DTC P0630: VIN Not Programmed or Mismatch Honda Odyssey III

Testing & Diagnostics 3 illustrations ~1235 words

Note. This DTC is stored only when the PCM does not have the VIN information of the vehicle. Use the HDS to input the missing VIN information.

  1. Turn the ignition switch ON (II).
  2. Check the VIN with the HDS. Does the HDS show the vehicle's VIN? YES - Go to step 5 . NO - Go to step 3.
  3. Input the VIN to the PCM with the HDS. Does the screen show COMPLETE? YES - Go to step 5 . NO - Go to step 4.
  4. Check for DTCs with the HDS. Is DTC P0603 indicated? YES - Go to the DTC P0603 troubleshooting. NO - Update the PCM if it does not have the latest software, or substitute a known-good PCM (see «PCM UPDATING AND SUBSTITUTION FOR TESTING»(ref-220945-S16531944742006022100000) ), then recheck. If the symptom/indication goes away with a known-good PCM, replace the original PCM (see «PCM REPLACEMENT»(ref-220946-S32339521312006022100000) ).
  5. Clear the DTC with the HDS.
  6. Turn the ignition switch OFF.
  7. Turn the ignition switch ON (II), and wait 5 seconds.
  8. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0630 is indicated, update the PCM if it does not have the latest software, or substitute a known-good PCM (see «PCM UPDATING AND SUBSTITUTION FOR TESTING»(ref-220945-S16531944742006022100000) ), then recheck. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO - Intermittent failure, system is OK at this time.

Scheme 97

Scheme 97: DTC P0641: Sensor Reference Voltage A Malfunction

Scheme 98

Scheme 98

Scheme 99

Scheme 99
  1. Turn the ignition switch ON (II).
  2. Clear the DTC with the HDS.
  3. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0641 indicated? YES - Go to step 4. NO - Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the PCM and these connectors. MAP sensor APP sensor Front/rear A/F sensor (Sensor 1) IMT actuator EGR valve FTP sensor Input shaft (mainshaft) speed sensor Output shaft (countershaft) speed sensor
  4. Turn the ignition switch OFF.
  5. Disconnect the MAP sensor 3P connector.
  6. Turn the ignition switch ON (II).
  7. Clear the DTC with the HDS.
  8. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0641 indicated? YES - Go to step 9. NO - Replace the MAP sensor (see «MAP SENSOR REPLACEMENT»(ref-220946-S26621663042006022100000) ), then go to step 53 .
  9. Turn the ignition switch OFF.
  10. Disconnect APP sensor A/B 6P connector.
  11. Turn the ignition switch ON (II).
  12. Clear the DTC with the HDS.
  13. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0641 indicated? YES - Go to step 14. NO - Replace the accelerator pedal (see «ACCELERATOR PEDAL REMOVAL/INSTALLATION»(ref-220953-S12746817652006022200000) ), then go to step 53 .
  14. Turn the ignition switch OFF.
  15. Disconnect the front A/F sensor (Bank 2, Sensor 1) 8P connector.
  16. Turn the ignition switch ON (II).
  17. Clear the DTC with the HDS.
  18. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0641 indicated? YES - Go to step 19. NO - Replace the front A/F sensor (Bank 2, Sensor 1) (see «A/F SENSOR REPLACEMENT»(ref-220946-S35067538432006022100000) ), then go to step 53 .
  19. Turn the ignition switch OFF.
  20. Disconnect the rear A/F sensor (Bank 1, Sensor 1) 8P connector.
  21. Turn the ignition switch ON (II).
  22. Clear the DTC with the HDS.
  23. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0641 indicated? YES - Go to step 24 . NO - Replace the rear A/F sensor (Bank 1, Sensor 1) (see «A/F SENSOR REPLACEMENT»(ref-220946-S35067538432006022100000) ), then go to step 53 .
  24. Turn the ignition switch OFF.
  25. Disconnect the IMT actuator 5P connector.
  26. Turn the ignition switch ON (II).
  27. Clear the DTC with the HDS.
  28. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0641 indicated? YES - Go to step 29. NO - Replace the IMT actuator (see «RESONATOR REMOVAL/INSTALLATION»(ref-220953-S20435178352006022200000) ), then go to step 53 .
  29. Turn the ignition switch OFF.
  30. Disconnect the EGR valve 6P connector.
  31. Turn the ignition switch ON (II).
  32. Clear the DTC with the HDS.
  33. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0641 indicated? YES - Go to step 34. NO - Replace the EGR valve (see «EGR VALVE REPLACEMENT»(ref-220955-S10934333292006022100000) ), then go to step 53 .
  34. Turn the ignition switch OFF.
  35. Disconnect the FTP sensor 3P connector.
  36. Turn the ignition switch ON (II).
  37. Clear the DTC with the HDS.
  38. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0641 indicated? YES - Go to step 39. NO - Replace the FTP sensor (see «FTP SENSOR REPLACEMENT»(ref-220957-S25518953132006022100000) ), then go to step 53 .
  39. Turn the ignition switch OFF.
  40. Disconnect the input shaft (mainshaft) speed sensor 3P connector.
  41. Turn the ignition switch ON (II).
  42. Clear the DTC with the HDS.
  43. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0641 indicated? YES - Go to step 44. NO - Replace the input shaft (mainshaft) speed sensor (see «INPUT SHAFT (MAINSHAFT) SPEED SENSOR REPLACEMENT»(ref-220958-S38527852412006022100000) ), then go to step 53 .
  44. Turn the ignition switch OFF.
  45. Disconnect the output shaft (countershaft) speed sensor 3P connector.
  46. Turn the ignition switch ON (II).
  47. Clear the DTC with the HDS.
  48. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0641 indicated? YES - Go to step 49. NO - Replace the output shaft (countershaft) speed sensor (see «OUTPUT SHAFT (COUNTERSHAFT) SPEED SENSOR REPLACEMENT»(ref-220958-S09835782602006022100000) ), then go to step 53 .
  49. Turn the ignition switch OFF.
  50. Jump the SCS line with the HDS.
  51. Disconnect PCM connectors A (44P), B (44P), and C (44P).
  52. Check for continuity between body ground and PCM connector terminals A19, A25, B18, B19, C12, and C13 individually. Is there continuity? YES - Repair short in the wire between the PCM (A19, A25, B18, B19, C12, or C13) and the each sensor, then go to step 53. NO - Go to step 59 .
  53. Turn the ignition switch OFF.
  54. Reconnect all connectors.
  55. Turn the ignition switch ON (II).
  56. Reset the PCM with the HDS.
  57. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(ref-220951-S17680691112006022100000) ).
  58. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0641 is indicated, check for poor connections or loose terminals at the PCM and these connectors: MAP sensor APP sensor Front/rear A/F sensor (Sensor 1) IMT actuator EGR valve FTP sensor Input shaft (mainshaft) speed sensor Output shaft (countershaft) speed sensor After checking the above, go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO - Troubleshooting is complete.
  59. Update the PCM if it does not have the latest software, or substitute a known-good PCM (see «PCM UPDATING AND SUBSTITUTION FOR TESTING»(ref-220945-S16531944742006022100000) ).
  60. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0641 is indicated, check for poor connections or loose terminals at the PCM and these connectors: MAP sensor APP sensor Front/rear A/F sensor (Sensor 1) IMT actuator EGR valve FTP sensor Input shaft (mainshaft) speed sensor Output shaft (countershaft) speed sensor After checking the above, go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(ref-220946-S32339521312006022100000) ).
