Upper Electronics Module (Uem) Diagnostic Trouble Codes (Xc): Other Volvo V70 II

Verification

HINT: After carrying out the repair, check that the fault has been remedied.

Scheme 1898

Scheme 1899

Scheme 1900

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Check whether Extended X supply (EXT_X) is working.

Is each component working (sun roof, mirror lamps in sun visor, rain sensor and interior lighting)?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-431021-S05959197462011101900000)

Fault-tracing information

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Checking the connectors and components

1. Check the lamp
2. Check the connector for the upper electronic module (UEM) and cargo compartment lighting/third row reading lamps. Check for contact resistance and oxidation. Remedy as necessary
3. Reinstall the connectors, components etc. Other information: For further information about signals and other values, see «Signal specification»(ref-430923-S15249807432011101900000) See «Checking wiring and terminals»(ref-430909-S05889726072011101900000) .

Does the lamp function?

1. YES Refer to «Verification»(ref-431021-S40760902662011101900000)
2. NO Refer to «Checking for short-circuits to ground»(ref-431021-S35944838172011101900000)

Checking for short-circuits to ground

Check the cable between control module terminal #9 and the cargo compartment lighting/third row reading lamps. Check for a short-circuit to ground.

Replace the cable if a fault is found.

Other information

1. For further information about signals and other values, see «Signal specification»(ref-430923-S15249807432011101900000)
2. To connect the breakout box, see «Connecting the breakout box»(ref-430921-S34302379142011101900000)
3. See «Checking wiring and terminals»(ref-430909-S05889726072011101900000) .

Scheme 1901

1. Continue Refer to «Verification»(ref-431021-S40760902662011101900000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall the connectors, components etc.
3. Ignition on. Check that the relevant lamp button and lamp are functioning.

Does the lamp function?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-431021-S19313379462011101900000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Check the lamp
2. Check the connector for the upper electronic module (UEM) and cargo compartment lighting/third row reading lamps. Check for contact resistance and oxidation. Remedy as necessary
3. Reinstall the connectors, components etc. Other information: For further information about signals and other values, see «Signal specification»(ref-430923-S15249807432011101900000) See «Checking wiring and terminals»(ref-430909-S05889726072011101900000) .

Does the lamp function?

1. YES Refer to «Verification»(ref-431021-S15218179492011101900000)
2. NO Refer to «Checking for open-circuits and short-circuits to voltage»(ref-431021-S24852582492011101900000)

Checking for open-circuits and short-circuits to voltage

Check the cable between control module terminal #9 and the cargo compartment lighting/third row reading lamps. Check for an open-circuit. Check for a short-circuit to supply voltage.

Also check the ground connection of the cargo compartment lighting/third row reading lamps.

Remedy as necessary.

Other information

1. For further information about signals and other values, see «Signal specification»(ref-430923-S15249807432011101900000)
2. To connect the breakout box, see «Connecting the breakout box»(ref-430921-S34302379142011101900000)
3. See «Checking wiring and terminals»(ref-430909-S05889726072011101900000) .

1. Continue Refer to «Verification»(ref-431021-S15218179492011101900000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall the connectors, components etc.
3. Ignition on. Check that the relevant lamp button and lamp are functioning.

Does the lamp function?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-431021-S26411857272011101900000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Checking for permanent or intermittent faults

Check whether any customer symptoms persist.

Do any symptoms persist?

1. YES Refer to «Replacement of control unit and programming»(ref-431021-S03791229662011101900000)
2. NO Refer to «Fault-tracing information»(ref-431021-S04209534742011101900000)

Reading off the programmed values

Note. Read off the programmed values from the upper electronic module (UEM) before replacing the control module.

1. Ignition on
2. Click on the symbol for VCT2000 to read off the programmed values. The retained values are programmed customer parameters in the upper electronic module (UEM). The retained values should be noted for later use. Other information For information about programming the customer parameters, see «Diagnostic functions»(ref-430929-S30787651682011101900000) .

1. Continue Refer to «Replacing control modules and downloading software»(ref-431021-S11031565642011101900000)

Replacing control modules and downloading software

Replace the control module and download the new software. See Interior lighting and upper electronic module (UEM), replacing .

HINT: When diagnostic trouble code (DTC) E001 is stored, communication with the control module cannot be established. This can be remedied in two ways.

1. Press the remote control button for local lighting
2. Remove fuse 11C/28 from the fusebox in the passenger compartment. Reinstall the fuse again.

Scheme 1902

1. Continue Refer to «Checking the interior lighting»(ref-431021-S10570180312011101900000)

Checking the interior lighting

Two times can be programmed for the interior lighting

1. Short

1. The period from when the door is unlocked, or the engine stops, to when the interior lighting goes out can be changed if it is too long or too short.

2. Long

1. The period from when the door is opened, or a lamp is lit with a switch, to when the lamp goes out can be changed if it is too long or too short.

To program a long interior lighting period you must step ("click") through the short interior lighting period programming.

1. Continue Refer to «Programming a short interior lighting period»(ref-431021-S01459973902011101900000)

Programming a short interior lighting period

The general lighting and rear reading lamps light and remain lit for 30 seconds when

1. The door has been unlocked from outside with a key or the remote control.
2. The engine has been stopped and the ignition key turned to 0.

The default period is 30 seconds. This can be changed to between 5 and 255 seconds.

Read off the programmed values.

To change the time, mark the desired value in the scrolling list and start programming.

Do you want to program any more parameters?

1. YES Refer to «Programming a long interior lighting period»(ref-431021-S28544748362011101900000)
2. NO Refer to «Checking the anti-dazzle function in the rear view mirror»(ref-431021-S24835156912011101900000)

Programming a long interior lighting period

The general lighting and rear reading lamps light and remain lit for 10 minutes when

1. A door is opened after being unlocked.
2. The lamp is lit with a switch.

The default period is 10 minutes. This can be changed to between 0 and 255 minutes at 10 minute intervals.

Read off the programmed values.

To change the time, mark the desired value in the scrolling list and start programming.

1. Continue Refer to «Checking the anti-dazzle function in the rear view mirror»(ref-431021-S24835156912011101900000)

Checking the anti-dazzle function

Note. If the upper electronic module (UEM) has been replaced software, specially developed for downloading after replacing the control module, must be downloaded to the control module before the anti-dazzle function is changed. See Interior lighting and upper electronic module (UEM), replacing .

The rear view mirror anti-dazzle function can be adjusted

1. If the rear view mirror anti-dazzle function is too powerful or too weak, it can be adjusted.

Specific software for setting the anti-dazzle function must be installed in the car to do this.

Order the software. See 9499432 .

Install the software. See 9499432 .

Fault-tracing indicates that the control module had previously identified an intermittent fault, but that the fault is no longer present.

Set-up

1. The sunroof has lost its position and must be calibrated before it will work again. Other information See «Sun roof module (SRM), calibrating»(ref-431088-S03020320922011101900000)

1. Continue Refer to «Verification»(ref-431021-S30400289202011101900000)

HINT: After the repair it is necessary to check that the fault has been rectified.

1. Ignition off.
2. Connect the connectors, install the components, etc.
3. Ignition on. Try to operate the sunroof automatically by pressing the switch down two stages.

Does the sunroof move automatically?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-431021-S24007852572011101900000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Ignition on
2. Operate the sun roof to full tilt. Check that the automatic operation of the sun roof works.

Was the function OK?

1. YES Refer to «Verification»(ref-431021-S31182028662011101900000)
2. NO Refer to «Replacing the sun roof motor»(ref-431021-S02681193272011101900000)

Replacing the sun roof motor

1. Replace the sun roof motor. See «Motor sun roof, replacement»(ref-430952-S21500415122011101900000)
2. Ignition off
3. Reinstall the components, reconnect the connectors etc.
4. Ignition on. Check that the automatic closing of the sun roof works.

Does the automatic closing of the sun roof work?

1. YES Refer to «Verification»(ref-431021-S31182028662011101900000)
2. NO Refer to «Replacing the sun roof control module»(ref-431021-S00464263152011101900000)

Replacing the sun roof control module

Replace the sun roof control module according to Control module, sun roof, replacing .

1. Continue Refer to «Verification»(ref-431021-S31182028662011101900000)

HINT: After the repair it is necessary to check that the fault has been rectified.

1. Ignition off.
2. Connect the connectors, install the components, etc.
3. Ignition on. Check that the automatic sunroof closing works.

Does it work?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-431021-S13122048832011101900000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Ignition on. Check that the sun roof can be moved to its limit positions.

Can the sun roof be operated?

1. YES Refer to «Intermittent fault»(ref-431021-S32391194982011101900000)
2. NO Refer to «Checking the connectors»(ref-431021-S22438009812011101900000)

Checking the connectors

Check the connector between the sun roof module (SRM) and sun roof motor. Check for contact resistance and oxidation.

Check that fuse 11C/7 (11C/13 XC90) in the passenger compartment fuse box is intact.

Check connector 54/13. Check for contact resistance and oxidation.

Other information

1. To access the connector between the sun roof module (SRM) and motor, see «Motor sun roof, replacement»(ref-430952-S21500415122011101900000) .
2. See «Checking wiring and terminals»(ref-430909-S05889726072011101900000) .

Was a fault detected?

1. YES Refer to «Verification»(ref-431021-S42332012892011101900000)
2. NO Refer to «Checking for open-circuits and short-circuits»(ref-431021-S32533796752011101900000)

Checking for open-circuits and short-circuits

Check the cable between sun roof module (SRM) terminal #10A and ground, left A-post. Check for a short-circuit to supply voltage.

Check the cable between the sun roof module (SRM) terminal #1A and fuse 11C/7 (11C/13 XC90) in the passenger compartment fuse box for a short-circuit to ground or an open-circuit.

Replace the cable if a fault is found.

After carrying out repairs, the sun roof module (SRM) should be calibrated. See Sun roof module (SRM), calibrating .

Other information

1. For further information about signals and other values, see «Signal specification»(ref-430923-S15249807432011101900000) .
2. To connect the breakout box, see «Connecting the breakout box»(ref-430921-S34302379142011101900000) .
3. To access the sun roof module (SRM) connector, see «Control module, sun roof, replacing»(ref-430952-S23697945242011101900000) .
4. See «Checking wiring and terminals»(ref-430909-S05889726072011101900000) .

Scheme 1903

Was a fault detected?

1. YES Refer to «Verification»(ref-431021-S42332012892011101900000)
2. NO Refer to «Replacing the sun roof motor»(ref-431021-S11240181702011101900000)

1. Replace the sun roof motor. See «Motor sun roof, replacement»(ref-430952-S21500415122011101900000) .
2. Ignition off
3. Reinstall the components and connectors etc.
4. Ignition on.

After carrying out repairs, the sun roof module (SRM) should be calibrated. See Sun roof module (SRM), calibrating .

Check that automatic closing of the sun roof works by pressing forward the switch 2 steps.

Does the automatic closing of the sun roof work?

1. YES Refer to «Verification»(ref-431021-S42332012892011101900000)
2. NO Refer to «Replacing the sun roof control module»(ref-431021-S42256301892011101900000)

1. Ignition off Replace the sun roof control module according to «Control module, sun roof, replacing»(ref-430952-S23697945242011101900000) .

1. Continue Refer to «Verification»(ref-431021-S42332012892011101900000)

Intermittent fault

Check the connector between the sun roof module (SRM) and sun roof motor. Check for contact resistance and oxidation. Check for loose connections.

Check connector 54/13. Check for contact resistance and oxidation. Check for loose connections.

Check the cable between sun roof module (SRM) terminal #10A and ground, left A-post. Check for an intermittent short-circuit to supply voltage.

Check the cable between the sun roof module (SRM) terminal #1A and fuse 11C/7 (11C/13 XC90) in the passenger compartment fuse box for a short-circuit to ground or an intermittent open-circuit.

After carrying out repairs, the sun roof module (SRM) should be calibrated. See Sun roof module (SRM), calibrating .

Other information

1. For further information about signals and other values, see «Signal specification»(ref-430923-S15249807432011101900000) .
2. To connect the breakout box, see «Connecting the breakout box»(ref-430921-S34302379142011101900000) .
3. To access the connector between the sun roof module (SRM) and motor, see «Motor sun roof, replacement»(ref-430952-S21500415122011101900000) .
4. See «Checking wiring and terminals»(ref-430909-S05889726072011101900000) .

1. Continue Refer to «Information»(ref-431021-S01214660492011101900000)

HINT: After the repair it is necessary to check that the fault has been rectified.

1. Ignition off.
2. Connect the connectors, install the components, etc.
3. Ignition on. Check that the sunroof can be moved to its end position.

Does the sunroof move?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-431021-S35613753962011101900000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

1. Ignition on
2. Operate the sun roof to full tilt. Check that the automatic operation of the sun roof works.

Was the function OK?

1. YES Refer to «Verification»(ref-431021-S08422166882011101900000)
2. NO Refer to «Checking the wiring»(ref-431021-S29314326762011101900000)

1. Replace the sun roof motor. See «Motor sun roof, replacement»(ref-430952-S21500415122011101900000)
2. Ignition off
3. Reinstall the components, reconnect the connectors etc.
4. Ignition on. Check that automatic closing of the sun roof works by pressing forward the switch 2 steps.

Does the automatic closing of the sun roof work?

1. YES Refer to «Verification»(ref-431021-S08422166882011101900000)
2. NO Refer to «Replacing the sun roof control module»(ref-431021-S30605543312011101900000)

Replace the sun roof control module according to Control module, sun roof, replacing .

1. Continue Refer to «Verification»(ref-431021-S08422166882011101900000)

HINT: After the repair it is necessary to check that the fault has been rectified.

1. Ignition off.
2. Connect the connectors, install the components, etc.
3. Ignition on. Check that the automatic sunroof closing works.

Does it work?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-431021-S35497166152011101900000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Replace the sun roof control module according to Control module, sun roof, replacing .

1. Continue Refer to «Verification»(ref-431021-S29806470922011101900000)

HINT: After the repair it is necessary to check that the fault has been rectified.

1. Ignition off.
2. Connect the connectors, install the components, etc.
3. Ignition on. Check that the automatic sunroof control works by pressing the switch down two stages.

Does it work?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-431021-S04316889582011101900000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Signal too high

See Signal too high

Initiating sun roof position

Note. Diagnostic trouble code (DTC) UEM-0058 is stored if the sun roof has been blocked at some point or incorrectly installed.

Try to adjust the sun roof so that it does not move at an angle or stick.

Check that nothing is located in the groove preventing the sun roof from being operated.

Other information

1. See «Sun roof, adjusting»(ref-431088-S25297856472011101900000)

1. Continue Refer to «Erasing diagnostic trouble code (DTC)»(ref-431021-S04877652852011101900000)

See Signal too high

See Signal too high

1. Ignition on. Try to operate the sun roof to its limit positions.

Can the sun roof be operated?

1. YES Refer to «Intermittent fault»(ref-431021-S41286980582011101900000)
2. NO Refer to «Checking for a short-circuit»(ref-431021-S25929093922011101900000)

Checking for a short-circuit

Check the cable between the sun roof module (SRM) and the roof lamp module. Check for a short-circuit to supply voltage.

UEM-0061 Motor sun roof. Signal too high

The sun roof module (SRM) terminal #2A and roof lamp module terminal #4B.

UEM-0062 Motor sun roof. Signal too high

The sun roof module (SRM) terminal #8A and roof lamp module terminal #3B.

UEM-0063 Motor sun roof. Signal too high

The sun roof module (SRM) terminal #3A and roof lamp module terminal #2B.

UEM-0064 Motor sun roof. Signal too high

The sun roof module (SRM) terminal #7A and roof lamp module terminal #1B.

Remedy as necessary.

Other information

1. For further information about signals and other values, see «Signal specification»(ref-430923-S15249807432011101900000)
2. To access the roof lamp module connector, For -2002, see «Interior lighting and upper electronic module (UEM), replacing»(ref-430927-S13783131922011101900000) For 2003-, see «Interior lighting, replacing»(ref-430927-S21103868592011101900000) .
3. To access the sun roof module (SRM) connector, see «Control module, sun roof, replacing»(ref-430952-S23697945242011101900000)
4. See «Checking wiring and terminals»(ref-430909-S05889726072011101900000) .

Scheme 1904

Scheme 1905

Was a fault detected?

1. YES Refer to «Verification»(ref-431021-S16474693892011101900000)
2. NO Refer to «Checking the cable»(ref-431021-S36103548562011101900000)

Checking the cable

Check the wiring between the sun roof switch and the roof lamp module. Check for a short-circuit to supply voltage.

Other information

1. For further information about signals and other values, see «Signal specification»(ref-430923-S15249807432011101900000)
2. See «Checking wiring and terminals»(ref-430909-S05889726072011101900000) .

Scheme 1906

1. Continue Refer to «Replacing the sun roof switch»(ref-431021-S33256245572011101900000)

Replacing the sun roof switch

Visually check the roof lamp module and its switches.

If no fault is found replace the sun roof switch. See Switch, sun roof, replacing .

1. Continue Refer to «Verification»(ref-431021-S16474693892011101900000)

Check the connector on the sun roof module (SRM) and the connector on the roof lamp module. Check for contact resistance and oxidation. Check for loose connections.

Visually check the cable between the sun roof module (SRM) and the roof lamp module. Check for an intermittent short-circuit to supply voltage. Check for an intermittent open-circuit.

UEM-0061 Motor sun roof. Signal too high

The sun roof module (SRM) terminal #2A and roof lamp module terminal #4B.

UEM-0062 Motor sun roof. Signal too high

The sun roof module (SRM) terminal #8A and roof lamp module terminal #3B.

UEM-0063 Motor sun roof. Signal too high

The sun roof module (SRM) terminal #3A and roof lamp module terminal #2B.

UEM-0064 Motor sun roof. Signal too high

The sun roof module (SRM) terminal #7A and roof lamp module terminal #1B.

Check the wiring between the sun roof switch and the roof lamp module (RCM). Check for an intermittent short-circuit to supply voltage.

Visually check the roof lamp module and its switches.

HINT: If no fault is found replace the sun roof switch.

Other information

1. For further information about signals and other values, see «Signal specification»(ref-430923-S15249807432011101900000)
2. To access the roof lamp module connector, For -2002, see «Interior lighting and upper electronic module (UEM), replacing»(ref-430927-S13783131922011101900000) For 2003-, see «Interior lighting, replacing»(ref-430927-S21103868592011101900000) .
3. To access the sun roof module (SRM) connector, see «Control module, sun roof, replacing»(ref-430952-S23697945242011101900000)
4. To replace the printed circuit board and its switches, For -2002, see «Interior lighting and upper electronic module (UEM), replacing»(ref-430927-S13783131922011101900000) For 2003-, see «Interior lighting, replacing»(ref-430927-S21103868592011101900000) .
5. To replace the switch for the sun roof, see «Switch, sun roof, replacing»(ref-431006-S13363001262011101900000)
6. See «Checking wiring and terminals»(ref-430909-S05889726072011101900000) .

1. Continue Refer to «Information»(ref-431021-S41565723362011101900000)

HINT: After the repair it is necessary to check that the fault has been rectified.

1. Ignition off.
2. Connect the connectors, install the components, etc.
3. Ignition on. Try to move the sunroof to its end position.

Does the sunroof move?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-431021-S09416291962011101900000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too high

See Signal too high

See Signal too high

Replace the sun roof switch. See Switch, sun roof, replacing .

Check that the function is now OK.

Scheme 1907

Is the function OK?

1. YES Refer to «Verification»(ref-431021-S13530593992011101900000)
2. NO Refer to «Checking the cable»(ref-431021-S25056096602011101900000)

Check the wiring between the sun roof switch and the roof lamp module. Check for a short-circuit to supply voltage.

If a fault is found replace the wiring.

Other information

1. For further information about signals and other values, see «Signal specification»(ref-430923-S15249807432011101900000)
2. See «Checking wiring and terminals»(ref-430909-S05889726072011101900000) .

Has a fault been detected?

1. YES Refer to «Verification»(ref-431021-S13530593992011101900000)
2. NO Refer to «Replacing the control module»(ref-431021-S25373073632011101900000)

Replacing the control module

If no fault has been found, replace the sun roof module (SRM).

Other information

1. To replace the sun roof module (SRM), see «Control module, sun roof, replacing»(ref-430952-S23697945242011101900000) .

1. Continue Refer to «Verification»(ref-431021-S13530593992011101900000)

HINT: After the repair it is necessary to check that the fault has been rectified.

1. Ignition off.
2. Connect the connectors, install the components, etc.
3. Ignition on. Check that the sunroof control works.

Does the sunroof control work?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-431021-S38081543742011101900000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Faulty signal

See Faulty signal

See Faulty signal

See Faulty signal

1. Ignition on. Check that the sun roof can be moved to its limit positions.

Can the sun roof be operated?

1. YES Refer to «Intermittent fault»(ref-431021-S34871464862011101900000)
2. NO Refer to «Checking for a short-circuit»(ref-431021-S33720700012011101900000)

Check the cable between the sun roof module (SRM) and the roof lamp module. Check for a short-circuit to supply voltage.

UEM-0070 Sun roof. Faulty signal

The sun roof module (SRM) terminal #3A and roof lamp module terminal #2B.

UEM-0070 Sun roof. Faulty signal

The sun roof module (SRM) terminal #7A and roof lamp module terminal #1B.

Replace the cable if a fault is found.

Other information

1. For further information about signals and other values, see «Signal specification»(ref-430923-S15249807432011101900000)
2. To access the roof lamp module connector, For -2002, see «Interior lighting and upper electronic module (UEM), replacing»(ref-430927-S13783131922011101900000) For 2003-, see «Interior lighting, replacing»(ref-430927-S21103868592011101900000) .
3. To access the sun roof module (SRM) connector, see «Control module, sun roof, replacing»(ref-430952-S23697945242011101900000)
4. See «Checking wiring and terminals»(ref-430909-S05889726072011101900000) .

1. Continue Refer to «Checking the cable»(ref-431021-S24198213972011101900000)

Check the wiring between the sun roof switch and the roof lamp module. Check for a short-circuit to supply voltage.

Other information

1. For further information about signals and other values, see «Signal specification»(ref-430923-S15249807432011101900000)
2. See «Checking wiring and terminals»(ref-430909-S05889726072011101900000) .

1. Continue Refer to «Replacing the sun roof switch»(ref-431021-S09199204852011101900000)

Visually check for damage to the roof lamp module and its switches.

If no fault is found replace the sun roof switch. See Switch, sun roof, replacing .

1. Continue Refer to «Verification»(ref-431021-S41901464692011101900000)

Check the connector on the sun roof module (SRM) and the connector on the roof lamp module. Check for contact resistance and oxidation. Check for loose connections.

Check the cable between the sun roof module (SRM) and the roof lamp module. Check for an intermittent short-circuit to supply voltage. Check for an intermittent open-circuit.

UEM-0070 Sun roof. Faulty signal

The sun roof module (SRM) terminal #3A and roof lamp module terminal #2B.

UEM-0070 Sun roof. Faulty signal

The sun roof module (SRM) terminal #7A and roof lamp module terminal #1B.

Check the wiring between sun roof switch and RCM. Check for an intermittent short-circuit to supply voltage.

If no fault is found replace the sun roof switch. See Switch, sun roof, replacing .

Other information

1. For further information about signals and other values, see «Signal specification»(ref-430923-S15249807432011101900000)
2. To access the roof lamp module connector, For -2002, see «Interior lighting and upper electronic module (UEM), replacing»(ref-430927-S13783131922011101900000) For 2003-, see «Interior lighting, replacing»(ref-430927-S21103868592011101900000) .
3. To access the sun roof module (SRM) connector, see «Control module, sun roof, replacing»(ref-430952-S23697945242011101900000)
4. To replace the switch for the sun roof, see «Switch, sun roof, replacing»(ref-431006-S13363001262011101900000)
5. See «Checking wiring and terminals»(ref-430909-S05889726072011101900000) .

1. Continue Refer to «Information»(ref-431021-S13774440602011101900000)

HINT: After the repair it is necessary to check that the fault has been rectified.

1. Ignition off.
2. Connect the connectors, install the components, etc.
3. Ignition on. Check that the sunroof can be moved to its end position.

Does the sunroof move?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-431021-S19502980322011101900000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

1. Ignition on. Check that the sun roof can be operated automatically by pressing the switch 2 steps.

Can the sun roof be operated automatically?

1. YES Refer to «Intermittent fault»(ref-431021-S31509841782011101900000)
2. NO Refer to «Checking for open-circuits and short-circuits»(ref-431021-S05179373582011101900000)

Check the cable between the sun roof module (SRM) terminal #6A and the upper electronic module (UEM) terminal #8A. Check for an open-circuit.

Replace the cable if a fault is found.

Other information

1. For further information about signals and other values, see «Signal specification»(ref-430923-S15249807432011101900000)
2. To connect the breakout box, see «Connecting the breakout box»(ref-430921-S34302379142011101900000)
3. To access the sun roof module (SRM) connector, see «Control module, sun roof, replacing»(ref-430952-S23697945242011101900000)
4. See «Checking wiring and terminals»(ref-430909-S05889726072011101900000) .

Scheme 1908

Was a fault detected?

1. YES Refer to «Verification»(ref-431021-S00879785742011101900000)
2. NO Refer to «Replacing the sun roof control module»(ref-431021-S38006675062011101900000)

Check the cable between the sun roof module (SRM) terminal #6A and the upper electronic module (UEM) terminal #8A. Check for an intermittent open-circuit.

Replace the cable if a fault is found.

If no fault was found, try replacing the sun roof module (SRM).

Other information

1. For further information about signals and other values, see «Signal specification»(ref-430923-S15249807432011101900000)
2. To connect the breakout box, see «Connecting the breakout box»(ref-430921-S34302379142011101900000)
3. To access or replace the sun roof module (SRM) connector, see «Control module, sun roof, replacing»(ref-430952-S23697945242011101900000)
4. See «Checking wiring and terminals»(ref-430909-S05889726072011101900000) .

1. Continue Refer to «Information»(ref-431021-S13711873452011101900000)

1. Ignition off. Replace the sun roof control module according to «Control module, sun roof, replacing»(ref-430952-S23697945242011101900000) .

1. Continue Refer to «Verification»(ref-431021-S00879785742011101900000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Check that the sun roof can be operated automatically by pressing the switch 2 steps.

Can the sun roof be operated automatically?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-431021-S17540186152011101900000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

1. Ignition on. Check that the sun roof can be operated automatically by pressing the switch 2 steps.

Can the sun roof be operated automatically?

1. YES Refer to «Intermittent fault»(ref-431021-S11846195382011101900000)
2. NO Refer to «Replacing the sun roof control module»(ref-431021-S06441046422011101900000)

1. Ignition off. Replace the sun roof control module according to «Control module, sun roof, replacing»(ref-430952-S23697945242011101900000) .

1. Continue Refer to «Verification»(ref-431021-S29524174952011101900000)

The control module has previously registered a fault. The fault is now no longer present.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Check that the sun roof can be operated automatically by pressing the switch 2 steps.

Can the sun roof be operated automatically?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-431021-S36035393482011101900000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Re-configuration

1. The configuration of the siren does not correspond to the configuration of the car
2. Ignition on
3. Click the VCT2000 symbol to re-configure the siren.

1. Continue Refer to «Reading off diagnostic trouble codes (DTC)»(ref-431021-S09835812992011101900000)

Replacing the siren

1. A faulty siren is installed
2. Replace the siren. See «Siren, replacing»(ref-431006-S14848374132011101900000)
3. Ignition on. Activate the configuration.

Checking the function

1. Ignition on
2. Activate the rain sensor. HINT: The wiper blades make a reference stroke to determine the cleanliness and condition of the windshield when the rain sensor is activated. The rain sensor is deactivated when the ignition is switched off. To reactivate the rain sensor with the ignition on, move the stalk to position "0" and then to intermittent wiping. Spray water on the windshield where the rain sensor is positioned. The wiper blades must now wipe the windshield clean. HINT: In cars equipped with the rain sensor it replaces the intermittent function. One way of checking the function of the rain sensor is to twist the collar on the lever. This changes the sensitivity of the rain sensor. The windshield wiper should make one stroke. If the intermittent or high speed functions are activated it indicates that the rain sensor function is missing.

1. Continue Refer to «Checking the supply to the rain sensor»(ref-431021-S05917741552011101900000)

Scheme 1909

1. A number of measurements are required to check the wiring for the rain sensor. Measurements should be carried out on the wiring connector with the rain sensor disconnected. The terminals correspond to ground, voltage and data cables. The data cable is connected to terminal #1 on the rain sensor, terminal #2 is the ground cable and terminal #3 is the power supply for the rain sensor
2. Move the windshield wiper stalk to position "0".
3. Ignition off
4. Disconnect the rain sensor
5. Ignition on. Check the voltage level between the voltage terminal #3 and ground terminal #2 of the wiring. HINT: The voltage must be 12V. Other information: For further information about signals and other values, see «Signal specification»(ref-430923-S15249807432011101900000) See «Rain sensor»(ref-431006-S36613426452011101900000) See «Checking wiring and terminals»(ref-430909-S05889726072011101900000) .

Is the voltage between the terminals 12 V?

1. YES Refer to «Checking the data cable»(ref-431021-S05702906372011101900000)
2. NO Refer to «Checking the wiring»(ref-431021-S36383266462011101900000)

Checking the data cable

HINT: The wiring between upper electronic module (UEM) and the rain sensor consists of two cables.

The upper electronic module (UEM) transmits pulses to the rain sensor using the data cable.

Disconnect the rain sensor.

Check that the data is transmitted on the data cable terminal #1 by checking the voltage level between the data and ground cables for the wiring (that is terminals #1 and #2).

HINT: Use the oscilloscope function and check that a pulsed signal is transmitted. The difference between the high and low values of the pulses is approximately 12 V. In the event of an open-circuit in the data cable no pulses are transmitted and a continuous voltage is displayed.

If the difference between high and low values of the pulses is between 2 V and 10 V it indicates that the wiring is oxidized or trapped. Replace the wiring between the rain sensor and the roof wiring in the event of a fault.

If no other fault is found try replacing the rain sensor.

Remedy as necessary.

Other information

1. To access or replace the control module, see «Interior lighting and upper electronic module (UEM), replacing»(ref-430927-S13783131922011101900000)
2. See «Rain sensor»(ref-431006-S36613426452011101900000)
3. For further information about signals and other values, see «Signal specification»(ref-430923-S15249807432011101900000)
4. To connect the breakout box, see «Connecting the breakout box»(ref-430921-S34302379142011101900000)
5. See «Checking wiring and terminals»(ref-430909-S05889726072011101900000) .

Scheme 1910

1. Continue Refer to «Verification»(ref-431021-S19905256182011101900000)

Note. After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Activate the rain sensor. HINT: The wiper blades make a reference stroke to determine the cleanliness and condition of the windshield when the rain sensor is activated. The rain sensor is deactivated when the ignition is switched off. To reactivate the rain sensor with the ignition on, move the lever to position 0 and then to intermittent wiping. Spray water on the windshield where the rain sensor is positioned. The wiper blades must now wipe the windshield clean.

Is the rain sensor functioning?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-431021-S16478044102011101900000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Signal missing

See Signal missing

1. Ignition on
2. Activate the rain sensor. HINT: The wiper blades make a reference stroke to determine the cleanliness and condition of the windshield when the rain sensor is activated. The rain sensor is deactivated when the ignition is switched off. To reactivate the rain sensor with the ignition on, move the stalk to position "0" and then to intermittent wiping. Spray water on the windshield where the rain sensor is positioned. The wiper blades must now wipe the windshield clean. HINT: In cars equipped with the rain sensor it replaces the intermittent function. One way of checking the function of the rain sensor is to twist the collar on the lever. This changes the sensitivity of the rain sensor. The windshield wiper should make one stroke. If the intermittent or high speed functions are activated it indicates that the rain sensor function is missing.

1. Continue Refer to «Checking the wiring»(ref-431021-S21919611652011101900000)

Scheme 1911

Scheme 1912

1. HINT: The wiring between the upper electronic module (UEM) and the rain sensor consists of two cables.
2. Windshield wiper stalk in position "0". Check the cable between upper electronic module (UEM) terminal #13 (#A13) and rain sensor terminal #1. Check for a short-circuit to ground. HINT: The upper electronic module (UEM) terminal #20 (#A20) is signal ground. Remedy as necessary. Other information: See «Interior lighting and upper electronic module (UEM), replacing»(ref-430927-S13783131922011101900000) See «Rain sensor»(ref-431006-S36613426452011101900000) See «Signal specification»(ref-430923-S15249807432011101900000) See «Connecting the breakout box»(ref-430921-S34302379142011101900000) See «Contents»(ref-430909-S26456997912011101900000) .

1. Continue Refer to «Verification»(ref-431021-S14140881622011101900000)

Note. After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Activate the rain sensor. HINT: The wiper blades make a reference stroke to determine the cleanliness and condition of the windshield when the rain sensor is activated. The rain sensor is deactivated when the ignition is switched off. To reactivate the rain sensor with the ignition on, move the lever to position 0 and then to intermittent wiping. Spray water on the windshield where the rain sensor is positioned. The wiper blades must now wipe the windshield clean.

Is the rain sensor functioning?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-431021-S10938510032011101900000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Ignition on
2. Activate the rain sensor. HINT: The wiper blades make a reference stroke to determine the cleanliness and condition of the windshield when the rain sensor is activated. The rain sensor is deactivated when the ignition is switched off. To reactivate the rain sensor with the ignition on, move the stalk to position "0" and then to intermittent wiping. Spray water on the windshield where the rain sensor is positioned. The wiper blades must now wipe the windshield clean. HINT: In cars equipped with the rain sensor it replaces the intermittent function. One way of checking the function of the rain sensor is to twist the collar on the lever. This changes the sensitivity of the rain sensor. The windshield wiper should make one stroke. If the intermittent or high speed functions are activated it indicates that the rain sensor function is missing.

1. Continue Refer to «Checking the wiring»(ref-431021-S31949138802011101900000)

Note. After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Activate the rain sensor. HINT: The wiper blades make a reference stroke to determine the cleanliness and condition of the windshield when the rain sensor is activated. The rain sensor is deactivated when the ignition is switched off. To reactivate the rain sensor with the ignition on, move the lever to position 0 and then to intermittent wiping. Spray water on the windshield where the rain sensor is positioned. The wiper blades must now wipe the windshield clean.

Is the rain sensor functioning?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-431021-S08556123272011101900000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Ignition on
2. Activate the rain sensor. HINT: The wiper blades make a reference stroke to determine the cleanliness and condition of the windshield when the rain sensor is activated. The rain sensor is deactivated when the ignition is switched off. To reactivate the rain sensor with the ignition on, move the stalk to position "0" and then to intermittent wiping. Spray water on the windshield where the rain sensor is positioned. The wiper blades must now wipe the windshield clean. HINT: In cars equipped with the rain sensor it replaces the intermittent function. One way of checking the function of the rain sensor is to twist the collar on the lever. This changes the sensitivity of the rain sensor. The windshield wiper should make one stroke. If the intermittent or high speed functions are activated it indicates that the rain sensor function is missing.

1. Continue Refer to «Checking the rain sensor»(ref-431021-S34631392482011101900000)

Checking the rain sensor

1. Ignition off. Check that the rain sensor is properly secured. Check that there is no dirt on the inside of the windshield. Check that there are no stone chips or damage to the windshield where the rain sensor is positioned. Remedy as necessary. Other information: See «Rain sensor»(ref-431006-S36613426452011101900000)

Was a fault detected?

1. YES Refer to «Verification»(ref-431021-S33557726342011101900000)
2. NO Refer to «Replacing the rain sensor»(ref-431021-S11363815752011101900000)

Replacing the rain sensor

1. Ignition off. If no other fault is found, try replacing the rain sensor. Other information See «Rain sensor»(ref-431006-S36613426452011101900000)

1. Continue Refer to «Verification»(ref-431021-S33557726342011101900000)

Note. After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Activate the rain sensor. HINT: The wiper blades make a reference stroke to determine the cleanliness and condition of the windshield when the rain sensor is activated. The rain sensor is deactivated when the ignition is switched off. To reactivate the rain sensor with the ignition on, move the lever to position 0 and then to intermittent wiping. Spray water on the windshield where the rain sensor is positioned. The wiper blades must now wipe the windshield clean.

Is the rain sensor functioning?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-431021-S35090718322011101900000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Internal fault

See Internal fault

1. Ignition on
2. Activate the rain sensor. HINT: The wiper blades make a reference stroke to determine the cleanliness and condition of the windshield when the rain sensor is activated. The rain sensor is deactivated when the ignition is switched off. To reactivate the rain sensor with the ignition on, move the stalk to position "0" and then to intermittent wiping. Spray water on the windshield where the rain sensor is positioned. The wiper blades must now wipe the windshield clean. HINT: In cars equipped with the rain sensor it replaces the intermittent function. One way of checking the function of the rain sensor is to twist the collar on the lever. This changes the sensitivity of the rain sensor. The windshield wiper should make one stroke. If the intermittent or high speed functions are activated it indicates that the rain sensor function is missing.

1. Continue Refer to «Checking the wiring»(ref-431021-S05773964392011101900000)

Note. After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Activate the rain sensor. HINT: The wiper blades make a reference stroke to determine the cleanliness and condition of the windshield when the rain sensor is activated. The rain sensor is deactivated when the ignition is switched off. To reactivate the rain sensor with the ignition on, move the lever to position 0 and then to intermittent wiping. Spray water on the windshield where the rain sensor is positioned. The wiper blades must now wipe the windshield clean.

Is the rain sensor functioning?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-431021-S23018351482011101900000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Replacing control module and programming

1. Ignition off. The LED for the PAD lamp is mounted internally in the rear view mirror and cannot be replaced. Check there are no indications that the power supply to the upper electronic module (UEM) is faulty. Check that the fault in the LED remains after the power is switched off and on again. If the fault remains, the upper electronic module (UEM) must be replaced. NOTE: If possible, read off the programmed data from the control module before it is replaced. This should be done as this information is not stored in Volvo's central database. Switch off the ignition before replacing the control module.

1. Continue Refer to «Replacing the control module»(ref-431021-S33623486032011101900000)

Note. Read off the programmed values from the upper electronic module (UEM) before replacing the control module.

1. Ignition on
2. Click on the symbol for VCT2000 to read off the programmed values. The retained values are programmed customer parameters in the upper electronic module (UEM). The retained values should be noted for later use. Other information For information about programming the customer parameters, see «Diagnostic functions»(ref-430929-S30787651682011101900000) .

1. Continue Refer to «Replacing control modules and downloading software»(ref-431021-S12799358362011101900000)

Replace the control module and download the new software. See Interior lighting and upper electronic module (UEM), replacing .

HINT: When diagnostic trouble code (DTC) E001 is stored, communication with the control module cannot be established. This can be remedied in two ways.

1. Press the remote control button for local lighting
2. Remove fuse 11C/28 from the fusebox in the passenger compartment. Reinstall the fuse again.

1. Continue Refer to «Checking the interior lighting»(ref-431021-S35722646412011101900000)

Two times can be programmed for the interior lighting

1. Short

1. The period from when the door is unlocked, or the engine stops, to when the interior lighting goes out can be changed if it is too long or too short.

2. Long

1. The period from when the door is opened, or a lamp is lit with a switch, to when the lamp goes out can be changed if it is too long or too short.

To program a long interior lighting period you must step ("click") through the short interior lighting period programming.

1. Continue Refer to «Programming a short interior lighting period»(ref-431021-S38650743452011101900000)

The general lighting and rear reading lamps light and remain lit for 30 seconds when

1. The door has been unlocked from outside with a key or the remote control.
2. The engine has been stopped and the ignition key turned to 0.

The default period is 30 seconds. This can be changed to between 5 and 255 seconds.

Read off the programmed values.

To change the time, mark the desired value in the scrolling list and start programming.

Do you want to program any more parameters?

1. YES Refer to «Programming a long interior lighting period»(ref-431021-S02662496972011101900000)
2. NO Refer to «Checking the anti-dazzle function in the rear view mirror»(ref-431021-S09384391812011101900000)

The general lighting and rear reading lamps light and remain lit for 10 minutes when

1. A door is opened after being unlocked.
2. The lamp is lit with a switch.

The default period is 10 minutes. This can be changed to between 0 and 255 minutes at 10 minute intervals.

Read off the programmed values.

To change the time, mark the desired value in the scrolling list and start programming.

1. Continue Refer to «Checking the anti-dazzle function in the rear view mirror»(ref-431021-S09384391812011101900000)

Note. If the upper electronic module (UEM) has been replaced software, specially developed for downloading after replacing the control module, must be downloaded to the control module before the anti-dazzle function is changed. See Interior lighting and upper electronic module (UEM), replacing .

The rear view mirror anti-dazzle function can be adjusted

1. If the rear view mirror anti-dazzle function is too powerful or too weak, it can be adjusted.

Specific software for setting the anti-dazzle function must be installed in the car to do this.

Order the software. See 9499432 .

Install the software. See 9499432 .

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Check that the LEDs in the display in the rear view mirror light.

Are the LEDs in the display working?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-431021-S09170565702011101900000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Replacing the control module and programming

1. Ignition off. The LEDs are mounted internally in the rear view mirror and cannot be replaced. Check there are no indications that the power supply to the upper electronic module (UEM) is faulty. Check that the fault in the LED remains after the power is switched off and on again. If the fault remains, the upper electronic module (UEM) should be replaced. NOTE: If possible, read off the programmed data from the control module before it is replaced. This should be done as this information is not stored in Volvo's central database. Switch off the ignition before replacing the control module.

1. Continue Refer to «Replacing the control module»(ref-431021-S35743532212011101900000)

Note. Read off the programmed values from the upper electronic module (UEM) before replacing the control module.

1. Ignition on
2. Click on the symbol for VCT2000 to read off the programmed values. The retained values are programmed customer parameters in the upper electronic module (UEM). The retained values should be noted for later use. Other information For information about programming the customer parameters, see «Diagnostic functions»(ref-430929-S30787651682011101900000) .

1. Continue Refer to «Replacing control modules and downloading software»(ref-431021-S32010265342011101900000)

Replace the control module and download the new software. See Interior lighting and upper electronic module (UEM), replacing .

HINT: When diagnostic trouble code (DTC) E001 is stored, communication with the control module cannot be established. This can be remedied in two ways.

1. Press the remote control button for local lighting
2. Remove fuse 11C/28 from the fusebox in the passenger compartment. Reinstall the fuse again.

1. Continue Refer to «Checking the interior lighting»(ref-431021-S07951908592011101900000)

Two times can be programmed for the interior lighting

1. Short

1. The period from when the door is unlocked, or the engine stops, to when the interior lighting goes out can be changed if it is too long or too short.

2. Long

1. The period from when the door is opened, or a lamp is lit with a switch, to when the lamp goes out can be changed if it is too long or too short.

To program a long interior lighting period you must step ("click") through the short interior lighting period programming.

1. Continue Refer to «Programming a short interior lighting period»(ref-431021-S23177167692011101900000)

The general lighting and rear reading lamps light and remain lit for 30 seconds when

1. The door has been unlocked from outside with a key or the remote control.
2. The engine has been stopped and the ignition key turned to 0.

The default period is 30 seconds. This can be changed to between 5 and 255 seconds.

Read off the programmed values.

To change the time, mark the desired value in the scrolling list and start programming.

Do you want to program any more parameters?

1. YES Refer to «Programming a long interior lighting period»(ref-431021-S05971982732011101900000)
2. NO Refer to «Checking the anti-dazzle function in the rear view mirror»(ref-431021-S15348467332011101900000)

The general lighting and rear reading lamps light and remain lit for 10 minutes when

1. A door is opened after being unlocked.
2. The lamp is lit with a switch.

The default period is 10 minutes. This can be changed to between 0 and 255 minutes at 10 minute intervals.

Read off the programmed values.

To change the time, mark the desired value in the scrolling list and start programming.

1. Continue Refer to «Checking the anti-dazzle function in the rear view mirror»(ref-431021-S15348467332011101900000)

Note. If the upper electronic module (UEM) has been replaced software, specially developed for downloading after replacing the control module, must be downloaded to the control module before the anti-dazzle function is changed. See Interior lighting and upper electronic module (UEM), replacing .

The rear view mirror anti-dazzle function can be adjusted

1. If the rear view mirror anti-dazzle function is too powerful or too weak, it can be adjusted.

Specific software for setting the anti-dazzle function must be installed in the car to do this.

Order the software. See 9499432 .

Install the software. See 9499432 .

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Check that the LEDs in the display in the rear view mirror light.

Are the LEDs in the display working?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-431021-S00843192852011101900000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Ignition off. The light-emitting diode for indicating disconnected passenger airbag is located internally in the interior rearview mirror and cannot be replaced. Check that the fault in the LED remains after the power is switched off and on again. Read off by clicking the VCT2000 symbol. Turn the ignition key to position I. Check that the requested status from the Supplemental restraint system module (SRS) is ON and that the status of the PAD lamp in the Upper electronic module (UEM) is ON when the lamp is lit. Check visually in the vehicle that the status of the PAD-light matches the read-out value.

Does the LED work as it should?

1. YES FAULT NOT FOUND: Troubleshooting has been completed.
2. NO Refer to «Replacing control module and programming»(ref-431021-S03893993632011101900000)

1. Ignition off. If the fault remains, the upper electronic module (UEM) must be replaced. NOTE: If possible, read off the programmed data from the control module before it is replaced. This should be done as this information is not stored in Volvo's central database. Switch off the ignition before replacing the control module.

1. Continue Refer to «Replacing the control module»(ref-431021-S27177831292011101900000)

Note. Read off the programmed values from the upper electronic module (UEM) before replacing the control module.

1. Ignition on
2. Click on the symbol for VCT2000 to read off the programmed values. The retained values are programmed customer parameters in the upper electronic module (UEM). The retained values should be noted for later use. Other information For information about programming the customer parameters, see «Diagnostic functions»(ref-430929-S30787651682011101900000) .

1. Continue Refer to «Replacing control modules and downloading software»(ref-431021-S32175377142011101900000)

Replace the control module and download the new software. See Interior lighting and upper electronic module (UEM), replacing .

HINT: When diagnostic trouble code (DTC) E001 is stored, communication with the control module cannot be established. This can be remedied in two ways.

1. Press the remote control button for local lighting
2. Remove fuse 11C/28 from the fusebox in the passenger compartment. Reinstall the fuse again.

1. Continue Refer to «Checking the interior lighting»(ref-431021-S28468573462011101900000)

Two times can be programmed for the interior lighting

1. Short

1. The period from when the door is unlocked, or the engine stops, to when the interior lighting goes out can be changed if it is too long or too short.

2. Long

1. The period from when the door is opened, or a lamp is lit with a switch, to when the lamp goes out can be changed if it is too long or too short.

To program a long interior lighting period you must step ("click") through the short interior lighting period programming.

1. Continue Refer to «Programming a short interior lighting period»(ref-431021-S01600103342011101900000)

The general lighting and rear reading lamps light and remain lit for 30 seconds when

1. The door has been unlocked from outside with a key or the remote control.
2. The engine has been stopped and the ignition key turned to 0.

The default period is 30 seconds. This can be changed to between 5 and 255 seconds.

Read off the programmed values.

To change the time, mark the desired value in the scrolling list and start programming.

Do you want to program any more parameters?

1. YES Refer to «Programming a long interior lighting period»(ref-431021-S00788687512011101900000)
2. NO Refer to «Checking the anti-dazzle function in the rear view mirror»(ref-431021-S09452130292011101900000)

The general lighting and rear reading lamps light and remain lit for 10 minutes when

1. A door is opened after being unlocked.
2. The lamp is lit with a switch.

The default period is 10 minutes. This can be changed to between 0 and 255 minutes at 10 minute intervals.

Read off the programmed values.

To change the time, mark the desired value in the scrolling list and start programming.

1. Continue Refer to «Checking the anti-dazzle function in the rear view mirror»(ref-431021-S09452130292011101900000)

Note. If the upper electronic module (UEM) has been replaced software, specially developed for downloading after replacing the control module, must be downloaded to the control module before the anti-dazzle function is changed. See Interior lighting and upper electronic module (UEM), replacing .

The rear view mirror anti-dazzle function can be adjusted

1. If the rear view mirror anti-dazzle function is too powerful or too weak, it can be adjusted.

Specific software for setting the anti-dazzle function must be installed in the car to do this.

Order the software. See 9499432 .

Install the software. See 9499432 .

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Check that the LEDs in the display in the rear view mirror light.

Are the LEDs in the display working?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-431021-S26841717902011101900000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Ignition off. The LEDs are mounted internally in the rear view mirror and cannot be replaced. Check there are no indications that the power supply to the upper electronic module (UEM) is faulty. Check that the fault in the LED remains after the power is switched off and on again. If the fault remains, the upper electronic module (UEM) should be replaced. NOTE: If possible, read off the programmed data from the control module before it is replaced. This should be done as this information is not stored in Volvo's central database. Switch off the ignition before replacing the control module.

1. Continue Refer to «Replacing the control module»(ref-431021-S27668723482011101900000)

Note. Read off the programmed values from the upper electronic module (UEM) before replacing the control module.

1. Ignition on
2. Click on the symbol for VCT2000 to read off the programmed values. The retained values are programmed customer parameters in the upper electronic module (UEM). The retained values should be noted for later use. Other information For information about programming the customer parameters, see «Diagnostic functions»(ref-430929-S30787651682011101900000) .

1. Continue Refer to «Replacing control modules and downloading software»(ref-431021-S01343190402011101900000)

Replace the control module and download the new software. See Interior lighting and upper electronic module (UEM), replacing .

HINT: When diagnostic trouble code (DTC) E001 is stored, communication with the control module cannot be established. This can be remedied in two ways.

1. Press the remote control button for local lighting
2. Remove fuse 11C/28 from the fusebox in the passenger compartment. Reinstall the fuse again.

1. Continue Refer to «Checking the interior lighting»(ref-431021-S13649332932011101900000)

Two times can be programmed for the interior lighting

1. Short

1. The period from when the door is unlocked, or the engine stops, to when the interior lighting goes out can be changed if it is too long or too short.

2. Long

1. The period from when the door is opened, or a lamp is lit with a switch, to when the lamp goes out can be changed if it is too long or too short.

To program a long interior lighting period you must step ("click") through the short interior lighting period programming.

1. Continue Refer to «Programming a short interior lighting period»(ref-431021-S10338484542011101900000)

The general lighting and rear reading lamps light and remain lit for 30 seconds when

1. The door has been unlocked from outside with a key or the remote control.
2. The engine has been stopped and the ignition key turned to 0.

The default period is 30 seconds. This can be changed to between 5 and 255 seconds.

Read off the programmed values.

To change the time, mark the desired value in the scrolling list and start programming.

Do you want to program any more parameters?

1. YES Refer to «Programming a long interior lighting period»(ref-431021-S20089307242011101900000)
2. NO Refer to «Checking the anti-dazzle function in the rear view mirror»(ref-431021-S34120263072011101900000)

The general lighting and rear reading lamps light and remain lit for 10 minutes when

1. A door is opened after being unlocked.
2. The lamp is lit with a switch.

The default period is 10 minutes. This can be changed to between 0 and 255 minutes at 10 minute intervals.

Read off the programmed values.

To change the time, mark the desired value in the scrolling list and start programming.

1. Continue Refer to «Checking the anti-dazzle function in the rear view mirror»(ref-431021-S34120263072011101900000)

Note. If the upper electronic module (UEM) has been replaced software, specially developed for downloading after replacing the control module, must be downloaded to the control module before the anti-dazzle function is changed. See Interior lighting and upper electronic module (UEM), replacing .

The rear view mirror anti-dazzle function can be adjusted

1. If the rear view mirror anti-dazzle function is too powerful or too weak, it can be adjusted.

Specific software for setting the anti-dazzle function must be installed in the car to do this.

Order the software. See 9499432 .

Install the software. See 9499432 .

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Check that the LEDs in the display in the rear view mirror light.

Are the LEDs in the display working?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-431021-S39728667232011101900000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Ignition off. Identity number for hardware does not correspond to the installed software. Replace the upper electronic module (UEM), check that new hardware has the correct P/N. NOTE: If possible, read off the programmed data from the control module before it is replaced. This should be done as this information is not stored in Volvo's central database. Switch off the ignition before replacing the control module.

1. Continue Refer to «Replacing the control module»(ref-431021-S14330615922011101900000)

Note. Read off the programmed values from the upper electronic module (UEM) before replacing the control module.

1. Ignition on
2. Click on the symbol for VCT2000 to read off the programmed values. The retained values are programmed customer parameters in the upper electronic module (UEM). The retained values should be noted for later use. Other information For information about programming the customer parameters, see «Diagnostic functions»(ref-430929-S30787651682011101900000) .

1. Continue Refer to «Replacing control modules and downloading software»(ref-431021-S01567113232011101900000)

Replace the control module and download the new software. See Interior lighting and upper electronic module (UEM), replacing .

HINT: When diagnostic trouble code (DTC) E001 is stored, communication with the control module cannot be established. This can be remedied in two ways.

1. Press the remote control button for local lighting
2. Remove fuse 11C/28 from the fusebox in the passenger compartment. Reinstall the fuse again.

1. Continue Refer to «Checking the interior lighting»(ref-431021-S05961588422011101900000)

Two times can be programmed for the interior lighting

1. Short

1. The period from when the door is unlocked, or the engine stops, to when the interior lighting goes out can be changed if it is too long or too short.

2. Long

1. The period from when the door is opened, or a lamp is lit with a switch, to when the lamp goes out can be changed if it is too long or too short.

To program a long interior lighting period you must step ("click") through the short interior lighting period programming.

1. Continue Refer to «Programming a short interior lighting period»(ref-431021-S12322416992011101900000)

The general lighting and rear reading lamps light and remain lit for 30 seconds when

1. The door has been unlocked from outside with a key or the remote control.
2. The engine has been stopped and the ignition key turned to 0.

The default period is 30 seconds. This can be changed to between 5 and 255 seconds.

Read off the programmed values.

To change the time, mark the desired value in the scrolling list and start programming.

Do you want to program any more parameters?

1. YES Refer to «Programming a long interior lighting period»(ref-431021-S15790225202011101900000)
2. NO Refer to «Checking the anti-dazzle function in the rear view mirror»(ref-431021-S15810533292011101900000)

The general lighting and rear reading lamps light and remain lit for 10 minutes when

1. A door is opened after being unlocked.
2. The lamp is lit with a switch.

The default period is 10 minutes. This can be changed to between 0 and 255 minutes at 10 minute intervals.

Read off the programmed values.

To change the time, mark the desired value in the scrolling list and start programming.

1. Continue Refer to «Checking the anti-dazzle function in the rear view mirror»(ref-431021-S15810533292011101900000)

Note. If the upper electronic module (UEM) has been replaced software, specially developed for downloading after replacing the control module, must be downloaded to the control module before the anti-dazzle function is changed. See Interior lighting and upper electronic module (UEM), replacing .

The rear view mirror anti-dazzle function can be adjusted

1. If the rear view mirror anti-dazzle function is too powerful or too weak, it can be adjusted.

Specific software for setting the anti-dazzle function must be installed in the car to do this.

Order the software. See 9499432 .

Install the software. See 9499432 .

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Check that the LEDs in the display in the rear view mirror light.

Are the LEDs in the display working?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-431021-S20942178462011101900000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Ignition off. The LED for the seat belt reminder is mounted internally in the rear view mirror and cannot be replaced. Check there are no indications that the power supply to the upper electronic module (UEM) is faulty. Check that the fault in the LED remains after the power is switched off and on again. If the fault remains, the upper electronic module (UEM) must be replaced. NOTE: If possible, read off the programmed data from the control module before it is replaced. This should be done as this information is not stored in Volvo's central database. Switch off the ignition before replacing the control module.

1. Continue Refer to «Replacing the control module»(ref-431021-S03067843072011101900000)

Note. Read off the programmed values from the upper electronic module (UEM) before replacing the control module.

1. Ignition on
2. Click on the symbol for VCT2000 to read off the programmed values. The retained values are programmed customer parameters in the upper electronic module (UEM). The retained values should be noted for later use. Other information For information about programming the customer parameters, see «Diagnostic functions»(ref-430929-S30787651682011101900000) .

1. Continue Refer to «Replacing control modules and downloading software»(ref-431021-S01365499802011101900000)

Replace the control module and download the new software. See Interior lighting and upper electronic module (UEM), replacing .

HINT: When diagnostic trouble code (DTC) E001 is stored, communication with the control module cannot be established. This can be remedied in two ways.

1. Press the remote control button for local lighting
2. Remove fuse 11C/28 from the fusebox in the passenger compartment. Reinstall the fuse again.

1. Continue Refer to «Checking the interior lighting»(ref-431021-S07541765202011101900000)

Two times can be programmed for the interior lighting

1. Short

1. The period from when the door is unlocked, or the engine stops, to when the interior lighting goes out can be changed if it is too long or too short.

2. Long

1. The period from when the door is opened, or a lamp is lit with a switch, to when the lamp goes out can be changed if it is too long or too short.

To program a long interior lighting period you must step ("click") through the short interior lighting period programming.

1. Continue Refer to «Programming a short interior lighting period»(ref-431021-S35079112032011101900000)

The general lighting and rear reading lamps light and remain lit for 30 seconds when

1. The door has been unlocked from outside with a key or the remote control.
2. The engine has been stopped and the ignition key turned to 0.

The default period is 30 seconds. This can be changed to between 5 and 255 seconds.

Read off the programmed values.

To change the time, mark the desired value in the scrolling list and start programming.

Do you want to program any more parameters?

1. YES Refer to «Programming a long interior lighting period»(ref-431021-S12726630442011101900000)
2. NO Refer to «Checking the anti-dazzle function in the rear view mirror»(ref-431021-S40186609942011101900000)

The general lighting and rear reading lamps light and remain lit for 10 minutes when

1. A door is opened after being unlocked.
2. The lamp is lit with a switch.

The default period is 10 minutes. This can be changed to between 0 and 255 minutes at 10 minute intervals.

Read off the programmed values.

To change the time, mark the desired value in the scrolling list and start programming.

1. Continue Refer to «Checking the anti-dazzle function in the rear view mirror»(ref-431021-S40186609942011101900000)

Note. If the upper electronic module (UEM) has been replaced software, specially developed for downloading after replacing the control module, must be downloaded to the control module before the anti-dazzle function is changed. See Interior lighting and upper electronic module (UEM), replacing .

The rear view mirror anti-dazzle function can be adjusted

1. If the rear view mirror anti-dazzle function is too powerful or too weak, it can be adjusted.

Specific software for setting the anti-dazzle function must be installed in the car to do this.

Order the software. See 9499432 .

Install the software. See 9499432 .

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Check that the LEDs in the display in the rear view mirror light.

Are the LEDs in the display working?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-431021-S34273126652011101900000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Ignition off. The LED for the seat belt reminder is mounted internally in the rear view mirror and cannot be replaced. Check there are no indications that the power supply to the upper electronic module (UEM) is faulty. Check that the fault in the LED remains after the power is switched off and on again. If the fault remains, the upper electronic module (UEM) must be replaced. NOTE: If possible, read off the programmed data from the control module before it is replaced. This should be done as this information is not stored in Volvo's central database. Switch off the ignition before replacing the control module.

1. Continue Refer to «Replacing the control module»(ref-431021-S20993907832011101900000)

Note. Read off the programmed values from the upper electronic module (UEM) before replacing the control module.

1. Ignition on
2. Click on the symbol for VCT2000 to read off the programmed values. The retained values are programmed customer parameters in the upper electronic module (UEM). The retained values should be noted for later use. Other information For information about programming the customer parameters, see «Diagnostic functions»(ref-430929-S30787651682011101900000) .

1. Continue Refer to «Replacing control modules and downloading software»(ref-431021-S24580334622011101900000)

Replace the control module and download the new software. See Interior lighting and upper electronic module (UEM), replacing .

HINT: When diagnostic trouble code (DTC) E001 is stored, communication with the control module cannot be established. This can be remedied in two ways.

1. Press the remote control button for local lighting
2. Remove fuse 11C/28 from the fusebox in the passenger compartment. Reinstall the fuse again.

1. Continue Refer to «Checking the interior lighting»(ref-431021-S25218793962011101900000)

Two times can be programmed for the interior lighting

1. Short

1. The period from when the door is unlocked, or the engine stops, to when the interior lighting goes out can be changed if it is too long or too short.

2. Long

1. The period from when the door is opened, or a lamp is lit with a switch, to when the lamp goes out can be changed if it is too long or too short.

To program a long interior lighting period you must step ("click") through the short interior lighting period programming.

1. Continue Refer to «Programming a short interior lighting period»(ref-431021-S02652879832011101900000)

The general lighting and rear reading lamps light and remain lit for 30 seconds when

1. The door has been unlocked from outside with a key or the remote control.
2. The engine has been stopped and the ignition key turned to 0.

The default period is 30 seconds. This can be changed to between 5 and 255 seconds.

Read off the programmed values.

To change the time, mark the desired value in the scrolling list and start programming.

Do you want to program any more parameters?

1. YES Refer to «Programming a long interior lighting period»(ref-431021-S27280551972011101900000)
2. NO Refer to «Checking the anti-dazzle function in the rear view mirror»(ref-431021-S24069449822011101900000)

The general lighting and rear reading lamps light and remain lit for 10 minutes when

1. A door is opened after being unlocked.
2. The lamp is lit with a switch.

The default period is 10 minutes. This can be changed to between 0 and 255 minutes at 10 minute intervals.

Read off the programmed values.

To change the time, mark the desired value in the scrolling list and start programming.

1. Continue Refer to «Checking the anti-dazzle function in the rear view mirror»(ref-431021-S24069449822011101900000)

Note. If the upper electronic module (UEM) has been replaced software, specially developed for downloading after replacing the control module, must be downloaded to the control module before the anti-dazzle function is changed. See Interior lighting and upper electronic module (UEM), replacing .

The rear view mirror anti-dazzle function can be adjusted

1. If the rear view mirror anti-dazzle function is too powerful or too weak, it can be adjusted.

Specific software for setting the anti-dazzle function must be installed in the car to do this.

Order the software. See 9499432 .

Install the software. See 9499432 .

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Check that the LEDs in the display in the rear view mirror light.

Are the LEDs in the display working?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-431021-S04215973282011101900000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Checking the remote receiver

The remote receiver is located in the inner rear view mirror, and receives signals from both the remote control and the tire pressure sensors. The function of the remote receiver can be checked using the remote control.

Check that the remote receiver works by pressing the lock and unlock button on the remote control. The vehicle should be locked and unlocked.

Note. Fault-trace the symptoms first, if the remote control and receiver are not working.

Scheme 1913

Does the remote control and remote receiver work?

1. YES Refer to «Checking tire pressure sensors»(ref-431021-S33439533822011101900000)
2. NO OKAY: Troubleshooting has been completed.

Checking tire pressure sensors

1. Ignition on. Each tire pressure sensor has its own ID number and battery voltage status, which are sent to and stored in the Upper electronic module (UEM) Read out the ID numbers for the tire pressure sensors by clicking on the VCT2000 symbol. Use the following special tools to activate the sensor. «9512987»(ref-403953-S35674831992011061500000) The special tool activates the sensor, which then starts to send information to the Upper Electronic Module (UEM). After activating a sensor, press the "Show data" button for the relevant wheel. Repeat activation for all wheels. Different ID numbers should appear. If the same ID number is displayed as for the previous wheel, activation has failed. Then activate the relevant wheel again and press the "Show data" button again. NOTE: Do not forget to press the correct button after each wheel has been activated. NOTE: Make sure no special tools lie under the edge of the rim against the tire where the sensor is installed. Activation will not happen if the tool is placed next to the rim. The tool must then be kept in position for 5 seconds for the signals to be received correctly. Use only one special tool at a time in the vicinity of the vehicle. NOTE: Avoid positioning the vehicle close to other moving vehicles, the receiver may then receive signals from the sensors of these vehicles. The incorrect ID number may then appear. Then read off the ID number that is stored for the relevant diagnostic trouble code, by clicking on the diagnostic trouble code in the list. The ID number is then displayed in the window above the list. Compare the read-out ID number for the relevant wheel with the ID number that is stored with the DTC. If a sensor does not respond during the test: Replace the tire pressure sensor for the relevant wheel. It is probably the sensor that caused the DTC to be stored. If all sensors respond: The sensor that caused the diagnostic trouble code to be stored has probably had an intermittent malfunction. Replace the tire pressure sensor for the relevant wheel. Other information See «Tire pressure sensor, replacement»(ref-430991-S14617015782011101900000)

1. Continue Refer to «Verification»(ref-431021-S29750217602011101900000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Read out the ID numbers for the tire pressure sensors by clicking on the VCT2000 symbol. Use the following special tools to activate the sensor. «9512987»(ref-403953-S35674831992011061500000) The special tool activates the sensor, which then starts to send information to the Upper Electronic Module (UEM). After activating a sensor, press the "Show data" button for the relevant wheel. Repeat activation for all wheels. Different ID numbers should appear. NOTE: Ensure that the special tool is positioned under the edge of the rim against the tire where the sensor is installed. The sensor will not be activated if the tool is against the rim. The sensor must then be held in place for approximately 5 seconds for the signals to be correctly received. Use only one special tool at a time in the vicinity of the car. NOTE: Carry out the above in an area away from where other cars are being driven. The receiver can pick up signals from sensors on other cars. An incorrect ID number would then be displayed. Check that the relevant sensor(s) respond. Test different wheels to ensure that different ID numbers are displayed.

Is the sensor OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-431021-S10331385212011101900000)

See Signal missing

See Signal missing

See Signal missing

The remote receiver is located in the inner rear view mirror, and receives signals from both the remote control and the tire pressure sensors. The function of the remote receiver can be checked using the remote control.

Check that the remote receiver works by pressing the lock and unlock button on the remote control. The vehicle should be locked and unlocked.

Note. Fault-trace the symptoms first, if the remote control and receiver are not working.

Does the remote control and remote receiver work?

1. YES Refer to «Checking tire pressure sensors»(ref-431021-S09516585512011101900000)
2. NO OKAY: Troubleshooting has been completed.

1. Ignition on. Each tire pressure sensor has its own ID number and battery voltage status, which are sent to and stored in the Upper electronic module (UEM) Read out the ID numbers for the tire pressure sensors by clicking on the VCT2000 symbol. Use the following special tools to activate the sensor. «9512987»(ref-403953-S35674831992011061500000) The special tool activates the sensor, which then starts to send information to the Upper Electronic Module (UEM). After activating a sensor, press the "Show data" button for the relevant wheel. Repeat activation for all wheels. Different ID numbers should appear. If the same ID number is displayed as for the previous wheel, activation has failed. Then activate the relevant wheel again and press the "Show data" button again. If the sensor does not respond, the battery has probably been discharged or the sensor does not work. Replace the sensor for the relevant wheel. NOTE: Do not forget to press the correct button after each wheel has been activated. NOTE: Make sure no special tools lie under the edge of the rim against the tire where the sensor is installed. Activation will not happen if the tool is placed next to the rim. The tool must then be kept in position for 5 seconds for the signals to be received correctly. Use only one special tool at a time in the vicinity of the vehicle. NOTE: Avoid positioning the vehicle close to other moving vehicles, the receiver may then receive signals from the sensors of these vehicles. The incorrect ID number may then appear. Then read off the ID number that is stored for the relevant diagnostic trouble code, by clicking on the diagnostic trouble code in the list. The ID number is then displayed in the window above the list. Compare the read-out ID number for the relevant wheel with the ID number that is stored with the DTC. Replace the tire pressure sensor for the relevant wheel. Other information See «Tire pressure sensor, replacement»(ref-430991-S14617015782011101900000)

1. Continue Refer to «Verification»(ref-431021-S07814729982011101900000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Read out the ID numbers for the tire pressure sensors by clicking on the VCT2000 symbol. Use the following special tools to activate the sensor. «9512987»(ref-403953-S35674831992011061500000) The special tool activates the sensor, which then starts to send information to the Upper Electronic Module (UEM). After activating a sensor, press the "Show data" button for the relevant wheel. Repeat activation for all wheels. Different ID numbers should appear. NOTE: Ensure that the special tool is positioned under the edge of the rim against the tire where the sensor is installed. The sensor will not be activated if the tool is against the rim. The sensor must then be held in place for approximately 5 seconds for the signals to be correctly received. Use only one special tool at a time in the vicinity of the car. NOTE: Carry out the above in an area away from where other cars are being driven. The receiver can pick up signals from sensors on other cars. An incorrect ID number would then be displayed. Check that the relevant sensor(s) respond. Test different wheels to ensure that different ID numbers are displayed.

Is the sensor OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-431021-S40830310672011101900000)

Low battery

See Low battery

See Low battery

See Low battery

Checking the receiver

The receiver is in the rear view mirror. It receives signals from both the remote control and tire pressure sensors. The remote control can be used to check that the receiver is working.

Check the function of the receiver by pressing the locking and unlocking button on the remote control. The vehicle must lock and unlock.

Note. Fault-trace the symptoms if the remote control and receiver are not working.

Are the remote control and receiver working?

1. YES Refer to «Checking the tire pressure sensors»(ref-431021-S17435067242011101900000)
2. NO OKAY: Troubleshooting has been completed.

Checking the tire pressure sensors

1. Ignition on. Each tire pressure sensor has its own ID number which is transmitted to and stored in the upper electronic module (UEM). Read off the last stored ID number by clicking on the VCT2000 symbol. The last stored ID number is displayed until a new ID number is received and stored. NOTE: The last stored value is erased when the ignition is switched off and on again. Activate one of the sensors by using the special tool: «9512987»(ref-403953-S35674831992011061500000) The special tool activates the sensor which then starts to send information to the Upper electronic module (UEM) and the sensor's id-number can then be read in the character window. NOTE: Ensure that the special tool is positioned under the edge of the rim against the tire where the sensor is installed. The sensor will not be activated if the tool is against the rim. The sensor must then be held in place for approximately 5 seconds for the signals to be correctly received. Use only one special tool at a time in the vicinity of the car. NOTE: Carry out the above in an area away from where other cars are being driven. The receiver can pick up signals from sensors on other cars. An incorrect ID number would then be displayed. Repeat this procedure for each wheel. Different ID numbers must be displayed. If a sensor does not respond during the test: Check that a tire pressure sensor is installed on the rim. Install a new sensor if there is no sensor installed. If the sensor is installed but is still not working, it may be defective or be a sensor intended for another make or model. Replace the tire pressure sensor. If all sensors respond: Intermittent fault. The control module has previously detected that one or more sensors are not communicating. This may be because the vehicle previously had a wheel mounted without a functioning sensor.

1. Continue Refer to «Verification»(ref-431021-S42546466252011101900000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Read out the ID numbers for the tire pressure sensors by clicking on the VCT2000 symbol. Use the following special tools to activate the sensor. «9512987»(ref-403953-S35674831992011061500000) The special tool activates the sensor, which then starts to send information to the Upper Electronic Module (UEM). After activating a sensor, press the "Show data" button for the relevant wheel. Repeat activation for all wheels. Different ID numbers should appear. NOTE: Ensure that the special tool is positioned under the edge of the rim against the tire where the sensor is installed. The sensor will not be activated if the tool is against the rim. The sensor must then be held in place for approximately 5 seconds for the signals to be correctly received. Use only one special tool at a time in the vicinity of the car. NOTE: Carry out the above in an area away from where other cars are being driven. The receiver can pick up signals from sensors on other cars. An incorrect ID number would then be displayed. Check that the relevant sensor(s) respond. Test different wheels to ensure that different ID numbers are displayed.

Is the sensor OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-431021-S13857622282011101900000)

Replacing software

Note. If possible, read off the programmed data before replacing software.

1. Ignition off. The upper electronic module (UEM) has registered a fault in the configuration file. The fault may be due to a program fault. The software must be replaced.

1. Continue Refer to «Reading off programmed values»(ref-431021-S14627036242011101900000)

Reading off programmed values

Note. Read off the programmed values from the upper electronic module (UEM) before re-programming.

1. Ignition on
2. Click on the symbol for VCT2000 to read off the programmed values. The obtained values are programmed customer parameters in the upper electronic module (UEM). These values should be noted for later use. Other information For information about programming the customer parameters, see «Diagnostic functions»(ref-430929-S30787651682011101900000) .

1. Continue Refer to «Downloading software»(ref-431021-S15744044072011101900000)

Downloading software

Download new software. See Interior lighting and upper electronic module (UEM), replacing .

Do not replace the control module.

HINT: If diagnostic trouble code (DTC) UEM-E001 is stored, communication with the control module cannot be established. This can be remedied in two ways.

1. Press the remote control button for local lighting
2. Remove fuse 11C/28 from the fusebox in the passenger compartment. Reinstall the fuse again.

1. Continue Refer to «Checking the interior lighting»(ref-431021-S09828363122011101900000)

Two times can be programmed for the interior lighting

1. Short

1. The period from when the door is unlocked, or the engine stops, to when the interior lighting goes out can be changed if it is too long or too short.

2. Long

1. The period from when the door is opened, or a lamp is lit with a switch, to when the lamp goes out can be changed if it is too long or too short.

To program a long interior lighting period you must step ("click") through the short interior lighting period programming.

1. Continue Refer to «Programming a short interior lighting period»(ref-431021-S19257865152011101900000)

The general lighting and rear reading lamps light and remain lit for 30 seconds when

1. The door has been unlocked from outside with a key or the remote control.
2. The engine has been stopped and the ignition key turned to 0.

The default period is 30 seconds. This can be changed to between 5 and 255 seconds.

Read off the programmed values.

To change the time, mark the desired value in the scrolling list and start programming.

Do you want to program any more parameters?

1. YES Refer to «Programming a long interior lighting period»(ref-431021-S00170616422011101900000)
2. NO Refer to «Checking the anti-dazzle function in the rear view mirror»(ref-431021-S37721326922011101900000)

The general lighting and rear reading lamps light and remain lit for 10 minutes when

1. A door is opened after being unlocked.
2. The lamp is lit with a switch.

The default period is 10 minutes. This can be changed to between 0 and 255 minutes at 10 minute intervals.

Read off the programmed values.

To change the time, mark the desired value in the scrolling list and start programming.

1. Continue Refer to «Checking the anti-dazzle function in the rear view mirror»(ref-431021-S37721326922011101900000)

Note. If the upper electronic module (UEM) has been replaced software, specially developed for downloading after replacing the control module, must be downloaded to the control module before the anti-dazzle function is changed. See Interior lighting and upper electronic module (UEM), replacing .

The rear view mirror anti-dazzle function can be adjusted

1. If the rear view mirror anti-dazzle function is too powerful or too weak, it can be adjusted.

Specific software for setting the anti-dazzle function must be installed in the car to do this.

Order the software. See 9499432 .

Install the software. See 9499432 .

Faulty communication

See Faulty communication

Faulty configuration

See Faulty configuration
