Engine Overhaul (2.4L): Application Mitsubishi Eclipse IV рестайлинг

>> B << SEALANT APPLICATION TO ENGINE COOLANT TEMPERATURE SENSOR

Apply 3M™ AAD Part number 8731 or equivalent to the engine coolant temperature sensor.

Scheme 624

>> C << SEALANT APPLICATION TO ENGINE OIL PRESSURE SWITCH

Apply 3M™ AAD Part number 8672 or equivalent to the threads of the engine oil pressure switch.

Scheme 625

>> D << SEALANT APPLICATION TO ENGINE OIL PRESSURE SWITCH

Scheme 626

Scheme 627

1. Apply 3M™ AAD Part number 8672 or equivalent to the threads of the engine oil pressure switch.
2. Using special tool MD998012, tighten the engine oil pressure switch to the specified torque. Tightening torque: 19 +/- 3 N.m (14 +/- 2 ft-lb)

Scheme 628

Scheme 629

1. Apply a 3 mm (0.12 inch) diameter bead of sealant MITSUBISHI Genuine Part number MD970389 or equivalent to the groove as shown in illustration.
2. Coat the threads of the bolt indicated in the illustration with 3M™ AAD 8672 or equivalent before tightening.
3. Install the housing quickly (within 15 minutes) while the sealant is wet and tighten the bolts to the specified torque. Tightening torque: 24 +/- 4 N.m (18 +/- 2 ft-lb) NOTE: After installation, keep the sealed area away from the coolant for approximately one hour.

Scheme 630

1. Check that the rubber ring is undamaged and seated correctly in the thermostat flange.
2. Install the thermostat as shown in illustration. The jiggle valve must be at the top position.

Scheme 631

1. Install the intake manifold stay and tighten the bolts just finger tight.
2. Check to ensure that the stay is in close contact with the bosses of the intake manifold and cylinder block.
3. First tighten the intake manifold side bolts to the specified torque, then the cylinder block side bolts to the specified torque. Tightening torque: 31 +/- 3 N.m (23 +/- 2 ft-lb)
