Remove fuel injector sight shield (upper engine cover) from engine. Disconnect the boost source and signal hoses from the boost control solenoid. see scheme 29 Disconnect the boost control solenoid electrical connector. Remove the boost control solenoid retaining nut. Remove the boost control solenoid. To install, reverse removal procedure.
