Throttle Body Cleaning

Scheme 299

1. Check for damage to the air cleaner. If the air cleaner is damaged, replace it (see «AIR CLEANER REMOVAL/INSTALLATION»(ref-220953-S28950794582006022200000) ).
2. Remove the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(ref-220953-S20883818412006022200000) ).
3. Clean off the carbon from the throttle valve and inside the throttle body with a paper towel soaked in throttle plate and induction cleaner. NOTE: Remove the throttle body to clean it. Be careful not to pinch your fingers. To avoid removing the molybdenum coating, do not clean the bearing area of the throttle shaft (A). Do not spray throttle plate and induction cleaner directly on the throttle body. Use Honda genuine throttle plate and induction cleaner.
4. Install the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(ref-220953-S20883818412006022200000) ).
5. Reset the PCM with the HDS.
6. Turn the ignition switch ON (II), and wait 2 seconds.
7. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(ref-220951-S17680691112006022100000) ).

Scheme 300

1. Remove the bolts (A).
2. Remove the air cleaner housing (B).
3. Install the parts in the reverse order of removal.

Scheme 301

1. Open the air cleaner housing cover (A).
2. Remove the air cleaner element (B) from the air cleaner housing (C).
3. Clean and remove any debris from inside the air cleaner housing.
4. Check the air cleaner element for damage or clogging. If it is damaged or clogged, replace it. NOTE: Do not use compressed air to clean the air cleaner element.
5. Install the parts in the reverse order of removal.

Scheme 302

Scheme 303

1. Remove the front bumper (see «FRONT BUMPER REMOVAL/INSTALLATION»(ref-220973-S27568540082006022200000) ).
2. Remove the bolt (A), clips (B), and cover (C).
3. Remove the intake air duct (D).
4. Remove the bolts (A), and resonator (B).
5. Install the parts in the reverse order of removal.

Scheme 304

1. Remove the intake manifold cover (see step 1 in «REMOVAL»(ref-220942-S09039881152006022100000) ).
2. Disconnect the IMT actuator 5P connector (A).
3. Remove the bolts and the IMT actuator (B).
4. Install the actuator in the reverse order of removal with a new O-ring (C).

Scheme 305

1. Disconnect accelerator pedal position (APP) sensor A/B 6P connector (A).
2. Remove the accelerator pedal (B). NOTE: The APP sensor is not available separately. Do not disassemble the accelerator pedal assembly.
3. Install the accelerator pedal in the reverse order of removal.

Scheme 306

1. Disconnect accelerator pedal position (APP) sensor A/B 6P connector (A).
2. Remove the accelerator pedal (B). NOTE: The APP sensor is not available separately. Do not disassemble the accelerator pedal assembly.
3. Install the accelerator pedal in the reverse order of removal.
4. Adjust the brake pedal height (see «PEDAL HEIGHT ON MODEL WITH POWER ADJUSTABLE PEDALS»(ref-220964-S41723543562006022200000) ).
