filter (DPF) in exhaust system
- Fixed vane turbocharger with boost pressure control
- EGR cooling
- Charge air cooling
- Oil life monitoring system
Technical Data
| Parameter | D13A |
|---|---|
| Fuel | Diesel |
| Power output | 55 kW |
| at | 4000 rpm |
| Torque | 190 Nm |
| at | 1750 rpm |
| Cylinders / layout | 4 / in-line |
| Number of valves per cylinder | 4 |
| Displacement | 1248 cm 3 |
| Bore | 69.6 mm |
| Stroke | 82 mm |
| Compression ratio | 17.6:1 |
| Emissions standard | Euro 4 |
| Engine management system | Multijet 6JO |
General View
General view of D13A diesel engine
• Service: No. 1 cylinder is at the crankshaft pulley end of the engine.
