VALVE CLEARANCE ADJUSTMENT
Adjust the valve clearance as follows
| CAUTION | Rotate the crankshaft clockwise at any time. |
Scheme 459
Scheme 460
Scheme 461
- Rotate crankshaft clockwise and then align the timing mark on the camshaft sprocket with the timing mark on the rocker cover. (Place No.1 cylinder on the top dead center of compression stroke.)
- Remove the rocker cover.
- Measure the valve clearances marked with arrows shown in the illustration. When No. 1 cylinder is on the top dead center of compression stroke. When No. 4 cylinder is on the top dead center of compression stroke.
- Using a thickness gauge, adjust the clearance between the valve shaft end and the adjusting screw. Standard value (in cold state): Intake side: 0.11 mm (0.004 inch) Exhaust side: 0.20 mm (0.008 inch) NOTE: After the engine assembly is installed on the vehicle, check the valve clearance again with the engine warmed up. Adjust if necessary.
- Hold the adjusting screw with a screwdriver so it does not rotate, then tighten the lock nut.
- Rotate the crankshaft one time clockwise and then align the timing mark with the timing mark on the crankshaft sprocket. (Place No.4 cylinder on the top dead center of compression stroke.)
- Adjust the valve clearance for the rest of the valves.
- Install the rocker cover.
