Engine Overhaul (3.8L): Component Locations Mitsubishi Eclipse IV рестайлинг

SPECIAL TOOLS

SPECIAL TOOLS DESCRIPTION TOOL TOOL NUMBER AND NAME SUPERSESSION APPLICATION MD998781 Flywheel stopper General service tool Loosening and tightening crankshaft bolts MB990767 End yoke holder MB990767-01 Holding camshaft sprocket when loosening or torquing bolt. MD998715 Pin MIT308239 MD998769 Crankshaft spacer General service tool Rotation of crankshaft when installing piston and timing belt MD998767 Tensioner wrench MD998752-01 Adjustment of timing belt tension MD998443 Lash adjuster holder (8) MD998443-01 Supporting of the lash adjuster to prevent it from falling when rocker shaft assembly is removed or installed MD998713 Camshaft oil seal installer MD998713-01 Installation of camshaft oil seal MD998442 Air bleed wire General service tool Air bleeding of auto lash adjuster MD998051 Cylinder head bolt wrench General service tool Loosening and tightening cylinder head bolts MD998735 Valve spring compressor MD998735-01 Compression of valve spring MD998772 Valve spring compressor MLR-MD998772 or General service tool Compression of valve spring MB991999 Valve stem seal installer General service tool Installation of valve stem seal MD998717 Crankshaft front oil seal installer MD998717-01 Installation of crankshaft front oil seal MD998012 Oil pressure switch wrench - Removal and installation of engine oil pressure switch MD998718 Crankshaft rear oil seal installer MD998718-01 Installation of crankshaft rear oil seal

Scheme 406

Scheme 407

Scheme 408

Scheme 409

Scheme 410

Scheme 411

Scheme 412

Scheme 413

Scheme 414

Scheme 415

Scheme 416

Scheme 417

Scheme 418

Scheme 419

Scheme 420

Scheme 421

Required Special Tool

1. MD998781: Flywheel Stopper

Scheme 422

1. Using special tool MD998781, hold the drive plate.
2. Remove the crankshaft bolt.

Scheme 423

Scheme 424

1. Using special tool MD998781, hold the drive plate.
2. Clean the bolt hole in crankshaft bolt, damper pulley seating surface and the washer.
3. Degrease the cleaned seating surface of the damper pulley.
4. Install the damper pulley.
5. Apply a minimum amount of engine oil to the thread and lower flange of the crankshaft bolt.
6. Install the washer to the crankshaft bolt with its inside chamfered side toward the bolt head.
7. Tighten the crankshaft bolt to the specified torque. Tightening torque: 185 +/- 5 N. m (137 +/- 3 ft-lb)

Scheme 425
