DTC P1684: Throttle Valve Return Spring Performance Problem Honda Odyssey III

Testing & Diagnostics 25 illustrations ~3147 words
CAUTIONDo not insert your fingers into the installed throttle body when you turn the ignition switch ON (II) or while the ignition switch is ON (II). If you do, you will seriously injure your fingers. If the throttle valve is activated.

Scheme 204

Scheme 204
Scheme 204
  1. Turn the ignition switch ON (II).
  2. Clear the DTC with the HDS.
  3. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on, then let it idle.
  4. Turn the ignition switch OFF, and wait 10 seconds.
  5. Turn the ignition switch ON (II).
  6. Check for Temporary DTCs or DTCs with the HDS. Is DTC P1684 indicated? YES - Go to step 7. NO - Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the throttle body and the PCM.
  7. Turn the ignition switch OFF.
  8. Disconnect the intake air duct from the throttle body.
  9. Push the throttle valve open (Scheme 204)
  10. Release the throttle valve. Does the throttle valve return? YES - Clean the throttle body (see «THROTTLE BODY CLEANING»(ref-220953-S27185000352006022200000) ), then go to step 12. NO - Go to step 11.
  11. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(ref-220953-S20883818412006022200000) ).
  12. Turn the ignition switch ON (II).
  13. Reset the PCM with the HDS.
  14. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(ref-220951-S17680691112006022100000) ).
  15. Turn the ignition switch OFF, and wait 10 seconds.
  16. Turn the ignition switch ON (II).
  17. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P1684 is indicated, check for poor connections or loose terminals at the throttle body and the PCM, then go to step 1. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting. NO - Troubleshooting is complete.

Scheme 205

Scheme 205: DTC P2101: Electronic Throttle Control System (ETCS) Malfunction
Scheme 205: DTC P2101: Electronic Throttle Control System (ETCS) Malfunction

Scheme 206

Scheme 206
Scheme 206
  1. Record all freeze data and any on-board snapshot with the HDS.
  2. Clear the DTC with the HDS.
  3. Do the ETCS TEST in the INSPECTION MENU with the HDS.
  4. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2101 indicated? YES - Go to step 7 . NO - Go to step 5 .
  5. Test-drive the vehicle for several minutes in the range of these recorded freeze data parameters: Engine speed Vehicle speed Accelerator position
  6. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2101 indicated? YES - Go to step 7 . NO - Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the throttle body and at the PCM, then clean the throttle body (see «THROTTLE BODY CLEANING»(ref-220953-S27185000352006022200000) ).
  7. Turn the ignition switch OFF.
  8. Disconnect the intake air duct from the throttle body.
  9. Turn the ignition switch ON (II).
  10. Clear the DTC with the HDS.
  11. Do the ETCS TEST in the INSPECTION MENU with the HDS.
  12. Visually check the throttle valve operation. NOTE: Be careful not to pinch your fingers during the check. Does the throttle valve operate smoothly? YES - Clean the throttle body (see «THROTTLE BODY CLEANING»(ref-220953-S27185000352006022200000) ), then go to step 21 and recheck. If DTC P2101 is indicated, go to step 19 . NO - Go to step 13 .
  13. Turn the ignition switch OFF.
  14. Disconnect the throttle body 6P connector.
  15. Jump the SCS line with the HDS.
  16. Disconnect PCM connector C (44P).
  17. Connect throttle body 6P connector terminals No. 5 and No. 6 with a jumper wire.
  18. Check for continuity between PCM connector terminals C2 and C3. Is there continuity? YES - Go to step 26 . NO - Repair open in the wires between the throttle body and the PCM (C2, C3), then go to step 20 .
  19. Turn the ignition switch OFF.
  20. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(ref-220953-S20883818412006022200000) ).
  21. Turn the ignition switch ON (II).
  22. Reset the PCM with the HDS.
  23. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(ref-220951-S17680691112006022100000) ).
  24. Test-drive the vehicle for several minutes in the range of these recorded freeze data parameters: Engine speed Vehicle speed Accelerator position
  25. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P2101 is indicated, check for poor connections or loose terminals at the throttle body and the PCM, then clean the throttle body (see «THROTTLE BODY CLEANING»(ref-220953-S27185000352006022200000) ), and go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting. NO - Troubleshooting is complete.
  26. Update the PCM if it does not have the latest software, or substitute a known-good PCM (see «PCM UPDATING AND SUBSTITUTION FOR TESTING»(ref-220945-S16531944742006022100000) ).
  27. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P2101 is indicated, check for poor connections or loose terminals at the throttle body and the PCM, then clean the throttle body (see «THROTTLE BODY CLEANING»(ref-220953-S27185000352006022200000) ), and go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting. NO - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(ref-220946-S32339521312006022100000) ).

Scheme 207

Scheme 207: DTC P2118: Throttle Actuator Current Range/Performance Problem
Scheme 207: DTC P2118: Throttle Actuator Current Range/Performance Problem

Scheme 208

Scheme 208
Scheme 208
  1. Jump the SCS line with the HDS.
  2. Disconnect PCM connector C (44P).
  3. Measure resistance between PCM connector terminals C2 and C3. Is there about 1.0 ohm or less? YES - Go to step 4 . NO - Go to step 15 .
  4. Disconnect the throttle body 6P connector.
  5. At the throttle body side, measure resistance between throttle body 6P connector terminals No. 5 and No. 6 with the throttle fully closed. Is there about 1.0 ohm or less? YES - Go to step 6 . NO - Repair short in the wires between the throttle body and PCM (C2, C3), then go to step 7 .
  6. Replace the throttle body (see «PCM REPLACEMENT»(ref-220946-S32339521312006022100000) ).
  7. Reconnect all connectors.
  8. Turn the ignition switch ON (II).
  9. Reset the PCM with the HDS.
  10. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(ref-220951-S17680691112006022100000) ).
  11. Turn the ignition switch OFF.
  12. Turn the ignition switch ON (II).
  13. Slowly press the accelerator pedal to the floor.
  14. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P2118 is indicated, check for poor connections or loose terminals at the throttle body and the PCM, then go to step 16 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting. NO - Troubleshooting is complete.
  15. Update the PCM if it does not have the latest software, or substitute a known-good PCM (see «PCM UPDATING AND SUBSTITUTION FOR TESTING»(ref-220945-S16531944742006022100000) ).
  16. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P2118 is indicated, check for poor connections or loose terminals at the throttle body and the PCM, then go to step 16 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting. NO - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(ref-220946-S32339521312006022100000) ).

Scheme 209

Scheme 209: DTC P2122: APP Sensor A (Throttle Position Sensor D) Circuit Low Voltage
Scheme 209: DTC P2122: APP Sensor A (Throttle Position Sensor D) Circuit Low Voltage

Scheme 210

Scheme 210
Scheme 210

Scheme 211

Scheme 211
Scheme 211

Scheme 212

Scheme 212
Scheme 212

Scheme 213

Scheme 213
Scheme 213

Scheme 214

Scheme 214
Scheme 214

Scheme 215

Scheme 215
Scheme 215
  1. Turn the ignition switch ON (II).
  2. Check APP SENSOR A in the DATA LIST with the HDS. Is there about 0.2 V or less? YES - Go to step 3 . NO - Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at APP sensor A and the PCM.
  3. Turn the ignition switch OFF.
  4. Disconnect APP sensor A/B 6P connector.
  5. Turn the ignition switch ON (II).
  6. At the wire harness side, measure voltage between APP sensor A/B 6P connector terminals No. 2 and No. 3. Is there about 5 V? YES - Go to step 7 . NO - Go to step 17 .
  7. Turn the ignition switch OFF.
  8. Jump the SCS line with the HDS.
  9. Disconnect PCM connector A (44P).
  10. At the wire harness side, check for continuity between APP sensor A/B 6P connector terminal No. 1 and body ground. Is there continuity? YES - Repair short in the wire between APP sensor A and the PCM (A17), then go to step 23 . NO - Go to step 11 .
  11. Connect APP sensor A/B 6P connector terminal No. 1 to body ground with a jumper wire.
  12. Check for continuity between PCM connector terminal A17 and body ground. Is there continuity? YES - Go to step 13 . NO - Repair open in the wire between APP sensor A and the PCM (A17), then go to step 23 .
  13. Reconnect PCM connector A (44P).
  14. At the wire harness side, connect APP sensor A/B 6P connector terminals No. 3 and No. 1 with a jumper wire.
  15. Turn the ignition switch ON (II).
  16. Check APP SENSOR A in the DATA LIST with the HDS. Is there 0.2 V or less? YES - Go to step 28 . NO - Go to step 22 .
  17. Turn the ignition switch OFF.
  18. Jump the SCS line with the HDS.
  19. Disconnect PCM connector A (44P).
  20. Connect APP sensor A/B 6P connector terminal No. 3 to body ground with a jumper wire.
  21. Check for continuity between PCM connector terminal A24 and body ground. Is there continuity? YES - Go to step 28 . NO - Repair open in the wire between APP sensor A and the PCM (A24), then go to step 23 .
  22. Replace accelerator pedal (see «ACCELERATOR PEDAL REMOVAL/INSTALLATION»(ref-220953-S12746817652006022200000) ).
  23. Reconnect all connectors.
  24. Turn the ignition switch ON (II).
  25. Reset the PCM with the HDS.
  26. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(ref-220951-S17680691112006022100000) ).
  27. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P2122 is indicated, check for poor connections or loose terminals at APP sensor A and the PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting. NO - Troubleshooting is complete.
  28. Update the PCM if it does not have the latest software, or substitute a known-good PCM (see «PCM UPDATING AND SUBSTITUTION FOR TESTING»(ref-220945-S16531944742006022100000) ).
  29. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P2122 is indicated, check for poor connections or loose terminals at APP sensor A and the PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting. NO - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(ref-220946-S32339521312006022100000) ).

Scheme 216

Scheme 216: DTC P2123: APP Sensor A (Throttle Position Sensor D) Circuit High Voltage
Scheme 216: DTC P2123: APP Sensor A (Throttle Position Sensor D) Circuit High Voltage

Scheme 217

Scheme 217
Scheme 217

Scheme 218

Scheme 218
Scheme 218
  1. Turn the ignition switch ON (II).
  2. Check APP SENSOR A in the DATA LIST with the HDS. Is there about 4.9 V or more? YES - Go to step 3 . NO - Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at APP sensor A and the PCM.
  3. Turn the ignition switch OFF.
  4. Disconnect APP sensor A/B 6P connector.
  5. Turn the ignition switch ON (II).
  6. At the wire harness side, measure voltage between APP sensor A/B 6P connector terminals No. 2 and No. 3. Is there about 5 V? YES - Go to step 12 . NO - Go to step 7 .
  7. Turn the ignition switch OFF.
  8. Jump the SCS line with the HDS.
  9. Disconnect PCM connector A (44P).
  10. Connect APP sensor A/B 6P connector terminal No. 2 to body ground with a jumper wire.
  11. Check for continuity between PCM connector terminal A34 and body ground. Is there continuity? YES - Go to step 19 . NO - Repair open in the wire between APP sensor A and the PCM (A34), then go to step 14 .
  12. Turn the ignition switch OFF.
  13. Replace the accelerator pedal (see «ACCELERATOR PEDAL REMOVAL/INSTALLATION»(ref-220953-S12746817652006022200000) ).
  14. Reconnect all connectors.
  15. Turn the ignition switch ON (II).
  16. Reset the PCM with the HDS.
  17. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(ref-220951-S17680691112006022100000) ).
  18. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P2123 is indicated, check for poor connections or loose terminals at APP sensor A and the PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting. NO - Troubleshooting is complete.
  19. Update the PCM if it does not have the latest software, or substitute a known-good PCM (see «PCM UPDATING AND SUBSTITUTION FOR TESTING»(ref-220945-S16531944742006022100000) ).
  20. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P2123 is indicated, check for poor connections or loose terminals at APP sensor A and the PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting. NO - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(ref-220946-S32339521312006022100000) ).

Scheme 219

Scheme 219: DTC P2127: APP Sensor B (Throttle Position Sensor E) Circuit Low Voltage
Scheme 219: DTC P2127: APP Sensor B (Throttle Position Sensor E) Circuit Low Voltage

Scheme 220

Scheme 220
Scheme 220

Scheme 221

Scheme 221
Scheme 221

Scheme 222

Scheme 222
Scheme 222

Scheme 223

Scheme 223
Scheme 223

Scheme 224

Scheme 224
Scheme 224

Scheme 225

Scheme 225
Scheme 225
  1. Turn the ignition switch ON (II).
  2. Check APP SENSOR B in the DATA LIST with the HDS. Is there about 0.2 V or less? YES - Go to step 3 . NO - Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at APP sensor B and the PCM.
  3. Turn the ignition switch OFF.
  4. Disconnect APP sensor A/B 6P connector.
  5. Turn the ignition switch ON (II).
  6. At the wire harness side, measure voltage between APP sensor A/B 6P connector terminals No. 5 and No. 6. Is there about 5 V? YES - Go to step 7 . NO - Go to step 17 .
  7. Turn the ignition switch OFF.
  8. Jump the SCS line with the HDS.
  9. Disconnect PCM connector A (44P).
  10. At the wire harness side, check for continuity between APP sensor A/B 6P connector terminal No. 4 and body ground. Is there continuity? YES - Repair short in the wire between APP sensor B and the PCM (A18), then go to step 24 . NO - Go to step 11 .
  11. Connect APP sensor A/B 6P connector terminal No. 4 to body ground with a jumper wire.
  12. Check for continuity between PCM connector terminal A18 and body ground. Is there continuity? YES - Go to step 13 . NO - Repair open in the wire between APP sensor B and the PCM (A18), then go to step 24 .
  13. Reconnect PCM connector A (44P).
  14. At the wire harness side, connect APP sensor A/B 6P connector terminals No. 6 and No. 4 with a jumper wire.
  15. Turn the ignition switch ON (II).
  16. Check APP SENSOR B in the DATA LIST with the HDS. Is there about 0.2 V or less? YES - Go to step 29 . NO - Go to step 22 .
  17. Turn the ignition switch OFF.
  18. Jump the SCS line with the HDS.
  19. Disconnect PCM connector A (44P).
  20. Connect APP sensor A/B 6P connector terminal No. 6 to body ground with a jumper wire.
  21. Check for continuity between PCM connector terminal A25 and body ground. Is there continuity? YES - Go to step 29 . NO - Repair open in the wire between APP sensor B and the PCM (A25), then go to step 24 .
  22. Turn the ignition switch OFF.
  23. Replace the accelerator pedal (see «ACCELERATOR PEDAL REMOVAL/INSTALLATION»(ref-220953-S12746817652006022200000) ).
  24. Reconnect all connectors.
  25. Turn the ignition switch ON (II).
  26. Reset the PCM with the HDS.
  27. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(ref-220951-S17680691112006022100000) ).
  28. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P2127 is indicated, check for poor connections or loose terminals at APP sensor B and the PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting. NO - Troubleshooting is complete.
  29. Update the PCM if it does not have the latest software, or substitute a known-good PCM (see «PCM UPDATING AND SUBSTITUTION FOR TESTING»(ref-220945-S16531944742006022100000) ).
  30. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P2127 is indicated, check for poor connections or loose terminals at APP sensor B and the PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting. NO - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(ref-220946-S32339521312006022100000) ).

Scheme 226

Scheme 226: DTC P2128: APP Sensor B (Throttle Position Sensor E) Circuit High Voltage
Scheme 226: DTC P2128: APP Sensor B (Throttle Position Sensor E) Circuit High Voltage

Scheme 227

Scheme 227
Scheme 227

Scheme 228

Scheme 228
Scheme 228
  1. Turn the ignition switch ON (II).
  2. Check APP SENSOR B in the DATA LIST with the HDS. Is there about 4.0 V or more? YES - Go to step 3 . NO - Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at APP sensor B and the PCM.
  3. Turn the ignition switch OFF.
  4. Disconnect the APP sensor A/B 6P connector.
  5. Turn the ignition switch ON (II).
  6. At the wire harness side, measure voltage between APP sensor A/B 6P connector terminals No. 5 and No. 6. Is there about 5 V? YES - Go to step 12 . NO - Go to step 7 .
  7. Turn the ignition switch OFF.
  8. Jump the SCS line with the HDS.
  9. Disconnect PCM connector A (44P).
  10. Connect APP sensor A/B 6P connector terminal No. 5 to body ground with a jumper wire.
  11. Check for continuity between PCM connector terminal A35 and body ground. Is there continuity? YES - Go to step 19 . NO - Repair open in the wire between APP sensor B and the PCM (A35), then go to step 14 .
  12. Turn the ignition switch OFF.
  13. Replace the accelerator pedal (see «ACCELERATOR PEDAL REMOVAL/INSTALLATION»(ref-220953-S12746817652006022200000) ).
  14. Reconnect all connectors.
  15. Turn the ignition switch ON (II).
  16. Reset the PCM with the HDS.
  17. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(ref-220951-S17680691112006022100000) ).
  18. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P2128 is indicated, check for poor connections or loose terminals at APP sensor B and the PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting. NO - Troubleshooting is complete.
  19. Update the PCM if it does not have the latest software, or substitute a known-good PCM (see «PCM UPDATING AND SUBSTITUTION FOR TESTING»(ref-220945-S16531944742006022100000) ).
  20. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P2128 is indicated, check for poor connections or loose terminals at APP sensor B and the PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting. NO - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(ref-220946-S32339521312006022100000) ).
