4.7L V8 Engine: Specifications — Dodge Pickup R2500 (1996-2010)

4.7L V8 Engine: Specifications Dodge Pickup R2500

Mechanical 29 illustrations

TORQUE SPECIFICATIONS

DESCRIPTION	N.m	Ft. Lbs.	In. Lbs.
Camshaft Non - Oiled Sprocket Bolt	122	90
Bearing Cap Bolts	11		100
Timing Chain Cover-Bolts	58	43
Connecting Rod Cap-Bolts	27	20
	PLUS 90° TURN
Bed Plate-Bolts	Refer to Procedure
Crankshaft Damper-Bolt	175	130
Cylinder Head Bolts	Refer to Procedure
Cylinder Head Cover-Bolts	12		105
Exhaust Manifold-Bolts	25	18
Exhaust Manifold Heat Shield-Nuts	8		72
	Then loosen 45°
Flexplate-Bolts	60	45
Engine Mount Bracket to Block-Bolts	61	45
Rear Mount to Transmission-Bolts	46	34
Generator Mounting-Bolts M10 Bolts	54	40
Generator Mounting-Bolts M8 Bolts	28		250
Intake Manifold-Bolts	12		105
	Refer to Procedure for Tightening Sequence
Oil Pan-Bolts	15		130
Oil Pan-Drain Plug	34	25
Oil Pump-Bolts	28		250
Oil Pump Cover-Bolts	12		105
Oil Pickup Tube-Bolt and Nut	28		250
Oil Dipstick Tube to Engine Block-Bolt	15		130
Oil Fill Tube-Bolts	12		105
Timing Chain Guide-Bolts	28		250
Timing Chain Tensioner Arm-Special
Pin Bolt	17		150
Hydraulic Tensioner-Bolts	28		250
Timing Chain Primary Tensioner-Bolts	28		250
Timing Drive Idler Sprocket-Bolt	34	25
Thermostat Housing-Bolts	13		105
Water Pump-Bolts	58	43
